Numatic NRV 240 User manual

Original Instructions -Original Instructions -
CAUTIONCAUTION
Read instructions before using the machine.Read instructions before using the machine.
www.numatic.co.uk
NA1 - NS1 - AS0 - AH29
NRV 240-11
NRV 370-11
NRV 380-11
NRV 470-11
EVR 370-11
NSR 240-11
NRV 240-11 (110 Volt)
NRV 370-11 (110 Volt)

Assembly
Kit NA1 / NS1
EVR 370 - Kit AS0
Kit AH29

Power On Indicator LightStart
Using your machine
LowLow
LowLow HighHigh

Cleaning
12
3
4
5
1
87
62
EVR 370-11 Only
Cleaning the Tool Head
321

Fitting the Face
12
Removing the Face
1 2
Wand docking / Tool Tidy

470 Handle Fitting
12 3 4 5 6
Drum Size Cleaning
Range
Weight
(Ready to
work)
Sound Pressure Protection Class Dimensions
Data
1 2 3 4 5 6
NRV/NSR 240
NRV 370
NRV 380
NRV 470
9 L
15 L
15 L
27 L
31.8 m
9.0 kg
9.1 kg
9.1 kg
11.6 kg
LpA ≤ 70
dB(A) Class II
360 mm x 370 mm x 415 mm
360 mm x 370 mm x 510 mm
355 mm x 355 mm x 485 mm
358 mm x 450 mm x 710 mm
EVR 370 15 L 26.8 m 9.1 kg360 mm x 370 mm x 510 mm
TriTex Filter
604165 TriTex-Filter
HepaFlo Bags
604015 NVM 1CH (Pack of 10) 240 Drum Size
604016 NVM 2BH (Pack of 10) 370 / 380 Drum Size
604018 NVM 3AH (Pack of 10) 470 Drum Size
Replacement parts

Failure to rectify the problem or in the event of a breakdown contact your Numatic dealer or the
Numatic Technical helpline [phone]
Safety Critical Components
Mains leads:
Rating Label
About your machine (GB) 1.1
PPE (personal protective equipment). That may be required for certain operations.
Ear Protection Safety Footwear Head Protection Safety Gloves
Eye Protection Protective Clothing Dust / Allergens
Protection Hi Viz Jacket Caution Floor Sign
NOTE: A risk assessment should be conducted to determine which PPE should be worn.
WEEE Legislation (Waste, Electrical and Electronic Equipment)
Vacuum cleaner, accessories and packaging should be sorted for environmentally - friendly
recycling.
(Only for UK/EU Countries)
Do not dispose of vacuum cleaner into household waste! According to the European Directive
2012/19/EU on waste electrical and electronic equipment and its incorporation into national law.
Vacuum cleaners that are no longer suitable for use must be separately collected and sent for
recovery in an environmentally - friendly manner.
1Company Name & Address
2Model
3Voltage / Alternating Current
4Frequency
5Rated Input Power
6Weight
7WEEE Logo
8Protection Class 2 Symbol
9Approval Mark
10 Machine yr/wk Serial Number
Maintenance
Daily
Keep the machine clean, including hoses and tubes.
Ensure the bag and  lter are  tted.
Regularly examine the power cord.
Check dust bag frequently.
Check  lters are clean.
Weekly - as daily and:-
Check for any worn or damaged parts and replace immediately.
1
2
3
4
5
6
7
8
9
10
(220-240 Volt) HO5-V2V2-F 12.5m x 2 Core x 0.75 mm2
(220-240 Volt) HO5-V2V2-F 12.5m x 2 Core x 1.00 mm2
(110 Volt) HO5-V2V2-F 10m x 2 Core x 1.50 mm2 Yellow Cable + Industrial Plug

Information for DRY use Vacuum cleaners 1.1
WARNING
Read the instruction manual before using the machine.
Operators shall be adequately instructed on the use of their machine.
As with all electrical equipment, care and attention must be exercised at all times during use, in addition to ensuring that
routine and preventative maintenance is carried out periodically to ensure safe operation.
Failure to carry out maintenance as necessary, including the replacement of parts to the correct standard could render
this equipment unsafe and the manufacturer can accept no responsibility in this respect.
Maintenance should only be carried out by a quali ed person.
This machine is for DRY USE only and must not be stored outside or used in wet conditions.
The machine shall be disconnected from the mains by removing the plug from the supply socket during cleaning or
maintenance and when replacing parts or converting the machine to another function.
Only use the socket outlet on the machine for purposes speci ed in the instructions (if  tted).
This machine is not to be used by children or persons with reduced physical, sensory or mental capabilities, or lack of
experience or knowledge.
This appliance is intended to be cleaned and maintained by an adult.
Children being supervised are not to play with the machine.
This machine is not a toy.
This machine is not suitable for picking up hazardous or explosive dust.
Contact your local distributor if you require a machine capable of performing these tasks.
CAUTION
Ensure that the  ltration system  tted to the machine is suitable for the material being collected.
This vacuum cleaner is intended for indoor use in the collection of dry materials.
This machine should be stored indoors only.
NOTES
The primary use for this machine is commercial, for example in hotels, schools, hospitals, factories, shops and offi ces.
This product complies with the requirements of clause 20 of IEC/EN 60335-2-69 Stability and Mechanical Hazards.
This vacuum cleaner is  tted with a thermal protection device. If the vacuum cleaner stops working, remove the plug
from the wall before investigating where the fault lies.
If the vacuum cleaner has a blockage, switch off , remove the plug from the socket, inspect the fl oor tool, tubes and hose
for debris. If the fl oor tool, tubes and hose are clear, replace the dust bag and clean the  lter.
The vacuum cleaner should be inspected after use for damage.
The vacuum cleaner should be stored in a dry place.
When moving from one place to another, consider the weight of the machine.
DO
• Keep your machine clean including hoses and tubes.
• Change dust bag frequently.
• Keep  lters clean.
• Keep diff user  lter (where  tted) clean.
• Use  lter bags, they will enhance performance and help keep machine clean.
• Use a Numatic Original  lter bag under  ne dust conditions.
• Keep hoses and tubes clear.
• Replace any worn or damaged parts immediately.
• Only use the brushes provided with the machine. The use of other brushes may impair safety.
• Regularly examine the power cord. If damage is found such as cracking or ageing the power cord must be
replaced by a quali ed person.
• Only replace the power cord with the correct Numatic approved replacement part.
DO NOT
• Pull on the cable to unplug the machine from the power supply.
• Use to suck up hot ashes or lighted cigarette ends.
• Use steam cleaners or pressure washers to clean the machine or use in the rain.
• Immerse in water for cleaning.
• Attempt machine maintenance or cleaning unless the power supply plug has been removed from the supply outlet.
• Use in wet environments or to collect wet materials.
• Under any circumstances place foreign objects including (but not limited to) air fresheners, air freshener capsules
or scented beads of any type into the top  lter of the machine. Doing so can be dangerous and risk damage to the
machine and may invalidate the machine warranty.

604015
240 Drum HepaFlo Dust Bags
(Pack of 10) NVM-1CH
604016
370/380 Drum HepaFlo Dust
Bags (Pack of 10) NVM-2BH
For best performance make sure
you use genuine
Numatic bags
HepaFlo Dust Bags
Schematic Diagram
Notes
........................................................................................................
........................................................................................................
........................................................................................................
........................................................................................................
........................................................................................................
........................................................................................................
........................................................................................................
........................................................................................................
........................................................................................................
........................................................................................................

910104 05/21 (A09)
Numatic International Limited.
Chard, Somerset TA20 2GB ENGLAND
Tel.: [phone] www.numatic.co.uk
Specication subject to change without prior notice
