Nordmende RII1232A+ User manual

BUILT-IN REFRIGERATOR
Instruction booklet
EINBAUKÜHLSCHRANK
Bedienungsanleitung
RII1232A+

EN -1-
Index
BEFORE USING THE APPLIANCE ..........................................2
General warnings ....................................................................2
Safety warnings.......................................................................4
Installing and operating your fridge .........................................5
Before Using your Fridge ........................................................6
HOW TO OPERATE THE APPLIANCE.....................................6
Thermostat setting ..................................................................6
Temperature indicator .............................................................7
Putting food in the coldest area of the refrigerator ..................7
FOOD STORAGE IN THE APPLIANCE ....................................9
Refrigerator Compartment ......................................................9
Freezer Compartment .............................................................9
CLEANING AND MAINTENANCE............................................10
Defrosting...............................................................................11
Replacing the Light bulb.........................................................12
SHIPMENT AND REPOSITIONING..........................................12
BEFORE CALLING YOUR AFTER SALES SERVICE.............12
Tips For Saving Energy..........................................................14
PARTS OF THE APPLIANCE AND THE COMPARTMENTS ..15
The operating instructions apply to several models. Differences may therefore occur.

EN -2-
BEFORE USING THE APPLIANCEPART 1.
General warnings
WARNING: Keep vantilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
WARNING: Do not use electrical appliances inside the food
storage compartments of the
appliance, unless they are of the type recommended by the
manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: To avoid a hazard due to the instability of the
appliance, it must be xed in accordance with the instructions.
• If your appliance uses R600 as a refrigerant – you can learn
this information from the label on the cooler- you should
be careful during shipment and installation to prevent your
appliance’s cooler elements from being damaged. Although
R600a is an environmentally friendly and natural gas, it is
explosive. In the event of a leak caused by damage to the
cooler elements, move your fridge from open ame or heat
sources and ventilate the room where the appliance is located
for a few minutes.
• While carrying and positioning the fridge, do not give damage
to the cooler gas circuit.
• Do not store explosive substances such as aerosol cans with
a ammable propellant in this appliance.
• This appliance is intended to be used in households and
similar applications such as;
- staff kitchen areas in shops, ofces and other working
environments

EN -3-
- farm houses and by clients in hotels, motels and other
residential type environments
- bed and breakfast type environments;
- catering and similar non-retail applications
• If the socket does not match the refrigerator plug, it must
be replaced by the manufacturer, its service agent or similar
qualied persons in order to avoid a hazard.
• This appliance is not intended for use by persons (including
children)with reducedphysical,sensoryormental capabilities,
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children
should be supervised to ensure that they do not play with the
appliance.
• A specially grounded plug has been connected to the power
cable of your refrigerator. This plug should be used with
a specially grounded socket of 16 amperes. If there is no
such socket in your house, please have it installed by an
authorized electrician.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazard involved.
Children should not play with the appliance. Cleaning and
user maintenance should not be made by children without
supervision.
• If the supply cord is demaged, it must be replaced by the
manufacturer, its service agent or similar qualied persons in
order to avoid a hazard.
• This appliance is not intended for use at altitudes exceeding
2000 m.

EN -4-
Old and out-of-order fridges
• If your old fridge has a lock, break or remove the lock before discarding it, because
children may get trapped inside it and may cause an accident.
• Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore,
take care not to harm the environment when you are discarding your old fridges.
• Please ask your municipal authority about the disposal of the WEEE for
the reuse, recycle and recovery purposes.
Notes:
• Please read the instruction manual carefully before installing and using your appliance.
We are not responsible of the damage occurred due to misuse.
• Follow all instructions on your appliance and instruction manual, and keep this manual
in a safe place to resolve the problems that may occur in the future.
• This appliance is produced to be used at houses and it can only be used in house and
for the specied purposes. It is not suitable for commercial or common use. Such use
will cause the guarantee of the appliance to be cancelled and our company will not be
responsible for the losses to be occurred.
• This appliance is produced to be used in houses and it is only suitable for cooling / storing
foods. It is not suitable for commercial or common use and/or for storing substances
except for food. Our company is not responsible for the losses to be occurred in the
contrary case.
Safety warnings
• Do not use multiple receptacles or extension cord.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• This appliance is designed for use by adults, do not allow children
to play with the appliance or let them to hang over the door.
• Do not plug-in or out the plug from the receptacle with wet hands
to prevent electrocution!

EN -5-
• Do not place glass bottles or beverage cans in the freezer
department. Bottles or cans may explode.
• Do not place explosive or ammable material in your fridge for
your safety. Place drinks with higher alcohol amount vertically and
by closing their necks tightly in the fridge department.
• When taking ice made in the freezer department, do not touch it, ice may
cause ice burns and/or cuts.
• Do not touch frozen goods with wet hands! Do not eat ice-cream and ice cubes
immediately after you take them out of the freezer department!
• Do not re-freeze the frozen goods after being melted. This may cause health issues like
food poisoning.
• Do not cover the body or top of fridge with lace. This affects the performance of your
fridge.
• Fix the accessories in the fridge during transportation to prevent damage to accessories.
Installing and operating your fridge
Before starting to use your fridge, you should pay attention to the following points:
• Operating voltage for your fridge is 220-240 V at 50Hz.
• The plug must be accessible after installation.
• There can be an odor when you rst switch on the appliance. It will disappear after the
appliance starts to cool.
• Before making the connection to the power supply, ensure that the voltage on the
nameplate corresponds to the voltage of electrical system in your home.
• Insert the plug into a socket with an efcient ground connection. If the socket has
no ground contact or the plug does not match, we suggest you to call an authorized
electrician for assistance.
• The appliance must be connected with a properly installed fused socket. Power supply
(AC) and voltage at the operating point must with the details on the name plate of the
appliance (name plate is located on the inside left of the appliance).
• We do not take responsibility for damages that occur due to ungrounded usage.
• Place your fridge in a place that it would not be exposed to direct sunlight.
• Your fridge should never be used outdoors or left under the rain.
• Your appliance should be at least 50 cm away from stoves, Gas ovens and heater cores,
and should be at least 5 cm away from electrical ovens.
• When your fridge is placed next to a deep freezer, there should be at least 2 cm between
them to prevent humidity on the outer surface.
• Do not place heavy items on the appliance.
• Clean the appliance thoroughly, especially in the interior, before
use (See Cleaning and Maintenance).
• Installation procedure into the kitchen unit is given in the The
installation procedure into the kitchen unit is given in the Installation
Manual. This product is intended to be used in proper kitchen units
only.

EN -6-
• Before using your fridge, wipe all parts with warm water added
with a tea spoonful of sodium bicarbonate, and then rinse with
clean water and dry. Place all parts after cleaning.
Before Using your Fridge
• When it is operated for the rst time or after transportation, keep your
fridge in the upright position for 3 hours and plug it on to allow efcient
operation. Otherwise, you may damage the compressor.
• Your fridge may have a smell when it is operated for the rst time; the smell will fade
away when your fridge starts to cool.
HOW TO OPERATE THE APPLIANCE
PART 2.
Thermostat setting
• Thermostat automatically regulates the inside
temperature of the refrigerator compartment
and freezer compartment. By rotating the knob
from position 1 to 5, colder temperatures can be
obtained.
• The “ “ position shows thermostat is closed and no cooling is available.
• For short-term storage of food in the freezer compartment, you can set the knob between
minimum and medium position (1-3).
• For long-term storage of food in the freezer compartment, you can set knob medium
position.(3-4)
• Note that; the ambient temperature, temperature of the freshly stored food and how often
the door is opened, affects the temperature in the refrigerator and freezer compartments.
If required, change the temperature setting.
• When you rst switch on the appliance, you should ideally try to run it without any food
in for 24 hours and not open the door. If you need to use it straight away, try not to put
much food inside.
• If the unit is switched off or unplugged, you must allow at least 5 minutes before restarting
in order not to damage the compressor.
• The freezer of the refrigerator cools down to -18°C and less.

EN -7-
“Door Open” Indicator;
• The “Door Open” indicator on the lock slide indicates whether the door
is closed properly or not.
• If the red indicator is visible, the door is still open.
• If the red indicator is invisible, the door is properly closed.
• Observe that the freezer door should always be kept closed properly.
This will prevent food inside the freezer from defrosting; it will avoid
heavy ice and frost build-up inside the freezer and an unnecessary
increase in energy consumption.
Temperature indicator
In order to help you better set your refrigerator, we have equipped it with a
temperature indicator located in the coldest area.
To better store the food in your refrigerator, especially in the coldest area, make
sure the message “OK” appears on the temperature indicator. If « OK » does
not appear, this means that the temperature setting has not been done properly.
Since “OK” appears in black, it will be difcult to see this indication if the
temperature indicator is badly lit. To be able to see this indication properly, there
should be enough light.
Each time the temperature setting device is changed, wait for the stabilisation of the
temperature inside the appliance before proceeding, if necessary, with a new temperature
setting. Please change the position of the temperature setting device progressively and wait
at least 12 hours before starting a new check and potential change.
NOTE: Following repeated openings (or prolonged opening) of the door or after putting fresh
food into the appliance, it is normal for the indication “OK” not to appear in the temperature
setting indicator. If there is an abnormal ice crystals build up (bottom wall of the appliance)
on the refrigerator compartment evaporator (overloaded appliance, high room temperature,
frequent door openings), put the temperature setting device on a lower position until
compressor off periods are obtained again.
Putting food in the coldest area of the refrigerator
Your foods will be better stored if you put them in the most
appropriate cooling area. The coldest area is just above the
crisper.
The following symbol indicates the coldest area of your
refrigerator.
To be sure to have a low temperature in this area, make sure
the shelf is located at the level of this symbol, as shown in the
illustration.

EN -8-
The upper limit of the coldest area is indicated by
the lower side of the sticker (head of the arrow). The
coldest area upper shelf must be at the same level
with the arrow head. The coldest area is below this
level.
As these shelves are removable, make sure they
are always at the same level with these zone limits
described on the stickers, in order to guarantee
temperatures in this area.
Each type of food has an ideal conservation
temperature and consequently a particular location to
follow.

EN -9-
FOOD STORAGE IN THE APPLIANCEPART 3.
Refrigerator Compartment
Refrigerator compartment is used for storing fresh food for few days.
• Do not place food in direct contact with the rear wall of the refrigerator compartment.
Leave some space around food to allow circulation of air.
• Do not place hot food or evaporating liquid in the refrigerator.
• Always store food in closed containers or wrapped.
• To reduce humidity and avoid formation of frost, never place liquids in unsealed
containers in the refrigerator.
• Meat of all types, wrapped in packages, is recommended to be placed on the glass shelf
just above the vegetable bin, where the air is colder.
• You can put the fruits and vegetables into crisper without packing.
• To avoid the cold air escaping, try not to open the door too often, and not leave the door
open for a long time.
Freezer Compartment
Freezer compartment is used for freezing fresh foods and for storing frozen foods for the
period of time indicated on packaging, and for making ice cubes.
• For freezing fresh food; wrap and seal fresh food properly, that is the packaging should
be air tight and shouldn’t leak. Special freezer bags, aluminum foil (heavy grade, in
doubt double wrap), polythene bags and plastic containers are ideal.
• Do not allow the fresh food to be frozen to come into contact with the already frozen
food.
• Always mark the date and the content on the pack and do not exceed the stated storage
time.
• In case of a power failure or malfunction, the freezer compartment will maintain a
sufciently low temperature for food storage. However, avoid opening the freezer door
to slow down the temperature rise within the freezer compartment.
• The maximum amount of fresh foods that can be loaded in the freezer within 24 hours is
indicated on the name plate ( see Freezing Capacity).
• Never place warm food in the freezer compartment.
• When purchasing and storing frozen food products; ensure that the packaging is not
damaged.
• The storage time and the recommended temperature for storing frozen foods are
indicated on the packaging. For storing and using, follow the manufacturer’s instructions.
If no information is provided, food should not be stored for more than 3 months.

EN -10-
• Place frozen food in the freezer compartment as soon as possible after buying it.
• Once the food is thawed, it must not be refrozen; you must cook it as quickly as possible
in order to consume or to freeze once again.
• When making ice cubes, ll the ice tray with water and place in freezer compartment.
After the water completely turned into ice, you can twist the tray as shown below to get
the ice cube.
CLEANING AND MAINTENANCE
PART 4.
• Disconnect the appliance from the power supply before cleaning.
• Do not pour water over the appliance.
• The refrigerator compartment should be cleaned
periodically using a solution of bicarbonate of soda
and lukewarm water.
• Clean the accessories separately with soap and
water. Do not put them in the dishwasher.
• Do not use abrasive products, detergents or soaps. After washing,
rinse with clean water and dry carefully. When the cleaning
operations have been completed, reconnect the plug with dry
hands.

EN -11-
Defrosting
Defrosting the Refrigerator compartment:
• Defrosting occurs automatically in refrigerator compartment during operation; the defrost
water is collected by the evaporating tray and evaporates automatically.
• The evaporating tray and the defrost water drain hole should be cleaned periodically with
defrost drain plug to prevent the water from collecting on the bottom of the refrigerator
instead of owing out.
• You can also pour ½ glass of the water to drain hole to clean inside.
Defrosting the Freezer compartment:
WARNING: Never use sharp metal tools, unless recommended by manufacturer, for this
operation as they can damage the refrigeration circuit.
After a period of time, frost will build up in certain areas in the freezer compartment. The
frost, accumulated in the freezer compartment, should be removed periodically (use the
plastic scraper if available).
Complete defrosting will become necessary if the frost layer exceeds 3-5 mm to maintain the
efciency of the freezer.
• The day before you defrost, set the thermostat dial to position “5” to freeze the foods
completely.
• During defrosting, frozen foods should be wrapped in several layers of paper and kept in
a cool place. The inevitable rise in temperature will shorten their storage life. Remember
to use these foods within a relatively short period of time.
• Set the thermostat knob to position “ “ and switch off the appliance.
• Leave the door open to accelerate defrosting. Remove the defrost water from the
compartment.
• Clean the interior by hand with lukewarm water and a little detergent.
Never use abrasive products or aggressive cleaning agents.
• Dry the inside of the unit, plug on the mains, and set the thermostat knob to position “5”.
After 24 hours, reset the thermostat to the desired position.

EN -12-
Replacing the Light bulb
When replacing the bulb of the refrigerator compartment;
1. Unplug the unit from the power supply,
2. Press the hooks on the sides of the light cover top and remove the light cover
3. Change the present light bulb with a new one of not more than 15 W.
4. Replace the light cover and after waiting 5 minutes plug the unit.
SHIPMENT AND REPOSITIONINGPART 5.
Transportation and changing of installation position
• Original package and foam may be kept for re-transportation (optionally).
• You should fasten your fridge with thick
package, bands or strong cords and follow the
instructions for transportation on the package
for re-transportation.
• Remove movable parts (shelves,
accessories, vegetable bins etc.) or x them
into the fridge against shocks using bands
during re-positioning and transportation.
BEFORE CALLING YOUR AFTER SALES SERVICE
PART 6.
If your refrigerator is not working properly, it may be a minor problem, therefore check the
following.
The appliance does not operate,
Check if;
• There is a power failure,
• The mains plug is not properly plugged in, or is loose
• The thermostat setting is on position “ “,
• The socket is defective. To check this, plug in another appliance that you know which is
working into the same socket.
Replacing LED lighting
If your refrigerator has LED lighting contact the help desk as this should be changed by
authorized personnel only.

EN -13-
The appliance performs poorly;
Check if;
• You have overloaded the appliance,
• The doors are not closed perfectly,
• There are not enough ventilation ducts on the kitchen unit as mentioned in the Installation
Manual.
If there is noise;
The cooling gas which circulates in the refrigerator circuit may make a slight noise (bubbling
sound) even when the compressor is not running. Do not worry, this is quite normal. If these
sounds are different check if;
• The appliance is installed rmly as described in the Installation Manual.
• The objects on the appliance are vibrating.
f there is water in the lower part of the refrigerator;
Check if;
The drain hole for defrost water is not clogged (use defrost drain plug to clean the drain hole).
If your fridge is not cooling enough;
Your fridge is designed to operate in the ambient temperature intervals stated in the standards,
according to the climate class stated in the information label. We do not recommend operating
your fridge out of stated temperatures value limits in terms of cooling effectiveness.
Climate
Class Ambient Temperature oC
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
Recommendations
• In order to increase space and improve the appearance, the “cooling section” of
refrigerators is positioned inside the back wall of the refrigerator compartment. When
the compressor is working, this wall is covered with frost or water drops. Do not worry.
This is quite normal. The appliance should be defrosted only if an excessively thick ice
layer forms on the back wall.
• If the appliance is not used for a long time (for example during the summer holidays), set
the thermostat knob to position “ “. Defrost and clean the refrigerator leaving the door
open to prevent the formation of mildew and smell.

EN -14-
Tips For Saving Energy
1.Install the appliance in a coll, well vantilated room , but not in direct sunlight and not near
heat source (radiator, cooker.. etc). Otherwise use an insulating plate.
2.Allow ward food and drinks to cool down outside the appliance.
3.When thawing frozen food, place it in the refrigerator compartment. The low temperature
of the frozen food will help to cool the refrigerator compartment when it is thawing. So it
causes energy saving. If the frozen food is put out, it causes wastage of energy.
4.When placing, drinks and slops they must be covered. Otherwise humidity increases at
the appliance. Therefore the working time gets longer. Also covering drinks and slops
helps to save smell and taste.
5.When placing food and drinks, open the appliance door as briey as possible.
6.Keep close the covers of any different temrepature compartment in the appliance (crisper,
chiller ...etc ).
7.Door gasket must be clean and pliable. Replace gaskets if worn.

EN -15-
* In some models
PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
PART 7.
The purpose of this presentation is informing you about the parts of your appliance.
The parts may vary depending on the model of the appliance.
1) Freezer compartment & Freezer door
2) Termostat box
3) Fridge compartment shelves
4) Crisper cover
5) Crispers
6) Left & right feet
7) ) Bottle shelf
8) Door midle shelves
9)Egg holder
10) Ice box
1
2
3
4
5
6
7
8
9
10

DE -16-
Die Bedienungsanleitung gilt für verschiedene Modelle. Deshalb können Unterschiede
auftreten.
Inhalt
VOR DER INBETRIEBNAHME......................................................17
Allgemeine Warnhinweise..........................................................17
Sicherheits-Warnhinweise..........................................................19
Aufstellung und Inbetriebnahme Ihres Kühlschranks.................20
Vor der Inbetriebnahme Ihres Kühlschranks ..............................21
BEDIENUNGSANLEITUNG...........................................................22
Einstellung des Thermostates....................................................22
Zubehör......................................................................................23
"Tür offen" -Anzeige: (Für eintürige Kühlschränke mit Gefrierfach) ....................... 23
LAGERUNG VON LEBENSMITTELN IM GERÄT ........................25
Kühlschrank ...............................................................................25
Gefrierfach .................................................................................25
REINIGUNG UND WARTUNG.......................................................26
Kühlschrank abtauen .................................................................27
Abtauen des Gefrierfaches (falls vorhanden);............................28
Wechseln der Glühlampe...........................................................28
TRANSPORT UND STANDORTÄNDERUNG...............................29
BEVOR SIE DEN KUNDENDIENST RUFEN ................................29
Tipps Zum Energiesparen..........................................................31
INNENAUSSTATTUNG UND ZUBEHÖRTEILE............................32

DE -17-
Allgemeine Warnhinweise
WARNUNG: Halten Sie die Belüftungsöffnungen des Gerätes bzw.
des Einbauschranks stets frei und offen.
WARNUNG: Verwenden Sie keine mechanischen Werkzeuge oder
andere Mittel als vom Hersteller vorgeschlagen, um denAbtauvorgang
zu beschleunigen.
WARNUNG: Verwenden Sie im Nahrungsmittelfach des Gerätes
keine elektrischen Geräte, sofern sie nicht vom Typ sind, die vom
Hersteller empfohlen sind.
WARNUNG: Achten Sie darauf, die Kältemittelkreise des Kühlgeräts
nicht zu beschädigen.
WARNUNG: Um Schaden wegen Unstabilität des Gerätes zu
vermeiden, muss es gemäß der Anweisungen befestigt werden.
• Wenn Ihr Gerät R600a als Kältemittel verwendet - dies können Sie
dem Typenschild am Gerät entnehmen -, müssen Sie bei Transport
undAufstellung des Gerätes darauf achten, die Kühlelemente nicht
zu beschädigen. Obwohl R600a ein umweltfreundliches Naturgas
ist, ist es explosiv. Im Falle eines Lecks durch Schäden an den
Kühlerelementen, halten Sie Ihren Kühlschrank von offenen
Flammen oder Wärmequellen fern und lüften Sie den Raum, wo
sich das Gerät bendet, für ein paar Minuten.
• Achten Sie beim Transportieren und Aufstellen des Kühlschranks
darauf, den Kältemittelkreislauf nicht zu beschädigen.
• Lagern Sie in diesem Gerät keine explosiven Stoffe wie Spraydosen
mit brennbarem Treibmittel.
• Dieses Gerät ist zur Verwendung im Haushalt und in ähnlichen
Anwendungen konzipiert wie z.B.;
- Personalküchenbereiche in Läden, Büros und anderen
Arbeitsumgebungen
- Bauernhäuser und von Kunden in Hotels, Motels und anderen
Unterkünften
- Unterkünfte mit Bett und Frühstück;
VOR DER INBETRIEBNAHMETEIL 1.

DE -18-
- Catering und ähnliche Non-Retail-Anwendungen
• Ist das Netzkabel beschädigt, muss es vom Hersteller, dem
Vertrieb oder einer ähnlich qualizierten Person ersetzt werden,
um eine Gefahr zu vermeiden.
• Dieses Gerät ist nicht zur Verwendung durch Personen
(einschließlich Kinder) mit eingeschränkten physischen,
sensorischen oder geistigen Fähigkeiten oder mangelnder
Erfahrung und Wissen bestimmt, es sei denn sie stehen unter
Aufsicht oder ausführlicher Anleitung zur Benutzung des Gerätes
durch eine verantwortliche Person, für ihre Sicherheit. Achten Sie
stets darauf, dass Kinder niemals mit dem Gerät herumspielen.
• Das Netzkabel des Kühlschranks ist mit einem geerdeten
Netzstecker ausgestattet. Dieser Netzstecker muss in eine
geerdete, mit mindestens 16 Ampere gesicherte Steckdose
gesteckt werden. Wenn Sie keine geeignete Steckdose haben,
lassen Sie eine solche von einem qualizierten Elektriker
installieren.
• Dieses Gerät darf von Kindern ab 8 Jahren und älter und Personen
mit eingeschränkten körperlichen, sensorischen oder geistigen
Fähigkeiten oder ohne die nötige Erfahrung und das nötige Wissen
verwendet werden, wenn diese unter Aufsicht stehen oder die
Anweisungen zur Benutzung des Gerätes in einer sicheren Weise
erhalten haben und die damit verbundenen Gefahren verstehen
können. Kinder sollten nicht mit dem Gerät spielen. Reinigung
und Wartung dürfen nicht von Kindern ohne Aufsicht durchgeführt
werden.
• Ist das Netzkabel beschädigt, muss es vom Hersteller, dem
Vertrieb oder einer ähnlich qualizierten Person ersetzt werden,
um eine Gefahr zu vermeiden.
• Dieses Gerät ist nicht für den Einsatz auf Höhen über 2000 m
vorgesehen.
