Congratulations,
By purchasing the you have made an excellent choice.
The purchase of a professional espresso coffee-maker involves various elements of selection: the name of the manufacturing firm, the machine’s
specific functions, its technical reliability, the option of immediate and suitable servicing, its price. You certainly evaluated all these factors and then
made your choice: the model.
We think you have made the best choice and after every coffee and cappuccino you will be able to assess this.
You will see how practical, convenient and efficient working with con is.
If this is the first time you have bought a Nuova Simonelli coffee machine, welcome to high quality coffee-making; if you are already a customer of
ours, we feel flattered by the trust you have shown us.
Thanks of the preference.
With best wishes,
Nuova Simonelli s.r.l.

42
ENGLISH
2 Groups 3 Groups 4 Groups
NET WEIGHT 74 kg 164 lb 88 kg 194 lb 102 kg 225 lb
NET WEIGHT * 76 kg 168 lb 90 kg 198 lb - -
GROS WEIGHT 80 kg 176 lb 100 kg 220 lb 115 kg 254 lb
GROS WEIGHT * 82 kg 181 lb 102 kg 225 lb - -
POWER 4500 W 4500 W 5000 W 5000 W 5000 W 5000 W
POWER * 7300 W 7300 W 9100 W 9100 W - -
DIMENSIONS 815 mm 32 1\16” 1045mm 411\8” 1275 mm 50 3\16”
720 mm 28 5/16” 950 mm 37 3/8” 1180 mm 46 7\16”
565mm 223\16” 565 mm 223\16” 565 mm 223\16”
370mm 149\16” 370 mm 149\16” 370 mm 149\16”
565 mm 22 3/16” 565 mm 22 3/16” 565 mm 22 3/16”
C
TECHNICAL CHARACTERISTICS
D
H
A
B
A
B
C
D
H
A
B
C
D
H
A
B
C
D
H
A
B
C
D
H
A
B
C
D
H
A
B
C
D
H
* For version T3 only

43
ENGLISH
INDEX
TECHNICAL CHARACTERISTICS .......42
1. DESCRIPTION
S - V - DIGIT - T3 .......45
1.1 ACCESSORIES LIST.........................46
2. SAFETY PRESCRIPTION ..............47
3. TRANSPORT AND HANDLING..........50
3.1 MACHINE IDENTIFICATION ...................50
3.2 TRANSPORT ...............................50
3.3 HANDLING.................................50
4. INSTALLATION AND PRELIMINARY
OPERATIONS........................50
5. ADJUSTMENTS TO BE MADE
BY A
QUALIFIED TECHNICIAN ONLY.....52
5.1 FILLING BOILER MANUALLY .................52
5.2 PRESSURE SWITCH (version S and V)
/ PUMP (version S, V, Digit and T3)
ADJUSTMENT ..............................52
5.3 HOT WATER ECONOMISER ADJUSTMENT .....53
5.4 CLOCK BATTERY REPLACEMENT
(Digit and T3 version only) ...................53
5.5 PUSH-BUTTON PANEL REPLACEMENT ........53
6. USE...................................54
6.1 COMMISSIONING PROCEDURE
OR AFTER BOILER MAINTENANCE
(T3 VERSION) ..............................54
6.2 TURNING THE MACHINE ON..................54
6.2.1 AURELIA T3 and Digit .......................54
6.2.2 AURELIA V - S .............................55
6.2.3 AURELIA DIGIT - V - S WITH
LED SYSTEM (OPTIONAL)....................55
6.3 MAKING COFFEE ...........................56
6.4 USING STEAM..............................56
6.5 MAKING CAPPUCCINO ......................56
6.6 HOT WATER SELECTION.....................57
6.7 TIMED STEAM NOZZLE ......................57
7. PROGRAMMING AURELIA T3 and DIGIT ..58
7.1 KEY.......................................58
7.2 PROGRAMMING (USER Mode) ................58
7.3 PROGRAMMING (TECHNICIAN MODE) .........59
7.4 PROGRAMMING AURELIA V . . . . . . . . . . . . . . . . . . 68
7.5 PROGRAMMING AURELIA S . . . . . . . . . . . . . . . . . . 71
8. CLEANING ..........................73
8.1 SWITCHING OFF THE MACHINE...............73
8.2 CLEANING THE OUTSIDE OF THE MACHINE ....73
8.3 CLEANING THE STAINLESS
COFFEE-HOLDERS..........................73
8.4 CLEANING THE UNIT WITH THE AID
OF THE BLIND FILTER.......................73
8.5 CLEANING FILTERS AND FILTER-HOLDERS ....73
9. MAINTENANCE ......................74
9.1 RESIN AND SOFTENER REGENERATION .......74
10. Aurelia Digit MACHINE
FUNCTION MESSAGES................75
11. Aurelia V MACHINE
FUNCTION MESSAGES................77
12. Aurelia S MACHINE
FUNCTION
MESSAGES................78

44
ENGLISH

45
ENGLISH
Fig. 1
KEY
1Steam knob
2LCD Display
3Functions buttons
4Selections buttons
5Delivery unit buttons
6Steam knob
7Filter-holder
8Data plate
9Manual steam nozzle
10 Delivery unit
11 Main switch
12 2 coffees spout
13 Optical level
14 Pressure Gauge
15 Adjustable foot
16 Manual steam nozzle
17 Hot water nozzle
18 Electric cup-warmer
(steam cup-warmer, optional)
1. DESCRIPTION S - V - DIGIT - T3
14 13
8
7
6
9
11 1012
352 4
17
16
18
1
15

46
ENGLISH
Fig. 2
1.1 ACCESSORIES LIST
A11
A06
A07
A03
A02
A01
A05
A08
A04
A09
A10
A12
CODE DESCRIPTION 2 GROUPS 3 GROUPS 4 GROUPS
A01 Filling tube 3/8” 111
A02 Unit tub draining tube
Ø 20 mm - l. 150 cm 111
A03 Worktop draining
tube Ø 25 mm - l.
150 cm 111
A04 Filter-holder 345
A05 Double filter 234
A06 Single filter 111
A07 Blind filter 111
A08 Spring 345
A09 Double delivery spout 234
A10 Single delivery spout 111
A11 Coffee presser 111

47
ENGLISH
This book is an integral and essential
part of the product and must be given
to the user.
Read this book carefully. It provides
important information concerning
safety of installation, use and mainte-
nance.
Save it carefully for future reference.

After unpacking, make sure the appli-
ance is complete.
In case of doubts, do not use the
appliance, but consult a qualified
technician.
Packaging items which are potential-
ly dangerous (plastic bags, polysty-
rene foam, nails, etc.) must be kept
out of children’s reach and must not
be disposed of in the environment.

DANGER OF POLLUTION
Before connecting the appliance
make sure the rating plate data cor-
respond with the mains.

In particular you must ensure that the
size of the wiring cables is sufficient
to absorb power input.
The use of adapters, multiple sockets
or extensions is strictly forbidden. If
they prove necessary, call a fully
qualified electrician.

When installing the device, it is nec-
essary to use the parts and materials
supplied with the device itself.
Should it be necessary to use other
parts, the installation engineer needs
to check their suitability for use in
contact with water for human con-
sumption.

This appliance must only be used as
described in this handbook. The
manufacturer shall not be liable for
any damage caused due to improper,
incorrect and unreasonable use.

Fig. 3
Fig. 4
2. SAFETY PRESCRIPTION
This plate is on the front panel at the
top right hand side of the appliance.
The appliance must be installed by
qualified technicians in accordance
with current standards and manufac-
turer’s instructions.
The manufacturer is not liable for any
damage caused due to failure to
ground the system.
For the electrical safety of the appli-
ance, it is necessary to equip the
system with the proper grounding.
This must be carried out by a quali-
fied electrician who must ensure that
the electric power of the system is
sufficient to absorb the maximum
power input stated on the plate.
This appliance is not suitable for use
by children or persons with reduced
physical, sensory or mental capabili-
ties, or by persons with a lack of
experience or knowledge, unless
supervised or given instructions.

For appliances powered at 220-230 V,
the maximum impedance from the
mains must be no higher than 0.37
Ohm.

The machine must be installed in
compliance with the local health
standards in force for plumbing sys-
tems.
Therefore, contact an authorized
plumber.

The device needs to be supplied with
water that is suitable for human con-
sumption and compliant with the
regulations in force in the place of
installation. Theinstallationengineer
needs confirmation from the owner/
manager of the system that the water
complies with the requirements and
standards stated above.


48
ENGLISH
Before performing any maintenance
operations, the authorised service
engineer must switch off the machine
and open the phase disconnector.

For all cleaning operations comply
exclusively with the instructions
given in this booklet.

If the appliance breaks down or fails
to work properly, switch it off. Any
intervention is strictly forbidden.
Repairs should only be made by the
manufacturer or authorized service
centres.
Only original spare parts must be
used.
Failure to observe the above, could
make the appliance unsafe.

For installation, the qualified electri-
cian must fit an omnipolar switch in
accordance with the safety regula-
tions in force and with 3 (0,12) or
more mm (in) between contacts.

To avoid dangerous overheating,
make sure the supply cord is fully
uncoiled.

Do not obstruct the extraction and/or
dissipator grids, especially of the cup
warmer.

The user must not replace the appli-
ance supply cord. If the cord is dam-
aged, switch off the appliance and
have a qualified technician change
the cord.

Fig. 5
During installation, the mains power
system needs to be equipped with a
disconnector switch to cut off each
phase.

Single-phase appliances with current
above 15 A and three-phase appli-
ances sold without plugs are directly
wired to the mains power and there-
fore, it is not possible to use a plug.

Basic rules must be observed when
using any electric appliance.
In particular:
do not touch the appliance when
hands or feet are wet;
do not use the appliance when
barefoot;
do not use the appliance when
barefoot;
do not pull the supply cord out of
the socket to disconnect it from
the mains;
do not leave the appliance
exposed to atmospheric agents
(rain, sun, etc.);
do not let the appliance be used
by children, unauthorised staff or
staff who have not read and fully
understood the contents of this
handbook.

CAUTION
RISK OF ELECTRIC SHOCK
The maximum and minimum storage
temperatures must fall within a range
of [-5, +50]°C.

The operating temperature must be
within the range of [+5, +35]°C.

At the end of installation, the device is
switched on and taken to rated operat-
ing conditions, leaving it in a state in
which it is “ready for operation”.
The device is then switched off and the
whole hydraulic circuit is bled of the
first lot of water in order to remove any
initial impurities.
The device is then refilled and taken to
rated operating conditions.
After reaching the “ready for opera-
tion” condition, the following dispens-
ing operations are carried out:
- 100% of the coffee circuit through
the coffee dispenser (for more than one
dispenser, this is divided equally);
- 100%ofthe hot watercircuitthrough
the water dispenser (for more than one
dispenser, this is divided equally);
- opening of each steam outlet for 1
minute.
At the end of installation, it is good
practice to draw up a report of the
operations.


49
ENGLISH
CAUTION
RISK OF POLLUTION
Non disperdere la macchina
nell’ambiente: per lo smaltimento
rivolgersi ad un centro autorizzato o
contattare il costruttore che darà
indicazioni in merito.

CAUTION
RISK OF INTOXICATION
Use the steam nozzle with care and
never place hands below the jet of
steam.Do not touch the nozzle imme-
diately after use.

CAUTION
RISK OF BURNS OR SCALDING
We remind you that before carrying
out any installation, maintenance,
unloading or adjustment operations,
the qualified operator must put on
work gloves and protective footwear.

If no longer using the appliance, we
recommend making it inoperative;
after removing the plug from the
mains electricity, cut the power sup-
ply cable.

Fig. 6
Fig. 7
INFORMATION TO THE USERS
Under the senses of art. 13 of
Law Decree 25th July 2005, n.
151 “Implementation of the
Directives/ Guidelines 2002/95/
CE, 2002/96/CE and 2003/108/
CE, concerning the reduction
of theuse ofdangeroussubstancesinelectric
and electronic equipment, as well as the dis-
posal of wastes“.
The symbol of the crossed large rubbish con-
tainer that is present on the machine points out
that the product at the end of its life cycle must
be collected separately from the other wastes.
The user for this reason will have to give the
equipment that got to its life cycle to the suita-
ble separate waste collection centres of elec-
tronic and electrotechnical wastes, or to give it
back to the seller or dealer when buying a new
equipmentof equivalent type,in terms ofone to
one. The suitable separate waste collection for
the following sending of the disused equipment
to recycling, the dealing or handling and com-
patible environment disposal contributes to
avoid possible negative effects on the environ-
ment and on the people's health and helps the
recycling of the materials the machine is com-
posed of. The user's illegal disposal of the
productimpliestheapplication of administrative
fines as stated in Law Decree n.22/1997” (arti-
cle 50 and followings of the Law Decree
n.22/1997).
CAUTION
The maximum noise disturbance
level is lower than 70db.

If the pipe connecting to the mains
water is replaced the old pipe must
never be re-used.


50
ENGLISH
After unpacking, assess that the machine and
its accessories unit are complete, then proceed
as follows:
SODFHWKHPDFKLQHVRWKDWLWLVOHYHORQDIODW
surface;
DVVHPEOH LWV VXSSRUWLQJ IHHW E\ LQVHUWLQJ
the insert into the cylindrical unit;
WZLVW WKHUXEEHUIRRWLQWRWKH VFUHZ WKUHDG
inside the unit;
VFUHZ WKH ZKROH DVVHPEOHG XQLW LQWR WKH
allotted setting for the machine’s adjustable
feet;
OHYHOWKHPDFKLQHE\UHJXODWLQJWKHDGMXVW-
able feet;
NOTE: the unit grooves have to face upwards,
as shown in the following illustration.
It is advisable to install a softener (1) and then
a mesh filter (2) on the external part of the
plumbingsystem,during preliminaries and after
levelling the machine.
Fig. 9
4.INSTALLATION AND
PRELIMINARY
OPERATIONS
Always quote the machine serial number in all
communications to the manufacturer, Nuova
Simonelli.
The machine is transported on pallets which
also contain other machines - all boxed and
secured to the pallet with supports.
Prior to carrying out any transport or handling
operation, the operator must:
SXWRQZRUNJORYHVDQGSURWHFWLYHIRRWZHDU
as well as a set of overalls which must be
elasticated at the wrists and ankles.
The pallet must be transported using a suit-
able means for lifting (e.g., forklift).
CAUTION
RISK OF IMPACT
OR CRASHING
CAUTION
RISK OF IMPACT
OR CRASHING
During all handling operations, the operator
must ensure that there are no persons,
objects or property in the handling area.
The pallet must be slowly raised to a height
of 30 cm (11,8 in) and moved to the loading
area. After first ensuring that there are no
persons, objects or property, loading opera-
tions can be carried out.
Upon arrival at the destination and after
ensuring that there are no persons, objects
or property in the unloading area, the prop-
er lifting equipment (e.g. forklift) should be
used to lower the pallet to the ground and
then to move it (at approx. 30 cm (11,8 in)
from ground level), to the storage area.
Before carrying out the following operation,
the load must be checked to ensure that it is
in the correct position and that, when the
supports are cut, it will not fall.
The operator, who must first put on work
gloves and protective footwear, will proceed
to cut the supports and to storing the prod-
uct. To carry out this operation, the techni-
cal characteristics of the product must be
consulted in order to know the weight of the
machine and to store it accordingly.
3. TRANSPORT AND HANDLING
3.1 MACHINE
IDENTIFICATION
3.2 TRANSPORT
3.3 HANDLING
Fig. 8

51
ENGLISH
Fig. 10
NOTE: Foracorrectfunctioningofthemachine
the water works pressure must not
exceed 4 bars.
Otherwise install a pressure reducer
upstream of the softener; the internal
diameter of water entrance tube must
not be less than 6mm.
KEY
1 Softener
2 Mesh filter
3 Drain Ø 50 mm
CAUTION
RISK OF SHORT CIRCUITS
Priortoconnecting the machinetotheelectrical
mains, assess that the voltage shown on the
machine’s data plate corresponds with that of
the mains.
If it does not, carry out the connections on the
basis of the available electrical line, as follows:
IRUV 380 / 3 phases voltage +Neutral:
Fig. 11
Fig. 12
KEY
1 Black
2 Grey
3 Brown
The machine must always be protected by
an automatic omnipolar switch of suitable
power with contact openings of equal dis-
tance or more than 3mm.
Nuova Simonelli is not liable for any dam-
age to people or objects due to not observ-
ing current security measures.
Avoid throttling in the connecting tubes.
Assess that the drain pipe (3) is able to
eliminate waste.
WARNING
2
3
1
IRUV 230 / monophase voltage
4 Blue
5 Yellow-green
Recommended mains pressure for the
water is [2.3] bar.
WARNING
In this way impurities like sand, particles of
calcium, rust etc will not damage the delicate
graphite surfaces and durability will be guaran-
teed.
Followingthese operations,connect theplumb-
ingsystemsasillustratedinthefollowingfigure. NOTE: At the start of the day’s activities and in
any case, if there are any pauses of
more than 8 hours, then it is necessary
to change 100% of the water in the cir-
cuits, using the relevant dispensers.
NOTE: In case of use where service is continu-
ous, make the above changes at least
once a week.

52
ENGLISH
Fig. 14
Fig. 17
Fig. 18
Fig. 16
Fig. 15
5. ADJUSTMENTS TO BE MADE BY A QUALIFIED TECHNICIAN ONLY
NOTE: this operation must be carried out with
the machine turned off.
Allmodels areequippedwithalevel
gauge to keep the water level inside the boiler
constant. When using the machine for the first
time, it is advisable to fill the boiler by hand to
avoid damaging the electrical resistor and turn-
ing on the electronic protection.
If this should happen, just turn the machine off
and then start it up again to complete its loading
procedure (see chapter “MACHINE
FUNCTIONS MESSAGE – LEVEL ERROR”).
To fill the boiler manually for the first time, pro-
ceed as follows:
UHPRYHWKHZRUNWRSJULG
WXUQWKHPDQXDO³$´OHYHOWDSVRWKDWZDWHU
will enter the boiler;
RQFHWKHPD[LPXPOHYHOKDVEHHQUHDFKHG
as indicated by the optical level, turn tap “A”
off;
VZLWFKWKHPDFKLQHRQE\SODFLQJWKHJHQ-
eral switch on “I”; this will activate the level
gauge which will automatically maintain the
water level inside the boiler.
NOTE: this operation can be carried out while
the machine is turned on.
To adjust the service pressure of the boiler,
thus regulating the water temperature, accord-
ing to the various functions and needs of the
coffee desired, proceed as follows:
UHPRYHWKHZRUNWRSJULGFRYHU
UHPRYH WKH SODVWLF SURWHFWLRQ XQVFUHZLQJ
the two side screws (A), as shown in the
following figure;
5.1 FILLING BOILER
MANUALLY 5.2 PRESSURE SWITCH
(version S and V) /
PUMP (version S, V,
Digit and T3)
ADJUSTMENT
XVH WKH SUHVVXUH VZLWFK DGMXVWPHQW VFUHZ
to INCREASE (anticlockwise) or REDUCE
(clockwise) the pressure;
7KH VHW SXPS SUHVVXUH LV VKRZQ RQ WKH
lower part of the gauge.
7RDGMXVWSXPSSUHVVXUHXVHWKHDGMXVWPHQW
dial of thepump to INCREASE(clockwise) or
REDUCE (anticlockwise) the pressure;
Advisable pressure: 1 - 1,4 bar
(according to the kind of coffee).
Pressure can be adjusted directly from the pro-
gramming function on the Digit and T3 versions.
Fig. 13
A
MAX
MIN
MAX
MAX
MIN
MIN
Advisable pressure: 9 bar.
T3 and Digit versions
S and V versions
A

53
ENGLISH
NOTE: this operation can be carried out while
the machine is turned on.
All models are equipped with a hot
water mixer tap which adjusts the water tem-
perature and optimises the system’s perform-
ance.
To adjust the hot water economiser, use a
screwdriver to turn the screw inside the cup
warmer as illustrated in the figure.
7XUQLW&/2&.:,6($17,&/2&.:,6(WR
REDUCE / INCREASE the temperature of
the hot water;
Fig. 19
5.3 HOT WATER
ECONOMISER
ADJUSTMENT
5.4 CLOCK BATTERY
REPLACEMENT
(Digit and T3 ver-
sion only)
The electronic control unit on the Digit and T3
version has a lithium battery to power the clock
and this has a life of around three years, after
which it may be necessary to replace it.
In case the machine has remained unutilised
for a long time, the clock can be blocked by
proceeding as follows:
ZLWKWKHPDFKLQHRIIWKHGLVSOD\ZLOOUHDG
SUHVV WKH key for 5 seconds; the
display will read:
The clock will start up again as soon as the
machine is plugged in once more.
5.5 PUSH-BUTTON
PANEL
REPLACEMENT
Replacement of the lithium battery must be
carried out EXCLUSIVELY by Qualified
Technician.
Nuova Simonelli cannot be held liable for
any damage to people or things due to non
observance of the safety prescriptions
described in this booklet.
For correct functioning of the machine, person-
alising each button panel card at time of
replacement is necessary; proceed as follows
on the selectors placed on the card (on the key
side).
GROUP sw1 sw2 sw3 sw4 sw5 sw6 sw7 sw8
Group1 On Off Off Off On Off Off Off
Group2 Off On Off Off Off On Off Off
Group3 Off Off On Off Off Off On Off
Group4 Off Off Off On Off Off On Off
WARNING
OFF
STOP CLOCK
At the end of the adjustments, refit the plastic
protection in its housing and fasten it into place
with the two side screws before refitting the
work surface grille.

54
ENGLISH
Beforestartingtousetheappliance,theoperator
must be sure to have read and understood the
safety prescriptions contained in this booklet.
When commissioning the machine for the first
time or after carrying maintenance switch ON
the machine using the main switch positioned
lower down and on the right and proceed as
follows:
1) If the message “OFF – CLOCK
DISENABLED” appears on the display pro-
ceed as follows in step three.
2) If the message “OFF” appears on the dis-
play press the key until the mes-
sage “OFF – CLOCK DISENABLED”
appears on the display and then proceed
as follows in step three.
3) Switch ON the machine by pressing the
key and automatically water will
exit from the units for 45 seconds to ensure
that the coffee boiler has been correctly
filled.
This cycle cannot and must not be inter-
rupted.
If this cycle is interrupted due to an electric-
ity failure or accidental switching off of the
machine using the main switch, when the
machine is switched on again the cycle will
start again for another 45 seconds.
6.2 TURNING THE
MACHINE ON
6.2.1 AURELIA T3 and Digit
SWITCH ON:
plug the machine into the
power socket and press the
switch “A” so it is in position “I”;
the machine will switch on.
Pressingtheswitches“B”and"C"
so that they are in position “I” will
switch on the LEDs even when
the machine is switched off.
NOTE: LEDs are installedas standard onthe T3
versionandOptionalontheDigitversion.
7KH GLVSOD\ ZKLFK LV QRW LOOXPLQDWHG ZLOO
read:
OFF
NOTE: The machine is not operational, since
the main switch only powers the elec-
tronic card.
For electronic card maintenance, turn the
machine off by means of the external main
switch or disconnect the plug.
WARNING
MANUAL SWITCHING ON/OFF
Automatic On/Off NOT PROGRAMMED
NOTE: make sure that the general switch is
always on the position “I”.
The state of the machine will be shown
by the signal:
6. USE
SWITCH ON: press the key for 2
seconds, the buzzer will beep,
the display will light up to indi-
cate the release of the EPROM
for about 1 second. The control
unit will start up an auto diagno-
sis cycle to check the functions,
all the selection keys will light
up.Once thecheck iscompleted
the display will read:
with the day and time. When
110°C has been reached, the
heating message will disappear
andwillbereplacedbythewords:
NOTE:on completion of the check up all the
selection keys are activated.
In case the auto diagnosis indicates error or
malfunction, call an assistance centre; the
operator MUST NOT intervene.
WARNING
HEATING
MACHINE READY
6.1 COMMISSIONING
PROCEDURE OR
AFTER BOILER
MAINTENANCE
(T3 VERSION)
ABC
Fig. 20
In case the auto diagnosis indicates error or
malfunction, call an assistance centre; the
operator MUST NOT intervene.
WARNING

55
ENGLISH
Automatic On/Off PROGRAMMED
NOTE: make sure that the general switch is
always on the position “I”.
The state of the machine will be shown
by the signal:
The machine will SWITCH ON at the first
programmed switch-on time (see the sec-
tion entitled PROGRAMMING at the para-
graph PROGRAMMING ON - OFF).
Thecontrol unit willperform an
auto diagnosis of all functions
and all of the selection keys
will light up. Once the diagno-
sis is complete, the display will
read as follows:
with the date and time. Once
the temperature of 110°C has
been the word “Heating” will
disappear to be replaced by:
NOTE: once the auto diagnosis has been com-
pleted all the keys are activated.
6.2.2 AURELIA V - S
SWITCH ON: plug the machine in and posi-
tion the main switch on “I”.The
state of the machine will be
shown by the signal:
In case the auto diagnosis indicates error or
malfunction, call the assistance centre; the
operator MUST NOT intervene.
In case the auto diagnosis indicates error or
malfunction, call the assistance centre; the
operator MUST NOT intervene.
The machine will SWITCH OFF at the first
time set for stopping the coffee maker (see
chapter on PROGRAMMING and paragraph
on PROGRAMMING ON – OFF).
NOTE: the machine can be switched on or off
manually as indicated in the previous
paragraph.
Fig. 21
SWITCH OFF: press the main switch into
the“O” position toswitch the
machine and the signal off.
6.2.3 AURELIA DIGIT - V - S
WITH LED SYSTEM
(OPTIONAL)
SWITCH ON: plug the machine into the
power socket and press the
switch“A”soit is inposition“I”;
the machine will switch on.
Pressing the switches “B” and
"C" so that they are in position
“I” will switch on the LEDs
even when the machine is
switched off.
WARNING
WARNING
ABC
Fig. 22
In case the auto diagnosis indicates error or
malfunction, call the assistance centre; the
operator MUST NOT intervene.
WARNING
HEATING
MACHINE READY
POWER OFF: press the key for 2
seconds; the machine will turn
off and the display will read:
OFF

56
ENGLISH
6.5 MAKING
CAPPUCCINO
Toobtainthe typical cappuccino foam, immerse
the nozzle all the way into a container 1/3 full
of milk (preferably cone-shaped). Turn on the
steam. Before the milk starts to boil, pull the
nozzle slightly up and lightly move it vertically
across the surface of the milk. When you have
completed the procedure, clean the nozzle
carefully with a soft cloth.
Fig. 25
CAUTION
RISK OF BURNS OR SCALDING
6.3 MAKING COFFEE
Unhitch the filter-holder and fill it with one or
two doses of ground coffee depending on the
filter used.
Fig. 23
Press the coffee with the provided coffee
presser,dustoffanycoffeeresiduefromtherim
of the filter (this way the rubber gasket will last
longer).
Insert the filter in its unit.
Press the desired coffee button:
Bystarting upthe coffeebrewing procedure the
unit’s pump is activated and the unit’s solenoid
valve is opened.
By pressing it, the button will turn on and signal
the operation.
NOTE: when in pause, leave the filter-holder
inserted in the unit so that it will keep
warm.
To guarantee the utmost thermic stabil-
ity during use, the delivery units are
thermo-compensatedwithcompletehot
water circulation.
To use steam just pull or push the provided
lever (Fig. 24).
By pulling it completely the lever will hold a
positionof maximumdelivery; by pushing it, the
lever will automatically give way.
The two steam nozzles are articulated to guar-
antee their easy use.
6.4 USING STEAM
Fig. 24
While using the steam nozzle, you must pay
attention to not place your hands beneath it
or touch just after it has been used.
1 small coffee 2 small coffees
1 long coffee 2 long coffees
NOTE: Before using the steam wand, always
bleed out any condensation for at least
2secondsor accordingtothe manufac-
turer’s instructions.

57
ENGLISH
6.6 HOT WATER
SELECTION
CAUTION
RISK OF BURNS OR SCALDING
While using the hot water nozzle, pay care-
ful attention not to place your hands
beneath it or touch it just after it has been
used.
This nozzle delivers hot water to make tea or
herb teas.
Place a suitable container under the hot water
nozzle.
Press the hot water selection button once
.
Make sure the button lights up.
Water will be delivered from the hot water noz-
zle for as long as the set time indicates.
NOTE: Hot water can be delivered at the same
time as coffee.
6.7 TIMED STEAM
NOZZLE
CAUTION
RISK OF BURNS OR SCALDING
While steam is being delivered do not touch
the nozzle with any part of the body, and
have it always facing downwards towards
the cup-holder grid.
It provides steam ejection to foam milk or to
heat up other liquids.
Place a suitable container under the automatic
steam nozzle.
Press the steam selection button once .
Make sure that the button lights up.
Steamwill beejected from the automatic steam
nozzle.
Press it again to arrest delivery.
As an optional on Digit and V models, it is pos-
sible to fit a wand with temperature probe,
which stays open until the drink to be heated
reaches the set temperature.

58
ENGLISH
RESET key to turn the machine on
and off and to exit menu.
7. AURELIA T3
and DIGIT
PROGRAMMING
7.1 KEY
CURSOR key: to scroll
the menu and to increase
and decrease values.
ENTER key: to access the menu.
Fig. 26
1
2345
1LCD Display.
2
3
5
4
LIST OF DISPLAY FUNCTIONS
(USER Mode)
AUTO CLEAN CYCLE
DOSES
POURING COUNT
TOTAL
MACHINE TOTAL
TOTAL WASHES
7.2 PROGRAMMING
(USER Mode)
To enter the user mode programming environ-
ment, press and hold down the washing
key for 8 seconds and wait to hear the first
acoustic signal.
The machine will read:
AUTO.CLEAN.CYCLE
AUTOMATIC CLEANING CYCLE
7KHGLVSOD\ZLOOVKRZ
3UHVV and the display will read:
WKHFHQWUDONH\RIHDFKXQLW 1 long cof-
fee, will begin to flash on and off. Insert the
blind filter (fig. 2 A07) into the filter-holder,
addhalfa dose ofPULICAFFand attach the
filter-holder into the unit where you intend to
carry out the automatic cleaning cycle.
Carrying out a cleaning cycle in more than
one unit at a time is possible.
3UHVV WKH  1 long coffee key to
start the unit automatic cleaning cycle.
The display will read
AUTO.CLEAN.CYCLE
¡ L
where1Lindicatesthatthecleaningcyclehas
been activated within the 1
st
unit. Once the
AUTO.CLEAN.CYCLE
AUTO.CLEAN.CYCLE
SELECT
cycle of 15 deliveries, each one 5 seconds
long, with a 10-second pause between each
onehas beencompleted, the 1 long cof-
fee key forthe selectedgroup will startto flash
on and off again and the display will read.
RINSE
DOSES
7KHGLVSOD\ZLOOUHDG
DOSES
3UHVVWKH key and all of the dose,
hot water and steam keys will start to flash.
3UHVVLQJRQHRIWKHIODVKLQJNH\VZLOOVKRZ
the corresponding programmed setting on
the display.
3UHVVWKH key to return to the previ-
ous function.
3UHVV WKH key to quit the display
mode.
POURING COUNT
7KHGLVSOD\ZLOOUHDG
DELIVERY COUNT
3UHVVWKH key and all of the dose,
hot water and steam keys will start to flash.
3UHVVLQJRQHRIWKHIODVKLQJNH\VZLOOVKRZ
the corresponding counter on the display.
3UHVVWKH key to return to the previ-
ous function.
3UHVV WKH key to quit the display
mode.
3UHVVWKH key to view the next func-
tions or to quit the display mode.
