Nortel BayStack ARN Dimensions

Retirement Bulletin
Bulletin Number: R-2006-0230-Global
Date: 01 January 2007
Multiprotocol Router Advanced Remote Node (ARN)
Manufacture Discontinue Notice
REVISION HISTORY
Date Revision # Summary of Changes
01 January 2007 Original bulletin This is the original publication
Last Time Order Date: July 31, 2007
Last Ship Date: August 31, 2007
Manufacture Discontinue (MD) Date: August 31, 2007
End of Life (EOL) Date: September 1, 2012
Last Supported Software Release: BayRS 15.7, 15.6, 15.4
Market Regions Affected: Global, NA, CALA, EMEA, and Asia Pacific
Introduction
The Multiprotocol Router ARN product portfolio is being discontinued by Nortel*. The last
order date is July 31, 2007 with table below providing a list of discontinued codes. Any
Multiprotocol Router ARN order codes not listed in the table have also been discontinued.
The recommended replacement product for the Multiprotocol Router ARN is the Secure
Router 1001 or 1002. Please note that the Secure Router products are IP WAN routers and
do not support legacy multiprotocol features of the BayRS family, including the Multiprotocol
Router ARN. The Secure Router 1001 and 1002 provide superior price/performance with
advanced features in the areas of Routing, WAN, VPN, Security, Quality of Service and
Network Management.
Technical support for the Multiprotocol Router ARN products will continue through the
normal Nortel Technical Support Center. This notice will also serve as the final EOL notice
for the order codes identified below and no additional notice will be issued.
Nortel Page 1 of 4

Definition
Manufacture Discontinue (MD) – This notice serves as formal communication of Nortel
Networks’ intent to MD the product(s) noted. No further orders will be accepted as of the
Last Time Order Date shown above and no further shipments made after the product has
been discontinued. The MD of these products should not be interpreted as the
discontinuance of any Nortel Networks agreements to support the existing field population.
Services to the existing product base will continue to be provided until the End of Life (EOL)
date shown above.
Product Overview (See Table for Detail)
ADVANCED REMOTE NODE (ARN) SYSTEMS
Base Unit
CV1001004 ARN Ethernet Base Unit (16M DRAM)
CV1001005 ARN Ethernet Base Unit (32M DRAM)
CV1001009 ARN -48VDC Ethernet Base Unit (16M DRAM)
CV1001010 ARN -48VDC Ethernet Base Unit (32M DRAM)
CV1001014 ARN 10/100M-TX UTP Base Unit (16M DRAM)
CV1001015 ARN 10/100M-TX UTP Base Unit (32M DRAM)
CV1001019 ARN 100M-FX Fiber Base Unit (16M DRAM)
CV1001020 ARN 100M-FX Fiber Base Unit (32M DRAM)
CV1101004 ARN Token Ring Base Unit (16M DRAM)
CV1101005 ARN Token Ring Base Unit (32M DRAM)
CV1001001 ARN Ethernet Base Unit (0M DRAM)
CV1101001 ARN Token Ring Base Unit (0M DRAM)
Options
CV0011057 ARN Rack Mount Replacement Kit
CV0011058 ARN Accessory Kit, includes console cable, rack mount hardware
and flash security cover.
FACTORY CONFIGURED OPTIONS
Expansion Module Options (one per system)
CV0004011 ARN Tri Serial Expansion Module
CV0004012 ARN Ethernet Expansion Module
CV0004013 ARN Token Ring Expansion Module
CV0004014 ARN Ethernet and Tri-Serial Expansion Module
CV0004015 ARN Token Ring and Tri-Serial Expansion Module
CV0004026 ARN Ethernet and 7-Serial Expansion Module (See Note 1)
CV0004027 ARN 7-Serial Expansion Module (See Note 1)
Modem Console Module (one per system)
CV0004020 ARN V.34 Modem Console Module (North America only)
Nortel Page 2 of 4

WAN Adapter Module Options (up to two per system)
CV0004001 ARN Serial Adapter Module
CV0004002 ARN ISDN BRI S/T Adapter Module (without NT1)
CV0004003 ARN ISDN BRI U Adapter Module (with NT1)
CV0004004 ARN 56/64 DSU/CSU Adapter Module (North America only)
CV0004005 ARN V.34 Modem Adapter Module (North America only)
CV0004022 ARN X.25 PAD
CV0004023 ARN T1/FT1 DSU/CSU Adapter Module (North America only) .
CV0004024 ARN E1/FE1 Adapter Module (RJ)
CV0004025 ARN E1/FE1 Adapter Module (BNC)
FIELD UPGRADE/SPARE OPTIONS
DRAM/FLASH Memory
AA0011001 4M Flash Card Spare - Formatted
AA0011002 8M Flash Card Spare - Formatted
AA0011005 16M Flash Card Spare - Formatted
CV0011025 4M to 8M DRAM SIMM Spare/Upgrade
CV0011026 4M or 8M to 16M DRAM SIMM Spare/Upgrade
CV0011027 4M, 8M or 16M to 32M DRAM SIMM Spare/Upgrade
Expansion Module Options (one per system)
CV0011011 ARN Tri Serial Expansion Module Field Upgrade/Spare
CV0011012 ARN Ethernet Expansion Module Field Upgrade Spare
CV0011013 ARN Token Ring Expansion Module Field Upgrade/Spare
CV0011014 ARN Ethernet Tri-Serial Expansion Module Field Upgrade/Spare
CV0011015 ARN Token Ring Tri-Serial Expansion Module Field
Upgrade/Spare
CV0011042 ARN Ethernet and 7-Serial Expansion Module Upgrade/Spare
CV0011043 ARN 7-Serial Expansion Module Field Upgrade/Spare
CV0011059 ARN Expansion Slot Filler Plate (set of five).
Modem Console Module (only 1 per system)
CV0011020 ARN V.34 Modem Console Module Field Upgrade/Spare (North
America only)
WAN Adapter Module Options (up to two per system)
CV0011001 ARN Serial Adapter Module Field Upgrade/Spare
CV0011002 ARN ISDN BRI S/T Adapter Module Field Upgrade/Spare (without
NT1)
CV0011003 ARN ISDN BRI U Adapter Module Field Upgrade/Spare (with NT1)
CV0011004 ARN 56/64 DSU/CSU Adapter Module (North America only) Field
Upgrade/Spare
CV0011005 ARN V.34 Modem Adapter Module (North America only) Field
Upgrade/Spare
CV0011033 ARN X.25 PAD Field Upgrade/Spare
CV0011034 ARN T1/FT1 DSU/CSU Adapter Module (North America only)
Field Upgrade/Spare
CV0011035 ARN X.25 PAD Module ONLY Upgrade/Spare
CV0011040 ARN E1/FE1 Adapter Module Field Upgrade/Spare (RJ)
CV0011041 ARN E1/FE1 Adapter Module Field Upgrade/Spare (BNC)
Nortel Page 3 of 4

Software Dependencies
Software support on the product will continue per Nortel support policy. BayRS 15.7 will
continue to be fully supported for one year after manufacture discontinuation and limited
support for four more years after full support ends. BayRS 15.6 and 15.4 will continue to
have limited support for five years after manufacture discontinuation.
Alternative/Replacement Products/Solutions
The recommended replacement product for Multiprotocol Router ARN is the Secure Router
1001 or 1002. Please note that Nortel’s Secure Router products are IP WAN routers and do
not support legacy multiprotocol features of the BayRS family, including the Multiprotocol
Router ARN. The Secure Router 1001 and 1002, however, provide superior
price/performance with advanced features in the areas of Routing, WAN, VPN, Security,
Quality of Service and Network Management.
Related Product and Sales & Marketing Bulletins (if applicable)
Not applicable.
Customer Actions
Customers are advised to consider this notification in conducting last time buys or planning
a product replacement with the Nortel Secure Router 1000 Series family. For more
information, please contact your Nortel Networks account representative. Content herein is
not intended to supercede existing customer contractual commitments.
