Just one look at the Cleancare
model range will tell you that it
is different... different in design,
different in concept and
different in execution, whilst at
the same time incorporating a
wealth of technology and
innovation, both old and new,
that will confirm again and
again that it is these very
differences that are so vitally

Our character range of smaller cleaners
is really different in looks but, at
the same time, it is bristling with
unique and sometimes patented
features that are the result of 30
years of experience.
Within the full programme you
will find professional models
to suit a whole range of
applications,
commercial and
industrial, with each series of
equipment engineered to the highest of
constructional and operational standards.
The exciting use of Structofoam and
stainless steel is evident in many
designs and the use of our unique
Twinflo’ professional motors
provides truly outstanding
performance and reliability
throughout the range.
By design the Cleancare range
is vast, ensuring that in
selecting your own equipment
specification there is no
need for compromise.
Let us not forget:-
Good selection
at the onset is
key to good
operational
performance.

Numatic International with the
introduction of Henry and his happy but
cheeky little smile more than 25 years
ago, have now come to truly understand
just how much our commercial and
consumer customers appreciate the
unique individual character concept,
with more than 5,000,000 in use
worldwide.
We have also learned that it is not simply the
character that has endeared the Henry concept to the customers
but more so the full professional specification of the machine’s design.
We must all be reminded that the Henry machine and concept was created for professional
users in the first instance... being used in hospitals, hotels, shops and schools, not to mention
buses and boats, trains and planes and it was from this beginning that his reputation grew
and his fame spread, both nationwide and worldwide, to all those demanding sound common
sense engineering and improved professional performance... the smile was a bonus!
What we did not fully appreciate all those years ago was the simple fact that the user of an animate
object, a character like Henry, would take such
pride looking after the product, treating it as
they would their own, almost as one of the
family so to speak; resulting in a much extended
trouble free life and giving a whole new
meaning to the expression:-
4

Whoever you are, there is always a truly fast and friendly professional
machine ready to help you with all your cleaning duties.
Today we manufacture the NRV and NVP range with character
faces as standard and with other models, as shown in the catalogue,
the face is supplied for self application allowing the user to decide
which style is preferred.
The Friendly Professional range
5

A1
The 200 series has all the many features of the Henry
design with full professional Twinflo' power and performance;
Hi-Lo operation; Tritex filtration but with the addition of our extended
commercial 12.5 metre cable rewind and storage system.
There are two variations of this model, the 200 with its full range of
standard accessories and the 200T, TurboElectric, with its own unique
24 volt floating power brush system adjusting automatically to
varying floor surfaces. The ideal choice for
extensive carpet care.
Whichever of the 200s suits your
specific needs you can be sure of excellent
professional results.
1200W 45 L/sec 2600mm 24v 9L 31.8m 7.3Kg 355 x 355
x 415mm
230V
AC 50/60Hz
Motor Power Airflow Suction Brush Capacity Range Weight Dimensions
T20
1200W 45 L/sec 2600mm 9L 31.8m 6.9Kg 355 x 355
x 415mm
230V
AC 50/60Hz
Motor Power Airflow Suction Capacity Range Weight Dimensions
NRV200T-2
NRV200-22
Character faces as standard. Also available 115V/120V specification.
NRV200-22
Kit-A1
NRV200T-2
Kit-T20
6

Professionals being exactly that, take the time to consider each
and every feature of a machine in making their preferred
choice and this decision-making is even more pronounced
in the NRV-370 and 380 series which, by virtue of
being 66% greater in capacity, will end up working
longer hours... day in day out.
The NRV-370 is the big brother to the NRV-200 with the
same superb Twinflo' power and performance; Hi/Lo
operation; 12.5-metre cable system, but with an additional 66%
capacity... a full commercial standard.
The NRV-380 is the smallest model in our range to be supplied
with its own Structofoam container... this, in itself, is warranteed
for 3 years and can take a beating 24 hours a day if necessary.
Structofoam is an exclusive Numatic formulation providing
unrivalled strength and impact qualities, without suffering a
weight penalty and used extensively
throughout our bigger machines.
Two machines... both
15 litre capacity; one
truly professional
and one heavy-duty
professional... the choice is
yours.
A1
1200W 45 L/sec 2600mm 15L 31.8m 355 x 355
x 465mm
230V
AC 50/60Hz
Motor Power Airflow Suction Capacity Range Weight Dimensions
370 = 7.5Kg
380 = 8.6Kg
NRV370 face as standard, NRV380 supplied with our exclusive, easily applied face. Also available 115V/120V specification.
NRV380-22
NRV370-22
NRV370-22
NRV380-22
7

1200W 45 L/sec 2600mm 8L 26.8m 5.8Kg 340 x 340
x 350mm
230V
AC 50/60Hz
Motor Power Airflow Suction Capacity Range Weight Dimensions
NPH1
Character faces as standard. Also available 115V/120V specification.
The NVP-180 is designed as the most compact model within our commercial range yet
totally without compromise.
Full Twinflo' professional power; Tritex filtration; 10-metre plugged
replaceable cable; big 8 litre capacity, small in size, light in weight,
but big in performance.
There is only one control... the On/Off switch... but once selected
you will have power in abundance for continuous commercial operation.
The unique caddy top is simply brilliant and
so practical, somewhere for the cable,
your tools and even a duster and polish, right where you
need them, when you need them, each and every time.
Accessories are everything that is required to a professional
standard, right down to the convenient microlight aluminium
tube set and full size combination nozzle.
This is commercial cleaning just as it should
be... simple but sound.
Twinflo’
8

Two machines both of the same professional design concept
but providing a choice of 9 litre or 15 litre capacity.
In the first instance the specification is to the highest
standard... a full two-stage Twinflo' motor providing
superb long life performance; Tritex filtration; the
Nucable 10-metre plugged cable system allowing
easy replacement in the event
of accidental damage... all in all
a high performance, thoroughly practical
design.
The unique caddy top makes sound common
sense... somewhere for the cable and, during
operation, somewhere for the small tools, a duster and perhaps
polish, always there when you need it.
Both the 9 litre and 15 litre containers are fitted with a 4-wheel
mobility system ensuring stability and skid free movement
over all surfaces.
The accessory kit is everything
that it should be but we
have been extra
thoughtful to the
user, providing our
microlight aluminium tube
set and full size combination
floor nozzle as standard.
NPH1
1200W 45 L/sec 2600mm 26.8m
355 x 355x 430mm
355 x 355x 480mm
230V
AC 50/60Hz
Motor Power Airflow Suction Capacity Range Weight Dimensions
200 = 6.1Kg
370 = 6.4Kg
200 = 9L
370 = 15L
Character faces as standard. Also available 115V/120V specification.
NVP370-2
NVP200-2
NVP200-2
NVP370-2
9

The Q series is built to an exacting professional standard,
having gained their outstanding specification from more than
20 years of commercial operation.
The deep-drawn steel power head incorporates
our patented Microtec noise reduction system;
the Twinflo' high performance motor; a Hi/Lo
operation control and our exclusive Nucable replaceable
plugged cable feature.
Both machines incorporate Tritex primary filtration and are
equipped with our skid free mobility and stability package.
The NVQ-200 has a capacity of 9 litres with the NVQ-370
increased by 66% to 15 litres.
Both machines have a fully comprehensive accessory kit
with nothing spared and including stainless steel
in both the tube set and the
full size combination
floor nozzle.
The NVQ-200
and NVQ-370 will not only
impress the users but
equally those around them.
A1
1200W 45 L/sec 2600mm 26.8m
355 x 355 x 435mm
355 x 355 x 485mm
230V
AC 50/60Hz
Motor Power Airflow Suction Capacity Range Weight Dimensions
200 = 7.8Kg
370 = 8.1Kg
200 = 9L
370 = 15L
Our exclusive, easily applied happy face is supplied with each machine, one look tells you it really does make all the difference. Also available 115V/120V specification.
NVQ370-22
NVQ200-22
NVQ200-22
NVQ370-22
10

1200W 45 L/sec 2600mm 15L 26.8m 8.5Kg 355 x 355
x 485mm
230V
AC 50/60Hz
Motor Power Airflow Suction Capacity Range Weight Dimensions
T20
When it comes to extensive carpet care there are two fundamental requirements: a really
high performance efficient cleaner design and an efficient powered floor nozzle.
In the NVQ-370 Turbo you have everything that is needed plus numerous additional
features.
The power head is all-steel incorporating our patented Microtec
sound reduction system and the high performance Twinflo'
motor system.
The primary Tritex filtration makes sure that what goes
in stays in and the container, with its full 15 litre
capacity, is equipped with our skid free 4-wheel
mobility and stability package.
The TurboElectric power brush system is truly unique
with its 24 volt floating brush design automatically
adjusting to varying floor surfaces.
A fully comprehensive range of additional
accessories is supplied as standard.
Our exclusive, easily applied happy face is supplied with each machine, one look tells you it really does make all the difference. Also available 115V/120V specification.
11

The NVQ-380 really does incorporate the best of all worlds in commercial terms. On the
top you have the advanced all-steel deep-drawn power head incorporating our Microtec
sound reduction system; the superb Twinflo' high performance motor; a Hi/Low control
system and the Nucable plugged replaceable cable facility.
The filter system is nothing less than 3-stage Tritex making sure that
what goes in stays in. The container is our exclusive
Structofoam and this, in itself, is warranteed for 3
years providing exceptional strength with no weight
penalty. Structofoam is used extensively in our bigger
machines having proved itself year in, year out for
more than two decades.
The accessory kit is also to an exceptional standard
incorporating a comprehensive range of tools.
The end result is a powerful, quiet, exceptionally
strong machine that is genuinely hard to beat.
A1
1200W 45 L/sec 2600mm 15L 26.8m 9.5Kg 355 x 355
x 485mm
230V
AC 50/60Hz
Motor Power Airflow Suction Capacity Range Weight Dimensions
Our exclusive, easily applied happy face is supplied with each machine, one look tells you it really does make all the difference. Also available 115V/120V specification.
12

13
The cleaning of today’s fleet of aircraft worldwide has its own
special requirements which are embodied into the Aircraft
Model range. When you think about the problem, it is
enormous.
You’ve got areas almost as big as a tennis court,
housing hundreds of people, covered in seats which
form obvious obstructions to normal cleaning,
and to cap it all, the aircraft has it’s own power
supply at 115V/400Hz.
The Numatic Aircraft vacuum cleaner range has taken all
these considerations into account and are used extensively
throughout the world.
There are two models in the range, both rugged and compact,
both designed to work effectively in these highly specialised
areas, ensuring quick and efficient cleaning,
which is of course a prime requirement.
The Aircraft Accessory Kit incorporates 38mm
hoses and stainless steel tubesets as standard
in order to ensure optimised performance,
whilst the compact suction
nozzle is able to get in and
out of all those nooks
and crannies.
There is also an
Aircraft RSV (RucSac)
model built to the same 110V/400Hz specification
- model RSAV130. See page 20 for full specifications.
BB15
1200W 45 L/sec 2600mm 43.2m
340 x 340 x 395mm
355 x 355 x 485mm
115V
400Hz
Motor Power Airflow Suction Capacity Range Weight Dimensions
250 = 8.5Kg
380 = 9.5Kg
250 = 9L
380 = 15L
AVQ380-2
AVQ250-2
AVQ250-2
AVQ380-2

A1
1200W 45 L/sec 2600mm 12L 26.8m 8.9Kg 355 x 355
x 485mm
230V
AC 50/60Hz
Motor Power Airflow Suction Capacity Range Weight Dimensions
When good is not good enough, the certified microfilter machine provides an exceptional
99.97% efficiency standard but totally without loss of convenience and usability.
The power head itself has all the technical features of the Q series,
low noise levels; Twinflo' performance and Hi/Low operation, but
by careful design the HEPA microfilter module has been incorporated
into the head design - ensuring that this machine, that often must
be used in critical areas, is no larger than the truly convenient size
of a standard professional 370.
The accessory kit is comprehensive and to an equally high standard in every respect.
In any application where the dust present might be considered injurious to health,
specify the MFQ and be safe.
Twinflo’
Also available 115V/120V specification.
14

15
A1
1200W 45 L/sec 2600mm 12L 26.8m 9.3Kg 355 x 355
x 485mm
230V
AC 50/60Hz
Motor Power Airflow Suction Capacity Range Weight Dimensions
There is, within many specialized operations, the need for a compact vacuum cleaner
that can meet the Clean Room Class 100 specification.
In developing the CRQ370 machine we have taken full account of
the high filtration requirements whilst, at the same time, ensuring
that the machine itself is, in every way, as convenient and user
friendly as a standard model.
The 5-stage HEPA filtration design provides a certified operational
performance of 100% down to a particle size of 0.1um without loss
of power or performance.
The standard accessory kit supplied is complete for normal cleaning operation, but there
is also a wide range of specialised tools and accessories should they be required for
special uses.
Also available 115V/120V specification.

The all-steel construction of today's NQS models is where the Numatic story started.
We learnt from the 250 that the commercial cleaning business was rough and tough but,
having said that, the majority of our early machines are still working 20+ years later.
After all those years the NQS-250 is better than ever, the all-steel deep-drawn power
head incorporates our patented Microtec noise reduction system; Twinflo' performance
is superb - too good sometimes - so we fitted a Hi/Lo control so you can turn the power
down if necessary. The Nucable plugged replaceable cable system is standard as is the
blower facility and diffuser attachment.
Filtration is to our Tritex standard and the container is also a single
deep-drawn steel pressing with superb 4-wheel mobility and
stability.
The standard accessory kit is to the same high standard, even
down to stainless steel tubes and full size combination floor
nozzle.
Without doubt, yesterday's quality standards to which we have
added many improved features - resulting in tomorrow's
performance standards. The best of both worlds.
A1
1200W 45 L/sec 2600mm 9L 26.8m 8.3Kgs 340 x 340
x 395mm
230V
AC 50/60Hz
Motor Power Airflow Suction Capacity Range Weight Dimensions
Our exclusive, easily applied happy face is supplied with each machine, one look tells you it really does make all the difference. Also available 115V/120V specification.
16

Not just tough... very tough, this is the model that proved itself to outlast the rest in the
most arduous of applications.
The all-steel power head is low noise level; Twinflo' performance; Hi/Lo operation and,
in every way, just about as good as you can get, even down to the Nucable plugged
replaceable cable system and a standard blower facility.
Filtration is to our Tritex standard with the added advantage
of giant Microflo' 15 litre dust bags, easy clean emptying.
The all-steel container is mounted on, but removable from,
a rugged tubular chassis which really does give it go-
anywhere mobility.
A full range of accessories to an equally high standard is
supplied which can be upgraded from the standard 32mm
(1
1
/ 4 ") to 38mm (1
1
/ 2 ") as required.
A1
1200W 45 L/sec 2600mm 14L 26.8m 11.7Kgs 395 x 350
x 560mm
230V
AC 50/60Hz
Motor Power Airflow Suction Capacity Range Weight Dimensions
Our exclusive, easily applied happy face is supplied with each machine, one look tells you it really does make all the difference. Also available 115V/120V specification.
17

BB2
NVQ 1200W 45 L/sec 2600mm 23L 26.8m 13.8Kgs
NVDQ 2400W 90 L/sec 2600mm 23L 26.8m 16.0Kgs 415 x 415
x 645mm
230V
AC 50/60Hz
Model Motor Power Airflow Suction Cap Range Weight Dimensions
These were the first models designed and manufactured completely in Structofoam and
they have proven themselves to be the complete answer to engineering integrity.
Structofoam is our unique material specification that has superb strength and impact
resistance allowing machines to be truly rugged yet without a weight penalty.
Power and performance are to the full Twinflo' standard with a choice of one or two-
motored specifications. All models are equipped with dual 2-stage primary filter systems
as standard, to which can be added giant Microflo' dust bags if required.
The rugged Structofoam container is mounted on 4 x 75mm (3") non-marking, heavy-
duty castors and the compact size makes it ideal for numerous trades where it must
frequently be moved from place to place such as builders, shop fitters, contractors etc.
The accessory kit is full 38mm (1
1
/ 2 ") with stainless steel tube sets and even the 400mm
(16") floor nozzle is a Structofoam design.
For a middle range machine size, the specification, performance and convenience
of the 570's would be difficult to beat.
1
2
NVDQ570-2
NVQ570-22
Also available 115V/120V specification.
18

BB2
The 900 series sets an entirely new standard in design and construction of industrial
vacuum cleaners, built by professionals to ensure high performance coupled with reliability
and long service life.
The exciting use of Structofoam throughout this machine really makes it as strong as a
truck, whilst its innovative design makes it every bit as easy to use as smaller machines.
Power and performance are to the full Twinflo' specification and there is a choice of one
or two-motored models with a dual 2-stage primary filter system as standard.
The rugged container is classic Structofoam engineering and the giant wheels and heavy-
duty castors provide excellent mobility and transit even in the most demanding applications.
The standard 38mm (1
1
/ 2 ") accessory kit includes our extra long double swivel hose;
stainless steel tubes; 400mm (16") Structofoam floor nozzle and additional useful
accessories.
The innovative yet thoroughly practical design of the 900's is really different, but
it is that difference that really counts.
NVQ 1200W 45 L/sec 2600mm 40L 26.8m 22.5Kgs
NVDQ 2400W 90 L/sec 2600mm 40L 26.8m 25.0Kgs 800 x 490
x 880mm
230V
AC 50/60Hz
Model Motor Power Airflow Suction Cap Range Weight Dimensions
NVDQ900-2
NVQ900-22
Also available 115V/120V specification.
19

A30A
When it comes to congested environments there can be no doubt that the practical features
of the RSV (Ruc Sac Vac) brings with it great advances in convenience cleaning, producing
vastly improved results by virtue of the old adage "the right machine for the right job". In
many countries Ruc Sac cleaning has become commonplace with substantial
improvements in cost effective operation.
The Ruc Sac range of vacuum cleaners comes in two prime
sizes, the larger 9-litre 200 and the smaller 6-litre 130, both
sharing many of the advanced design features.
Particular attention has been paid to user comfort, convenience
and safety with an ergonomically designed, comfortable harness
system; lighter weight and lower noise levels.
The RSV's performance is excellent, with the extra large filter
system and 2-stage Microflo' disposable dust bags ensuring
continuous operation and clean and easy emptying. The standard
accessory kit incorporates all that is needed for quick and efficient
cleaning of all surfaces.
The RSV130 is also available to a full Aircraft 110V/400Hz specification - model
reference RSAV130. See page 13.
RSV130 1100W 40 L/sec 2400mm 6L 31.4m 6.0Kgs 440 x 360 x 250mm
RSV200 1100W 40 L/sec 2400mm 9L 31.4m 6.3Kgs 500 x 360 x 250mm
230V
AC 50/60Hz
Model Motor Power Airflow Suction Cap Range Weight Size
Also available 115V/120V specification.
RSV200-1
RSV130-1
20
