Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 321749-A Rev 01
.

Document status: Standard
Document version: 01.01
Document date: 21 December 2006
Copyright © 2006 , Nortel Networks
All Rights Reserved.
Sourced in Canada and the United States of America
The information in this document is subject to change without notice. The statements, configurations, technical
data, and recommendations in this document are believed to be accurate and reliable, but are presented without
express or implied warranty. Users must take full responsibility for their applications of any products specified in this
document. The information in this document is proprietary to Nortel Networks.

3
Contents
New in this release 5
Features 5
Other changes 5
Introduction 7
Navigation 7
Precautions 9
Installing the chassis 13
Configuration 39
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.

4Contents
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.

5
New in this release
The following sections detail what is new in Quick Start (NN46205-310;
321749-A Rev 01) for this document release:
Features There are no new features added to this document for this release.
Other changes
Information about hsecure is added. To view these changes, see
"Configuration" (page 39).
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.

6New in this release
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.

7
Introduction
This Quick Start Guide provides basic instruction on how to install the
hardware and perform basic configuration of the Ethernet Routing Switch
8010, 8006, 8003, and 8010co chassis and software.
The Quick Start Guide is intended for experienced installers.
Navigation
•"Precautions" (page 9)
•"Installing the chassis" (page 13)
•"Configuration" (page 39)
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.

8Introduction
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.

9
Precautions
For your safety, review the following personal safety warnings before
working with the Ethernet Routing Switch.
WARNING
Risk of injury by electric shock
To avoid the danger of electric shock, be careful when working
with power equipment and connections.
WARNING
Risk of injury by fan blades
When removing the fan module, do not put your hands into the
opening because there are spinning fan blades in the adjacent fan
modules. There is also a risk of electric shock from the electrical
connector at the rear of the slot.
WARNING
Risk of eye injury by laser
Never look directly into the end of a fiber cable or use optical
device to look at the end of a fiber cable unless certain the other
end of the cable is not connected. The laser travelling through a
fiber cable can injure the retina.
Protecting modules
Follow these general practices to prevent equipment damage when working
on the Ethernet Routing Switch:
•Always wear an antistatic wrist strap connected to an Electrostatic
discharge (ESD) grounding jack when handling modules.
•Always set modules on appropriate antistatic material.
•Handle modules by the faceplate. Do not touch pins or electrical
connections.
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.

10 Precautions
•Do not leave slots open. All slots must be filled with modules or, if empty,
covered with slot covers to maintain safety compliance, proper cooling,
and EMI containment in the shelf.
•Ensure that your environment meets the necessary requirements for
temperature, humidity, and cleanliness.
•Replace the optional air filter regularly (approximately every three
months) to maintain proper cooling and airflow through the shelf.
•Do not overtighten thumb screws or lug nuts. Tighten until snug plus a
quarter turn. If you use a power tool to tighten screws, use a low torque
setting (2-3 in/lbs).
Protecting cables and connectors
•Support cables to prevent any stress on the connectors. If you have
a high cable density configuration, you need to install additional
cable-management equipment.
•Do not exceed the bend radius recommended for the type of cable
installed.
•Fiber optic cables and connectors require special care.
— Protect connectors with rubber safety plugs when cables are not
inserted.
— When installing or replacing cables, follow appropriate fiber-cleaning
procedures.
•Do not exceed the bend radius recommended for fiber optic cable. The
acceptable bend radius for fiber optic cable is ten times its diameter, or
2.5-5 cm (1-2 in.). Anything less than the recommendation can cause
a loss of integrity of data transmission. Loss of integrity because of
incorrect bend radius is difficult to diagnose.
Electrostatic discharge
Electrostatic discharge (ESD) is the transfer of charge between bodies at
different electrical potentials. ESD can change the electrical characteristics
of a semiconductor device and degrade or destroy it. ESD can also
disrupt the normal operation of an electronic system by causing equipment
malfunction or failure.
To dissipate or neutralize electrostatic charges, use proper grounding and
use conductive or dissipative materials.
Use an ESD wrist strap. Any charge in your body will go to ground rather
than transfer to hardware modules.
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.

Electrostatic discharge 11
Proper antistatic packaging effectively shields the product from charge and
reduces the generation of charge caused by movement of the product
within the container.
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.

12 Precautions
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.

13
Installing the chassis
This section gives instructions you can use when you install the chassis.
Unpacking
Step Action
1Remove the shipping container.
2Place the chassis on antistatic material.
3Check all items for damage.
4Use the following chassis shipping accessories checklist to verify the
contents of the shipping container.
—End—
If you find any damage, contact your Nortel sales representative.
Table 1
Chassis shipping accessories checklist
Check Accessory Use To
Bracket kit containing: two
rack-mounting brackets and
Phillips-head screws
Support the chassis in an equipment
rack
Screw package Mount the chassis in an equipment
rack
Side cable-management bracket(s):
two brackets for the 8010 chassis and
one bracket for the 8006 and 8003
chassis
Manage network interface cables
Rubber footpads Keep the chassis from slipping when
mounting it on a flat surface
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.

14 Installing the chassis
Check Accessory Use To
Console cable with built-in adapter Connect an optional management
console to the chassis. Each end of
the cable has a female DB9 and a
DB25 connector.
Cable guide Keep cable clusters fastened and out
of the way, but still accessible for
maintenance
Removing a module or power filler panel
Nortel ships the 8000 series chassis with a filler panel covering each empty
module slot. On an 8003, 8006, and 8010 chassis, the filler panel covers
an empty module slot. On the 8010co chassis, the filler panel resembles a
module and is installed in the empty module slot. Remove any filler panels
prior to installing the chassis to make it lighter to install.
To remove a module or power filler panel:
Step Action
1Using a Phillips screwdriver, loosen the 2 screws that fasten the
filler panel to the chassis.
2Pull the panel away from the slot.
Figure 1 "Removing a filler cover for 8003, 8006, and 8010 chassis"
(page 14) shows the location of the filler cover for the 8003, 8006,
and 8010 chassis. Figure 2 "Removing a filler panel for 8010co
chassis" (page 15) shows the location of the filler panel for the
8010co chassis.
Figure 1
Removing a filler cover for 8003, 8006, and 8010 chassis
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.

Installing the 8003, 8006, or 8010 chassis into the rack 15
Figure 2
Removing a filler panel for 8010co chassis
—End—
Installing the 8003, 8006, or 8010 chassis into the rack
To install the 8003, 8006, or 8010 chassis into the rack:
Step Action
1Hold each rack-mounting bracket to the side of the chassis, aligning
the screw holes (Figure 3 "Attach rack-mounting bracket to the 8010
chassis" (page 16)).
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.

16 Installing the chassis
Figure 3
Attach rack-mounting bracket to the 8010 chassis
2Attach the bracket to the chassis with the supplied Phillips-head
screws.
CAUTION
Risk of injury
All fully loaded chassis require two people to lift. To
prevent injury, keep your back straight and lift with your
legs.
8010 chassis weighs approximately 101 kg (225 lbs)
8006 chassis weighs approximately 77 kg (170 lbs)
8003 chassis weighs approximately 49.5 kg (110 lbs)
3To insert the chassis in a standard equipment rack (19-inch), hold the
chassis in position and align the flanged end of each mounting rail
with the two holes on each side of the vertical rack support (Figure 4
"Installing the 8010 chassis in an equipment rack" (page 17)).
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.

Installing the 8010co chassis into the rack 17
Figure 4
Installing the 8010 chassis in an equipment rack
4Insert and tighten the rack-mounting screws with a Phillips
screwdriver.
—End—
Installing the 8010co chassis into the rack
The hardware required for mounting the chassis in a rack depends on
whether the rack type is a 19-inch two-post rack or a Hendry rack.
Installing the 8010co chassis in a 19-inch two-post rack
Use the 12 Phillips screws and a Phillips screwdriver to install the chassis in
a standard 19-inch two-post rack.
To install the 8010co chassis in a 19-inch two-post rack:
Step Action
1Place the installation shelf at the bottom of the rack inside the rails.
2Holding the installation shelf in position, align the shelf’s mounting
rail with the two holes on each side of the vertical rack support.
3Insert a Phillips screw through each installation shelf mounting hole
and into the corresponding hole in the rack (Figure 5 "Installing the
shelf in a 19-inch equipment rack: 8010co chassis" (page 18)).
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.

18 Installing the chassis
Figure 5
Installing the shelf in a 19-inch equipment rack: 8010co chassis
4Add a hex nut to each screw and tighten using a hex wrench.
5Tighten each screw with a Phillips screwdriver.
6If the holes in the rack’s vertical supports require clip nuts, insert a
clip nut in each of the 12 locations.
7Lift the 8010co chassis onto the installation shelf.
CAUTION
Risk of injury
It requires three people to lift the 8010co chassis. To
make the chassis lighter, remove the I/O modules and
power supplies before lifting .
8Holding the 8010co chassis in position, align the flanged end of the
chassis mounting rail with six holes on each side of the vertical rack
support.
Make sure that the hole pairs on either side of the vertical support
match horizontally.
9Tighten each screw with a Phillips screwdriver.
—End—
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.

Installing the 8010co chassis into the rack 19
Installing the 8010co chassis in a Hendry rack
Use the 12 hex-head screws and a nutdriver to install the chassis in a
Hendry rack.
To install the 8010co chassis in a Hendry rack:
Step Action
1Place the installation shelf at the bottom of the rack.
2Holding the installation shelf in position, align the shelf’s mounting
rail with two holes on each side of the vertical rack support.
3Insert a hex-head screw through each installation shelf mounting
hole and into the corresponding hole in the rack (Figure 6 "Installing
the shelf in a Hendry rack: 8010co chassis" (page 19)).
Figure 6
Installing the shelf in a Hendry rack: 8010co chassis
4Tighten each screw with a nutdriver.
5Using a Phillips screwdriver, remove the 5 screws securing each of
the two mounting rails to the 8010co chassis (Figure 7 "Removing
the mounting rails from the 8010co chassis" (page 20)).
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.

20 Installing the chassis
Figure 7
Removing the mounting rails from the 8010co chassis
6Using the 10 screws that you removed from the two mounting rails,
reinstall the mounting rails.
7If the holes in the rack’s vertical supports require clip nuts, insert a
clip nut in each of the 12 locations.
8Lift the 8010co chassis onto the installation shelf.
CAUTION
Risk of injury
It requires three people to lift the 8010co chassis. To
make the chassis lighter, remove the I/O modules and
power supplies before lifting .
9Holding the 8010co chassis in position, align the flanged end of the
chassis mounting rail with the six holes on each side of the vertical
rack support.
Make sure that the hole pairs on either side of the vertical support
match horizontally.
Nortel Ethernet Routing Switch 8600
Quick Start
NN46205-310 01.01 Standard
4.1 21 December 2006
Copyright © 2006 , Nortel Networks Nortel Networks Confidential
.
