INSTALLATION INSTRUCTIONS

READ & SAVE THESE INSTRUCTIONS!

CAUTIONS

1. Before wiring the paddle fan, turn off the electric power supply

at the main fuse or circuit breaker box and leave

it off until the installation is complete.

2. Mount the outlet box so it will support a minimum of

45 pounds. The outlet box must be mounted flush to ceiling.

Do not use a plastic outlet box.

3. Do not install paddle fan with less than 7 feet clearance

between floor and lowest edge of fan blades.

4. If you are unfamiliar with electric wiring, acquire

the services of a qualified electrician.

5. Use proper cable and fittings. Be certain the fan is properly

grounded. Wiring must comply with national and local

electrical codes.

6. Electrical requirements: 120vAC, 60 Hz, single phase,

1 amp. – without optional lighting accessory.

7. Fan blades may be cleaned with a mild soap solution. Do not

use an abrasive cleaner or a strong chemical cleaner.

8. WARNING: To reduce the risk of fire or electrical shock,

do not use this fan with any solid-state speed control

device (NOTE: Refer to NuTone's catalog for appropriate

speed control switches.)

9. WARNING: To reduce the risk of personal injury,

do not bend the blade brackets when installing the

brackets, balancing the blades or cleaning the fan. Do not

insert foreign objects between rotating fan blades.

10. CAUTION: To reduce the risk of electric shock, connect only

to supply circuit provided with a ground fault circuit

interrupter.

11. CAUTION: To reduce the risk of electric shock, fire or

personal injury, a light kit must be marked suitable for use

with this fan and must be marked as suitable for outdoor use.

12. Do not operate reversing switch while fan blades are in

motion. Fan should be turned off and blades stopped before

reversing blade direction.

LOCATION

1. Minimum ceiling height: 8 feet. When fan is installed,

this allows a minimum of 7 feet between the floor and fan

blades.

2. The center of the fan must be located at least 32" from

any vertical surface.

3. Do not mount fan below, next to or between air ducts, beams

or any other obstruction which may interfere with the natural

air flow pattern created by the fan.

4. Fan can be mounted using down rod or closer to ceiling using

ceiling cup as close up adapter.

MOUNTING ON A SLOPED CEILING

1. Refer to Figure 1. A paddle fan equipped with a ball and

hanger bracket assembly can be safely mounted to a sloped

MINIMUM

MAXIMUM

25°

FIGURE 1

FIGURE 2

ALWAYS MOUNT HANGER

WITH OPENING TOWARD

TOP OF SLOPE

HEADER

OUTLET BOX

RUBBER

PADS

SUPPLEMENTAL

MOUNTING SCREWS

SOCKET

HANGER

ceiling where the maximum angle of the sloped ceiling does

not exceed 25°.

2. For any angled ceiling, use appropriate NuTone Extension

Stems to insure proper clearance between the blades and

ceiling. See NuTone catalog.

MOUNTING OUTLET BOX

Refer to Figure 2.

CAUTION: To reduce the risk of personal injury, install the

supplemental mounting means and use only the hardware

provided with the fan or use a listed outlet box marked as

acceptable for fan support. If the combined weight of the

ceiling fan and any light kit used with it exceeds 35 pounds,

the fan should be supported independently of the outlet

box. The weight of your fan is 20 lbs.

1. Fan mounts to a standard 4" metallic outlet box or a listed fan

support box. For damp location mounting, use outlet box listed

for “Damp Locations”. For outdoor mounting use outlet box

listed for wet locations.

“OpenAire”

MODEL: PFOB-52

2. When using a standard outlet box install a header between

joists and securely mount outlet box to header. Using two

screws supplied with the outlet box attach socket hanger

securely to outlet box. Place rubber pads between hanger

and box. Using 3" screws (supplied) install screws through

the socket hanger mounting slots, outside of the outlet

box, through the ceiling and into the header. Do not

overtighten or socket hanger may be damaged. These

screws serve as supplemental support independent of

the outlet box.

When using a listed outlet box marked acceptable for

fan support, follow instructions provided with the box.

MOUNTING THE FAN WITH DOWN ROD

1. Refer to Figure 6. To install the ball and stem assembly

to the fan, feed the wires from the fan through the rubber

canopy, the ceiling canopy and down rod.

2. Insert stem of rod into flange on the top of fan. (It may

be necessary to back out the set screw in flange).

Line up holes in stem and flange and insert smooth pin

through flange and stem. Secure pin with hitch pin. Tighten

set screw in flange.

3. Refer to Figure 6. Run wires from fan through

rubber cover. Lift fan and place ball hanger into socket

of socket hanger. Rotate fan until groove in ball locks

with tab in socket.

MOUNTING FAN WITH

CLOSE UP ADAPTER

1. Remove soft plastic bushing from the center of the ceiling

cup. Secure ceiling cup to top of fan using three screws

and lockwashers provided in the hardware bag. ( The

down rod and ball are not required for this installation.)

2. Hang the fan from the tab on the back of the hanger

bracket using one of the holes in the ceiling cup. This will

support the fan while wiring connections are made.

WIRING CONNECTIONS

Refer to Figure 4.

All wiring must comply with national and local codes.

Be certain the power is disconnected before proceeding.

1. Connect fan wires to house supply wires using listed wire

connectors. Make connections as follows: Black to black,

white to white and green ground wire to green or bare

copper ground from house supply.

IMPORTANT: For wall switch control use only listed

general use switches.

2. After splices are made turn them upwards and carefully

push into outlet box with white and green wires on one

side of outlet box and black wires on the other side.

3. Using four screws (supplied) secure ceiling cup to socket

hanger.

BLACK (FAN)

WHITE

(COMMON)

GREEN

(GROUND)

FIGURE 3

FIGURE 4

HOUSE SUPPLY

WIRES

GROOVE

TAB

LOCKS IN

GROOVE

LIGHT KIT

USE ONLY PFLK-123WH. Do not attempt to use any other

model.

ATTACHING FAN BLADES

1. Refer to Figure 5. Using three screws and washers

fasten top and bottom blade bracket to blade as shown.

2. Refer To Figure 6. Using two motor screws and washers

provided, secure blade to fan flywheel Repeat for

remaining blades.

OPERATION CHECK

1. Reconnect electrical supply at breaker or fuse box.

2. Check for proper operation of three speed pull chain switch

HI – MED – LOW – OFF.

3. Let fan come to a complete stop, then check operation of

reversing switch.

4. For fan balancing see instructions provided with the

balancing kit.

OPTIONAL EXTENSION STEM

Refer to Figure 7.

To use the optional extension stem (not supplied) follow

these steps:

1. Loosen anti-turn screw and slide hanger ball from

standard stem.

2. Remove ground wire and pin.

3. Attach ground wire and pin to extension stem.

4. Slide hanger ball onto stem and completely tighten

anti-turn screw.

NOTE: To avoid possible electric shock, be sure the

green ground wire has been replace and the anti-turn

screw has been tightened completely.

5. Mount extension stem to fan as described in “Mounting

Fan”.

IMPORTANT SAFEGUARDS

1. Be sure fan is switched off before cleaning it.*

2. Keep hands, clothing and other objects away from moving

fan blades.

3. Exercise close supervision of children if they are present

when fan is in operation.

4. Shut off electricity to fan at main fuse or circuit breaker box

before servicing or working near fan.

5. Do not operate fan if it has been damaged in any manner.

Contact your nearest NuTone Authorized Service Center.

*Fan blades may be cleaned with a mild soap solution. Do not use

an abrasive cleaner or a strong chemical cleaner.

MOUNTING

BRACKET

FIGURE 7

GROUND

WIRE

BALL

HANGER

EXTENSION

STEM

HITCH PIN

ANTI-TURN

SCREW

DO NOT DISCARD!

FIGURE 5

FIGURE 6

RUBBER

COVER

DOWNROD

ASSEMBLY

RUBBER

CANOPY

STOP PIN

SET

SCREW

CANOPY

LOCK

Product specifications subject to change without notice.

4820 Red Bank Road, Cincinnati, Ohio 45227

Printed in Taiwan, Rev. 3/02, Part No. 83012

Two Year Limited Warranty
