Nubert Soundbase nuBoxx AS-225 max Manual

®
INSTALLATION
SERVICE
1 lineup
nuBoxx AS-225 max Commissioning 01/2022
Soundbase nuBoxx AS-225 max
Bassreflexöffnungen, Klang
https://www.nubert.de/anleitung-nuboxx-as-225-max/1106/
feet
Vibration-absorbing elastic buffers are used as feet for the AS-225 to
ensure a secure footing. The soundbase should not be set up
without these elastic buffers.
1
First set up the soundbase at the intended place of use. A few
notes on this:
The latest user manuals and other helpful information can be found here:
Danger! Be careful not to scratch the speaker! Don't drop anything into the box through the bass reflex tubes!
The rear arrangement of the bass reflex openings means that the
AS-225 should be at least 5 centimeters away from the rear wall in
order to ensure problem-free operation and to avoid flow noise.
With a generous distance from the wall - also to the side - you
reduce an increase in the bass and fundamental tone range. When
set up on shelves, the best sound is achieved when the front edge
of the box is either flush with the shelves or even protrudes
slightly.
Machine Translated by Google

2 connections
The soundbase automatically switches to the
Bluetooth input (LED flashes) and can now
be found and paired by appropriate players
such as smartphones for 2 minutes. The LED
lights up continuously to indicate an existing
connection.
It can be activated or deactivated by pressing
the wide button on the remote control for 8
seconds within 15 seconds after switching on.
The LED ring flashes once to confirm that
the automatic stand-by function has been
deactivated.
ÿAt the HDMI eARC input, a
ÿThe inputs AUX, COAX and
ÿSpannungsversorgung
OPTICAL allow the connection of standard
hi-fi devices such as CD players or network
streamers.
The LED ring flashes three times to
confirm that the function has been (re)activated.
ÿThe SUB OUT becomes a mono off
Bluetooth
Before switching on, connect all players and, if necessary, subwoofers to the sound base!
Notes: Make sure you activate the CEC and
ARC functions on the TV. Depending on
the TV and audio material, it may be
necessary to specify the audio output via PCM
or Dolby Digital in the TV menu.
To reset the soundbase to factory settings,
first press the mute x button on the remote
control for at least 3 seconds until the LED ring
starts flashing red. The reset must be
confirmed within 10 seconds by pressing the
p3 button. The soundbase restarts with all
factory settings.
output signal to supply a subwoofer. By
plugging in a cinch plug at the SUB OUT, a
high-pass filter is automatically activated for
the soundbase in order to relieve it of the low
bass and to ensure an ideal transition to the
subwoofer (80 Hz, 12 dB).
The included power cord is connected to
the power socket on the back of the speaker,
thereby establishing the connection to the
power supply. Now turn on the soundbase
by turning the switch next to the mains socket
to the ON position! (If necessary, “wake up”
the AS-225 from stand-by mode using the
remote control.)
TV with ARC or eARC audio output can be
connected.
2
To connect a device to the soundbase via
Bluetooth for the first time, a so-called pairing
process must be carried out.
The soundbase has an automatic stand-
by function that deactivates it after 20
minutes without a sound signal at the latest.
This function is explained in detail in the
safety instructions, technical data, warranty
provisions leaflet .
When using the soundbase for the first
time, the pairing process starts
automatically when you switch to the
Bluetooth input. If another device is to be
connected, the pairing process is started
by pressing the pairing button on the remote
control.
factory reset
Stand-by-Automatik
ÿ
ÿ
ÿ
ÿ
nuBoxx AS-225 max Commissioning 01/2022
Machine Translated by Google

3 Operation on the device
Reduced brightness: 1.5 dB
For better clarity, the inputs are also color-coded:
Rot
Rosa
TO
Example: input 4 (optical, LED red)
To indicate the volume value, each LED has two brightness
values:
In the next step you get to the control option for the mid and high
frequency range. The LEDs light up blue.
input selection
White
White
Adjust volume
Green
A control range of +/- 10 dB is available (increments of 0.5
dB).
Turn the device on/off
PCM
3
Tone control "Bass"
BLUETOOTH Blau
Entry:
The color of the LED ring provides information about
the current audio signal:
HDMI ARC
Example: Bass +6dB
Full Brightness: 3dB
After pressing the knob once, the input LED of the current input will
flash. Turning the knob changes the input.
OPTICAL
The special Nubert tone scale linearly raises or lowers medium and
high frequencies. A maximum control range of +/- 10 dB is also available
here (increments of 0.5 dB).
Pressing the rotary control again takes you to the control option for
the bass intensity. The LEDs light up green.
COAX
To adjust the volume, the rotary control is rotated in the
desired direction (increments of 1.5 dB).
Lila
Dolby Digital
Status LED color:
Additional functions can be selected by repeatedly pressing the
control dial. These are in order:
Klangregelung „Mid/High”
Example: Mid/High -3dB
If the rotary control on the front is pressed for 3 seconds, the sound base
is activated or switched to stand-by mode. If the loudspeaker has
been put into stand-by mode in this way, the automatic switch-on
is deactivated.
nuBoxx AS-225 max Commissioning 01/2022
Machine Translated by Google

®
Nubert electronic GmbH · Goethestr. 69 D-73525 Schwäbisch Gmünd www.nubert.de [email protected] Hotline: +49 ( 0) 7171 8712-0
nuBoxx AS-225 max Commissioning 01/2022
4 remote control
Bass: GREEN
wide
Bass +5 dB
focus on
space expansion
tone und tone level
The LED ring flashes three times.
Loudness
not active
space expansion
Example
volume and x(mute)
voice playback
The LED ring flashes once.
(on/off)
Example
The source selection and the volume
are not saved.
Effects disabled
Repeatedly pressing the wide button selects the strength and type of the wide
effect. Additional spatial information can be calculated in order to achieve a virtual
expansion of the stereo stage.
Mid/High: BLAU
p1 p2 p3
The tone button calls up the tone controls and also allows you to switch between
them. Settings can be made with the two arrow keys above tone level , such as
raising and lowering the bass intensity, or adjusting the mid/high range, each by up
to +/- 10 dB. In addition, the loudness effect can be activated or deactivated.
The color of the LED chain indicates the function that can currently be set using
the arrow keys:
Loudness
aktiv
distinct
Save: press the preset button
for 3 seconds.
quite a bit
The volume can be adjusted using the volume buttons. The x button allows the
speaker to be muted and also unmuted.
All sound settings can be saved as
presets and called up again quickly.
Loudness: ROT
Alternatively, the focus can also be on speech reproduction,
which contributes to good speech intelligibility, especially at low
volumes.
Mid/High -3 dB
Call up: short press the preset button.
4
Use the button to activate the loudspeaker or switch it to stand-by mode. If the
loudspeaker has been put into stand-by mode using the remote control, the
automatic switch-on is deactivated.
