Numatic NVQ 240-21 User manual

Original Instructions -Original Instructions -
CAUTION, Read instructions before using the machine.CAUTION, Read instructions before using the machine. www.numatic.co.uk
GB
NVQ 240-21, NVQ 370-21
NVQ 380-21, NVQ470-21
NQS 250-21, NQS 250B-21
NQS 350-21, NQS 350B-21

Kit- AS0 / AH0
Assembly
NVQ 380 / NVQ 470 only - Kit AS0 c/w 601101

Using your machine
NQS 250B
NQS 350B

9
Cleaning
12
3
4
5
1
10
876
2

470 Handle Fitting
NuCable

Wand Docking / Tool Tidy
200 drum only 200 drum only
TriTex Filter, Primärlter, Filter, Filter
604165 TriTex Filter
HepaFlo Dust Bags, Gleitschiene, Filtre, Zakken
604015 240 / 250 NVM 1CH Dust Bags (Pack of 10)
604016 370 / 380 NVM 2BH Dust Bags (Pack of 10)
604018 470 NVM 3AH Dust Bags (Pack of 10)
370 drum only 370 drum only

HO5-VV-F 10 x 2 Core x 1.00 mm2
HO5-VV-F 10 x 3 Core x 1.00 mm2
Failure to rectify the problem or in the event of a breakdown contact your Numatic dealer or the
Numatic Technical helpline [phone]
Safety Critical Components
Mains leads:
Rating Label
About your machine (GB)
PPE (personal protective equipment). That may be required for certain operations.
Ear Protection Safety Footwear Head Protection Safety Gloves
Eye Protection Protective Clothing Dust / Allergens
Protection Hi Viz Jacket Caution Floor Sign
NOTE: A risk assessment should be conducted to determine which PPE should be worn.
WEEE Legislation (Waste, Electrical and Electronic Equipment)
Vacuum cleaner, accessories and packaging should be sorted for environmentally - friendly
recycling.
(Only for UK/EU Countries)
Do not dispose of vacuum cleaner into household waste! According to the European Directive
2012/19/EU on waste electrical and electronic equipment and its incorporation into national law.
Vacuum cleaners that are no longer suitable for use must be separately collected and sent for
recovery in an environmentally - friendly manner.
1Company Name & Address
2Model
3Voltage / Alternating Current
4Frequency
5Rated Input Power
6Weight
7WEEE Logo
8Protection Class 2 Symbol
9Approval Mark
10 Machine yr/wk Serial Number
Maintenance
Daily
Keep the machine clean, including hoses and tubes.
Ensure the bag and  lter are  tted.
Regularly examine the power cord.
Check dust bag frequently.
Check  lters are clean.
Weekly - as daily and:-
Check for any worn or damaged parts and replace immediately.
1
2
3
4
5
6
7
8
9
10

Information for DRY use Vacuum cleaners
WARNING
Read the instruction manual before using the machine.
Operators shall be adequately instructed on the use of their machine.
As with all electrical equipment, care and attention must be exercised at all times during use, in addition to ensuring that
routine and preventative maintenance is carried out periodically to ensure safe operation.
Failure to carry out maintenance as necessary, including the replacement of parts to the correct standard could render
this equipment unsafe and the manufacturer can accept no responsibility in this respect.
Maintenance should only be carried out by a quali ed person.
This machine is for DRY USE only and must not be stored outside or used in wet conditions.
The machine shall be disconnected from the mains power by removing the plug from the power supply socket during
cleaning or maintenance and when replacing parts or converting the machine to another function.
Only use the socket outlet on the machine for purposes speci ed in the instructions (if  tted).
This machine is not to be used by children or persons with reduced physical, sensory or mental capabilities, or lack of
experience or knowledge.
This appliance is intended to be cleaned and maintained by an adult.
Children being supervised are not to play with the machine.
This machine is not a toy.
This machine is not suitable for picking up hazardous or explosive dust.
Contact your local distributor if you require a machine capable of performing these tasks.
CAUTION
Ensure that the  ltration system  tted to the machine is suitable for the material being collected.
This vacuum cleaner is intended for indoor use in the collection of dry materials.
This machine should be stored indoors only.
NOTES
The primary use for this machine is commercial, for example in hotels, schools, hospitals, factories, shops and offi ces.
This product complies with the requirements of clause 20 of IEC/EN 60335-2-69 Stability and Mechanical Hazards.
This vacuum cleaner is  tted with a thermal protection device. If the vacuum cleaner stops working, remove the plug
from the wall before investigating where the fault lies.
If the vacuum cleaner has a blockage, switch off , remove the plug from the power socket, inspect the fl oor tool, tubes
and hose for debris. If the fl oor tool, tubes and hose are clear, replace the dust bag and clean the  lter.
The vacuum cleaner should be inspected after use for damage.
The vacuum cleaner should be stored in a dry place.
When moving from one place to another, consider the weight of the machine.
DO
• Keep your machine clean including hoses and tubes.
• Change dust bag frequently.
• Keep  lters clean.
• Keep diff user  lter (where  tted) clean.
• Use  lter bags, they will enhance performance and help keep machine clean.
• Use a Numatic Original  lter bag under  ne dust conditions.
• Keep hoses and tubes clear.
• Replace any worn or damaged parts immediately.
• Only use the brushes provided with the machine. The use of other brushes may impair safety.
• Regularly examine the power cord. If damage is found such as cracking or ageing the power cord must be
replaced by a quali ed person.
• Only replace the power cord with the correct Numatic approved replacement part.
DO NOT
• Pull on the cable to unplug the machine from the power supply.
• Use to suck up hot ashes or lighted cigarette ends.
• Use steam cleaners or pressure washers to clean the machine or use in the rain.
• Immerse in water for cleaning.
• Attempt machine maintenance or cleaning unless the power supply plug has been removed from the supply outlet.
• Use in wet environments or to collect wet materials.
• Under any circumstances place foreign objects including (but not limited to) air fresheners, air freshener capsules
or scented beads of any type into the top  lter of the machine. Doing so can be dangerous and risk damage to the
machine and may invalidate the machine warranty.

Schematic Diagram
1 2 3 4 5 6
NVQ 240-21
NVQ 370-21
NVQ 380-21
NVQ 470-21
NQS 250-21
NQS 250B-21
NQS 350-21
NQS 350B-21
9 L
15 L
15 L
27 L
9 L
9 L
14 L
14 L
26.4
m
9.65 kg
10 kg
12 kg
12 kg
10 kg
10 kg
13.6 kg
14 kg
75 dB
(A)
0.5 dB
Class I
Class
II
360 mm x 370 mm x 415 mm
355 mm x 355 mm x 485 mm
355 mm x 355 mm x 485 mm
360 mm x 450 mm x 655 mm
340 mm x 340 mm x 395 mm
340 mm x 340 mm x 395 mm
395 mm x 350 mm x 560 mm
395 mm x 350 mm x 560 mm
1 2 3 4 5 6
Drum Size Cleaning
Range
Weight
(Ready to
work)
Sound Pressure (LpA)
Uncertainty (KpA)
Protection
Class Dimensions
Data
For best performance make sure you use genuine Numatic bags
604015
240 / 250 Drum HepaFlo Dust
Bags (Pack of 10) NVM-1CH
604016
370 / 380 Drum HepaFlo Dust
Bags (Pack of 10) NVM-2BH
604018
470 Drum HepaFlo Dust Bags
(Pack of 10) NVM-3AH
HepaFlo Dust Bags

233058 08/16 (A03)
Numatic International Limited. Chard, Somerset, TA20 2GB
Telephone: [phone] Fax: [phone]
© Numatic International Limited 2016
Numatic International Limited warrant to the original purchaser that its products
are free of defects in both material or workmanship for the period shown below:-
Homecare and Cleancare Vacuum cleaners........................................ 2 Years
Rotary Floor Machines.......................................................................... 2 Years
Twintec Auto Scrubber Dryer................................................................ 1 Year
Mopping, Compacts, Combi and Servocare Products......................... 1 Year
Individual Accessories and Spare Parts........................................... 6 Months
Note: This warranty expressly excludes consumable parts such as carbon
brushes, oor brushes, mops, batteries etc, that are considered replaceable from
time to time during the normal working life of the machine.
A. The warranty period commences from the date the goods are purchased.
B. All warranty claims must be processed through the Dealer from whom the
equipment was purchased. The Dealer will co-operate with the purchaser
throughout the warranty claims procedure and will arrange any necessary repairs
using genuine Numatic parts.
C. If the original Dealer is no longer able to full his obligations please contact
Numatic International Limited with full details of the claim and proof of purchase
so that this may be processed without delay.
D. Any warranty claim can only relate to the specic part that is proven to be at
fault and for which a replacement will be supplied but cannot be extended to
constitute a claim against the complete machine.
E. Numatic International will supply the Dealer with any warranty parts required,
subject to the claim being validated, after return of the faulty items in accordance
with Numatic International Limited’s General Conditions of Sale.
F. Claims will not be accepted if they are the result of fair wear and tear, misuse
or abuse of any kind.
G. No replacement will be given unless the appropriate evidence of the validity of
the claim has been provided to the satisfaction of Numatic International Limited.
H. Numatic International Limited reserve the right to charge for any unnecessary
work carried out as a result of an invalid claim.
I. No variation to this warranty may be made or implied by any member of Numatic
International Limited or its Dealers unless such variation is in writing and
authorised by the Company.

DEC-021 V3.0
EU, EC, EL, UE, ES: Declaration of Conformity Prohlášení o shodě Konformitätserklärung Overensstemmelseserklæring Declaración de conformidad Vastavusdeklaratsioon Déclaration de conformité
