NuTone HD50NT User manual

Broan-NuTone LLC Hartford, Wisconsin www.nutone.com 888-336-3948
REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
Architectural & Engineering Specications
February 2008
Heavy Duty
Ceiling/Wall Fan
MODEL HD50NT
80B 99043044C
DESCRIPTION
GRILLE:
•Attractive metal grille nished with white acrylic paint
•Conceals interior
•Low prole blends well with any decor
•Torsion spring grille mounting - no tools required
BLOWER:
•Plug-in, permanently lubricated, totally enclosed motor
•Centrifugal blower wheel for quiet, efcient performance
•Long life motor bearings
•Designed for continuous operation
HOUSING:
•Rugged 26-gage galvanized steel construction
•Integral key-holed mounting brackets for easy, secure installa-
tion directly to joist
•Provision for wire suspension when installed in a drop ceiling
•Tapered, polymeric duct tting with built-in backdraft damper
for easy, positive duct connection and no metallic clatter
U.L. Listed for use over bathtubs and showers when connected
to a GFCI protected branch wiring.
DESIGN FEATURES
Air Delivery: (See back page)
Sound Level: (See back page)
Dimensions: Housing: 8¼” long x 8” wide x 5¾” high.
Grille: 10¼” square x 3/8” thick.
Material & Finish: Housing: 26-gage galvanized steel.
Grille: White acrylic nished metal.
Motor: Long life bearings, designed for
continuous operation, 120 VAC, 60 Hz,
0.4 A.
Blower Wheel: One-piece, polymeric.
Duct Size: 4” diameter.
ARCHITECT’S SPECIFICATIONS
Heavy Duty Ceiling/Wall Fan shall be NuTone Model Number
HD50NT as manufactured by NuTone according to listed speci-
cations.
Fan shall ventilate no less air and create sound levels no greater
than values listed in the “Performance Ratings” charts on this
sheet. All air and sound ratings shall be certied by HVI and AMCA
licensed.
Housing shall be 8¼” x 8” x 5¾” and connect to 4” duct.
Fan shall be Energy Star® qualied.
INSTALLATION
•U.L. Listed for use over bathtub and showers when connected
to a GFCI protected branch wiring.
•Unit installs in ceiling or wall construction.
•Unit mounts on 16” – 24” O.C. joists or studs.
•Housing features integral, key-holed mounting brackets for easy,
secure mounting.
•Housing has collar for 4” round duct, and discharges vertically
or horizontally.
•Blower assembly mounts into housing with single screw for quick
assembly.
•Torsion springs on grille adjust for thickness variances in ceiling
or wall.
•Use a standard on-off toggle switch (purchase separately).
•Installation Instructions are included with each unit.

Broan-NuTone LLC Hartford, Wisconsin www.nutone.com 888-336-3948
PERFORMANCE RATINGS - MODEL HD50NT
AMCA LICENSED PERFORMANCE
AMPS
MODEL AMPS
NUMBER
HD50NT 0.4
WEIGHT
MODEL NO. SHIPPING WT.
HD50NT 7.1 lbs.
NuTone Inc. certies that the
models shown herein are
licensed to bear the AMCA
Seal. The ratings shown are
basedontestsandprocedures
performed in accordance with
AMCA Publication 211 and
AMCA Publication 311 and
comply with the requirements
of the AMCA Certied Ratings
Program.
HVI PERFORMANCE
MODEL NUMBER SONES CFM @0.1’’ Ps
HD50NT 1.5 50
Model Nominal
No. 0.0 0.1 .125 .250 .375 Volts Watts RPM Duct Size
HD50NT CFM 61 51 48 31 9 120 30 1070 4” Round
Sones 1.9 2.2 2.3 3.0 3.3
*There is a difference between sone values certied by HVI for residential
use and by AMCA for commercial/industrial use. Exact comparison of these
values is not possible. This difference is mainly due to the procedures used
to convert measured sound to perceived sound. ANSI S3.4, used by both HVI
and AMCA, species a procedure for calculating loudness as perceived by a
typical listener under specic conditions. HVI establishes values at a distance
of 5 feet from the fan in a “spherical free eld’’; AMCA establishes values at
a distance of 5 feet in a “hemispherical free eld”. HVI results are rounded to
the nearest 0.5 sone, AMCA to the nearest 0.1 sone.
SONES
Static Pressure (in. wg Ps)
The performance ratings include the effects of inlet grille and backdraft damper in the airstream. Speed (RPM) shown is nominal. Performance is based on actual speed
of test. The sound ratings are loudness values in fan sones at 5’ (1.5m) in a hemispherical free eld calculated per AMCA Std. 301. Values shown are for Installation Type
B: Free inlet fan sone levels. Air performance shown is for Installation Type B: Free inlet, Ducted outlet.
HVI-2100 CERTIFIED RATINGS comply with new
testing technologies and procedures prescribed
by the Home Ventilating Institute, for off-the-shelf
products,astheyareavailabletoconsumers.Product
performance is rated at 0.1 in. static pressure,
based on tests conducted in AMCA’s state-of-
the-art test laboratory. Sones are a measure of
humanly-perceived loudness, based on laboratory
measurements.
Model HVI Sones AMCA Sones
Number @ 0.1” Ps* @ 0.0” Ps*
HD50NT 1.5 1.9
