Nordmende WC46IX User manual

WC46IX
Wine Cooler User Manual
NOTE: Thank you for purchasing this NordMende wine cooler.
Our product will create the perfect temperature and humidity environment to
store your collection of wine quietly and peacefully.
JC-201

Content
Safety Instructions & Warnings………………………………..………..…………………………
2-6
Installation………………………………..………………………………………………………………….
7
Description of the Appliance………………………………..…………………………………….
8-9
Operation………………………………..……………………………………………………………………
10-12
Troubleshooting………………………………..………………………………………………………….
13
Maintenance and Cleaning………………………………..………………………………………….
14
Technical Parameters………………………………..………………………………………………….
15

2
Safety Instructions & Warnings
Your safety is of the utmost importance to our company.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If you
are unsure of any of the information contained in this
booklet, please contact the NordMende Customer
Service Department.
•This appliance can be used by children aged eight
years and above and persons with reduced physical,
sensory or mental capabilities, or who lack experience
and/or knowledge, if they are supervised or have been
instructed in the safe use and understand the dangers
associated with its use.
•Children must not play with the appliance. Cleaning
and user maintenance must not be carried out by
children, unless they are supervised.
•Make sure children do not have unsupervised access
to the appliance.
Intended Use
•This appliance is intended solely for storing wine and is
intended for HOUSEHOLD USE ONLY and not for
commercial or industrial use, as this will void your
warranty.
•Use the appliance exclusively as described in this user
manual. Any other use is deemed improper and may
result in damage to property or even personal injury.
The manufacturer accepts no liability for damage
caused by improper use.

3
•Keep ventilation openings on the appliance enclosure
or in the built-in structure clear of obstruction.
•Do not use mechanical devices or any other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
•Do not damage the refrigerant circuit.
•Do not use electrical appliances inside the storage
compartments of the appliance, unless they are
recommended by the manufacturer.
•Make sure that the appliance is connected to the
power supply in accordance with the rating label.
•Use an independent grounded socket with 10A or
higher, do not connect to a transformer or socket with
multiple outlets.
•Make sure that the socket is grounded properly and do
not modify the power cord and plug.
•Connect the power plug with the socket firmly to avoid
possible risk of fire.
•The plug should be within reach for easy disconnection
after the appliance is positioned in the event of an
accident.
•Do not store or burn gasoline or other flammables near
the appliance to avoid possible risk of fire.
•Do not store flammables, explosives, acid and alkaline
liquids etc. in the compartment of the appliance.
•Do not operate other appliances in the compartment.

4
Child Safety
•Do not allow children to play inside the appliance in
case of entrapment.
•Do not allow children to hang on the door, as the
appliance may fall over.
•Do not allow children to reach into the compressor
compartment or touch any metal components at the
rear of the appliance, to avoid possible injury.
Keep away from water
•Do not spray water on the appliance or wash the
appliance by pouring or filling with water, in case of
invalid insulation and possible electric shock.
Be careful of freezing
•While the appliance is in operation do not touch the
surface of the liner inside the compartment, especially
with wet hands, this is to avoid freezer burns.
Do not open the door for long periods
•Opening the door for long periods of time can cause a
significant increase in temperature inside the appliance.
Modification of the appliance is not allowed
•Do not modify or reconstruct the appliance by yourself
as it may cause damages to the appliance.
Unplug the appliance under certain conditions
•Unplug the appliance before cleaning and
maintenance.
•Unplug the appliance when a power cut has occurred.

5
Disposal of the appliance and packaging
•If you have sufficient space, we recommend keeping
the packaging, at least during the warranty period. If
the appliance needs to be sent out for repairs, only the
original packaging will provide sufficient protection.
•Do not allow children to play with the packaging film.
Children can become entangled in the packaging film
or swallow small parts and suffocate.
•Prevent children from pulling small parts off the
appliance or putting them in their mouths.
•Should you choose not to keep the packaging,
please dispose of it in an environmentally friendly way.
•Please dispose of your NordMende wine cooler in
accordance to local regulations regarding the disposal
of appliances with flammable refrigerants and blowing
gas.
•Before you scrap the appliance, please take the door
off to prevent children from becoming trapped.
•Please ask your local authority for the designated
WEEE disposal location in your area.

6
Do not damage the power cord
•Do not disconnect the appliance by pulling the power
cord rather than pulling out the plug.
•Do not sit the appliance on the power cord or step on
the cord intentionally.
•To avoid damage to the power cord, hold it up out of
the way when moving the appliance.
When the power cord is damaged
•Do not use the appliance if the power cord is damaged,
contact the NordMende Service Department and get it
replaced immediately by our service agent or by a
qualified electrician.
•If needed, extend the power cord with cord of
0.75mm2 or bigger by qualified electrician.

7
Installation
Unpackaging and positioning
•Do not use sharp or pointed objects to unpack this appliance.
•When unpacking the appliance, never damage the insulation material on the back
of the appliance.
•Do not tilt the appliance more than 45° or lay it on its side.
•Allow the unit to stand up right for 2 hours before start-up. The lubricant will flow
back into the compressor during this time.
•The appliance must be put on a flat, firm and dry floor or similar noncombustible
pad, do not use the packaging foam pad.柜结构及安装示意图
•Do not put the appliance in a wet area.
•Do not use the appliance in a frozen area.
•The appliance may not operate properly if exposed to low ambient temperatures
for extended periods of time. This can then lead to an increase in temperature
inside the appliance. Lowest ambient temperature that the appliamces can be
stored is +5°C
•Do not use the appliance in an outdoor area.
•Avoid direct sunlight.
•Please ensure that a 5mm space is allowed on either side of the appliance.
•If the appliance is being fitted up against a wall or with a 90° turn in a kitchen
please allow suffient space for the door to open 130°, allowing for the handle,
in order for the shelves and the wine to be put in and out of the wine cooler
comfortably.
This appliance is designed to be either built under counter or as a stand alone
product on the floor.
Dimensions for built under counter installation:
Wine bottles can be placed in the appliance after 1 hour of operation.

8
Description of the Appliance
Accessories & name
Installing the handle
The handle is delivered in a separated package with screws, inside the box.
①Reveal two small holes on the door frame from the inner side by pulling the door
seal to one side.
②Align the handle to the holes and insert the screws from the rear of the door.
③Tighten the screws with a hand screw-driver.
④Put the door seal back over to cover the screws.
Reversing the door
Our wine cooler is delivered with the door opening from left to
right. To reverse the opening direction:
7. Lower hinge
8. Door
9. Handle
10. Door seal
11.Upper hinge
1.Housing
3.Control panel
4. Cover board
5. Grill
6. Adjustable foot
2.Shelf

9
•Open the door to 90° and keep it steady.
•Unscrew the two screws ①from the right lower hinge ②[Figure 1].
•Pull the door ⑤outwards slowly [follow the arrow direction in Figure 2] to remove it
off the lower hinge ②and continue to pull the door ⑤downwards slowly until it is
also removed from the top right hinge ④, take off the lower hinge plate ③from the
door axis hole [Figure 2].
•Unscrew the top right hand hinge ④and the right lower hinge ②from the cabinet
⑥. Keep them in a polybag for safe keeping, so that you have them in the future if
you ever want to change back to a left hand opening door [Figure 3].
•Install the top left hand hinge ⑦and left lower hinge ⑧to the left hand side of the
cabinet. (⑦& ⑧delivered in a separated polybag inside the packaging) [Figure 4].
•Turn the door ⑤180° upside down and fit the lower hinge plate ③to the bottom
door axis holes. Fit the top door axis hole to the top left hand hinge ⑦and put the
lower hinge plate ③slowly on the left hand lower hinge ⑧while keeping the door
steady. Screw in the left lower hinge with the plate and the door reversal is
complete!
