Nordpeis N-20 U User manual

N-20 U
NO Brukerveiledning 2
Product no: IN-0N20U-011 / IN-0N20U-014 / IN-0N20U-017
Test report No: SPFR 20012-20B2
Last updated: 26.03.2019
GB User manual 10
SE Bruksanvisning 17
FI Käyttöohje 24

Index
1. Prior to assembling the insert 11
Chimney Draft 11
 6KDUHGÀXHJDVV\VWHP 
Air Supply 11
2. Technical Information 11
3. Safety distances 12
4. Assembly 12
Assembling and adjusting the legs 12
 5HDUÀXHJDVFRQQHFWLRQ  
 7RSÀXHJDVFRQQHFWLRQ 
Assembling Front Heat Shield 13
Operational control 13
Removing the self-closing door 13
/LJKWLQJWKH¿UHIRUWKH¿UVWWLPH  
6. Maintenance 14
Cleaning and inspection 14
Ashes 14
Thermotte™ 14
Door and glass 14
7. Warranty 14
$GYLFHRQOLJKWLQJD¿UH 
Some advice in case of combustion problems 15
,03257$176$)(7<35(&$87,216
1. Please follow the installation manual when
FRQQHFWLQJ\RXUVWRYH¿UHSODFHWRWKHFKLPQH\
ÀXHSLSH,IFRQQHFWHGGLႇHUHQWO\IURPLQVWUXFWLRQ
SOHDVHFRQVLGHUWKHKHDWUDGLDWLRQIURPWKHÀXH
pipe to the surrounding materials.
2. Before use, please carefully read the user manual
and follow the instructions.
,QWHJUDWHGRUGH¿QHGFRQYHFWLRQRSHQLQJVPD\
never be reduced or partially obstructed. This may
lead to overheating, which again can cause house
¿UHRUVHULRXVGDPDJHWRWKHSURGXFW
8VHRQO\GHVLJQDWHG¿UHVWDUWHUVNever use
JDVROLQHGLHVHORURWKHUOLTXLGVWRVWDUWWKH¿UH
This may cause explosions!
5. Never use other fuel than natural dry chopped
wood. Briquettes, peat, coke, coal and waste
from construction materials develops far higher
temperatures and emissions than natural wood.
Since your product has been designed for use
with natural wood only, other fuels may damage
the product, chimney and surrounding
constructions.
6. In case of damage to glass or door gasket, all use
of the product must be discontinued until the
damage has been repaired.
Failure to follow these precautions will leave your
warranty void and expose people and property to
danger.
Advise: Even if not required in your area, it is always
ZLVHWRKDYHDTXDOL¿HGVWRYH¿UHSODFH¿WWHUGRWKH
LQVWDOODWLRQRUDWOHDVWWKH¿QDOLQVSHFWLRQEHIRUHXVH
10 GB

1. Prior to assembling the insert
All our products are tested according to the latest
European requirements and also to the Norwegian
standard NS 3058 and NS 3059, which include particle
tests. However, several European countries have local
UHJXODWLRQVIRULQVWDOODWLRQRI¿UHSODFHVZKLFKFKDQJH
regularly. It is the responsibility of the client that these
regulations are complied with in the country/region
ZKHUHWKH¿UHSODFHLVLQVWDOOHG1RUGSHLV$6LVQRW
responsible for incorrect installation.
Important to check
(please note that this list is not exhaustive):
GLVWDQFHIURP¿UHER[WRFRPEXVWLEOHÀDPPDEOH
materials
• insulation materials/requirements between
¿UHSODFHVXUURXQGDQGEDFNZDOO
VL]HRIÀRRUSODWHVLQIURQWRI¿UHSODFHLIUHTXLUHG
ÀXHFRQQHFWLRQEHWZHHQ¿UHER[DQGFKLPQH\
LQVXODWLRQUHTXLUHPHQWVLIÀXHSDVVHVWKURXJKD
ÀDPPDEOHZDOO
DQDFFHVVIRUFOHDQLQJWKHDSSOLDQFHWKHÀXHJDV
FRQQHFWRUWKHFKLPQH\ÀXHPXVWEHSURYLGHG
Chimney draft
Compared with older models, the clean burning inserts
RIWRGD\SXWVLJQL¿FDQWO\KLJKHUGHPDQGVRQWKH
chimney. Even the best insert will not work properly
if the chimney does not have the right dimensions or
is not in good working order. The draught is mainly
controlled by gas temperature, outside temperature, air
supply as well as the height and inner diameter of the
chimney. The diameter of the chimney should never
EHOHVVWKDQWKDWRIWKHÀXHFKLPQH\FROODU)RUGUDIW
requirements at nominal heat output, see technical
table
The draught increases when:
• The chimney becomes warmer than the outside air
• The active length of the chimney over the hearth
increases
• Good air supply to the combustion
,WFDQEHGLႈFXOWWRREWDLQWKHULJKWGUDXJKWFRQGLWLRQV
in case the chimney is too large relative to the insert,
as the chimney does not heat up well enough. In such
cases you may want to contact professional for
evaluation of possible measures. Draught that is too
strong can be controlled with a damper. If necessary,
contact a chimney sweeper.
$WWHQWLRQ$GYHUVHÀXHGUDXJKWRUDGYHUVHZHDWKHU
conditions, e. g. mist, wind etc., may interfere the
QHFHVVDU\ÀXHGUDXJKW7KLVVKRXOGEHFKHFNHGEH-
IRUHOLJKWHQLQJWKH¿UHSODFH,IWKHUHLVQRQHFHVVDU\
ÀXHGUDXJKWLQWKHFKLPQH\WKHXVHRIWKH¿UHSODFH
should be avoided.
6KDUHGÀXHJDVV\VWHP
$SSOLDQFHFDQEHFRQQHFWHGWRVKDUHGÀXHJDVSLSH
sytem. In case of simultaneous operation with other
KHDWLQJDSSOLDQFHVWKHUHPXVWEHVXႈFLHQWFRPEXVWLRQ
air provided.
Air supply (mm=AIR)
A set for fresh air supply is available as an accessory.
This will ensure that the air supply to the combustion
FKDPEHULVOHVVDႇHFWHGE\YHQWLODWLRQV\VWHPVNLWFKHQ
fans and other factors which can create a down-draught
in the room. In all new constructions, we strongly
recommend the product is designed and prepared
for direct supply of outside air. In older houses also,
the use of fresh air supply set is also recommended.
,QVXႈFLHQWDLUVXSSO\FDQFDXVHSRRUGUDXJKWDQG
WKHUHE\ORZFRPEXVWLRQHႈFLHQF\DQGWKHSUREOHPVWKLV
HQWDLOVVRRWVWDLQVRQWKHJODVVLQHႈFLHQWXWLOLVDWLRQRI
the wood and a soot deposits in the chimney.
For your own safety, fully comply with the assembly
instructions. All safety distances are minimum distances.
Installation of the insert must comply with the current rules
and regulations of the country where the product is installed.
Nordpeis AS is not responsible for wrongly assembled inserts.
Subject to errors and changes.
For the latest updated version of the manual go to
www.nordpeis.com
2. Technical information
Inserts from Nordpeis all have secondary combustion
and are clean burning. The combustion takes place
LQWZRSKDVHV¿UVWWKHZRRGEXUQVDQGWKHQWKH
gases from the fumes are lit by the heated air. This
ensures that new inserts have minimal emissions of
soot particles and un-burnt gases (such as CO) and
are thus better for the environment. Clean burning
inserts require a small amount of wood to obtain good
heat output. Use exclusively clean and dry wood. We
recommend seasoned hardwood with a maximum
moisture content of 20%.
Warning! In case of the appliance connected to
VKDUHGÀXHJDVSLSHV\VWHPWKH6HOI&ORVLQJ
Door system must be operational.
Warrning! Extractor fans when operating
in the same room or space as the appliance
may cause problem.
Warning: Keep the air intakes, supplying
combustion and convection air free from blocka-
ge. If the requirements for ventilation are
NOT complied with, the product can overheat.
7KLVFDQFDXVHD¿UH
11
GB

3. Safety distances
Firewall
(QVXUHWKDWWKHPLQLPXPVDIHW\GLVWDQFHVDUHIXOO¿OHG
(FIG 1).
When connecting a steel chimney to the top outlet use
the security distances required by the manufacturer.
Important! When placing the insert on
DFRPEXVWLEOHÀRRUDVWHHOSODWHRIDWOHDVW
PPPXVWFRYHUWKHHQWLUHÀRRUVXUIDFHLQVLGH
WKHVXUURXQG$Q\ÀRRULQJPDGHRIFRPEXVWLEOH
material, such as linoleum, carpets etc. must be
removed from underneath the steel plate.
4. Assembly FIG 3 - to FIG 7
Assembling the front legs FIG 3
The insert is delivered with adjustable legs. The legs
are mounted on to the insert using the added bolts and
washers - fasten it as shown on the drawing.
Assembling the rear bracket leg FIG 3b
The bracket, rear leg is also adjustable. Assemble the
leg to the body by provided bolts and wahers.
Air inlet - FIG 4
Assemble air inlet as shown on the drawing. Fasten it
with screw by a torx key provided.
5HDUÀXHJDVFRQQHFWLRQ),*
A chimney adapter is set in a rear chimney connection
position. If you want utilize rear chimney connection
remove a lid from rear shield by a suited tool.
7RSÀXHJDVFRQQHFWLRQ),*E
7RXWLOL]HWKHWRSÀXHJDVFRQQHFWLRQIROORZEHORZVWHSV
1. Unscrew fastening bolts by provided tools.
2. Turn arround chimney adapter as shown on
the drawing.
3. Screw in the bolts to the body.
4. Place in the socket a rod stopping a chimney
sweeper ball.
Attention! Our inserts are prepared for connecting
WKHVPRNHSLSHRQWKHRXWVLGHRIWKHÀXHFROODU
Ø150.
*$OWHUQDWLYHYHUVLRQVRIWKHÀXHFROODUH[LVWGXHWR
The insert expands when in use, and for
this reason the surround must NEVER rest
on the insert, but have a gap of about 3 mm.
The insert must neither rest on the bench plate or
against the sides. It is recommended to dry stack
the surround in order to adjust the insert prior
WRSHUIRUDWLQJWKHFKLPQH\IRUWKHÀXHFRQQHFWLRQ
Technical TABLE
Insert N-20U
Material Steel
Surface treatment Heat resistant varnish
/ Decorative chrome
Weight of insert (kg) 108 kg
Draught system Ignition air vent control
and air vent control
Combustion system Clean burning
(Secondary combu-
stion)
Combustion air consumption (m³/h) 9-25
Operating range, Clean burn (kW) 4,5-9,0
Maximum fuel length (cm) 40
Flue outlet Top and rear
Flue collar (Ø mm) Outer 150
*alternate versions exists due to nationa requirements
)OXHJDVWHPSHUDWXUHDWÀXH
connector (°C)
246,5
'UDIWDWÀXHFRQQHFWRU
recommended (Pa)
14-25
Data according to EN 13 229
Area of convection air vent under
insert (cm2)
300
Area of convection air vent over
insert (cm2)
450
Minimum distance conv. air outlet
to ceiling (mm)
500
Nominal heat output (kW) 5,4
(ႈFLHQF\ 81,9
CO @ 13% O2 (%) 0,09
Flue gas temperature (°C) 196,4
Draft (Pa) >12
Fuel recommended: Wood logs
Fuel length recommended (cm) 25-30
Fuel charge (kg) 1,1
Refueling interval (minutes) 45
Opening of the air vent
control (%)
40-50
Operation* Intermittent*
,QWHUPLWHQWFRPEXVWLRQUHIHUVWRQRUPDOXVHRID¿UHSODFH
i.e. new wood is inserted when the previous load has burned
down to ember
Warning: If the requirements for ventilation are
127FRPSOLHGZLWKWKHFRROLQJDLUÀRZDURXQGWKH
product will be considerably reduced and
the product can overheat.
7KLVFDQFDXVHD¿UH
12 GB

1DWLRQDOUHTXLUHPHQWV)RUWKHÀXHFRQQHFWLRQWRWKH
chimney, follow the recommendations from the chimney
manufacturer.
Assembling Front Heat Shield FIG 7
1. Assemble front cover by bending its sides as shown
on the drawing FIG 7A & FIG 7B.
2. Place the radiation shield cover on its place as,
take care that slots at the end of cover matches to
hooks of rear cover - see FIG 7C
Multipurpose key
The insert is equipped with an handle, which is intended
for operating, ie.: air vents, opening and closing doors -
see FIG 8-FIG 8C.
Operational control
When the insert is in upright position, and prior
to mounting the surround, control that all functions
are easy to maneuver and appear satisfactory. See also
FIG 8a & FIG 8b
A. Ignition vent control B. Air vent control
Pushed in = closed
Pull out = open
Left position = closed
Right position = open
Removing the self-closing door mechanism FIG 9
In order to deactivate - follow instruction below:
- open the door,
- lock the spring by fastening the screw - FIG 9A,
- lift the door up and unfasten the screw - FIG 9B, when
a noise could be heard the self-closing door is
deactivated,
- lower the door back to its place.
Painting the surround
It is recommended to use the insert a few times in order
to let the varnish harden before any eventual masking
and painting. Only use water based breathing paint and
a designated masking tape. Carefully remove the tape
in order not to damage the varnish.
/LJKWLQJD¿UHIRUWKH¿UVWWLPH
When the insert is assembled and all instructions have
EHHQREVHUYHGD¿UHFDQEHOLW
Take care when inserting logs into the burn chamber, in
order not to damage the Thermotte plates.
This will be resolved once the humidity has evaporated.
,IQHHGHGOHDYHWKHGRRUVOLJKWO\RSHQWKH¿UVWWLPHV
the insert is used.
FIG B
FIG A
It is advisable to ventilate the room well when using
IRUWKH¿UVWWLPHDVWKHYDUQLVKRQWKHSURGXFWPD\
release some smoke or smell. Both the smoke and
smell will disappear and are not hazardous.
Kindling wood
Finely chopped (diameter of 3-5cm)
Length: 25-30cm
Ca. amount pr lighting : 2,1 kg (beech)
Place the air vent control in ignition (FIG A) (Pull out).
Insert small, dry pieces of wood, ignite and ensure the
ÀDPHVKDYHWDNHQSURSHUKROGRIWKHZRRG:KHQWKH
ÀDPHVDUHVWDEOHDQGWKHFKLPQH\LVZDUPSXVKLQWKH
DLUFRQWURORXWRIWKHLJQLWLRQPRGHDQGUHJXODWHWKH¿UH
normally.
When there is a glowing layer of ash, new wood logs
can be inserted. Pull the hot ember to the sides of the
combustion chamber when inserting new logs so that
the wood is ignited from the bottom. Insert 2 logs. One
positioned diagonally to the bottom with left end closer
to left front side of window pane. The second leaned
DJDLQVW¿UVWRQHDOVRGLDJRQDOO\LQRSSRVLWHGLUHFWLRQ
6HWWKHDLUYHQWRQDLUYDOYHRSHQLQJ7KH¿UH
VKRXOGEXUQZLWKEULJKWDQGOLYHO\ÀDPHV
Reload size
Chopped wood - 2 logs (diametre of 6-9cm)
Length: 25-30cm
Normal load size. 1,46 kg /h
(Max load size: 2,5 kg/h)
Attention!
8VLQJWKHLQVHUWZLWKORZFRPEXVWLRQHႇHFWDQG¿ULQJ
around the clock increase pollution as well as the risk
IRUD¿UHLQWKHFKLPQH\1HYHUDOORZWKHLQVHUWRUÀXHWR
EHFRPHJORZLQJUHG7XUQRႇWKHDLUYHQWFRQWUROVKRXOG
this happen. Regulation of the air vent control takes
some experience, but after a little while a natural rhythm
IRUWKH¿UHZLOOEHIRXQG
IMPORTANT! Always remember to open
t h e a i r v e n t c o n t r o l ( p r e f e r a b l y a l s o t h e d o o r )
before new wood logs are inserted into a hot burn
FKDPEHU/HWWKHÀDPHVJHWDJRRGJULSRQWKH
wood before the air control setting is reduced.
When the draught in the chimney is low and
WKHYHQWLVFORVHGWKHJDVIURPWKH¿UHZRRG
can be ignited with a bang. This can cause
damage to the product as well as the immediate
environment.
Warning!
In order to avoid injuries, please be aware that the
surfaface may become hot during operation and
extra care need to be taken to avoid skin burn.
WARNING:
Never leave the air control in ignition mode for pro-
longed periods as this may lead to overheating.
13
GB

Periodically, it may be necessary to change the gaskets
on the door to ensure that the burn chamber is air tight
and working optimally. These gaskets can be bought as
a set, usually including ceramic glue.
Ceramic glass should
be disposed of as resid-
ual waste, together with
pottery and porcelain
CERAMIC GLASS
CANNOT BE
RECYCLED
Recycling of ceramic glass
Ceramic glass cannot be recycled. Old glass, breakage
or otherwise unusable ceramic glass must be discarded
as residual waste. Ceramic glass has a higher melting
temperature, and can therefore not be recycled together
with glass. If mixed with ordinary glass, it would
damage the raw material and could, in worst case end
the recycling of glass. It is an important contribution to
the environment to ensure that ceramic glass does not
end up with the recycling of ordinary glass.
Packaging Recycle
The packaging accompanying the product should be
recycled according to national regulations.
7. Warranty
Warning!
8VHUHSODFHPHQWSDUWVUHFRPPHQGHGRQO\E\WKH
Manufacturer.
Warning!
$Q\XQDXWKRUL]HGPRGL¿FDWLRQRIWKHDSSOLDQFH
without written permission of the Manufacturer
are prohibited.
For detailed description of the warranty conditions see the enclosed
warranty card or visit our website www.nordpeis.com
The CE mark is placed on the side of the insert.
6. Maintenance FIG 14 - to FIG 23
Cleaning and inspection
The insert should be inspected thoroughly and clened
at least once per season (possibly in combination with
the sweeping of the chimney and chimney pipes).
How to get access to soot after a chimney sweep see
drawing FIG 10 and FIG 16.
Ensure that all joints are tight and that the gaskets are
rightly positioned. Exchange any gaskets that are worn
or deformed.
Remember that the insert must always be cold when
inspected. The inspection shall be performed by the
Professional servicemen.
Ashes
The ashes should be removed at regular intervals.
Be aware that the ashes can contain hot ember even
VHYHUDOGD\VDIWHUWKH¿UHLV¿QLVKHG8VHDFRQWDLQHU
of non-combustible material to remove the ashes. It is
recommended to leave a layer of ashes in the bottom
as this further insulates the burn chamber.
Take care with the Thermotte plates when the ashes are
removed, particularly when using an ash shovel, so as
not to damage them.
Thermotte™
7KHLQVXODWLRQSODWHV7KHUPRWWH),*DUHFODVVL¿HG
DV³ZHDUDQGWHDU´SDUWVZKLFKZLOOUHTXLUHWREH
exchanged after some years.
The wear time will depend on the individual use of your
SURGXFW1RUGSHLVRႇHUVDRQH\HDUZDUUDQW\RQWKHVH
parts. After this, replacements can be purchased.
In case it is necessary to take out the insulation plates,
this is done in followieng order.
$%DႉHSODWH
B. Back plate
C. Bottom front left
D. Bottom front right
E. Bottom plate left
F. Bottom plate right
See also drawings from FIG 10 to FIG 14.
Please note: Wood logs that are too long can cause
additional strain and crack the plates, due to the tension
created between the side plates.
Door and Glass
Should there be any soot on the glass it may be
necessary to clean it. Use dedicated glass cleaner, as
other detergents may damage the glass. (NB! Be care-
ful, even dedicated glass cleaner can damage the var-
nish on the door frame and the gaskets). A good advice
for cleaning the glass is to use a damp cloth or kitchen
roll paper and apply some ash from the burn chamber.
5XEDURXQGWKHDVKRQWKHJODVVDQG¿QLVKRႇZLWKD
piece of clean and damp kitchen roll paper.
NB! Only clean when the glass is cold.
14 GB

$GYLFHRQOLJKWLQJD¿UH
7KHEHVWZD\WROLJKWD¿UHLVZLWKWKHXVHRIOLJKWHQLQJ
briquettes and dry kindling wood. Newspapers cause
a lot of ash and the ink is damaging for the environment.
$GYHUWLVLQJÀ\HUVPDJD]LQHVPLONFDUWRQVDQGVLPLODU
DUHQRWVXLWDEOHIRUOLJKWLQJD¿UH*RRGDLUVXSSO\LV
LPSRUWDQWDWLJQLWLRQ:KHQWKHÀXHLVKRWWKHGUDXJKW
increases and door can be closed
Use clean and dry wood with a maximum moisture
content of 20%. Humid wood requires a lot of air for the
combustion, as extra energy/heat is required for drying
WKHKXPLGZRRGDQGWKHKHDWHႇHFWLVWKHUHIRUHPLQLPDO
This in addition creates soot in the chimney with the risk
RIFUHRVRWHDQGFKLPQH\¿UH
,QFDVHRIDFKLPQH\¿UHFORVHWKHGRRUDQGDLU
supplies on the stove / insert and call the Fire
%ULJDGH$IWHUDFKLPQH\¿UHWKHFKLPQH\PXVWLQ
all cases be inspected by an authorized chimney
sweeper before you use the appliance again.
Storing of wood
In order to ensure that the wood is dry, the tree should
be cut in winter and stored during the summer, covered
and in a location with adequate ventilation. The wood
pile must never be covered by a tarpaulin lying against
the ground as the tarpaulin will then act as a sealed lid
that will prevent the wood from drying. Always keep a
small amount of wood indoors for a few days before use
so that moisture in the surface of the wood can
evaporate.
8VDJH
Not enough air to the combustion may cause the glass
WRVRRW+HQFHVXSSO\WKH¿UHZLWKDLUMXVWDIWHUWKH
ZRRGLVDGGHGVRWKDWWKHÀDPHVDQGJDVHVLQWKH
combustion chamber are properly burnt. Open the air
YHQWDQGKDYHWKHGRRUVOLJKWO\DMDULQRUGHUIRUWKHÀD-
mes to establish properly on the wood.
Note that the air supply for the combustion also can
EHWRRODUJHDQGFDXVHDQXQFRQWUROODEOH¿UHWKDWYHU\
quickly heats up the whole combustion chamber to an
extremely high temperature (when using with a closed
or nearly closed door). For this reason you should never
¿OOWKHFRPEXVWLRQFKDPEHUFRPSOHWHO\ZLWKZRRG
Warning!
The Firebox shall to be always closed except during
ignition, refueling and ash removal.
Choice of fuel
All types of wood, such as birch, beech, oak, elm, ash
and fruit trees, can be used as fuel in the insert. Wood
VSHFLHVKDYHGLႇHUHQWGHJUHHVRIGHQVLW\WKHPRUH
dense the wood is, the higher the energy value. Beech,
oak and birch has the highest density.
Attention!
We do not recommend using fuel briquettes/
FRPSDFWZRRGLQRXUSURGXFWV8VHRIVXFKIXHO
may cause the product to overheat and exceed the
temperatures determined safe. Burning briquettes/
compact wood is done so at your own risk and only
small amounts (max 1/3 of normal load) should be
used for each load.
Warning:
Make sure the insert is not overheated it can cause
irreparable damage to the product. Such damage is
not covered by the warranty.
6RXUFH³+nQGERNHႇHNWLYRJPLOM¡YHQQOLJYHGI\ULQJ´E\(GYDUG
Karlsvik SINTEF Energy Research AS and Heikki Oravainen, VT
Warning:
NEVER use impregnated wood, painted wood,
plywood, chipboard, rubbish, milk cartons, printed
material or similar. If any of these items are used as
fuel the warranty is invalid.
Common to these materials is that during
combustion they can form hydrochloric acid and
heavy metals that are harmful to the environment,
yourself and the insert. Hydrochloric acid can also
corrode the steel in the chimney or masonry in a
masonry chimney. Also, avoid burning with bark,
VDZGXVWRURWKHUH[WUHPHO\¿QHZRRGDSDUWIURP
ZKHQOLJKWLQJD¿UH7KLVIRUPRIIXHOFDQHDVLO\
FDXVHDÀDVKRYHUWKDWFDQOHDGWRWHPSHUDWXUHV
that are too high.
Warning: NEVER use a lighting fuel such as petrol,
NDURVLQHDOFRKRORUVLPLODUIRUOLJKWLQJD¿UH7KLV
could cause injury to you as well as damaging the
product.
15
GB

Some advice in case of combustion problems
Error Explanation Solution
No draught
The chimney is blocked. Contact a chimney sweeper / dealer for more information or clean
WKHÀXHVPRNHEDႉHDQGEXUQFKDPEHU
7KHÀXHLVVRRW\RUWKHUHLVDFFXPXODWHGVRRWRQWKH
VPRNHEDႉH
7KHVPRNHEDႉHLVZURQJO\SRVLWLRQHG 9HULI\WKHDVVHPEO\RIWKHVPRNHEDႉHVHHDVVHPEO\LQVWUXFWLRQV
The insert
release smoke
when ligh-
WLQJWKH¿UH
and during
combustion
Downdraught in the room caused by no draught, that the
KRXVHLVWRR³DLUWLJKW´
/LJKWWKH¿UHZLWKDQRSHQZLQGRZ,IWKLVKHOSVPRUHELJJHUYHQWV
must be installed in the room.
Downdraught in the room – caused by extractor and/or
central ventilation system that pulls too much air out of
the room.
7XUQRႇUHJXODWHH[WUDFWRUDQGRURWKHUYHQWLODWLRQ,IWKLVKHOSVPRUH
vents must be installed.
7KHÀXHVIURPWZR¿UHSODFHVVWRYHVDUHFRQQHFWHGWRWKH
same chimney at the same height.
2QHÀXHPXVWEHUHSRVLWLRQHG7KHKHLJKWGLႇHUHQFHRIWKHWZRÀXH
pipes must be of at least 30 cm.
7KHÀXHLVLQDGHFOLQLQJSRVLWLRQIURPWKHVPRNHGRPHWR
the chimney.
7KHÀXHPXVWEHPRYHGVRWKDWWKHUHLVDQLQFOLQDWLRQRIDWOHDVW
10º from smoke dome to chimney. Possibly install a smoke suction
device*.
7KHÀXHLVWRRIDULQWRWKHFKLPQH\
7KHÀXHPXVWEHUHFRQQHFWHGVRWKDWLWGRHVQRWHQWHULQWRWKHFKLP-
ney but ends 5 mm before the chimney inner wall. Possibly install a
smoke suction device*.
Soot hatch in the basement or attic that is open and thus
creating a false draught.
Soot hatches must always be closed. Hatches that are not tight or
are defected must be changed.
'DPSHUWRSGUDXJKWYHQWVRUGRRUVRQ¿UHSODFHVWKDWDUH
not in use are open and create a false draught.
&ORVHGDPSHUGRRUVDQGWRSGUDXJKWYHQWVRQ¿UHSODFHVWKDWDUH
not in use.
$QRSHQKROHLQWKHFKLPQH\DIWHUWKDWD¿UHSODFHKDV
been removed, thus creating a false draught. +ROHVPXVWEHFRPSOHWHO\VHDOHGRႇZLWKPDVRQU\
Defect masonry in the chimney, e.g. it is not airtight
DURXQGWKHÀXHSLSHHQWU\DQGRUEURNHQSDUWLWLRQLQVLGH
the chimney creating a false draught.
Seal and plaster all cracks and sites that are not tight.
The cross-section in the chimney is too large which
results in no or very low draught.
7KHFKLPQH\PXVWEHUH¿WWHGSRVVLEO\LQVWDOODVPRNHVXFWLRQ
device*.
The cross-section in the chimney is too small and the
chimney cannot carry out all the smoke.
&KDQJHWRDVPDOOHU¿UHSODFHRUEXLOGQHZFKLPQH\ZLWKDODUJHU
cross section. Possibly install a smoke suction device*.
The chimney is too low and hence a poor draught. Increase the height of the chimney and/or install a chimney cap/
smoke suction device*.
7KH¿UHSODFH
releases smoke
inside when
it is windy
outside.
The chimney is too low in relationship to the surrounding
terrain, buildings, trees etc.
Increase the height of the chimney and/or install a chimney cap/
smoke suction device*.
Turbulence around the chimney due to the roof being too
ÀDW
Increase the height of the chimney and/or install a chimney cap/
smoke suction device*.
7KH¿UHSODFH
does not heat
VXႈFLHQWO\
7KH¿UHSODFHFRPEXVWLRQUHFHLYHVWRRPXFKR[\JHQGXH
to a leakage under the lower border of the insert or too
VWURQJFKLPQH\GUDXJKW'LႈFXOWWRUHJXODWHWKHFRPEXV-
tion and the wood burn up too quickly.
$Q\SRVVLEOHOHDNDJHPXVWEHVHDOHGRႇ$GUDXJKWUHJXODWRURU
possibly a damper can reduce the chimney draught. NB! A leakage
of only 5 cm2 is enough for 30% of the heated air to disappear.
Too much
draught
7KHVPRNHEXႇHULVZURQJO\SRVLWLRQHG 9HULI\WKHSRVLWLRQLQJRIWKHVPRNHEXႇHU±VHHDVVHPEO\LQVWUXF-
tions.
In case of using oven-dried wood, this requires less air
supply than when using normal wood. Turn down the air supply.
7KHJDVNHWVDURXQGWKHGRRUDUHZRUQDQGWRWDOO\ÀDW Replace the gaskets, contact your dealer.
The chimney is too large. Contact chimneysweeper or other professional for more details.
The glass is
sooty
The wood is too wet. Only use dry wood with a humidity of maximum 20%.
The air vent control is closed too tightly.
Open the air vent control to add air to the combustion. When new
wood logs are inserted all vent controls should be completely
RSHQHGRUWKHGRRUVOLJKWO\RSHQHGXQWLOWKHÀDPHVKDYHDJRRG
take on the wood.
White glass
Bad combustion (the temperature is too low). Follow the guidelines in this user guide for correct combustion.
Using wrong material for combustion (such as: painted
or impregnated wood, plastic laminate, plywood etc). Ensure to use only dry and clean wood.
Smoke is rele-
ased when the
door is opened
A levelling out of pressure occurs in the burn chamber. Open the air vent control for about 1 min before opening the door –
avoid opening the door too quickly.
7KHGRRULVRSHQHGZKHQWKHUHLVD¿UHLQWKHEXUQ
chamber. Open the door carefully and/or only when there is hot ember.
White smoke The combustion temperature is too low. Increase the air supply.
The wood is humid and contains water damp. Ensure to use only dry and clean wood.
Black or grey/
black smoke ,QVXႈFLHQWFRPEXVWLRQ Increase the air supply.
16 GB

18 PP
























5HYLVLRQQRWH
1DPH
2XWVLHGGLPHQVLRQVRIW
K
'UDZLQJXSGDWHDIWHUFKDQJHVD
31

=Brannmur/ Brandmur/ Palomuuri/ Firewall
=Brennbart materiale/Brændbart materiale/ Brännbart material/ Tulenarka materiaali/ Combustible material
300cm2
PP
FIG 1
450cm2
0 mm >400
300
>400
>15
450cm2
>250 >250
>700
>15
450cm2
>250 >250
1000
32

Thermotte ®™
B
C
D
B
FIG 2
A
B
C
Front leg assembling
FIG 3
Montering / Assembling / Montering / Asennus
F
E
D
13 mm
22-0N20A-100 x2
21-30006-020 x2
21-50000-022 x2
33

FIG 3b Bracket leg
FIG 3c Bracket leg
13 mm
22-0N20U-190 x1
21-50000-022 x1 21-30006-020 x1
13 mm
34

FIG 4 Air inlet pipe assembling
22-00N20-180 x1 21-30011-408 x4
Torx
FIG 4a
21-30011-408 x4
Torx 20
22-00N20-280
22-00N20-180
Air inlet adapter 90 assembling - optional
0
35

FIG 4b
Torx 20
21-30011-408 x422-00N20-290
x4
FIG 4c
36

FIG 4d
FIG 4e
37

FIG 5 Smoke adapter - rear chimney connection
FIG 4f
38

FIG 6
FIG 5b
180 0
5 mm
1.
3.
2.
4.
Lift handles - assembling 1-2 / disassembling 3-4
10 mm
!
Attention
39

FIG 8 Operational handle - primary valve usage
FIG 7
A
B
90 0
22-0N20U-160 x1
C
Front radiation shield - assembling
40

FIG 8b Operational handle - secondary valve usage
FIG 8c Operational handle - door opening usage
41

129HGOLNHKROG*%0DLQWHQDQFH6(8QGHUKnOO),Kunnossapito
FIG 10
22-0N20U-200 x2
21-30011-408 x2
LA-0N20U-040 x1
TORX
FIG 9 Self-closing door deactivation
A
B
2 x 360 0
2,5 mm
C
2 x 360 0
42
