Numax SE12D User manual

SE12D-V1 03/19
Failure to follow warnings could result in DEATH OR SERIOUS INJURY.
WARNING:
SAVE THIS MANUAL FOR FUTURE REFERENCE.
MODEL: SE12D
12V CORDLESS DRILL
• HTTP://WWW.NUMAXTOOLS.COM
• 1-888-669-5672
• PRIME GLOBAL PRODUCTS, INC.

TOOL USE AND CARE
Know this tool. Read this manual carefully, learn
its applications and limitations, as well as the
specific potential hazards related to this tool.
Always have a firm footing and grip on the tool to
counteract any force that may be enacted during
the operation of the tool.
Practice safe working practices and ensure all
relevant legal requirements are being followed
when using this tool.
Before adjusting, changing accessories, or
storing the tool; disconnect the tool from the
battery. This will reduce the risk of injury from
the power tool.
Check for misalignment or binding of moving
parts, breakage of parts, and any other condition
that may affect the tool’s operation. If damaged,
have the tool serviced before using.
Do not use the tool for anything other than its
intended use.
Do not use the tool if the trigger does not
actuate properly. Any tool that cannot be
controlled with the trigger is dangerous and must
be repaired.
Keep the tool and its handle dry, clean and free
of oil and grease. Always use a clean cloth when
cleaning. Never use brake fluids, gasoline,
petroleum-based products, or any strong
solvents to clean your tool.
MODEL: SE12D
WARNING:
HTTP://WWW.NUMAXTOOLS.COM 1-888-669-5672
GENERAL SAFETY RULES
FEATURES
UNPACKING
INSTALLING/REMOVING BATTERY PACK
1
2-3
3-4
4
4
4-5
4
4
4
4
5
5
5
5
6
VARIABLE SPEED SWITCH TRIGGER
ROTATION DIRECTION SWITCH (FORWARD / REVERSE / LOCK)
LED LIGHT
CHARGING THE BATTERY
INSTALLING BITS
DRILLING/DRIVING SCREWS
OPERATION
MAINTENANCE
WARRANTIES
01
MODEL: SE12D
These signal words are intended to explain the levels of risk associated with this tool and are included
in this manual, on the labels, packages and all other information provided with this tool.
SYMBOLS
SYMBOLS
SIGNAL MEANING
WARNING: Indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided,
may result in minor or moderate injury.
(Without symbol) Indicates a situation that may result in
property damage.
CAUTION:
CAUTION:
GENERAL SAFETY RULES
WORK AREA
Keep the work area clean and well lit.
Cluttered benches and dark areas increase the
risk of accidents.
Do not operate the tool in explosive
atmospheres, such as in the presence of
flammable liquids, gasses or dust. The tool
creates a spark which may ignite flammable
liquids, gases or dust.
Keep bystanders, children, and others away
while operating the tool. Distractions could
result in improper use and cause injury.
Do not use on a ladder or unstable supports.
Stable footing on a solid surface enables better
control of the tool in unexpected situations.
Avoid prolonged use. The tool’s repetitive
motion and vibration can cause harm to your
hands or arms. The user can use gloves for
extra cushion, take frequent breaks and limit
daily use to prevent this issue.
This tool vibrates with use. Continuous
operation can be harmful to your hands and
arms. Stop using the tool if you feel tingling or
pain. Resume work after recovery. Seek
medical advice if serious symptoms occur.
Make sure there are no hidden electrical
cables, gas pipes, etc. while working on the
work piece. These hazards could harm the user
if damaged while using this tool.
Wash hands after handling this product or its
power cord. They may contain chemicals
known to the State of California to cause
cancer and birth defects or other reproductive
harm.
Do not overreach. Keep proper footing and
balance at all times. Proper footing and
balance enables better control of the tool in
unexpected situations.
Wash hands after handling.
HTTP://WWW.NUMAXTOOLS.COM 1-888-669-5672 02
This product can expose you to
chemicals including lead, which is
known to the State of California to cause
cancer and other birth defects or other
reproductive harm. For more information
go to www.P65Warnings.ca.gov.
PERSONAL SAFETY
Always wear eye protection. Operator and
others in the work area should always wear
ANSI-Z87.1 approved safety goggle with side
shields. Eye protection is used to guard against
flying debris, which may cause severe eye
injury.
Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing, and gloves
away from moving parts. Loose clothes,
jewelry, or long hair can be caught in moving
parts.
Stay alert. Do not use tool while tired or under
the influence of drugs, alcohol, or medication. A
moment of inattention while operating the tool
may cause serious injury.
Avoid prolonged use. The tool’s repetitive
motion and vibration can cause harm to your
hands or arms. The user can use gloves for
extra cushion, take frequent breaks and limit
daily use to prevent this issue.
CALIFORNIA PROPOSITION 65
To avoid serious personal injury, do not attempt to use this product until you read the manual
thoroughly and understand it completely. Save this manual and review frequently for safe operation
and instruction of other who may use this tool. Keep this manual for the safety warnings, precau-
tions, operations, inspections, and maintenance information. Store this manual and the receipt In a
safe and dry place for future reference.
The warnings and precautions discussed in this manual cannot cover all possible conditions and
situations that may occur. Please be aware of the potential hazards, and take all necessary
precautions to avoid risk of injuries.
WARNING:
SAVE THIS MANUAL
SYMBOLS
SPECIFICATIONS

WARNING:
WARNING:
This tool has been shipped completely
assembled.
Carefully remove the tool and any accesso-
ries from the box.
Inspect the tool carefully to make sure no
breakage or damage occurred during
shipping.
Do not discard the packing material until you
have carefully inspected and satisfactorily
operated the tool.
If any parts are damaged or missing, please
call 1-888-669-5672.
If any parts are missing do not operate
this tool until the missing parts are
replaced. Failure to do so could result in
possible serious personal injury.
WARNING:
Never change the speed while the
tool is running. Doing so may result
in serious damage to the tool.
Do not attempt to modify this tool or
create accessories not recommended for
use with this tool. Any such alteration or
modification is misuse and could result
in hazardous condition leading to
possible serious personal injury.
INPUT: 100-240V, 50/60Hz
BATTERY: 12V Max, 1.5Ah, 18Wh
CHUCK SIZE: 3/8”
NO-LOAD SPEED: 0-400/0-1,400 RPM
TORQUE: 0-115/265 IN-LB
POWERFUL MOTOR:
Delivers up to 265 ft-lb of torque and a free
speed up to 1,400 RPM.
VARIABLE SPEED TRIGGER:
Adjustable 2-speed plus reverse provides
precise control for a wide range of applications.
LITHIUM-ION BATTERY:
High-capacity 1.5Ah lithium-ion battery
features enhanced battery life.
COMPACT DESIGN:
Ergonomic design allows access to tight areas
and reduces fatigue.
LED LIGHT:
Bright LED light illuminates dimly lit work areas.
UNPACKING
SPECIFICATIONS
OPERATION
INSTALLING/REMOVING BATTERY
PACK
VARIABLE SPEED SWITCH TRIGGER
To install, simply slide the battery pack and
make sure the latch on the battery snaps in
place and battery pack is secured to the tool.
To remove, depress the latch on both sides of
the battery and pull out the battery pack.
The variable speed switch trigger delivers
higher speed with increased trigger pressure
and lower speed with decreased trigger
pressure.
To turn on the tool, depress the switch
trigger. To turn it off, release the switch
trigger and allow the tool to come to a
complete stop.
TWO-SPEED SELECTOR
The speed of the drill can be changed for
various applications. Push the selector button
to change to the desired speed.
LOW SPEED (0-400 RPM), push the speed
selector to display “1”
HIGH SPEED (0-1,400 RPM), push the speed
selector to display “2”
LED LIGHT
The LED light illuminates when the trigger is
depressed. The time-out feature will automati-
cally shut off the lights when the tool is not in
use.
ROTATION DIRECTION SWITCH
(FORWARD / REVERSE / LOCK)
Set the rotation direction switch in the OFF
(Center lock) position to lock the trigger and
help prevent accidental starting when not in
use.
Push the direction of rotation switch to the
left of the trigger for forward operation. Push
the switch to the right to reverse the
direction.
The tool will not run unless the direction of
rotation selector is pushed fully to the left or
right.
FEATURES
Keep the tool and its handle dry, clean and free
of oil and grease. Always use a clean cloth when
cleaning. Never use brake fluids, gasoline,
petroleum-based products, or any strong
solvents to clean your tool.
Never use gasoline or other flammable liquids to
clean the tool. Never use the tool in the presence
of flammable liquids or gases. Vapors could
ignite by a spark and cause an explosion which
will result in death or serious injury.
Do not use the tool as a hammer.
Never press the trigger of the tool when it is not
intended to be used.
Do not drop or throw the tool. Dropping or
throwing the tool can result in damage that will
make the tool unusable or unsafe. If the tool has
been dropped or thrown, examine the tool
closely for bent, cracked or broken parts. STOP
and repair before using or serious injury could
occur.
Only use accessories that are identified by the
manufacturer for the specific tool model.
Use of unauthorized parts or failure to follow
maintenance instructions may create a risk of
injury.
Tool service must only be performed by a
qualified repair personnel.
TOOL SERVICE
The charger’s power plug must match the outlet.
Never modify the plug or try to plug the tool into
an outlet that does not match the plug.
Avoid contact with grounded elements such as
metal tables, pipes, ranges or refrigerators.
Contact with these elements can put you at risk
of electrical shock.
When operating the tool keep tool away from
wet conditions. Wet tools can cause electrical
shock.
Always inspect electrical cord for damage before
and after use. A damaged cord can cause
electrical shock.
ELECTRICAL SAFETY
Do not store batteries in areas that can reach or
exceed 105°F. (Such as outside sheds or metal
buildings in the summer).
Only charge the battery with a charger recom-
mended by the manufacturer. Use of any other
charger may cause risk of injury or fire.
Do not use chargers for anything other than
charging manufacturer recommended batteries,
otherwise electric shock could occur.
Do not expose the charger to rain nor snow.
Make sure the charger’s cord is in an area where
it will not be damaged.
Extension cords should not be used unless
necessary. Improper use of an extension cord
can result in electric shock.
Do not place an object on top of the charger.
This could block ventilation slots and cause
excessive internal heat.
Do not use the charger if it has been subjected
to a hard blow, has been dropped, or damaged
otherwise. Take the charger to an authorized
repair center.
Do not disassemble the charger. If the charger
needs to be repaired take it to an authorized
repair center.
Before cleaning the charger make sure to unplug
it from any power source. This will reduce the
risk of an electrical shock.
BATTERY AND CHARGER USE
AND CARE
Only use batteries that are recommended for this
tool by the manufacturer. Use of any other
battery may cause risk of injury or fire.
When the battery is not in use, keep it away from
metal objects that could connect one terminal to
another. If the terminals are connected the
battery could cause fire or burns.
Keep the battery free of abusive situations, if a
battery is damaged it can eject battery liquid. If
you get in contact with the battery liquid, flush
the contact area with water. If your eye gets in
contact with the battery liquid, flush with water
and seek medical help. Battery liquid can cause
irritation or burns.
MODEL: SE12D
HTTP://WWW.NUMAXTOOLS.COM 1-888-669-5672
03
MODEL: SE12D
HTTP://WWW.NUMAXTOOLS.COM 1-888-669-5672 04

PRODUCT WARRANTIES
1-Year Professional Tool Warranty
The Numax Tool Limited Warranty extends exclusively to the original purchaser of the Numax Product,
beginning on the date of purchase. During the warranty period Prime Global Products, Inc. (PGP)
expressly warrants that the Numax Product is free from defect in materials and workmanship subject to
the exceptions and limitations contained herein. PGP shall at its own option repair, replace, or offer a full
refund for a Numax Product that has a defect in materials or workmanship.
A DATED SALES RECEIPT OR PROOF OF PURCHASE FORM THE ORIGINAL RETAIL PURCHASER IS
REQUIRED TO MAKE A WARRANTY CLAIM. Warranty registration is also required and can be accom-
plished through Online Product Registration at www.numaxtools.com and select PRODUCT REGISTRA-
TION. To make a warranty claim, the original purchaser must return the Numax Product, postage prepaid
and insured, with proof of purchase to PGP or any of its authorized service centers. For questions, please
call 1-888-669-5672. Other than the postage and insurance requirement, no charge will be made for
repairs covered by this warranty.
Warranty Exclusions
These Warranties do not apply where:
• Repairs or alterations have been made, or attempted, by others and/or the unauthorized use of
non-conforming parts or accessories.
• Repairs are required due to normal wear and tear.
• The Product has been abused, misused, improperly maintained or operated, including: the failure to
use clean, dry, regulated compressed air at the recommended pressure; accidents caused by use of the
Product after partial failure.
• The Product is used commercially in assembly lines or production lines. The Product is intended for use
by individuals and these warranties do not extend to such commercial uses.
NO WARRANTY, ORAL OR WRITTEN, EXPRESSED OR IMPLIED, OTHER THAN THE ABOVE
WARRANTY IS MADE WITH REGARD TO THIS NUMAX PRODUCT. ANY IMPLIED WARRANTIES WILL
BE LIMITED IN DURATION TO THE APPLICABLE WARRANTY PERIOD SPECIFIED ABOVE. SOME
STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE
ABOVE MAY NOT APPLY TO YOU. YOUR REMEDIES ARE SOLELY AND EXCLUSIVELY AS STATED
ABOVE. PGP SHALL IN NO EVENT BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT, OR
SPECIAL DAMAGES. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDEN-
TAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION DOES NOT APPLY TO YOU. IN NO
EVENT, WHETHER AS A RESULT OF A BREACH OF CONTRACT, WARRANTY, TORT (INCLUDING
NEGLIGENCE) OR OTHERWISE, SHALL PGP’S LIABILITY EXCEED THE PRICE OF THE PRODUCT
WHICH HAS GIVEN RISE TO THE CLAIM OR LIABILITY. ANY LIABILITY CONNECTED WITH THE USE
OF THIS PRODUCT SHALL TERMINATE UPON THE EXPIRATION OF THE WARRANTY PERIOD
SPECIFIED ABOVE. NO EMPLOYEE OR REPRESENTATION OF PGP, OR ANY DISTRIBUTOR OR
DEALER, IS AUTHORIZED TO MAKE ANY CHANGE OR MODIFICATION OF THIS WARRANTY.
All matters related to the sale and/or use of the Numax Product that is the subject of these limited
warranties, along with the construction and enforcement of the terms of these limited warranties
themselves, shall be subject to the laws of the state of Georgia. Any dispute arising out of the sale and/or
use of the Freeman Product that is the subject of these limited warranties shall be brought in Cherokee
County, Georgia. Purchase and/or use of the Numax Product, makes you subject to the benefits and
limitations of these limited warranties. Accordingly, any writ, judgment or other enforcement, obtained
from a jurisdiction, county, parish, state or federal court or other country, other than from the forum
identified above, shall be void and unenforceable against PGP.
These warranties give you specific legal rights. You may also have other rights which vary from state to
state.
THESE WARRANTIES ARE SUBJECT TO CHANGE WITHOUT NOTICE.
WARNING:
Allow battery to cool down before
charging if the battery is hot after
continuous use.
WARNING:
Remove the battery from the tool
for any inspection, maintenance,
and cleaning.
MAINTENANCE
INSTALLING BITS
Always remove the battery before inserting or
removing bits. Select the proper style and size bit
for the job. This tool is equipped with a spindle
lock. The chuck can be tightened with one hand,
creating higher grip strengths on the bit.
DRILLING/DRIVING SCREWS
To use the drilling mode; Rotate the torque
selector collar until the drill symbol: appears
in line with the arrow.
NOTE: A ratcheting sound may be heard when the
chuck is opened or closed. This is part of the
locking feature and does not indicate a problem
with the tool’s operation.
1. To open the chuck jaws, turn the sleeve in
counterclockwise direction.
When using drill bits, allow the bit to hit the
bottom of the chuck. Center the bit in the chuck
jaws and lift about 1/16” off the bottom.
When using screwdriver bits, insert the bit far
enough for the chuck jaws to grip the hex of the
bit.
2. To close the chuck jaws, turn the sleeve in
the clockwise direction. The bit is secure when
the chuck makes a ratcheting sound and the
sleeve won’t rotate any further.
CHARGING THE BATTERY
1. To charge the battery, simply insert the
charger cable to the battery charging port.
2. The battery indicator light should turn from
green to red when the battery is charging.
3. When the indicator light has turned green
the battery should be fully charged.
To use the driving mode: Rotate the torque
selector collar until the desired clutch setting
appears in line with the arrow. The adjustable
clutch, when properly adjusted will slip at a
present torque to prevent driving the screw too
deep into different materials and to prevent
damage to the screw or tool.
The torque specifications shown here are
approximate values obtained with a fully
charged battery pack.
1 - 3 For driving small screws
4 - 7 For driving screws into soft material
8 - 11 For driving screws into soft/hard materials
12 - 15 For driving screws into hard wood
16 - 18 For driving large screws
MODEL: SE12D
HTTP://WWW.NUMAXTOOLS.COM 1-888-669-5672
05
MODEL: SE12D
HTTP://WWW.NUMAXTOOLS.COM 1-888-669-5672 06
2
8
10 12
