NuTone 8310 User manual

INSTALLATION INSTRUCTIONS
READ & SAVE THESE INSTRUCTIONS!
IMPORTANT SAFETY INSTRUCTIONS
WARNING: TO REDUCE THE RISK OF FIRE.
ELECTRIC SHOCK, OR INJURY TO PERSONS,
OBSERVE THE FOLLOWING:
A. Use this unit only in the manner intended by the
manufacturer. If you have questions, contact the
manufacturer.
B. Before servicing or cleaning unit, switch power off at
service panel and lock service panel to prevent power from
being switched on accidentally.
When the service disconnecting means cannot be locked,
securely fasten a prominent warning device, such as a tag,
to the service panel.
CAUTION:
For general ventilating use only. Do not use to exhaust
hazardous or explosive materials and vapors.
INSTALLATION INSTRUCTIONS
WARNING: TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY TO PERSONS,
OBSERVE THE FOLLOWING:
A. Installation work and electrical wiring must be done by
qualified person(s) in accordance with all applicable codes
and standards, including fire-rated construction.
B. Sufficient air is needed for proper combusition and
exhausting of gases through the flue (chimney) of fuel
burning equipment to prevent back drafting. Follow the
heating equipment manufacturer's guideline and safety
standards such as those published by the National Fire
Protection Association (NFPA), and the American Society
for Heating, Refrigeration and Air Conditioning Engineers
(ASHRAE), and the local code authorities.
C. When cutting or drilling into wall or ceiling, do not damage
electrical wiring and other hidden utilities.
D. Ducted fans must always be vented to the outdoors.
E. If this unit is to be installed over a tub or shower, it must be
marked as appropriate for the application.
F. NEVER place a switch where it can be reached from a tub
or shower.
• Do not mount over tub or in shower enclosure.
• Suitable for use with solid-state speed controls.
If the installation presents a problem that is not explained
here or if any parts of these instructions are not clear, consult
a professional installer. If you are not familiar with methods of
installing electrical wiring, or if you are not certain as to the
correctness of any step or procedure described, secure the
services of a qualified electrician.
INSTALLING THE HOUSING
• Cutout dimension: 9" diameter
• Blade Size: 8"
• Grille Diameter: 10
1
⁄ 2 "
MPORTANT: Remove shipping tape that secures louver.
1. Slide hanger bars (adjustable for 24" O.C. joists) through
tabs in housing. Nail one hanger bar to joist and slide
ventilator to desired position. Nail second hanger bar to
joist: cocking it slightly to clamp fan into place.
8˝ Round Fan
MODEL: 8310

MAKING CONNECTIONS
IMPORTANT: Prior to making wiring connections,
disconnect electrical power at the main source and leave it off
until the installation is complete. All wiring must comply with
electrical codes.
1. Refer to Figure 1. Place wiring into the outlet box. Secure
the connections with approved wire connectors and
replace the cover plate.
2. Refer to Figure 2. Run 120vAC wiring (with ground) from
main source through wall switch to the fan location.
3. Using wire nuts, connect supply wires to fan wires as
follows: black to black, white to white. Connect ground wire
to green ground screw.
4. Use electrical tape to insulate all wire nut connections.
5. Replace junction box cover and secure with screw.
6. Refer to Figure 3. Install outside wall cap with flange
against outside of brick or sheathing, allowing sufficient
room around flange for caulking. Connect discharge
opening in fan housing to outside wall cap with standard
3
1
⁄ 2 " x 10" duct.
7. Refer to Figure 4. For vertical discharge installations, use
elbow and 3
1
⁄ 4 " x 10" ductwork extended into roof cap.
FIGURE 1
FIGURE 2
FIGURE 3
FIGURE 4
BLACK HOT
WHITE
COMMON
GREEN GROUND
GROUND SCREW
FAN
JUNCTION
BOX
BLACK
HOT WHITE
COMMON
GREEN
GROUND
WALL
VENT
90°
ELBOW
WALL
FAN
120vAC 60 Hz
ROOF
VENT
EAVE
VENT
90°
ELBOW
FAN

FINAL ASSEMBLY INSTRUCTIONS
1. Check louvers in fan housing and outside wall cap to see
that they are not damaged or binding. Louvre can be
readily removed by depressing spring bearings on end of
hinge pins.
Refer to Figure 5. Install motor and blade assembly into
housing. Be sure motor leads are toward receptacle. Plug
motor lead into receptacle. Spin blade to be sure it turns
freely.
2. Fasten grille in place with thumbscrew (furnished.)
BE SURE UNIT AND SWITCHES ARE PROPERLY
GROUNDED AND ALL WIRING COMPLIES WITH LOCAL
CODE REQUIREMENTS.
MAINTENANCE AND CLEANING
FILTER
To clean the filter (optional,) soak in hot, sudsy water.
Rinse thoroughly and allow to dry.
GRILLE
Use only a mild soap and water solution to clean the grille.
Do not use abrasive cleaners.
FIGURE 5

Product specifications subject to change without notice.
4820 Red Bank Road, Cincinnati, Ohio 45227
Printed in U.S.A., Rev. 4/01, Part No. 15851
One Year Limited Warranty
WARRANTY OWNER: NuTone warrants to the original consumer purchaser of its products that such products will be free from defects in materials or workmanship for a period
of one (1) year from the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
During this one year period, NuTone will, at its option, repair or replace, without charge, any product or part which is found to be defective under normal use and service.
THIS WARRANTY DOES NOT EXTEND TO FLUORESCENT LAMP STARTERS OR TUBES, FILTERS, DUCT, ROOF CAPS, WALL CAPS AND OTHER ACCESSORIES
FOR DUCTING. This warranty does not cover (a) normal maintenance and service or (b) any products or parts which have been subject to misuse, negligence, accident,
improper maintenance or repair (other than by NuTone), faulty installation or installation contrary to recommended installation instructions.
The duration of any implied warranty is limited to the one year period as specified for the express warranty. Some states do not allow limitation on how long an implied warranty
lasts, so the above limitation may not apply to you.
NUTONE’S OBLIGATION TO REPAIR OR REPLACE, AT NUTONE’S OPTION, SHALL BE THE PURCHASER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS
WARRANTY. NUTONE SHALL NOT BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES ARISING OUT OF OR IN CONNECTION WITH
PRODUCT USE OR PERFORMANCE. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may
not apply to you. This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state. This warranty supersedes all prior warranties.
WARRANTY SERVICE: To qualify for warranty service, you must (a) notify NuTone at the address stated below or telephone [phone], (b) give the model
number and part identification and (c) describe the nature of any defect in the product or part. At the time of requesting warranty service, you must present
evidence of the original purchase date.
Date of Installation Builder or Installer
Model No. and Product Description
IF YOU NEED ASSISTANCE OR SERVICE:
For the location of your nearest NuTone Independent Authorized Service Center:
Residents of the contiguous United States Dial Free 1-800-543-8687
Please be prepared to provide:
Product model number • Date and Proof of purchase • The nature of the difficulty
Residents of Alaska or Hawaii should write to: NuTone Inc. Attn: Department of National Field Service, 4820 Red Bank Road, Cincinnati Ohio 45227-1599.
Residents of Canada should write to: Broan-NuTone Canada, 1140 Tristar Drive, Mississauga, Ontario, Canada L5T 1H9. Rev. 03/2001
