Numatic HZQ 190 Assembly instructions

HZQ
190, 200, 250, 350, 370,
450, 570, 750, 900
HZDQ
450, 570, 750, 900
Hazardous Dust Machines
Original Instructions
Warning! Read instructions before using machine
Operator Instruction Manual

231844 Page 2 of 24 (A10)
HZQ 190 BB 17 NVM 1CH
HZQ 200 BB 17 NVM 1CH
HZQ 250 BB 17 NVM 1CH
HZQ 350 BB 18 NVM 2BH
HZQ 370 BB 18 NVM 2BH
HZQ 450 BB 19 NVM 3AH
HZQ 570 BB 19 NVM 3BH / NVM 3BM
HZQ 750 BB 20 NVM 4BH / NVM 4BM
HZQ 900 BB 20 NVM 4BH / NVM 4BM
HZDQ 45 0 BB 19 NVM 3AH
HZDQ 570 BB 19 NVM 3BH / NVM 3BM
HZDQ 750 BB 20 NVM 4BH / NVM 4BM
HZDQ 900 BB 20 NVM 4BH / NVM 4BM
Machine, Kits and Bags.
NVM 1CH = HepaFlo Bags
NVM 2BH = HepaFlo Bags
NVM 3AH = HepaFlo Bags
NVM 3BH = HepaFlo Bags
NVM 4BH = HepaFlo Bags
HepaFlo Bag + Permatex Filter
NVM 3BM = MicroFlo Bags
NVM 4BM = MicroFlo Bags
MicroFlo Bag + MicroTex Filter

231844 Page 3 of 24 (A10)
BB 17 BB 18
BB 19 BB 20
Contents / Kits BB17 / BB 18 / BB19 / BB20

231844 Page 4 of 24 (A10)
HZQ 350
HZQ 450
HZQ 750
HZDQ 450
HZDQ 750
4 x 10mm
X 4
Handle Assembly, 350, 450, 750

231844 Page 5 of 24 (A10)
Handle Assembly, 900
X 4
X 4

231844 Page 6 of 24 (A10)
Fitting the bag

231844 Page 7 of 24 (A10)
I
0
=
=
Fitting the hose, Fitting the air seperator

231844 Page 8 of 24 (A10)
Moving the machine.

231844 Page 9 of 24 (A10)
A
AA
BB
B
Changing the bag, cleaning the lter (REF Page 15)

231844 Page 10 of 24 (A10)
Cause Solution
Dust caps still tted Remove the caps.
Blocked hose Unblock the hose.
Bag full Remove and replace
Cloth lter clogged Remove and replace, clean dirty lter by
vacuuming.
Hepa cartridge clogged Replace, seek advice from an instructed
person or manufacturer.
Variant Simplex Duplex
Model HZQ
190, 200, 250, 350,
450, 570, 750, 900
HZDQ
450, 570, 750, 900
Classication TYPE H TYPE H
Voltage 115 / 120 / 230V 115 / 120 / 230V
Frequency 50 - 60Hz 50 - 60Hz
Power rating 1200W MAX
1000 IEC
2400W MAX
2000 IEC
Sound Pressure 68 - 72dB(A) to IEC 60704-2-1
+/- 0.2dB(A)
72 - 78dB(A) to IEC 60704-2-1
+/- 0.2dB(A)
Low ow operation 16L/sec (0.96m3/min) 22L/sec (1.32m3/min)
(NB 16L sec corresponds to an airspeed of 20m/sec in a 32mm pipe)
(NB 22L sec corresponds to an airspeed of 20m/sec in a 38mm pipe)
Low Flow Indicator
This appliance is tted with a low ow indicator to show that air ow has reduced.
In the event of the indicator light ashing, check the following:-
