Nordpeis Odense User manual

Odense
NO Monteringsanvisning 2
Installation manual 4
GB
Art.no: FP-ODE00-0X0
Last updated: 07.05.2013

4 GB
NB! See separate instructions for the insert
General information
Our surrounds are all made of non-combustible
materials. All our inserts/stoves are tested
according to the latest European requirements
and also to the Norwegian SINTEF standard, which
includes particle tests. Several European countries
however have individual rules for installation of
inserts, stoves and replaces. You as a client are
totally responsible for the fullling of these local
rules concerning the installation in your region/
country. Nordpeis (Northstar) is not responsible
regarding correct installation.
You should check local regulations concerning:
• distance from rebox to combustible/ammable
materials
• insulation materials/requirements between
replace surround and back wall
• size of oor plates in front of replace/stove if
required
• uepipe connection between rebox and chimney
• insulation requirements if uepipe goes through
ammable wall such as a wood wall.
Adjustment
We recommend to stack the surround without glue in
order to adjust the insert prior to perforating the chimney
for the ue connection. Use a spirit level to ensure that
the surround is mounted straight. The insert will expand
with heat and for this reason the surround must not rest
on the insert. (Above the insert there must be a gap
of 3 to 5 mm. Laterally there is no need for gaps, but
between the lower part of the insert and the surround
there must be a gap of at least 2 mm.)
Floor plate
A reproof oor plate must be put in front of the replace
if the oor is of a combustible material.
Acrylic glue
The replace is to be assembled using acrylic glue.
Make sure all dust is removed and that the surfaces are
clean. When the replace is assembled, use the same
acylic glue for lling joints (FIG Z)
Minor damage
The replace can sustain minor damage during
transport and handling.
This can be repaired with acrylic/light ller. For perfect
results, you can ll and sand with a suitable ller. Minor
damage and uneven surfaces can be lled. If the
damage is deep or in the event of signicant damage,
you are recommended to ll repeatedly with tile
adhesive or cement putty to avoid sinking. Smooth off
with e.g. a damp sponge or a oat.
Fine Fissures
The building material around the replace can move.
In new houses in particular, it is common for building
materials to settle substantially in the early years. In
addition, all concrete elements shrink to a decreasing
extent for up to 15 months.
The result is that small cracks may appear in the
concrete/masonry.
Use the replace for a few months. If cracks appear,
scrape them out with a screwdriver or similar (to provide
more space for acrylic joint ller). Vacuum the surfaces
to remove any dust.
Inject acrylic joint ller and even it out with a spatula or
a nger wetted with soapy water.
The joint can be painted after a couple of days.
Painting
When the replace has been lled/sanded and the
glued joints are dry, the replace is ready to be painted.
Use only breathable paint (acrylic) intended for
masonry.
Treatment of marble
Clean the plates with mild soapy water and remove any
residue of spilled glue.
Never use acid/abrasive materials, as this will damage
the surface and polishing.
It is important to use detergent/sealant that is approved
for marble for cleaning and sealing.
Scratches in dark marble can be coloured with a pencil.
A professional stone centre can help you with different
products for surface treatment of the stone.
For your own safety, comply with the assembly
instructions. All safety distances are minimum distances.
Installation of the insert must comply with the rules and
regulations of the country where installed. Nordpeis AS
is not responsible for wrongly assembled inserts.
We accept no liability for typographical errors and
changes.

5
GB
Odense
Insert
S-31A
Steel chimney
Can be installed with steel chimney.
Weight including insert
Odense 253 kg
Floorplate
Please follow the instructions on oorplates in your
country.
Illustration (FIG 1)
*The illustration indicates the approximate centre height
of the hole for the ue. Consider possible inclination of
the ue prior to perforating the chimney. Distortions in
oors and walls may inuence the height. Dry stack
the replace for accurate height and positioning of
the ue/chimney connection. If a fresh air supply set
(accessory) is connected through the oor, mark where
the hole should be.
Safety Distances (FIG 2)
Ensure that the safety distances are complied with.
Please note that these safety distances can vary from
country to country.
Assembly instructions (FIG 3 - FIG 16)
FIG 3
Place the base element. Make sure it is level.
FIG 4
Make sure the surface is free of any dust and concrete
residues. Use acrylic glue between the elements and
place the upper bottom element.
FIG 5
Lower the concrete pedestal. Make sure all edges are
level with the inside of the upper bottom element.
Attention! If the product is placed in a corner and is
to be connected to a fresh air supply, make sure to
prepare for fresh air supply behind the product
before placing the insert. Connecting the insert can
be done up through the wood compartment. If the
product is not connected to a fresh air supply, clog
the hole with the added concrete cover and acrylic
glue FIG 15.
FIG 6
Adjust the height of the legs as shown in the illustration.
FIG 7
Lift the insert into place. Make sure the insert is level
with both sides of the bottom elements.
FIG 8
Makes sure the surface is free of any dust and concrete
residue. Apply acrylic glue and lower the back element
into place.
FIG 9
Place the rear radiation shield.
Attention! To utilize the rear connection, make sure
to remove the cut out in the radiation shield FIG 10
FIG 11
Place the front radiation shield.
FIG 12-13
If the product is to be rear connected, make sure to
prepare the top element before assembling it FIG 12.
Use a concrete drilling tool to remove the concrete in
the desired cut out and carefully sand the remaining
edges.
Makes sure the surface is free of any dust and concrete
residue. Apply acrylic glue and place the top element.
FIG 15
If the product is to be connected to a fresh air supply or
a ventilated chimney, keep the hole at the back of the
surround open. If not, use acrylic glue and the added
concrete cover to clog the hole.
FIG 16
The picture shows how Odense is prepared for
Nordpeis ventilated chimney and where to connect a
fresh air supply.
The top grate is prepared for the air channel
accomponying the ventilated chimney.
Once the replace is assembled, ll the joints with
acrylic and even them out with a sponge or nger and
some soapy water, in order to have a clear indentation
between the elements (FIG Z).

10 mm
13 mm
24 mm
2.5 mm
4 mm
5 mm
Du trenger følgende verktøy
NO
GB You need the following tools
3 mm

=mm
1790
650
430
1585 1355
700
500
415
210
500
265
240
165
350
155
65
236
215
FIG 1

=mm AIR

=Brannmur/Brandmur/Turvaetäisyydet/Firewall
=Brennbart materiale/Brændbart materiale/ Brännbart material/ Palavasta materiaalista/Combustible material
FIG 2
>450
>1105
>85
>170
>800
>875
>1035
>85
>550
>600
350*
*Mål for tilkobling pipe
*Measurement chimney connection

14
FIG 3 FIG 4
FIG 5 FIG 6
+/-35mm
Acryl
!

15
FIG 7 FIG 8
FIG 9
Acryl
FIG 10

16
Acryl
FIG 11 FIG 12
FIG 13
A
B
FIG 14

17
Acryl
FIG 15
FIG 16
1
2
FIG Z
