NULEA D1027C8 User manual

D1027C8
WIRELESS VERTICAL MOUSE
User Manual

- 01 -
7
6
12 11
13
15
14
5
8
1 3 2 94 10
Product Function
1Left Button
2Right Button
3Scroll Wheel
4DPI Button
5Desktop Button
6DPI/Channel Indicator
7Forward Button
8Back Button
Note: Bluetooth indicator/USB indicator ashes quickly on low battery.
9Charging Port
10 On/Off
11 Mode Switch Button
12 2.4G Indicator
13 Equipment 1 Indicator
14 Equipment 2 Indicator
15 USB Receiver
US/UK/CA

- 04 -
2.4G Connection
US/UK/CA
1
3
2
4

- 05 -
2.4G Connection
Bluetooth Connection
Windows System(Take Windows 10 as an example)
1 Turn on the mouse.
2 Press the switch button to switch to the second channel, then the blue LED will ash
slowly.
3 Long press the switch button for 3~5 seconds until the blue LED ashes quickly.
The mouse will be in Bluetooth pairing mode.
1 Turn on the mouse.
2 Take out the USB receiver.
3 Insert the USB receiver into the computer USB port.
4 Click the mode switch button to 2.4G mode then the rst red LED will ash slowly.
1 2 3

- 06 -
4 Click the “Bluetooth devices” button on the computer.
5 Click the “Add or remove Bluetooth devices” button.
6 Search the Bluetooth “BT5.2 Mouse”, and click the Pairing button.
7 When the Bluetooth “BT5.2 Mouse” is connected, the mouse is ready to use.

- 07 -
1 Click the “system preferences” button on the Mac.
2 Click the Bluetooth button on the system preference folder.
3 Search the Bluetooth “BT5.2 Mouse”, and click the Pairing button. If installed
completely, the mouse could be used normally.
Mac OS System
Please operate the Bluetooth installation steps(1~3) before pairing.
6

- 08 -
Mode Switch
When 2.4G or Bluetooth connect successfully, shortly press the switch button at the
bottom of the mouse, and you could switch the modes easily.
2.4G Mode red LED on
EquipmentEquipment 1
blue LED on
2 green LED
on

- 09 -
Mode Switch How Do You Wake up the Nulea Vertical Mouse?
The Nulea Vertical Mouse employs an intelligent sleep mode to safeguard the battery
for extended use:
1. In USB receiver and Bluetooth connection mode, Nulea Vertical mouse goes into
hibernation after 10 minutes of your last mouse use; If you need to use the mouse, you
must push the button to wake it up (moving the mouse will not wake it up);
2. The Nulea Vertical mouse goes into deep Bluetooth sleep 109 minutes after you
last used it in Bluetooth connection mode; at this point, you must press the button to
wake it up while also allowing the mouse to nd Bluetooth in order to reestablish the
connection (it takes 3 to 5 seconds to check whether the Bluetooth of the terminal
device is on).
Package Include
1x Wireless Mouse
1x USB-C Cable
1x User Manual

- 10 -
Basic Parameters
Chipset Yichip 1066
Engine Optics
Mouse Resolution 1000/1600/2400 dpi
Mouse Button Life Over 3 million
Mouse Size 112.08*79.92*77.86mm
Mouse Weight 121g
2.4G Transmission Parameters
Transmission distance 10m
Work voltage 3.7V
Work currency 8.0±0.5mA
Rate of return 125Hz
Bluetooth Transmission Parameters
Transmission distance 10m
Work voltage 3.7V
Work currency 6.0±0.5mA
Rate of return 125Hz
System needs Bluetooth receiver device
USB interface
Window® 8,Windows® 10 or higher versions
Mac OS X 10.10 or higher versions
Android 4.3 or higher versions

- 39 -
FCC ID
Any Changes or modications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
Correct Disposal of This Product
(Waste Electrical& Electronic Equipment)
This Marking shown on the product or its literature, indicate that it should not be
disposed with other household wastes at the end of its working life.
To prevent possible harm to the environment or human health from uncontrolled waste
disposal, please separate this from other types of wastes and recycle it responsibly to
promote the sustainable reuse of material resources Household user should contact
either the retailer where they purchased this product or their local government ofce, for
details of where and hew they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contact This product should not be mixed with other commercial wastes for disposal.

FCC Warning
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired
operation.
NOTE 1: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are desig
ned to provide reasonable protection against harmful interference in a residential in
stallation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmf
ul interference to radio communications. However, there is no guarantee that interf
erence will not occur in a particular installation. If this equipment does cause harmf
ul interference to radio or television reception, which can be determined by turning t
he equipment off and on, the user is encouraged to try to correct the interference b
y one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user's authority to operate the
equipment.
The device has been evaluated to meet general RF exposure requirement. The
device can be used in portable exposure condition without restriction.
“This device complies with Industry Canada’s license-exempt RSSs. Operation is
subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.”
« Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas
produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioelectrique subi, meme
sile brouillage est susceptible
d'en compromettre le fonctionnement. »

FCC ID:2AAVD-D1027C8
MADE IN CHINA
