Lightweight Wheeled Walker User Guide
pressure care and patient handling specialists
novis.com.au /1300 738 885
LightweightIndoor/OutdoorWheeledWalker
USER GUIDE
2
Overview
Intended Use
Important Notice
The Lightweight Indoor/Outdoor Wheeled Walker is designed for generalindoor and outdoor use with a
lightweight aluminium frame and 8inch (200 mm) wheels for easy operation and manoeuvrability on smooth
surfaces. The moulded handgrips with soft touch brakes are ideal for people with limited strength or mobility.
Handle height can easily be adjusted, with an overall extension range of 784 - 895 mm.
Includes the added convenience of a removable shopping bag and a water resistant PVC seat for improved
infection control and easier cleaning.
This wheeled walker is designed primarily for
general indoor and outdoor use as a walking
aid and a temporary seat. If used outside, it is
recommended for smooth or sealed surfaces.
It is not designed to be used as a wheelchair.
The maximum occupant weight is 136 kilograms,
as stated on the manufacturer’s label. The
wheeled walker should only be used and
maintained in accordance with the instructions in
this User Guide.
Before operating this medical equipment, it is
important to read this manual and understand
the operating instructions and safety
precautions. Failure to do so could result in
patient injury and/or damage to the product.
Therapeutic devices and/or medical equipment
should only be used in accordance with
manufacturer’s instructions and under the
consent, supervision and management of a
suitably qualied health professional.
Denition of Symbols Used
Important information
Caution
Electrical hazard
Infection control
Do not...
Class II equipment
Type B Applied part
Novis Healthcare has a policy of continuous
product improvement and reserves the right to
amend specications presented in this guide.
Information correct at time of production
(July 2020) .
© 2016 Novis Healthcare. All rights reserved
Gated user access
ensures your information
is secure
3
Lightweight Wheeled Walker User Guide
Index
Backrest
Handle with lever brake
Heat sealed PVC seat
Lightweight aluminium frame
Break cable
Shopping bag
8 inch (200 mm) wheels
Overview 2
Index 3
Set Up 4
Operation 6
Transportation and Storage 7
Safety and Maintenance 8
Cleaning and Specications 9
Warranty 10
4
Set Up
Box Contents and Inspection
Unfold the Wheeled Walker
Insert and Adjust Handle Height
Carefully remove all components from the box and
check items against the list below. Any damaged
or missing component should be reported to your
authorised dealer or manufacturer.
Prior to use, remove all packaging and plastic wrapping
and check the wheeled walker for any damage that may
have occurred in transit, paying particular attention to:
Any damage to the wheels, handles or frame.
Damage to the seat or backrest.
Any missing or loose screws or wheelnuts
Remove the protective covering from all four wheels.
Remove any protective wrapping and cardboard from
frame.
Place the wheeled walker on a stable surface.
Unfold by spreading the frame while pushing down
on the side braces, making sure each brace locks
horizontally in place.
Insert the handles into the tubes at the top of the frame,
with the brake cable on the outside of the frame.
Align handle and frame holes at the ideal height, and
then insert the bolt (from inside the frame) and push
until fully inserted. Ensure the bolt head ts securely
within the hexagonal frame hole.
Place washer on bolt (curved face against frame), screw
on the Star Knob and tighten rmly. Please note, the Star
Knob should be on the outside of the frame.
*Image for illustration purposes only.
*Image for illustration purposes only.
*Image for illustration purposes only.
Shopping Bag
5
Lightweight Wheeled Walker User Guide
Ideal Handle Height
A series of holes are placed 25 mm apart along the
handle, allowing handle height to be adjusted to suit
the user. Ideal handle height is set when the top of the
handle aligns with the user’s wrist.
Set Up
Insert the Backrest
Check Brake Function
Place the padded backrest into the bracketson the top
rear of the frame. Press buttons on backrest to click into
place.
Check the brake cables are running outside the frame
and adjust the cable guides to store cables neatly
against the frame.
Make sure the brakes are working properly before using
the wheeled walker (refer to page 6 “Operating the
brakes” for a description of brake function)
6
Operation
Using as a Walking Aid
Operating the Brakes
Using as a Temporar y Seat
When using the wheeled walker as a walking aid, it
is recommended both hands be placed rmly on the
handles, with ngers curled around the brake levers so
that the walker can be stopped
immediately in case of an emergency.
The ideal walking technique is to push the walker
forward to a comfortable arm’s length, then step in
towards the walker, and repeat.
To stop the wheeled walker, gently squeeze the brake
levers until the walker comes to a complete stop.
The brakes should be locked (park brake function)
whenever using the walker as a temporary seat, or when
leaving the walker unattended.
To lock the brakes, push down on the brake levers until
they click. Always check the brake lock is activated
before sitting on the seat.
To release the brake lock, pull up on the brake lever until
the lock disengages. Never release the brake lock while
sitting on the seat.
Before using the wheeled walker as a temporary seat,
ensure the wheeled walker is parked on a safe, level
surface. Before sitting, lock both brake levers and
ensure the lock is properly activated or
serious injury may result.
Brake On
Park Brake On
7
Lightweight Wheeled Walker User Guide
Transportation and Storage
Removing the Bag
The bag can be removed for cleaning or when attaching
specic accessories such as an Oxygen Bottle Carrier.
To remove the bag, undo the button clips located on
each side and the underneath of the shopping bag. Once
all clips are undone, the seat can be lifted up and the bag
can then be pulled free. Reverse this process to reinstall
the shopping bag.
Folding the Wheeled Walker
To fold the wheeled walker for storage or transport, lift
up the seat and pull up rmly on the strap located at the
base of the bag. This will disengage the side braces
and collapse the frame. Pushthe frame together for a
compact fold. For more compact storage, both handles
can also be removed. Simply unscrew both Star Knobs,
and remove the washers and boltsbefore sliding the
handles out of the frame.
*Image for illustration purposes only.
8
Safety and Maintenance
General Safety Precautions
Do not use the wheeled walker to transport a
person while seated.
A risk assessment should always be carried out to
ensure the product is suitable.
Before use, the user should read these instructions and
familiarise themselves with the wheeled walker.
Ensure all components are properly and securely
installed.
Ensure the user has sucient strength to safely operate
and control the wheeled walker and hand brakes.
Before sitting on the wheeled walker ensure the brake
locks are rmly applied.
Do not release brakes until user is standing.
Do not exceed the maximum recommended working
load.
Avoid storing the wheeled walker in direct sunlight; seat
or parts exposed to sunlight will heat up and may cause
injury to the skin.
Do not place more than 4.5 kilograms of shopping or
other items into the designated shopping bag.
When seated, do not attempt to reach for objects
by leaning forward on the seat or by reaching down
between your knees. Do not lean over the backrest to
reach objects behind you as this may cause the wheeled
walker to tip over.
Use only on designated footpaths or walkways; do not
use on roads, streets or highways.
Do not use the wheeled walker on any incline greater
than 9 degrees, or on a slope with water, ice or snow
covering.
Use caution when traversing kerbs or obstacles as this
may cause the wheeled walker to tip over and cause
harm or damage to the walker or the user.
Keep a safe distance between moving and stationary
parts, it may cause injuries.
Professional inspection of the wheeled walker is
recommended at least once a year.
Any service or repairs, especially to the brakes,
must be performed by a trained professional.
Any unauthorised repairs or service may void your
warranty.
Regularly check the wheeled walker for damage
and wear, paying special attention to the workings
of the brakes and the condition of the wheels. If the
wheeled walker is damaged in any way, stop using
the wheeled walker immediately and contact your
authorised dealer or the manufacturer.
Check handle grips do not twist on the handles.
Check the brake levers are rm; if loose or worn they
must be replaced before use.
Check the eciency of the braking system to ensure
rear wheels do not move when the brakes are
engaged or locked.
With brakes released, there should be no drag on the
wheels and the wheeled walker should move easily.
If you notice an unfamiliar braking sensation or
any abnormalities, stop using the wheeled walker
immediately and contact your authorised dealer or
the manufacturer.
Check all screws and wheelnuts are rmly secured.
Regular Maintenance
9
Lightweight Wheeled Walker User Guide
Cleaning
Do not use high pressure cleaners, steam
cleaners or harsh, caustic chemicals for
cleaning.
Cleaning and Specications
Specications
Frame
Wipe the wheeled walker frame with a damp cloth.
For more stubborn dirt, use a mild detergent solution up
to 40 °C. Dry thoroughly before useto avoid corrosion.
Clean the wheels using a damp brush with plastic
bristles (do not use a wire brush or you may damage
the rubber or painted nish).
Bag and seat
Regularly clean the padding materials using a mild
detergent solution up to 40°C, or wash with alcohol-
based disinfectants if necessary.
Dry thoroughly before use.
NAME Lightweight Indoor/
Outdoor Wheeled Walker
CODE BL0060
COLOUR Red
PRODUCT WEIGHT 7.5 kg
OVERALL HEIGHT 784 > 895mm
OVERALL WIDTH 606 mm
OVERALL DEPTH 704 mm
SEAT HEIGHT 540 mm
SEAT WIDTH 345 mm
SEAT DEPTH 31.5 mm
WHEELS 8” (200 mm)
FRAME Aluminum
SAFE WORKING LOAD 136 kg
ARTG 176830
WARRANTY 1 Year
10
Warranty
This warranty is provided by
Novis Healthcare (ABN 45 102 735 491)
of Unit 11/12 Mars Road Lane Cove West
New South Wales 2066.
Novis Healthcare (Novis) products
are manufactured to the highest
quality standards and are thoroughly
tested and inspected before
leaving our factory. In addition to
any statutory rights and remedies
you may have, Novis warrants all of
its products sold directly or via an
Authorised Novis Australia Dealer
against defective workmanship and
faulty materials from the date of
purchase by the end user for a period
of twelve months unless otherwise
specied for that product and its
components.
11
Lightweight Wheeled Walker User Guide
Warranty Claims
To claim under this warranty, please contact
Novis Healthcare and have your receipt or proof of
purchase available. Novis Healthcare may need to
assess the defect before determining any claim, and
additional information may be requested to process
your claim. Claims without proof of purchase may
not be able to be processed.
Novis Healthcare may at its option inspect the goods
on site or require them to be returned to itspremises
or one of its Authorised Service Agents in person or
freight prepaid by you.
Novis will undertake at its option, to repair or replace,
free of charge, each product or part thereof on the
condition that:
The product found on examination, to be suffering
from a manufacturing defect;
The product or relevant part has been serviced
regularly by Novis or one of its Authorised Service
Agents and has not been subjected to misuse,
neglect or been involved in an accident;
The repairs are not required as part of normal wear
and tear.
At our option
Goods repaired may be replaced by refurbished good
of the same type rather than being repaired.
Refurbished parts may be used to repair goods.
Novis Healthcare will not be held responsible for any
repair other than those carried out by it or one of its
Authorised Service Agents.
Warranty repairs do not extend the length of the
warranty period.
Our liability under this manufacturer’s warranty
is subject to us being satised that a defect
was caused by faulty parts, manufacture or
workmanship, and was not caused or substantially
contributed to by other factors or circumstances
beyond our control, including (but not limited
to) defective installation, maintenance or repair,
product modication or alteration, any neglect,
misuse, or excessive use, normal wear and tear or
failure to follow manufacturer’s instructions.
Our goods come with guarantees thatcannot be
excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a
major failure and for compensation for any other
reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major
failure.To obtain compensation, you will need
to provided documentary evidence of the loss
or damage suffered and documentary evidence
that such loss or damage was a reasonable
foreseeable consequence of a failure Novis
Healthcare to comply with a consumer guarantee
under the Australian Consumer Law. Subject to
the provisions of the Australian Consumer Law,
Novis Healthcare excludes, to the fullest extent
permitted by law, all liability in respect of loss of
prot or other economic loss, direct to indirect or
consequential, special, generalor other damages
or other expenses or costs which may include
negligence.
Limited Liabilities
IMPORTANT NOTICE FOR
AUSTRALIAN CONSUMERS:
12
1300 738 885
Unit 12, 12 Mars Road,
Lane Cove West NSW
2066
Pressure care and patient handling specialists
28072020F
Table of contents
Other Novis Mobility Aid manuals
