Nortel ASN Dimensions

Retirement Bulletin
Bulletin Number: R-2006-0232-Global
Date: 01 January 2007
Multiprotocol Router Access Stack Node (ASN)
Manufacture Discontinue Notice
REVISION HISTORY
Date Revision # Summary of Changes
01 January 2007 Original bulletin This is the original publication
Last Time Order Date: April 30, 2007
Last Ship Date: May 31, 2007
Manufacture Discontinue (MD) Date: May 31, 2007
End of Life (EOL) Date: June 1, 2012
Last Supported Software Release: BayRS 15.7, 15.6, 15.4
Market Regions Affected: Global, NA, CALA, EMEA, and Asia Pacific
Introduction
The Multiprotocol Router ASN product portfolio is being discontinued by Nortel*. The last
order date is April 30, 2007 with the table below providing a list of discontinued codes. Any
Multiprotocol Router ASN order codes not listed in the table have also been discontinued.
The recommended replacement product for the Multiprotocol Router ASN is the Secure
Router 3120. Please note that the Secure Router products are IP WAN routers and do not
support legacy multiprotocol features of the BayRS family, including the Multiprotocol Router
ASN. The Secure Router 3120 provides superior price/performance with advanced features
in the areas of Routing, WAN, VPN, Security, Quality of Service and Network Management.
Technical support for the Multiprotocol Router ASN products will continue through the
normal Nortel Technical Support Center. This notice will also serve as the final EOL notice
for the order codes identified below and no additional notice will be issued.
Definition
Manufacture Discontinue (MD) – This notice serves as formal communication of Nortel
Networks’ intent to MD the product(s) noted. No further orders will be accepted as of the
Nortel Page 1 of 5

Last Time Order Date shown above and no further shipments made after the product has
been discontinued. The MD of these products should not be interpreted as the
discontinuance of any Nortel Networks agreements to support the existing field population.
Services to the existing product base will continue to be provided until the End of Life (EOL)
date shown above.
Product Overview (See Table for Detail)
SYSTEM COMPONENTS
Base Units
AF0002B03
ASN2 Base Unit 0MB AC Redundant (Includes European Schuko
power cord)
AF0002C03 ASN2 Base Unit 0MB AC Redundant (Includes power cord used
in the UK and Ireland)
AF0002D03 ASN2 Base Unit 0MB AC Redundant (Includes power cord used
in Japan)
AF0002E03 ASN2 Base Unit 0MB AC Redundant (Includes North American
power cord)
AF0002F03
ASN2 Base Unit 0MB AC Redundant (Includes Australian power
cord, also used in New Zealand and the PRC)
AF0002G03
ASN2 Base Unit 0MB AC Redundant (Includes power cord used
in Denmark)
AF0002H03
ASN2 Base Unit 0MB AC Redundant (Includes power cord used
in India/South Africa)
AF0002K03
ASN2 Base Unit 0MB AC Redundant (Includes power cord used
in Italy)
AF0002L03 ASN2 Base Unit 0MB AC Redundant (Includes power cord used
in Switzerland)
AF0002M03
ASN2 Base Unit 0MB AC Redundant (Includes North American
10A/220 power cord)
AF0002W03
ASN2 Base Unit 0MB AC Redundant (Includes power cord used
in Israel.)
AF0002A15 ASN2 Base Unit 16M 48V Power. (No power cord included)
AF0002A16 ASN2 Base Unit 32M 48V Power. (No power cord included)
AF0002B12 ASN2 Base Unit 16M AC Redundant Power (Includes European
Schuko power cord)
AF0002B13 ASN2 Base Unit 32M AC Redundant Power (Includes European
Schuko power cord)
AF0002C12 ASN2 Base Unit 16M AC Redundant Power (Includes power cord
used in the UK and Ireland)
AF0002C13 ASN2 Base Unit 32M AC Redundant Power (Includes power cord
used in the UK and Ireland)
AF0002D12 ASN2 Base Unit 16M AC Redundant Power (Includes power cord
used in Japan)
AF0002D13 ASN2 Base Unit 32M AC Redundant Power (Includes power cord
used in Japan)
AF0002E12 ASN2 Base Unit 16M AC Redundant Power (Includes North
American power cord)
AF0002E13 ASN2 Base Unit 32M AC Redundant Power (Includes North
American power cord)
AF0002F12 ASN2 Base Unit 16M AC Redundant Power (Includes Australian
power cord, also used in New Zealand and the PRC)
AF0002F13 ASN2 Base Unit 32M AC Redundant Power (Includes Australian
power cord, also used in New Zealand and the PRC)
Nortel Page 2 of 5

AF0002G12 ASN2 Base Unit 16M AC Redundant Power (Includes power cord
used in Denmark)
AF0002G13 ASN2 Base Unit 32M AC Redundant Power (Includes power cord
used in Denmark)
AF0002H12 ASN2 Base Unit 16M AC Redundant Power (Includes power cord
used in India/South Africa)
AF0002H13 ASN2 Base Unit 32M AC Redundant Power (Includes power cord
used in India/South Africa)
AF0002K12 ASN2 Base Unit 16M AC Redundant Power (Includes power cord
used in Italy)
AF0002K13 ASN2 Base Unit 32M AC Redundant Power (Includes power cord
used in Italy)
AF0002L12 ASN2 Base Unit 16M AC Redundant Power (Includes power cord
used in Switzerland)
AF0002L13 ASN2 Base Unit 32M AC Redundant Power (Includes power cord
used in Switzerland)
AF0002M12 ASN2 Base Unit 16M AC Redundant Power (Includes North
American 10A/220 power cord)
AF0002M13 ASN2 Base Unit 32M AC Redundant Power (Includes North
American 10A/220 power cord)
AF0002W12 ASN2 Base Unit 16M AC Redundant Power (Includes power cord
used in Israel.)
AF0002W13 ASN2 Base Unit 32M AC Redundant Power (Includes power cord
used in Israel.)
ASN and HRPSU Power Cords
AA0018020 Power Cord: North America (U.S., Canada, Mexico, South Korea)
15A/110-120V AC
AA0020001 Model AA0020001 15A/100V Japan (Japan)
AA002001E6 Model AA0020001 15A/100V Japan (Japan)
DRAM/Flash Memory
50027 8M DRAM to 16M DRAM ASN Field Upgrade includes 2 SIMMs to
replace all existing DRAM for 16MB operation.
AA0011001 4M Flash Card Spare – Formatted
AA0011002 8M Flash Card Spare – Formatted
AA0011005 16M Flash Card Spare – Formatted
AF0011004 16M DRAM field kit
AF0011005 32M DRAM field kit/8M or 16M to 32M field upgrade (previous
order number 50028)
LAN Network Modules
34000 Dual Ethernet Net Module
34000-S Dual Ethernet Net Module Spare
34002 Dual Token Net Module
34002-S Dual Token Net Module Spare
34010 Single 100BASE-T Net module
34010-S Single 100BASE-T Net module Spare
AF1204001 Multimode FDDI Net Module (previous order number 34003)
AF1211001 Multimode FDDI Net Module Spare (previous order number
34003-S)
WAN Network Modules
34001 Dual Sync Net Module
34001-S Dual Sync Net Module Spare
34005 ISDN BRI/Dual Sync Net Module
34005-S ISDN BRI/Dual Sync Net Module Spare (Boxed)
Nortel Page 3 of 5

34008 Quad BRI Net Module for ASN
34008-S Quad BRI Net Module Spare
50023 ASN ISDN BRI Field Upgrade/Spare
AF2104004 MCE1 Net Module for channelized E1 and ISDN PRI
AF2104006 Quad Sync Net Module (Factory Installed)
AF2104010 MCE1 Net Module for channelized E1 and ISDN PRI Spare
AF2104016 Dual MCT1 Factory Installed (requires v 11.01 Software)
AF2104020 High Speed Serial Interface (HSSI) Net Module (requires v12.0
software)
AF2111001 Dual MCT1 Field Upgrade (requires v 11.01 Software)
AF2111005 Quad Sync Net Module Spare
AF2111006 High Speed Serial Interface (HSSI) Net Module Field Upgrade
(requires v12.0 software)
Optional Modules
34007 SPEX-Hot Swap Net Module
34007-S SPEX-Hot Swap Net Module Spare
7166 SPEX-Hot Swap Cable
AA0004001 ASN2 Fast Packet Cache - Factory Installed
AA0011004 ASN2 Fast Packet Cache – Spare
AF2104007 32-Contexts Hardware Compression co-processor Net Module
AF2104012 128-Contexts Hardware Compression co-processor Net Module
AF2104013 128-Contexts Hardware Compression co-processor Net Module -
Spare
AF2104015 32-Contexts Hardware Compression co-processor Net Module -
Spare
Options for Redundant Power Supply
AA0002001 HRPSU Base Unit Single AC input
AA0005003 HRPSU Power Module AC 200watt (24-pin)
AA0011029 HRPSU Rack Mount Replacement Kit
AA0018016 HRPSU output cable 200watt (24-pin)
AA0018017 HRPSU output cable 130watt (16-pin)
AA0018018 HRPSU output adapter 16-pin cable(s) to single base unit
Options
AF0011024 ASN2 Rack Mount Replacement Kit
Software Dependencies
Software support on the product will continue per Nortel support policy. BayRS 15.7 will
continue to be fully supported for one year after manufacture discontinuation and limited
support for four more years after full support ends. BayRS 15.6 and 15.4 will continue to
have limited support for five years after manufacture discontinuation.
Alternative/Replacement Products/Solutions
The recommended replacement product for Multiprotocol Router ASN is the Secure Router
3120. Please note that Secure Router products are IP WAN routers and do not support
legacy multiprotocol features of the BayRS family, including the Multiprotocol Router ASN.
The Secure Router 3120, however, provides superior price/performance with advanced
Nortel Page 4 of 5

features in the areas of Routing, WAN, VPN, Security, Quality of Service and Network
Management.
Related Product and Sales & Marketing Bulletins (if applicable)
Not applicable.
Customer Actions
Customers are advised to consider this notification in conducting last time buys or planning
a product replacement with the Nortel Secure Router 3120 family. For more information,
please contact your Nortel Networks account representative. Content herein is not intended
to supercede existing customer contractual commitments.
