NORTHROP GRUMMAN IR Patara Laser System User manual

Pre-Installation Guide
IR Patara Laser System
MAY 2017
CEO-UMAN-0065A

© 2017 Cutting Edge Optronics, Inc. ii IR Patara Laser Pre-Installation Guide
Worldwide Technical Support and Product Information
http://www.northropgrumman.com/BusinessVentures/CEO/Pages/Service.aspx
http://www.ngceoservice.com/ (Knowledge Center)
Hours: 8:00 a.m. to 5:00 p.m., Central time*
Service and Technical Support: [phone] (follow prompts for department directory)
Email: [e-mail]
Cutting Edge Optronics Headquarters
20 Point West Blvd. St. Charles, MO 63301 USA
Sales Support: [phone] (follow prompts for department directory)
*After office hours, please leave a voice mail message. Outside North America, contact a Cutting Edge Optronics sales office or distributor;
see the Cutting Edge Optronics website for a list of offices.

© 2017 Cutting Edge Optronics, Inc. iii IR Patara Laser Pre-Installation Guide
Important Information
Copyright
Under the copyright laws, this publication may not be reproduced or transmitted in any form, electronic or mechanical,
including photocopying, recording, storing in an information retrieval system, or translating, in whole or in part, without the
prior written consent of NG CEO.
Patents
Northrop Grumman Corporation products are covered by U.S. and foreign patents, issued and pending. Information in this
publication supersedes that in all previously published material. Specifications and price change privileges reserved.

© 2017 Cutting Edge Optronics, Inc. iv IR Patara Laser Pre-Installation Guide
Safety Information
Product End-of-Life Handling
NG CEO is committed to protecting the environment. In accordance with the Waste
Electrical and Electronic Equipment directive (WEEE) and Restriction of Hazardous
Substances in the European Union (RoHS EU) directives, NG CEO accepts the return of
our products for disposal. When you are ready to reclaim the instrument, you must properly
transfer it according to local regulations concerning WEEE equipment. Contact NG CEO
or your local distributor for shipping instructions. Please package the products as directed
for a return for repair.
ROC ROHS Declaration
In accordance with the Clause 6.2 of Marking for Control of Pollution Caused by
Electronic Information Products (SJ/T11364:2006) for Measures for the Administration
on Pollution Control of Electronic Information Products No. 39, Order of the Ministry of
Information Industry of the Peoples Republic of China, NG CEO includes the following
translation about our laser modules.

© 2017 Cutting Edge Optronics, Inc. v IR Patara Laser Pre-Installation Guide
Conventions
The following conventions appear in this manual:
This icon denotes a caution or a warning, which advise you of precautions to take
to avoid injury, data loss, or a system crash.
italic
Italic text denotes references to other resources that may be helpful to you or to
bring attention to important information.
This icon denotes a note, which alerts you to important information.
I
O
Power Switch Position Symbols
I = On O = Off
The following conventions may appear on the product:
DANGER
An injury hazard immediately accessible as you read the marking.
WARNING
A hazard not immediately accessible as you read the marking.
CAUTION
A hazard to property including the product.
ESD: Handle Appropriately
Laser Emission: Use caution.
Shock Hazard: Use caution.

© 2017 Cutting Edge Optronics, Inc. vi IR Patara Laser Pre-Installation Guide
Caution: Risk of danger. Refer to manual.
Chassis Ground
General Safety Summary
The Patara Laser System emits laser radiation that can permanently damage eyes and
skin, ignite fires, and vaporize materials.
Do not attempt to operate the laser system before carefully reading the complete
operation manual provided with the product. If you have any questions on the product
that have not been discussed sufficiently the manual, contact the manufacturer for
complete instructions. Failure to heed this warning may result in the destruction or
serious damage to the device, and will void the product warranty.

© 2017 Cutting Edge Optronics, Inc. vii IR Patara Laser Pre-Installation Guide
About This Guide
This document is to provide information necessary for smooth installation/integration of
the Patara Laser System with the eDrive Nitro Laser Controller. The Guide consists of
the following chapters:
Chapter 1: eDrive Dimensions, Power Requirement and Mounting describes details of
the eDrive Nitro
Chapter 2: Laser Head Dimensions, Beam Height, and Mounting Requirements describes
details of the Patara laser head
Chapter 3: Chiller and Coolant provides information about plumbing the Patara Laser
System.
Chapter 4: Facility Summary provides information on required utilities, laser operation
considerations, and suggested supplies.

Table of Contents
© 2017 Cutting Edge Optronics, Inc. viii IR Patara Laser Pre-Installation Guide
Table of Contents
Chapter 1: eDrive Dimensions, Power Requirement and Mounting 1
eDrive Dimensions 2
Input Power 2
Rack Mounting 3
Clearance 3
Weight 3
Chapter 2: Laser Head Dimensions, Beam Height, and Mounting Requirements 4
Laser head dimensions 5
Beam height 8
Mounting requirement 8
Weight 8
Chapter 3: Chiller and Coolant 9
Chiller Plumbing 10
CEO Supplied Hardware 10
Suggested Chiller Models 10
Chapter 4: Facility Summary 12
eDrive Facility Requirements 13
Chiller Facility Requirements 13
Precautions for Safe Operation 13
Suggested Supplies and Equipment 14

List of Figures and Tables
© 2017 Cutting Edge Optronics, Inc. ix IR Patara Laser Pre-Installation Guide
List of Figures and Tables
Figure 1-1 Dimensions of eDrive Nitro for Patara Laser 2
Table 1-1 Recommended Fuse Ratings 3
Figure 2-1 Patara Laser Head Dimensions, Sheet 1 6
Figure 2-2 Patara Laser Head Dimensions, Sheet 2 7
Figure 3-1 Chiller Plumbing 10

1
© 2017 Cutting Edge Optronics, Inc. 1 Patara-IR TEM00 Laser Pre-Installation Guide
Chapter 1: eDrive Dimensions, Power Requirement
and Mounting
This chapter provides the following information:
eDrive Dimensions
Input Power
Rack Mounting
Clearance
Weight

Chapter 1: eDrive Dimensions, Power Requirement, and Mounting
© 2017 Cutting Edge Optronics, Inc. 2 Patara-IR TEM00 Laser Pre-Installation Guide
eDrive Dimensions
Figure 1-1 Dimensions of eDrive Nitro for Patara Laser
Input Power
Use only power cords suitable for your driver. Use a power source that delivers power in
the range of 100 to 240 VAC-RMS, 47 to 63 Hz. Power switching is done automatically;

Chapter 1: eDrive Dimensions, Power Requirement, and Mounting
© 2017 Cutting Edge Optronics, Inc. 3 Patara-IR TEM00 Laser Pre-Installation Guide
there are no configuration switches to set for high or low power ranging. Table 1-1 lists
the recommended fuse selection for each voltage range.
Table 1-1 Recommended Fuse Ratings
AC Input
Frequency
Fuse Ratings
(F1, F2)
120V ±10%
15A
50/60 Hz
T 15A 250V
240V ±10%
8A
50/60 Hz
T 8A 250V
Fuse Dimensions: 0.25 x 1.25 inches
Rack Mounting
When installing the eDrive Nitro into an EIA-310D-compliant rack, always install rack
mounting screws into the two bottom holes of the front panel flanges first and then install
screws into the top holes. This will help to minimize any potential damage that might
occur to the eDrive front panel if the driver were to shift during installation.
For the eDrive Nitro, it is recommended that two people install the unit into a rack.
Supporting rails should be used. Lift the driver into place and then fasten the front panel
flanges into place.
WARNING. Using the eDrive Nitro without mounting rails can result in serious damage
to the driver or personal injury.
Clearance
Adequate clearance should be allowed on the front, sides, and rear of the eDrive for
access to connections and components. The front and rear vents of the eDrive must be a
minimum of 24 inches (61 cm) away from walls or vertical surfaces so air flow is not
restricted.
Weight
The total weight of eDrive Nitro for Patara laser is approximately 52 pounds (23.6kgs).

2
© 2017 Cutting Edge Optronics, Inc. 4 Patara-IR TEM00 Laser Pre-Installation Guide
Chapter 2: Laser Head Dimensions, Beam Height, and
Mounting Requirements
This chapter provides the following information:
Laser Head Dimensions
Beam Height
Mounting Requirement
Clearance
Weight

Chapter 2: Laser Head Dimensions, Beam Height, and Mounting Requirements
© 2017 Cutting Edge Optronics, Inc. 5 Patara-IR TEM00 Laser Pre-Installation Guide
Laser head dimensions
The detailed dimensions of the Patara laser are shown in Figure 2-1 and 2-2. The laser
head has dimensions of 26 inch (L) x 11 inch (W) x 6.13 inch (H).

Chapter 2: Laser Head Dimensions, Beam Height, and Mounting Requirements
© 2017 Cutting Edge Optronics, Inc. 6 Patara-IR TEM00 Laser Pre-Installation Guide
Figure 2-1 Patara Laser Head Dimensions, Sheet 1

Chapter 2: Laser Head Dimensions, Beam Height, and Mounting Requirements
© 2017 Cutting Edge Optronics, Inc. 7 Patara-IR TEM00 Laser Pre-Installation Guide
Figure 2-2 Patara Laser Head Dimensions, Sheet 2

Chapter 2: Laser Head Dimensions, Beam Height, and Mounting Requirements
© 2017 Cutting Edge Optronics, Inc. 8 Patara-IR TEM00 Laser Pre-Installation Guide
Beam height
The beam height of the Patara laser is 3 inches.
Mounting requirement
The laser has to be mounted on a flat optical table or equivalent bench. There are three
mounting holes that are 0.28 inches (7.1mm) in diameter. Two mounting holes are
located at the back of the laser head and one at the front. There are holes designed for
0.25 inch dowel pins to confine the position of the laser head. These are on the center line
of the laser head: see Figure 2-2.
Weight
The weight of the laser head is approximately 35 pounds (15.9kgs).

3
© 2017 Cutting Edge Optronics, Inc. 9 Patara-IR TEM00 Laser Pre-Installation Guide
Chapter 3: Chiller
This chapter provides the following information:
Chiller Plumbing
Standard NG CEO Supplied Hardware
Suggested Chiller Models

Chapter 3: Chiller and Coolant
© 2017 Cutting Edge Optronics, Inc. 10 Patara-IR TEM00 Laser Pre-Installation Guide
Chiller Plumbing
Plumbing for the Patara laser is described in Figure 3-1.
CHILLER
COOLANT:
OPTISHIELD® Plus ½ NPT
to 3/8
barb 3/8 reinforced
Hose (~8')
INLET
FROM
“LASER
COOLANT
OUT”
CAPACITY
~1.1 U.S. gallons
¾ NPT
to 3/8
barb
¾ NPT
to 3/8
barb
½ NPT
to 3/8
barb 3/8 reinforced
Hose (~18") 3/8 reinforced
Hose (~6')
OUTLET TO
“LASER
COOLANT
IN”
Figure 3-1 Chiller Plumbing
Standard NG CEO Supplied Hardware
1. Patara Laser head
2. eDrive
3. Chiller
4. Laser signal cable- Length 7 ft. (2.1 meters)
5. Diode power cable- Length 7 ft. (2.1 meters)
6. Plumbing Kit, including hoses and filter for chiller- Length 8 ft (2.4 meters)
7. Hose length may be modified to suit facility requirements
8. Power Cord for Chiller
9. Power Cord for eDrive
Suggested Chiller Models
NG CEO has used Polyscience chillers for long time. Other chillers with similar
specifications may be used. The customer may decide to buy a chiller through NG CEO
or purchase directly from the third party. When supplied by NG CEO, the following
models are specified for use with the Patara-IR TEM00 laser.

Chapter 3: Chiller and Coolant
© 2017 Cutting Edge Optronics, Inc. 11 Patara-IR TEM00 Laser Pre-Installation Guide
Table 3-1 Polyscience Chiller Specifications
Model Number
Input Power
Frequency
Nominal Rated
Amps
Dimensions
Weight
6362T31CE20C1
120V single
phase
60 Hz
13.5A
22 5/8 x 14 1/2 x
27 5/8 inch
156 Lbs
(71 kg)
6352T41CE30E1
208-230V
single phase
50/60 Hz
7.6A
22 5/8 x 14 1/2 x
27 5/8 inch
156 Lbs
(71 kg)
1Chiller models are air-cooled and feature a 1/3 HP compressor, stainless steel turbine pump and internal heating
element
