OPERATING MANUAL
18V CORDLESS
JOB SITE RADIO
JR-L0218D

2
NORDIC
PRODUCT SPECIFICATION
Voltage: 18V
USB Output: 5V 1.0Ah
DAB Frequency: 174-240MHz
FM Frequency: 87.5-108MHz
GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings and instructions. Failure to heed warnings and follow instructions may result in
electric shock, fire and/or serious injury.
Keep safety warnings and instructions for future reference.
BEFORE USE
Remove any packing material and loose parts from unit.
Check the accessories before use. It should be fit with the machine and your purpose.
If the machine is new, the battery must first be charged.
Attention! After long time storage, the battery capacity will be reduce.
A new battery or one which has not been used for an extended period achieves full performance only
after charging and discharging cycles. A substantial drop in operating period per charge indicates that the
battery is worn out and must be replaced.
WORKING AREA
• Keep work area clean and well lit. Cluttered and dark areas invite accidents.
• Do not operate in explosive atmospheres, such as in the presence of flammable liquids,
gases or dust. Power tools create sparks which may ignite the dust or fumes.
ELECTRICAL SAFETY
• Always check that the power supply corresponds to the voltage on the rating plate.
• Plugs must match the outlet. Never modify the plug in any way. Do not use adapter plugs with earthed equipment.
Unmodified plugs and matching outlets will reduce the risk of an electric shock.
• Avoid body contact with earthed surfaces such as pipes, radiators, kitchen ranges and refrigerators. There is an

3
NORDIC
increased risk of an electric shock if your body is earthed.
• Do not expose to rain or wet conditions. If water gets inside, it will increase the risk of an electric shock.
• If operating in a damp location is unavoidable, use a power supply protected by a residual current device (RCD).
Using an RCD reduces the risk of an electric shock.
SERVICE
Your power tool should be serviced by a qualified specialist using only standard spare parts. This will
ensure that it meets the required safety standards.
a) Use only the manufacturer’s recommended replacement parts and accessories.
b) Inspect and maintain the machine regularly. Have the machine repaired only by an authorized repairer.
c) When not in use, store the machine out of the reach of children.
ADDITIONAL SAFETY INSTRUCTIONS
FOR BATTERIES AND CHARGERS
Use only batteries and chargers applicable for this machine.
BATTERIES
• Never attempt to open for any reason.
• Do not store in locations where the temperature may exceed 40 °C.
• Charge only at ambient temperatures between 4 °C and 40 °C.
• When disposing of batteries, follow the instructions given in the section “Protecting the environment”.
• Do not cause short circuits. If connection is made between the positive (+) and negative (-) terminal directly or via
accidental contact with metallic objects, the battery is short circuited and an intense current will flow causing heat
generation which may lead to casing rupture or fire.
• Do not heat. If batteries are heated to above 100 °C, sealing and insulating separators and other polymer
components may be damaged resulting in electrolyte leakage and/or internal short circuiting leading to heat
generation causing rupture or file. Moreover do not dispose of the batteries in fire, explosion and/or intense burning
may result.
• Under extreme conditions, battery leakage may occur. When you notice liquid on the battery, proceed as follows:
• Carefully wipe the liquid off using a cloth. Avoid skin contact.
• In case of skin or eye contact, follow the instructions below:
1. Immediately rinse with water. Neutralize with a mild acid such as lemon juice or vinegar.
2. In case of eye contact, rinse abundantly with clean water for at least 10 minutes.
3. Consult a physician.
Fire hazard! Avoid short-circuiting the contacts of a detached battery. Do not incinerate the battery.



4
NORDIC
CHARGERS
• Never attempt to charge non-rechargeable batteries.
• Have defective cords replaced immediately.
• Do not expose to water.
• Do not open the charger.
• Do not probe the charger.
• The charger is intended for indoor use only.
SYMBOLS
In this manual and/or on the machine the following symbols are used:
Denotes risk of personal injury or damage to the tool.
Read manual before use
Wear eye protection
Wear ear protection
Wear safety gloves
In accordance with essential requirements of the European directive(s)
Class II - The machine is double insulated; Earthing wire is therefore not necessary
(only for charger)
Ambient temperature 40°C max. (only for battery)
Do not expose charger and battery pack to water
Use battery and charger only in closed rooms

5
NORDIC
Do not incinerate battery pack or charger
Protect from the rain.
OPERATION
Before using the equipment:
BATTERY CHARGER
The lithium-ion battery can be charged at any time and will not develop a “memory” when charged after
only a partial discharge. It is not necessary to run down the battery pack charge before recharging. Remove
the battery pack from the tool when convenient for you and your job. You can “top-off” your battery pack’s
charge before starting a big job or long period of use.
Due to lithium-ion’s fade-free properties, the only time it is necessary to charge the lithium-ion battery
pack is when the pack has reached the end of its charge. To signal the end of charge, power to the tool will
drop quickly. Charge the battery pack as needed.
CHARGING THE BATTERY
This lithium-ion battery pack is shipped partially charged. Before using it the first time, fully charge the
battery pack. A fully discharged battery pack with a temperature between 0°C and 40°C will charge in
about 1 hour.
Plug the charger adapter into power source. The green light on the charger stand will illuminate, indicating
the charger is powered.
Slide the battery all the way into the charger stand. The red light on the charger stand will illuminate,
indicating that the battery is charging.
The red light will go off after charging is complete and a green light will appear.
NOTE: Batteries may become warm while charging. This is normal. If the battery is hot after continuous
use in the tool, allow it to cool down to room temperature before charging. This will extend the life of
your batteries.
WARNING: Always disconnect the battery pack from the tool before any assembly, adjustments or
changing accessories.
INSERTION AND REMOVAL OF RECHARGEABLE BATTERY
Depress the battery-release button located on the front of the battery pack to release battery pack.



6
NORDIC
Pull the battery pack out and remove it from the tool.
WARNING: Always remove the battery pack before making adjustments to the equipment.
Be sure to read the following information before you put the cordless equipment into operation:
Charge the battery pack with the charger. An empty battery pack requires a charging period of approximately
0.5 to 1 hour.
CONTROL METHOD
• ON/OFF/STANDBY: Press the power button to turn on the radio. Once on press it again to enter
standby mode or hold it to turn the radio off.
• Using the buttons: All the button actions are just a quick press unless otherwiase stated in the
required action. This includes the button function of the dial.
• Using the dial: The dial on this radio is dual action. This means it will perform one action my turning
the dial and another action by pressing it.
SETUP
• First time use: After removing the radio from the packaging, connect the radio to the mains using
the adaptor supplied into the battery compartment in the base. Fully extend the aerial and press the
power button to turn on the radio.
• The date and time will automatically be set from the DAB+ signal recieved. The radio will then
proceed to scan for the first time.
• The number to the right of the display indicates the amount of channels found in your region during
this scan.
• After the scan is complete the radio will rune itself to the first alphabetically listed station available
in DAB+ mode.
DAB+MODE
• Selecting A Station: Use the tune +/- buttons to cycle through the available DAB+ stations on the
display. Press the dial to tune the radio into the station that is shown on the display.
• Scan: You can retune or refresh the amount of DAB+ stations by pressing the ‘Scan’ button. It is
recommended you do this when the radio has been moved or if you are getting a poor DAB+ signal.


7
NORDIC
DAB+ OPTIONS
• Menu Options: Press and hold the ‘info/menu’ button until you see ‘Full Scan’
• Pressthetune +/- buttons tocyclethe options and pressthedialto select. Theoptionsherearehereare
Full scan > Manual Tune > DRC > Prune > System
FULL SCAN
• To fully erase and retune all of the available DAB+ stations select ‘Full Scan’ in the menu options.
• The radio will now scan through all the available channels.
• All the channels found will be shown in alphabetical order.
MANUALLY TUNE DAB+
• This option will allow you to retune to an individual local frequency without performing a full scan.
Using this feature can help clear up a poor signal or interference without affecting the rest of the
station list.
• Press and hold the ‘Info/Menu’ button until the screen displays the DAB+ menu list. Rotate the dial
to highlight ‘Manual Tune’ and give the dial a quick press to select it.
• The next option will display all the DAB+ frequencies that are available to this radio. Rotate the dial
to cycle through the list and highlight the frequency that you preferred. Give the dial a quick press
to select it.
CLEANING AND MAINTENANCE
DANGER! Always pull out the mains power plug before starting any cleaning work.
CLEANING
Keep all safety devices, air vents and the motor housing free of dirt and dust as far as possible. Wipe the
equipment with a clean cloth or blow it with compressed air at low pressure.
We recommend that you clean the device immediately each time you have finished using it.
Clean the equipment regularly with a moist cloth and some soft soap. Do not use cleaning agents or
solvents; these could attack the plastic parts of the equipment. Ensure that no water can seep into the
device. The ingress of water into an electric tool increases the risk of an electric shock.
MAINTENANCE
There are no parts inside the equipment which require additional maintenance.

