SPECIFICATION SHEET
NTM SERIES
TWIN MOTORS
RANGE HOOD
Architect
QTY. REMARKS
Engineer
Submitted by Date
Project
REFERENCE
Contractor
Location
NTM30WHd050615*PRODUCT SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
Broan-NuTone Canada Inc., 1140 Tristar Drive, Mississauga, Ontario, Canada L5T 1H9 (1-888-882-7626)
The NTM Series Twin Motors Range Hood meets the
professional cooking needs of the serious at home
chef. Its rounded edges and sleek design compliments
any modern decor.
FEATURES
• 3-speed control panel with easy push button controls
• Rounded edges for contemporary look
• Smooth surfaces and fully enclosed underside make
cleaning easy
• Enclosed 120 V 40 W appliance bulb illuminates cooking
surface (bulb not included)
• Grease capture design system includes grease pan and
two grease guard cups that remove quickly for cleaning
• Unit has 3-ducting options - 3 1/4” x 10” (83 mm x 254 mm)
horizontal - vertical and 6” (152 mm) round vertical
(dampers and adapters included)
• Triple speed twin fan motors
• Available in 30" width, white and stainless steel
1 year warranty
TYPICAL SPECIFICATION
The Range Hood shall be NuTone NTM Series.
It shall be available in a 30" (762 mm) width. The Range
Hood shall be available in a white finish and a stainless
steel finish.
Unit shall have a built-in back draft damper and be ducted to
exterior of dwelling either horizontally or vertically.
Unit shall have three fan speed push-button controls, a light
push-button control and an on/off push-button control.
Unit shall have 2 triple speed fan motors.
Maximum air delivery shall be no less than 500 CFM
(236 L/s) and sound levels no greater than 4.1 Sones (3
1/4” x 10” vertical discharge). All air and sound ratings shall
be certified by HVI.
Units shall be CSA certified.
HVI-2100 CERTIFIED RATINGS comply with new testing technologies and procedures
prescribed by the Home Ventilating Institute, for off-the-shelf products, as they are
available to consumers. Product performance is rated at 0.1 in. (2.54 mm) static
pressure, based on tests conducted in AMCA’s state-of-the-art test laboratory. Sones
are a measure of humanly-perceived loudness, based on laboratory measurements.

PERFORMANCE RATINGS NTM SERIES
TWIN MOTORS
RANGE HOOD
MODELS AVAILABLE
HVI-2100 CERTIFIED RATINGS comply with new testing technologies and procedures
prescribed by the Home Ventilating Institute, for off-the-shelf products, as they are
available to consumers. Product performance is rated at 0.1 in. (2.54 mm) static
pressure, based on tests conducted in AMCA’s state-of-the-art test laboratory. Sones
are a measure of humanly-perceived loudness, based on laboratory measurements.
SIZE
30”
WHITE STAINLESS
STEEL
NTM30WH NTM30SS
DIMENSIONS
SPECIFICATIONS
VOLTS
120
AMPS
2.0
Max. CFM
(L/s)
SONES
Normal Setting
DUCT
(mm)
3-1/4” x 10”
(83 mm x 254 mm)
OR
6” (152 mm) Round
500
(236)
4.1
