Timago TGR-R RR S005 User manual

1
INSTRUCTIONS FOR USE
Pedal exerciser, foldable
Pedal exerciser with calories counter, foldable
Product code: TGR-R RR S005 / TGR-R RR S005L
1. Characteristics
Pedal exerciser for lower limbs is made of powder coated steel frame.
It is equipped with resistance mechanism, four anti-sliding pads and
rubber straps for feet. Owing to rotary resistance adjustment knob,
pedal exerciser is also suitable for patients after extensive injuries. It
can be used in hospitals, rehabilitation centres, and at home as a
devise for rehabilitation or individual recreation.
Elements of the pedal exerciser:
a. Strap for feet
b. Resistance adjustment knob
c. Locking pin
d. Anti-sliding pads
e. Counter (model TGR-R RR S005L)
2. Application
Pedal exerciseris designed for patients with contracture or muscular
atrophy caused by long-lasting immobilization in a plaster or by
surgery. The pedal exerciser is also used in rehabilitation process of
patients who require restoration of motor functions and re-learning of
correct mobility model lost by damage of neurological system. It is
possible to adjust the exerciser to the condition of limbs and to the
progress in rehabilitation owing to resistance adjustment.
3. Assembly, adjustment
To assemble pedal exerciser, extend both legs until the locking pins
click.

2
•Assemble adjustment knob into the mounting opening in the
upper part of the frame.
•To fold the exerciser, press locking pins and fold legs inwards.
•To disassemble the counter or change batteries (model TGR-R RR
S005L), fully unscrew the adjustment knob and disassemble the
counter or change batteries. Assemble the counter and
adjustment knob again. All data will be lost after battery change.
Resistance adjustment
It is advised to increase the resistance, intensity and/or workout
duration gradually in order to increase the level of physical fitness and
to improve muscle work and strength.
•To increase the resistance, turn knob clockwise.
•To decrease the resistance, turn knob counter-clockwise.
•In case of low impact exercises, the knob should be fully
unscrewed.
•In case of resistance exercises, the knob should be tightened to
required load.
Usage
a. Place pedal exerciser on the ground. Ensure anti-sliding pads fit
close to the ground to prevent the exerciser from moving.
b. Do the exercises in sitting position on a stable surface. Pedal
exerciser should be placed in front of the user so that the hip joint
is bent at the angle of not less than 90o.
c. Place feet on pedals and adjust the strap to foot circumference as
it prevents the foot from sliding off the pedal while exercising.
d. Set the resistance using the knob.
e. Turn the counter on (TGR-R RR S005L) pressing MODE button and
select appropriate function. To reset the counter, press and hold
the button RESET for 3 seconds.

3
Counter function
4. Technical data
Base dimensions
39.5 cm x 47 cm
Base height from the ground
17 cm
Weight:
TGR-R RR S005
TGR-R RR S005L
2.2 kg
2.3 kg
Maximum capacity
30 kg
Battery for the counter 1 pc
R03 AAA 1.5V
Frame colour
green, black
5. Notes
Timago International Group does not bear responsibility of improper
use of the pedal exerciser, failure to comply safety regulations and
misuse.
6. Maintenance
At least once a month pour several drops of gear oil into the opening
located under the adjustment knob.
RPM
rotation per minute
SCAN
display of workout parameters
(time, burnt calories)
CNT
full rotations
TIME
workout duration
CAL
calories counter
MODE/RESET
change of function/reset

4
Cleaning
Carry out regular maintenance of the technical condition of the pedal
exerciser:
•Clean pedal exerciser regularly using soft cloth and water with
soap. Dry thoroughly with soft cloth.
•Do not use strong polishing agents for cleaning as it may cause
damage to protective coats.
•Remove impurities from the moving elements of the exerciser.
7. Storage and transport conditions
Device should not be exposed to direct sunlight, water or moisture.
8. Warranty information
All products distributed by our company are covered by a warranty, the
terms of which are described in the warranty card available on our
website. Please contact the retailer from whom you purchased the
product. Please, keep in mind that for warranty purposes, the proof of
purchase (receipt or invoice) should be retained.
9. Labels
Reference
number
Manufacturer
LOT number Manufacture date
Serial number Medical device
Note
Please read the
instruction
The manufacturer checked for compliance with
essential medical devices requirements.

5
Our complete line of products is available from our distributors.
Learn more at: www.timago.com. Thank you for choosing Timago!
Timago International Group
Spółka z o.o. i Spółka – Spółka komandytowa
ul. Karpacka 24/12
43-316 Bielsko-Biała, Polska
T.: [phone]
F.: [phone]
E.: [e-mail]
Rev. II, date 20.05.2021
