Nortel Ethernet Routing Switch 8300
Leading enterprises are now seeking
a different approach to networking,
one that delivers increased availability,
performance, security and intelligence.
The most effective way of delivering
against these targets is to have a solution
that provides all the essential elements in
one seamless platform; enter the Ethernet
Routing Switch 8300 from Nortel.
The Ethernet Routing Switch 8300 (ERS
8300) is a chassis-based LAN Switch that
provides high-density Ethernet connec-
tivity both at the network edge (Access)
and in the Core. There are two chassis
options — a 10- and a 6-slot, each with
two slots that are reserved for the Switch
Fabric/CPU modules (minimum of one,
and maximum of two). With up to eight
slots available for I/O modules, the ERS
8300 can support up to 400 ports of
Gigabit Ethernet or 68 ports of 10
Gigabit Ethernet.
The Switch offers industry-leading
convergence-friendly features, port
density and Network Access Control
security capabilities. The ERS 8300 has
been designed to support enterprise-class
convergence deployments where relia-
bility, performance and security are of
paramount importance.
Ethernet Routing Switch 8300
Hot features
•Versatilesolutionforthemid-tier
enterprise Core or a high-performance
solution for the enterprise wiring closet
•Uniquealways-onapplicationavail-
ability delivered by Nortel’s Switch
Clustering technology
•Flexiblesolutionsenabledvia
BGP-LiteandVRF-Liteforvirtualized
IP Routing
•Simplied,automatedoptimization
of application performance via Nortel
Automatic QoS
•Delivershigh-density10G,Gigabit,
10/100 and 10/100/1000 Ethernet,
with optional Standard-based Power
over Ethernet (PoE)
•Includesintegrateduplinks—to
conserve slots and save money
•Supportslarge-scaleconvergence
deploymentsofIPtelephony,unied
communications and wireless LAN
mobility
•Offersenhancednetworksecurity
with access control and host integrity
checking via Nortel’s Secure Network
Access (SNA)

2
Chassis and Power Supplies
Order code Description
DS1402007-E5 Ethernet Routing Switch 8310 10-slot PoE Chassis.
Includes Chassis, dual Backplane, two Fan Trays,
RS232 Console Cable, Rack Mount Kit and Cable
Guide Kit.
DS1402008-E5 Ethernet Routing Switch 8306 6-slot PoE Chassis.
Includes Chassis, dual Backplane, one Fan Tray,
RS232 Console Cable, Rack Mount Kit and Cable
Guide Kit.
DS1405A14-E5 8301AC 100-240V AC Power Supply. Power
Cord ordered separately. Provides up to 800W of
PoE power.
†
DS1405*16-E5 8302AC 100-240V AC Power Supply. Use appropriate
Order Code for country-specic Power Cord. Provides
up to 400W of PoE power.
‡
DS1405011-E5 8005DC 1462W DC Power Supply.
DS1405017-E5 8005DC Dual Input 1462W DC Power Supply.
Interface Modules
Order code Description
DS1404077-E5 8348TX 48-port 10/100BASE-TX Ethernet Interface
Module.
DS1404078
DS1404078-E5
8348TX-PWR 48-port 10/100BASE-TX Power-over-
Ethernet Interface Module.
DS1404098-E5 8324FX 24-port 100BASE-FX Ethernet Interface Module.
DS1404079
DS1404079-E5
8324GT 24-port 10/100/1000BASE-T Ethernet Interface
Module.
DS1404093-E5 8348GTX 48-port 10/100/1000BASE-T Ethernet
Interface Module.
DS1404094-E5 8348GTX-PWR 48-port 10/100/1000BASE-T Power-over-
Ethernet Interface Module.
DS1404095-E5 8348GB 48-port 1000BASE-X SFP Ethernet Interface
Module.
DS1404100-E5 8308XL 8-port 10GBASE-X XFP Ethernet Interface
Module.
Ordering information
The Ethernet Routing Switch 8300 is deployed as a Chassis (10- or 6-slot), with at least one Power Supply (and up to three
8301AC, 8302AC, or 8005DC Supplies), at least one Switch Fabric/CPU Module (and up to two 8393SF or two 8394SF), and
additional Interface Modules as required.
Switch Fabric Modules
Order code Description
DS1404076-E5 Ethernet Routing Switch 8393SF Switch Fabric/
CPU module with 8-port 1000BASE-X SFP slots.
Includes PC Card Flash Memory.
DS1404118-E5 Ethernet Routing Switch 8393SF Switch Fabric/
CPU module with 8-port 1000BASE-X SFP slots.
Includes 256MB Memory, 64MB Flash and PCMCIA
Flash Memory.
DS1404099-E5 Ethernet Routing Switch 8394SF Switch Fabric/
CPU module with 2-port 10GBASE-X XFP slots.
Includes 256MB Memory, 64MB Flash and PC Card
Flash Memory.
Software
Order code Description
DS1421002-4.2 Ethernet Routing Switch 8300 Base Software
License
*
. Version 4.2.
DS1421006 Ethernet Routing Switch 8300 Advanced License
enabling BGP-Lite, DPPM, ECMP, OSPF, PIM-SM, SMLT,
RSMLT, VRRP
— one License required per Chassis.
DS1421007 Ethernet Routing Switch 8300 Advanced License
10-Pack, enabling BGP-Lite, DPPM, ECMP, OSPF, PIM-SM,
SMLT, RSMLT, VRRP
— deployable on up to 10 Chassis.
DS1421008 Ethernet Routing Switch 8300 Advanced License
50-Pack, enabling BGP-Lite, DPPM, ECMP, OSPF,
PIM-SM, SMLT, RSMLT, VRRP
— deployable on up to
50 Chassis.
DS1421009 Ethernet Routing Switch 8300 Advanced License
100-Pack, enabling BGP-Lite, DPPM, ECMP, OSPF,
PIM-SM, SMLT, RSMLT, VRRP
— deployable on up to
100 Chassis.
DS1421010 Ethernet Routing Switch 8300 Premier License
enabling VRF-Lite and Advanced Features
— one
License per Chassis.
DS1421011 Ethernet Routing Switch 8300 Premier License
10-Pack, enabling VRF-Lite and Advanced Features
—
deployable on up to 10 Chassis.
Equipment Bundles
Order code Description
DS1412013-E5 Ethernet Routing Switch 8310 Premium Chassis Bundle.
Includes 8310 10-slot Chassis (plus accessories), 2 x
8393SF Switch Fabric, 3 x 8301AC Power Supplies
(Power Cords ordered separately), plus Base SW
License.
DS1412014-E5 Ethernet Routing Switch 8310 Standard Chassis Bundle.
Includes 8310 10-slot Chassis (plus accessories), 1 x
8393SF Switch Fabric, 1 x 8301AC Power Supply (Power
Cords ordered separately), plus Base SW License.
DS1412036-E5 Ethernet Routing Switch 8310 Premium Chassis Bundle.
Includes 8310 10-slot Chassis (plus accessories), 2 x
8393SF Switch Fabric w/ 256MB, 3 x 8301AC Power
Supplies (Power Cords ordered separately), plus Base
Software License.
DS1412037-E5 Ethernet Routing Switch 8310 Standard Chassis Bundle.
Includes 8310 10-slot Chassis (plus accessories), 1 x
8393SF Switch Fabric w/ 256MB, 1 x 8301AC Power
Supply (Power Cords ordered separately), plus Base
Software License.
Order code Description
DS1421012 Ethernet Routing Switch 8300 Premier License
50-Pack, enabling VRF-Lite and Advanced Features —
deployable on up to 50 Chassis.
DS1421013 Ethernet Routing Switch 8300 Premier License
100-Pack, enabling VRF-Lite and Advanced Features
— deployable on up to 100 Chassis.
Software — continued

3
Ordering information
Pluggables Transceivers
Order code Description
AA1419013-E5 1-port 1000BASE-SX Small Form Factor Pluggable (SFP) –
Connector: LC.
AA1419048-E6 1-port 1000BASE-SX Small Form Factor Pluggable (SFP)
Digital Diagnostic Monitoring Interface (DDI) –
Connector: LC.
AA1419014-E5 1-port 1000BASE-SX Small Form Factor Pluggable (SFP) –
Connector: MT-RJ.
AA1419015-E5 1-port 1000BASE-LX Small Form Factor Pluggable (SFP) –
Connector: LC.
AA1419049-E6 1-port 1000BASE-LX Small Form Factor Pluggable (SFP)
Digital Diagnostic Monitoring Interface (DDI) –
Connector: LC.
AA1419051-E6 1-port 1000BASE-XD Small Form Factor Pluggable (SFP)
Digital Diagnostic Monitoring Interface (DDI) –
Connector: LC. 1550nm Wavelength, 40km.
AA1419052-E6 1-port 1000BASE-ZX Small Form Factor Pluggable (SFP)
Digital Diagnostic Monitoring Interface (DDI) –
Connector: LC. 1550nm Wavelength, 70km.
AA1419069-E5 1-port 1000BASE-BX Small Form Factor Pluggable (SFP)
Digital Diagnostic Monitoring Interface (DDI) – Connector:
LC. 1310nm Wavelength. Must be paired with AA1419070.
AA1419070-E5 1-port 1000BASE-BX Small Form Factor Pluggable (SFP)
Digital Diagnostic Monitoring Interface (DDI) – Connector:
LC. 1490nm Wavelength. Must be paired with AA1419069.
AA1419043-E5 1-port 1000BASE-T Small Form Factor Pluggable (SFP) —
Connector: RJ-45.
AA1419025-E5 1-port 1000BASE-CWDM Small Form Factor Pluggable
(SFP) Connector: LC. 1470nm Wavelength, 40km.
AA1419026-E5 1-port 1000BASE-CWDM Small Form Factor Pluggable
(SFP) Connector: LC. 1490nm Wavelength, 40km.
AA1419027-E5 1-port 1000BASE-CWDM Small Form Factor Pluggable
(SFP) Connector: LC. 1510nm Wavelength, 40km.
AA1419028-E5 1-port 1000BASE-CWDM Small Form Factor Pluggable
(SFP) Connector: LC. 1530nm Wavelength, 40km.
AA1419029-E5 1-port 1000BASE-CWDM Small Form Factor Pluggable
(SFP) Connector: LC. 1550nm Wavelength, 40km.
AA1419030-E5 1-port 1000BASE-CWDM Small Form Factor Pluggable
(SFP) Connector: LC. 1570nm Wavelength, 40km.
AA1419031-E5 1-port 1000BASE-CWDM Small Form Factor Pluggable
(SFP) Connector: LC. 1590nm Wavelength, 40km.
AA1419032-E5 1-port 1000BASE-CWDM Small Form Factor Pluggable
(SFP) Connector: LC. 1610nm Wavelength, 40km.
AA1419033-E5 1-port 1000BASE-CWDM Small Form Factor Pluggable
(SFP) Connector: LC. 1470nm Wavelength, 70km.
AA1419034-E5 1-port 1000BASE-CWDM Small Form Factor Pluggable
(SFP) Connector: LC. 1490nm Wavelength, 70km.
AA1419035-E5 1-port 1000BASE-CWDM Small Form Factor Pluggable
(SFP) Connector: LC. 1510nm Wavelength, 70km.
AA1419036-E5 1-port 1000BASE-CWDM Small Form Factor Pluggable
(SFP) Connector: LC. 1530nm Wavelength, 70km.
AA1419037-E5 1-port 1000BASE-CWDM Small Form Factor Pluggable
(SFP) Connector: LC. 1550nm Wavelength, 70km.
AA1419038-E5 1-port 1000BASE-CWDM Small Form Factor Pluggable
(SFP) Connector: LC. 1570nm Wavelength, 70km.
AA1419039-E5 1-port 1000BASE-CWDM Small Form Factor Pluggable
(SFP) Connector: LC. 1590nm Wavelength, 70km.
AA1419040-E5 1-port 1000BASE-CWDM Small Form Factor Pluggable
(SFP) Connector: LC. 1610nm Wavelength, 70km.
Order code Description
AA1403005-E5 1-port 10GBASE-SR XFP Pluggable — Connector: LC.
For distances of up to 300m over MMF.
AA1403007-E5 1-port 10GBASE-LRM XFP Pluggable — Connector: LC.
For distances of up to 220m over MMF.
AA1403001-E5 1-port 10GBASE-LR XFP Pluggable — Connector: LC.
For distances of up to 10km over SMF.
AA1403003-E5 1-port 10GBASE-ER XFP 40km Pluggable — Connector: LC.
For distances of up to 40km over SMF.
AA1403006-E5 1-port 10GBASE-ZR XFP 80km Pluggable — Connector: LC.
For distances of up to 80km over SMF.
Power Cords (Plug type: IEC-60320-C19)
Order code Description
AA0020049-E6 Power Cord 20A/125V NEMA 5-20, North America.
AA0020050-E6 Power Cord 15A/250V NEMA 6-15, North America.
AA0020051-E6 Power Cord 16A/250V CEE7/7, Continental Europe.
AA0020052-E6 Power Cord 16A/250V CEI 23-50 S17, Italy.
AA0020053-E6 Power Cord 16A/250V SI 32, Israel.
AA0020054-E6 Power Cord 15A/250V BS-546, India / South Africa.
AA0020055-E6 Power Cord 16A/230V 3-Pin IEC60309, International.
AA0020056-E6 Power Cord 20A/250V NEMA L6-20 Twist Lock, North
America.
AA0020057-E6 Power Cord 15A/250V AS 3112, Australia.
AA0020058-E6 Power Cord 13A/230V BS 1362, UK & Ireland.
AA0020059-E6 Power Cord 16A/250V GB 11918-89, Greater China.
AA0020060-E6 Power Cord 15A/250V NEMA L6-15 Twist Lock, North
America. This Power Cord is used with the 8005AC &
8301AC in 220-240V AC twist-lock applications.
Notes
†8301AC Power Supply utilizes the IEC 60320 C19 Socket type and requires Power
Cords ordered from the list above.
‡8302AC Power Supply utilizes the IEC 60320 C13 Socket type and accepts standard
country-specic Power Cords. The seventh character (*) of the Order Code is replaced
to indicate the required product nationalization:
“A” — No Power Cord option
“B” — Includes European “Schuko” Power Cord option, common in Austria, Belgium,
Finland, France, Germany, Netherlands, Norway and Sweden
“C” — Includes Power Cord used in UK and Ireland
“D” — Includes Power Cord used in Japan
“E” — Includes Power Cord used in North America
“F” — Includes Power Cord used in Australia, New Zealand and People’s Republic
of China
*8300 Base Software License includes Software License, Device Manager and
complete software documentation set. Support Contracts to be purchased separately.
General Note: Product Codes with the “-E5” or “-E6” sufx denote products
compliant with the European Union’s Environmental Directive on the Restriction of
Hazardous Substances (RoHS). Going forward, products will generally be produced as
RoHS-compliant, making the one item deployable worldwide.
Pluggables Transceivers — continued

BUSINESS MADE SIMPLE
In the United States:
Nortel
35 Davis Drive
Research Triangle Park, NC 27709 USA
In Canada:
Nortel
195 The West Mall
Toronto, Ontario M9C 5K1 Canada
VisitNortelontheWebatwww.nortel.com. For the latest Nortel news, visit www.nortel.com/news.
For more information, contact your Nortel representative, or call 1-800-4 NORTEL or 1-800-466-7835 from anywhere
in North America.
Nortel, the Nortel logo, Nortel Business Made Simple and the Globemark are trademarks of Nortel Networks. All other
trademarks are the property of their owners.
Copyright © 2009 Nortel Networks. All rights reserved. Information in this document is subject to change without notice.
Nortel assumes no responsibility for any errors that may appear in this document.
NN123190-021809
Interfaces/Interface modules
• 48-port10/100BASE-TModule
• 48-port10/100BASE-Twith802.3afPower-over-EthernetModule
• 24-port100BASE-FXModule
• 24-port10/100/1000BASE-TModule
• 48-port10/100/1000BASE-TModule
• 48-port10/100/1000BASE-Twith802.3afPower-over-EthernetModule
• 48-port1000BASE-XSFPModule
• 8-port10GBASE-XXFPModule
• 8393SFSwitchFabricModulewithintegrated8-port1000BASE-XSFP
• 8394SFSwitchFabricModulewithintegrated2-port10GBASE-XXFP
Performance specications
• Switcharchitecture:720Gbpsgrossthroughput
• SwitchFabricperformance:upto464Gbps(upto416Gbpswith
8393SF)
• Frameforwardingrate:upto345Mpps(upto310Mppswith8393SF)
• Framelength:64to1518Bytes(802.1QUntagged),64to1522bytes
(802.1Q Tagged)
• JumboFramesupport:upto9,000Bytes(802.1QTagged)
• Multi-LinkTrunks:upto31Groups,with8LinksperGroup
• VLANs:upto2,000Port-orProtocol-based(withperVLANTagging
option)
• MultipleSpanningTreeGroups:upto64
• VRF-Liteinstances:upto128
• ECMPRoutes:upto4
• BGPPeers:upto4
Network protocol and standards compatibility
• IEEE802.1DMACBridges(SpanningTreeProtocol)
• IEEE802.1pTrafcClassExpediting
• IEEE802.1QVirtualLANs
• IEEE802.1sMultipleSpanningTrees
• IEEE802.1wRapidRecongurationofSpanningTree
• IEEE802.1XPortBasedNetworkAccessControl(Extensible
Authentication Protocol)
• IEEE802.1ABStation&MediaAccessControlConnectivityDiscovery
(LLDP)
• IEEE802.310BASE-T(ISO/IEC8802-3,Clause14)
• IEEE802.3u100BASE-T(ISO/IEC8802-3,Clause25)
• IEEE802.3uAuto-NegotiationonTwistedPair(ISO/IEC8802-3,
Clause 28)
• IEEE802.3x100Mb/sFullDuplexOperation
• IEEE802.3zGigabitEthernet(1000BASE-X)
• IEEE802.3ab1000BASE-T
• IEEE802.3adLinkAggregationControlProtocol
• IEEE802.3ae10Gb/sEthernet(10GBASE-X)
RFC support
• RFC768UserDatagramProtocol
• RFC783TrivialFileTransferProtocolv2
• RFC791InternetProtocol
• RFC792InternetControlMessageProtocol
• RFC793TransmissionControlProtocol
• RFC826EthernetAddressResolutionProtocol
• RFC854TelnetProtocol
• RFC894TransmissionofIPoverEthernet
• RFC903ReverseAddressResolutionProtocol
• RFC950InternetStandardSubnettingProcedure
• RFC1027ARPtoImplementTransparentSubnetGateways
• RFC1058RoutingInformationProtocol
• RFC1112HostExtensionsforIPMulticasting
• RFC1122RequirementsforInternetHosts--CommunicationLayers
(Partial Support)
• RFC1155Structure&IdenticationofManagementInformationfor
TCP/IP-based Internets
• RFC1157SimpleNetworkManagementProtocol
• RFC1213TCP/IPMIB-II
• RFC1215ConventionforDeningTrapsforusewiththeSNMP
• RFC1256ICMPRouterDiscoveryMessages
• RFC1305NetworkTimeProtocolv3–Specication,
Implementation and Analysis
• RFC1493BridgeMIB
• RFC1519ClasslessInter-DomainRouting(CIDR)
• RFC1541DynamicHostCongurationProtocol
• RFC1542BootstrapProtocol(ClaricationsandExtensions)
• RFC1587OSPFNot-So-Stubby-AreaOption
• RFC1591DomainNameSystem
• RFC1643DenitionsofManagedObjectsfortheEthernet-like
Interface Types
• RFC1657DenitionsofManagedObjectsforBorderGateway
Protocol (BGP-4) using SMIv2
• RFC1723RIPv2CarryingAdditionalInformation(PartialSupport)
• RFC1724RIPv2MIBExtension
• RFC1757RemoteNetworkMonitoringMIB
• RFC1771BorderGatewayProtocol4(BGP-4)
• RFC1812IPv4RouterRequirements
• RFC1850OSPFv2MIB
• RFC1866HyperTextMarkupLanguagev2
• RFC1907ManagementInformationBaseforSNMPv2
• RFC2021RemoteNetworkMonitoringMIBv2usingSMIv2
• RFC2068HyperTextTransferProtocolv1.1
• RFC2096IPForwardingTableMIB
• RFC2138RADIUSAuthentication
• RFC2139RADIUSAccounting
• RFC2236InternetGroupManagementProtocolv2
• RFC2328OpenShortestPathFirstv2
• RFC2338VirtualRouterRedundancyProtocol
• RFC2362ProtocolIndependentMulticast—SparseMode
• RFC2375IPv6MulticastAddressAssignments
• RFC2453RoutingInformationProtocolv2
• RFC2460InternetProtocolVersion6
• RFC2465MIBforIPv6:TextualConventionsandGeneralGroup
• RFC2474DifferentiatedServicesinIPv4andIPv6
• RFC2475DifferentiatedServices
• RFC2570SimpleNetworkManagementProtocolv3
• RFC2571SNMPFrameworks
• RFC2572SNMPMessageProcessingandDispatching
• RFC2573SNMPv3Applications
• RFC2574SNMPv3User-basedSecurityModel
• RFC2575SNMPv3View-basedAccessControlModel
• RFC2576SNMPv1,v2,&v3ofInternetNetworkManagement
Framework
• RFC2597AssuredForwardingPHBGroup
• RFC2598ExpeditedForwardingPHB
• RFC2665EthernetMIB
• RFC2674ManagedObjectsforBridgeswithTrafcClasses,
MulticastFiltering&VLANExtensions
• RFC2737EntityMIBv2
• RFC2787VRRPMIB
• RFC2819RMONMIB
• RFC2851TextualConventionsforInternetNetworkAddresses
• RFC2863InterfacesGroupMIB
• RFC2865RemoteAuthenticationDialInUserService(RADIUS)
• RFC2866RADIUSAccounting
• RFC2932IPv4MulticastRoutingMIB(PartialSupport)
• RFC2933InternetGroupManagementProtocolMIB
• RFC2934ProtocolIndependentMulticastMIBforIPv4(Partial
Support)
• RFC2992AnalysisofanEqual-CostMulti-PathAlgorithm
• RFC3101TheOSPFNot-So-StubbyArea(NSSA)Option
• RFC3826AdvancedEncryptionStandardCipherAlgorithminthe
SNMP User-based Security Model
Physical specications
Ethernet Routing Switch 8306
• Height:15.8in.(40.1cm)—10U/RU
• Width:17.5in.(44.5cm)
• Depth:19.9in.(50.5cm)
• Weight(empty):49lb(22kg)
• Weight(fullyloaded):140lb(63kg)
• CoolingSystem:
–FanTrays:1perChassis
–Fans:6perFanTray
–ThermalSensors:1perFanTray
Ethernet Routing Switch 8310 — 14U/RU
• Height:22.9in.(58.2cm)
• Width:17.5in.(44.5cm)
• Depth:19.9in.(50.5cm)
• Weight(empty):85lb(39kg)
• Weight(fullyloaded):225lb(102kg)
• CoolingSystem:
–FanTrays:2perChassis
–Fans:8perFanTray
–ThermalSensors:1perFanTray
Environmental Specications
• Operatingtemperature:0°Cto40°C(32°Fto104°F)
• Storagetemperature:-25°Cto70°C(-13°Fto158°F)
• Operatinghumidity:85%maximumrelativehumidity,
non-condensing
• Storagehumidity:95%maximumrelativehumidity,
non-condensing
• Operatingaltitude:3,048m(10,000ft)maximum
• Storagealtitude:3,048m(10,000ft)maximum
• FreeFall/Drop:ISO4180-s,NSTA1A
• Vibration:IEC68-2-6/34
• Shock/Bump:IEC68-2-27-29
Electromagnetic summary
• GlobalbasicforCertication:CISPR22-1997ClassA
• S:FCCCFR47,Part15SubpartB,ClassA
• Canada:ICES-003,Issue-2,ClassA
• Europe:EN55022-1998ClassA,EN61000-3-2/A14,
EN 61000-3-3 (CE Marking)
• Australia/NewZealand:NZS3548:1995,ClassA
• Japan:VCCI-V3/97.04,ClassA
• Taiwan:CNS13438,ClassA
Electromagnetic emissions
• ElectromagneticImmunity
• GlobalbasisforCertication:CISPR24:1997
• Europe:EN50024:1998
Safety regulatory
• GlobalbasisforCertication:IEC60950currentEdition
with all CB Member deviations
• US:UL60950
• Canada:CSA22.2No.60950
• Europe:EN60950(CEMarking)
• Australia/NewZealand:AS/NZS3260
• Mexico:NOM-019-SCFI-1998
Technical specications
