Novus 6000 Series User manual

U s e r ’s m a n u a l
6000 series IP cameras

6000 series IP cameras user manual, version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA sp. z o.o.
2
1. WWW INTERFACE ......................................................................................................5
1.1. The Remote Preview Interface .............................................................................5
2. PLAYING BACK RECORDINGS FROM A MEMORY CARD...............................6
2.1. Player options for video search ............................................................................7
2.2. Player options for photo search ............................................................................8
3. CAMERA CONFIGURATION - REMOTE SETTING............................................10
3.1. "System" settings group .....................................................................................11
3.1.1. “Basic Information” menu.....................................................................11
3.1.2. "Date and Time" menu ..........................................................................11
3.1.3. "Local Config" menu.............................................................................11
3.1.4 "Storage" menu.......................................................................................12
3.1.5 "Fisheye parameters" menu....................................................................12
3.2. "Image" settings group .......................................................................................12
3.2.1. "Display Settings" menu........................................................................12
3.2.2. "Video/Audio" menu.............................................................................15
3.2.3. "OSD" menu..........................................................................................16
3.2.4. "Video Mask" menu ..............................................................................16
3.2.5. "ROI Config" menu...............................................................................16
3.2.6. "Zoom/Focus" menu..............................................................................17
3.3. "PTZ" settings group ..........................................................................................17
3.3.1. "PTZ Settings" menu.............................................................................17
3.3.2. "Restore" menu......................................................................................18
3.3.3. "PTZ function" menu ............................................................................18
3.4. “Alarm” settings group.......................................................................................21
3.4.1. “Motion Detection” menu ......................................................................21
3.4.2. “Anomaly” menu....................................................................................22
3.4.3. “Alarm In” menu....................................................................................22
3.4.4. “Alarm Out” menu .................................................................................23
TABLE OF CONTENTS

6000 series IP cameras user manual, version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA sp. z o.o.
3
3.5. “Event” settings group ....................................................................................... 23
3.5.1. “Exception” menu .......................................................................... 23
3.5.2. “Line Crossing” menu.................................................................... 24
3.5.3. “Region Entrance” menu............................................................... 26
3.5.4. “Region Exiting” menu ................................................................. 28
3.5.5. “Target Counting” menu................................................................ 30
3.5.6. “Intrusion” menu ........................................................................... 32
3.5.7. “Face Detection” menu.................................................................. 34
3.6. “Network” settings group .................................................................................. 36
3.6.1. “TCP/IP” menu............................................................................... 36
3.6.2. “More” menu .................................................................................. 37
3.7. “Security” settings group ................................................................................... 40
3.7.1. “User” menu ................................................................................... 40
3.7.2. “Online User” menu ....................................................................... 42
3.7.3. “Block and Allow Lists” menu ...................................................... 42
3.7.4. “Security Management” menu ....................................................... 42
3.8. “Maintenance” settings group............................................................................ 42
3.8.1. “Backup and Restore” menu .......................................................... 42
3.8.2. “Reboot” menu............................................................................... 43
3.8.3. “Upgrade” menu............................................................................. 43
3.8.4. “Operation Log” menu................................................................... 43
TABLE OF CONTENTS

6000 series IP cameras user manual, version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA sp. z o.o.
4
PRELIMINARY INFORMATION
PRELIMINARY INFORMATION
This user manual contains detailed information on the operation of the 6000 series IP cameras.
References in this publication of photos the camera and images can be simulations. The
actual images from the cameras may vary depending on the type, model, settings,
observation area or external conditions.
AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o. has made every effort to ensure that the
information contained in this publication is complete, accurate and up-to-date.
However, due to the continuous development of the product line, the appearance of
graphics, menu layout or function descriptions contained in this publication may differ
from those implemented in your device. This does not limit or invalidate this manual.
The following chapters describe all the functionalities of the 6000 series IP cameras.
However, depending on the camera model and / or firmware version, some functions may
not be available or not supported. Detailed information about the camera's functions is
included in the catalog card at www.aat.pl and in the "Quick Start Guide" attached to the
camera.
Technical data of the cameras, construction description, method of installation, start-up
and basic operation are included in the "Quick Start Guide" attached to the camera.
When using this "User’s manual", always have the quick reference guide close at hand so
that you can refer to it for matters not covered in the instructions for use.

6000 series IP cameras user manual, version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA sp. z o.o.
5
WWW INTERFACE - MAIN WINDOW
1. WWW INTERFACE
1.1. The Remote Preview Interface
1. Camera main menu bar
The description of the remote preview window, all its elements and functions can be found
in the quick start guide attached to the camera. For information on these parts and
functions, please refer to the quick start guide that came with your device. The quick start
guide is also available for download in the product card at www.aat.pl
1
- opens a menu playback from the memory card. Menu description from page 6
- displays the live view image
- opens the settings menu. Menu description from page 10
- logs out of the camera menu

6000 series IP cameras user manual, version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA sp. z o.o.
6
WWW INTERFACE - WORKING WITH CAMERA
2. PLAYING BACK RECORDINGS FROM A MEMORY CARD
The Search tab allows you to search, play and manage recordings and photos that the camera has
saved on the memory card. The player views and functions differ depending on the type of recorded
material you want to play back. The default operation mode is video playback.
The main functions of the player:
2
6
1
345

6000 series IP cameras user manual, version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA sp. z o.o.
7
WWW INTERFACE - WORKING WITH CAMERA
1. Search panel, from the top:
• selection list of the type of recorded material to be displayed ("Picture" or "Record" - video
recordings)
• recordings source selection list ("SD card" or "Local" - option inactive)
• calendar: select the day and time range in which to search for photos
• search start button
• change the view of the search pane. Pressing the button switches between the
calendar view and the searched files list view
• buttons for creating and downloading video clippings (detailed
description later in this chapter)
2. Selecting the type of events to search.
3. Toolbar for managing the searched recordings
4. Timeline
5. Scaling buttons, to change the time range of recordings presented on the timeline
2.1. Player options for video search
After selecting "Record" option from the recorded material type selection list, the player window will
display the corresponding menu items. The search panel will display a calendar in which you select
the date and (optionally) the hourly range in which you want to search for recordings.
After pressing the search button, the player searches for videos that match the criteria you set and
displays them as a list in the search pane area.
At the top of the list of recordings, there is an option to select the video playback method: "Mixed
stream" - video and audio playback, "Video stream" - video only playback.
The time ranges in which the searched recordings are located will be
marked in color on the timeline. The color of the timeline (and also
of the searched recording) corresponds to the type of events selected
before the search. Selecting the selected item on the list of searched
recordings (or double-clicking) will cause the selected video
fragment to be played.
The download button in the item line allows you to save the
selected video fragment to the computer disk.

6000 series IP cameras user manual, version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA sp. z o.o.
8
Playback control and recording management options:
1. Playback controls, from left:
• Play / pause
• Stopping playback
• Decrease / increase playback speed
• Enable / disable watermark
• Change the size of the playback buffer
2. Timeline
3. Options for creating and downloading video clippings. By pressing the "Scissors"
button mark the beginning and end of the video clip, which is downloaded and saved on the computer
disk after pressing the download button.
4. Scaling buttons to change the time range of recordings presented on the timeline
2.2. Player options for photo search
After selecting "Picture" option from the recorded material type selection list, the player window will
display the corresponding menu items. The search panel will display a calendar in which you select
the date and (optionally) the hourly range in which you want to search for pictures.
After pressing the search button, the player searches for photos that match the criteria you set and
displays them as a list in the search pane area.
WWW INTERFACE - WORKING WITH CAMERA
13
4
2

6000 series IP cameras user manual, version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA sp. z o.o.
9
Description of the player's components:
1. List of searched photos. The color of the found photo matches the type of events selected before the
search. Double-clicking on the selected item will display the photo in the preview window and add it
to the selected list (thumbnails at the bottom of the window). The "Export" button allows you to save
all searched photos on the PC. After clicking the button, the system window for selecting the save
location will open. After selecting the drive or folder, the photos will be saved in the automatically
created folder "ExportPic".
2. Selecting the type of events to search.
3. Thumbnails of selected photos. You can add up to 10 photos to the selected list.
WWW INTERFACE - WORKING WITH CAMERA
2
5
1
4
3
For the export to be possible, the browser must be running with administrator privileges. The
size and quality of the photos are defined in the "Settings -> System -> SD card" menu,
described on page 12.

6000 series IP cameras user manual, version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA sp. z o.o.
10
WWW INTERFACE - WORKING WITH CAMERA
4. Toolbar for managing the selected photos. Toolbar options, from left:
• Removes the selected (red frame) photo from the selected list
• Removes all photos from the selected list
• Saves the selected photo to the computer disk
• Saves all photos from the selected list on the computer disk
• Picture display - fit to the preview window
• Picture display - actual size
• Picture display - digital zoom: zoom +, zoom -
• Turns on the slideshow - photos from the selected list are displayed sequentially in the preview
window
• Stops the slide show
• Slider for setting the speed of changing photos in a slide show
3. CAMERA CONFIGURATION - SETTINGS
This tab allows you to modify and configure all parameters and camera settings available in a given
model. Most of the settings can be changed conveniently and safely by selecting a parameter value
from the drop-down list. In the case of fields that allow to enter your own parameter value, an
acceptable range is given.
