NTI XTENDEX Series User manual

MAN341 Rev Date 12/10/2019
ST-C6USB4K18GB-HDBT230
4K 18Gbps HDMI USB KVM Extender
over HDBaseT
Installation and Operation Manual
XTENDEX®Series

TRADEMARK
XTENDEX is a registered trademark of Network Technologies Inc in the U.S. and other countries.
COPYRIGHT
Copyright © 2019 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202.
CHANGES
The material in this guide is for information only and is subject to change without notice. Network Technologies Inc reserves the
right to make changes in the product design without reservation and without notification to its users.
Note: CATx connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products
should not be run underground, outdoors or between buildings.
WARNING: Outdoor or underground runs of CATx cable could be dangerous and will void the warranty.
WARNING: The CATx connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series
products must be wired straight through (pin 1 to pin 1, pin 2 to pin 2, etc.) The use of a CROSSOVER CABLE will
damage the extender and void your warranty.

TABLE OF CONTENTS
Introduction......................................................................................................................................................................1
Materials..........................................................................................................................................................................1
Preparation for Installation ..............................................................................................................................................2
Features and Functions...................................................................................................................................................3
Installation .......................................................................................................................................................................4
IR Connection..............................................................................................................................................................6
Troubleshooting...............................................................................................................................................................7
Interconnection Cable Wiring Method.............................................................................................................................7
Technical Specifications..................................................................................................................................................8
Warranty Information.......................................................................................................................................................9

NTI 4K HDMI USB KVM EXTENDER VIA CATX CABLE
1
INTRODUCTION
The XTENDEX®4K 18Gbps HDMI USB KVM Extender over HDBase-T transmits uncompressed digital Ultra-HD 4Kx2K 60Hz
4:4:4 HDMI signal, USB, and IR up to 230 feet over a single CAT6/6a/7 cable using HDBase-T technology. Each extender
consists of a Local Unit (Sender) that connects to a computer, and a Remote Unit (Receiver) that connects to a keyboard, monitor
and mouse.
Features
Transmits an uncompressed high speed HDMI signal over one CAT6/6a/7 cable.
Supports Ultra-HD 4Kx2K resolutions to 3840x2160@60Hz YUV 4:4:4, and HDTV resolutions to 1080p.
HDMI features supported:
oHDMI 2.0
o24-bit Deep Color
oRGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
oLPCM, Dolby Digital, and DTS Digital
oBandwidth up to 600 MHz (18 Gbps).
oSupport for CEC (consumer electronic control) compatible devices.
o3D
oHigh Dynamic Range
HDCP 2.2 compliant.
Bi-directional Infrared Remote (IR) control of HDMI source or display. IR transport channel can be forward or backward per
the installation.
USB ports for keyboard and mouse.
oKeyboard and mouse are hot-pluggable.
Only one power supply is necessary to power both the Local and Remote units.
MATERIALS
Materials supplied with this kit:
NTI XTENDEX Local and Remote Units
1 x 100-240VAC, 50 or 60Hz-12VDC/2A AC Adapter
2 x IR Emitter
2 x IR Receiver
1 Meter USB Type A Male to USB Type A Male cable
URL Slip with path to this manual
Materials Not supplied but REQUIRED:
CAT6/6a solid/stranded UTP; CAT7 solid/stranded STP (referred to as "CATx" throughout this manual) twisted-pair
cables terminated with RJ45 connectors wired straight thru- pin 1 to pin 1, etc. (see page 7 for proper EIA/TIA 568 B wiring
method). CAT5/5e cable is NOT recommended for use with this product.
WARNING: The CATx connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series
products must be wired straight through (pin 1 to pin 1, pin 2 to pin 2, etc.) The use of a CROSSOVER CABLE will
damage the extender and void your warranty.

NTI 4K HDMI USB KVM EXTENDER VIA CATX CABLE
2
Use NTI HDMI Cables for Input and Output cables
Available Cables Supported Resolution
1080p@60Hz 3840x2160
HD-xx-MM
Where x=3,6,10,15,20, 30 and 50 ft Yes Max. 10 ft (@ 30/60Hz)
HD-ACT-xx-MM
Where xx= 20,25,30,40,50 and 60 ft Yes Yes (@ 60Hz)
HD-ACT-xx-MM
Where xx= 75 and 100 ft Yes Yes (@ 30Hz)
DVI-HD-xM-MM
Where x= 1,2,3 and 5 meters Yes No
Cables can be purchased from Network Technologies Inc by calling [phone] (800-RGB-TECH) in the US and Canada or
[phone] (worldwide).
PREPARATION FOR INSTALLATION
Locations should be chosen for the monitor and video source that also have space to connect the Remote Unit and Local Unit
units within the distance provided by the CATx cables.
All cables should be installed in such a way that they do not cause stress on their connections to the equipment. Extended
lengths of cable hanging from a connection may interfere with the quality of that connection. Secure cables as needed to
minimize this.
Properly shut down and disconnect the power from the video source and monitor to be separated. If other equipment is
involved whose connections are being interrupted, be sure to refer to the instruction manuals for that equipment for proper
disconnection and re-connection procedures before proceeding.
WARNING: The CATx connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series
products must be wired straight through (pin 1 to pin 1, pin 2 to pin 2, etc.) The use of a CROSSOVER CABLE will
damage the extender and void your warranty.

NTI 4K HDMI USB KVM EXTENDER VIA CATX CABLE
3
FEATURES AND FUNCTIONS
No. Label Description
1 DC 12V For optional connection of power supply
2 Power Illuminates when the Local Unit is powered ON
3 Arrow Illuminates when there is data transmission from the Receiver; Flashes when there is no
communication
4 Display Flashes when the display device connected to the Remote Unit is communicating
5 HDBT OUT For connection of a CATx cable to the Remote Unit
6 HDMI INPUT For connection of a video cable from the video source
7 RESET Press this button to reboot the Local Unit
8 USB PC For connection of a USB cable from a PC
9 IR IN For connection of an IR Receiver
10 IR OUT For connection of an IR Emitter
No. Label Description
1 DC 12V For connection of power supply
2 Power Illuminates when the Remote Unit is powered ON
3 Arrow Illuminates when there is data transmission from the Local Unit; Flashes when there is no
communication
4 Display Flashes when the display device connected to the Remote Unit is communicating
5 HDBT OUT For connection of a CATx cable to the Local Unit
6 HDMI INPUT For connection of a video cable from the display
7 RESET Press this button to reboot the Remote Unit
8 USB PC For connection of a USB cable from a keyboard/mouse
9 IR IN For connection of an IR Receiver
10 IR OUT For connection of an IR Emitter

NTI 4K HDMI USB KVM EXTENDER VIA CATX CABLE
4
INSTALLATION
Note: The video source and display device can be powered-ON at any point during this installation.
1. Connect a video source to the HDMI port on the Local Unit using one of the cables recommended in the chart on page 1. If a
PC is being extended, also connect a USB cable between the PC and the Local Unit.
2. Connect a display to the HDMI port on the Remote Unit using one of the cables recommended in the chart on page 1. If
applicable, connect a keyboard or mouse to the USB ports.
Note: If the video source is DVI, then the display must also be a DVI-compatible model.

NTI 4K HDMI USB KVM EXTENDER VIA CATX CABLE
5
3. Connect a CAT6/6a/7 cable (up to 230 feet in length) between the "HDBT In" port on the Remote Unit and the "HDBT Out" port
on the Local Unit.
4. Connect AC Adapter to the "DC 12V" port on the Remote Unit. With the CATx cable connected, the Local Unit will also be
powered.

NTI 4K HDMI USB KVM EXTENDER VIA CATX CABLE
6
IR Connection
The ST-C6USB4K18GB-HDBT230 supports Bi-directional IR pass back. A user can control devices at each end of the
installation. With an IR Emitter and IR Receiver connected at each end, a user can control a TV connected at the Remote Unit
and the DVD player connected to the Local Unit.
Place the IR Emitter close to the device it controls to best transmit the IR signal coming from the remote control. The remote
control at the Local Unit will control the display device on the Remote Unit, and the remote control at the Remote Unit will control
the video source at the Local Unit.
IR Emitter
IR Receiver

NTI 4K HDMI USB KVM EXTENDER VIA CATX CABLE
7
TROUBLESHOOTING
Problem Solution
No Output on Display Check power supply connection
Make sure all cables are securely connected and fully inserted
Make sure the correct input port on the display has been selected
Make sure the correct video format is selected on the video source
Data transmission indicator is flashing
but no output Make sure the correct input port on the display has been selected
Connection indicator remains OFF Verify that the video source has a signal and is properly connected to the Local
Unit
Verify that the display device is well connected to the Remote Unit and that the
correct input port is selected
Output image is noisy (snow) Change the HDMI cable between the Local Unit and video source. Always use a
short cable when testing and for best results use a cable from the chart on
page 1.
INTERCONNECTION CABLE WIRING METHOD
The CATx connection cables (CAT6/6a/7 only) between the Local Unit and Remote Unit are terminated with RJ45 connectors and
must be wired according to the EIA/TIA 568 B industry standard. Wiring is per the table and drawing below.
Note: CAT5/5e cable is not recommended for use with this product.
Pin Wire Color Pair Function
1 White/Orange 2 T
2 Orange 2 R
3 White/Green 3 T
4 Blue 1 R
5 White/Blue 1 T
6 Green 3 R
7 White/Brown 4 T
8 Brown 4 R
WARNING: The CATx connection cable used between the NTI XTENDEX Series Local Unit and Remote Unit or any
XTENDEX Series products must be wired straight through (pin 1 to pin 1, pin 2 to pin 2, etc.) The use of a CROSSOVER
CABLE will damage the extender and void your warranty.
T
1
+
R
2
-
T
3
+
R
4
-
T
5
+
R
6
-
T
7
+
R
8
-
Pair 2 Pair 1 Pair 4
Pair 3

NTI 4K HDMI USB KVM EXTENDER VIA CATX CABLE
8
TECHNICAL SPECIFICATIONS
Items Specifications
Local Unit
Compatibility USB Computer or HDTV Video Source with HDMI output
Platforms supported Multiplatform support: Windows 2000/XP/Vista/7/8/10, Windows
Server 2000/2003/2008/2012/2016, Solaris, Linux, FreeBSD, and
MAC OS 9/10.
Local Unit Connections 1- HDMI Female, 1-USB Type A Female, 2-3.5mm Jacks, 1-RJ45
Female
Remote Unit
Resolutions Supported Ultra-HD 4Kx2K 60Hz 4:4:4 resolutions
(3840x2160@30/50/60Hz); HDTV resolutions to 1080p
Max. Data Rate 18Gbps
HDCP Supported HDCP 2.2
Remote Unit Connections 1- HDMI Female, 1-USB Type A Female, 2-3.5mm Jacks, 1-RJ45
Female
General
Maximum Transmission Distance 230 ft (70 meters) over CAT6/6a/7 cable
Power Supply 100-240VAC 5/60Hz; 12VDC2A AC Adapter for Remote Unit,
Local Unit power by CAT cable connected to Remote Unit
Operating Temperature 32 to 131 °F (0 to 55°C)
Operating Humidity 0 to 90% RH (no condensation)
Dimensions (WxDxH) 3.43x4.31x0.92 in (87x109.5x23.4 mm)
HDMI Signal Supports HDMI2.0 and HDCP2.2
Approvals CE, FCC, RoHS

NTI 4K HDMI USB KVM EXTENDER VIA CATX CABLE
9
WARRANTY INFORMATION
The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact Network
Technologies Inc at [phone] (800-RGB-TECH) or [phone] or visit our website at http://www.networktechinc.com for
information regarding repairs and/or returns. A return authorization number is required for all repairs/returns.
MAN341 Rev. 12/10/19
