SPECIFICATION SHEET
REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
70E 99044078A
NS1 SERIES
RANGE HOOD
A sleek, contemporary styled range hood with high-per-
formance capability.
FEATURES
• Clean, sleek appearance
• Durable,baked-onpolyesternishpaintorbrushednish
stainlesssteel
• Over50%quieterthantheaveragerangehood
• Large,fulllterdesign-dishwasher-safeforeasyclean-
ing
• Dualhalogenlightsprovidefocusedlightingforunmatched
cooktopvisibilityaswellasasoft,night-timelevel(lamps
notincluded)
• Centrifugal blower provides increased performance and
quieteroperation.
• Flush-mountedcontrols
• Versatiledesignallowsfor3¼"x10",7"round,ornon-ducted
dischargeswithoutre-positioningblower
• Adjustableductconnectors-accommodateoff-centerduc-
twork
• Availablein30"and36"widthsinWhite,Black,andStain-
lessSteel
• Tri-lingualcartongraphicsandinstallationmanual(English/
Spanish/FrenchCanadian)
NuTone, Inc. Cincinnati,Ohiowww.nutone.com888-336-3948
Volts 120
HZ 60
Amps 2.1
CFM (Normal) 100
Max. CFM (High) 350
Sones (Normal) 0.9
Sones (High) 8.0
Controls 2-sp rocker
Halogen Flood Light GU10MR16†
Charcoal Filter BPDF‡
† 2 bulbs req. (not included).
‡ Purchase separately for non-ducted installation.
SPECIFICATIONS
HVI-2100 CERTIFIED RATINGS comply with new testing technologies and
procedures prescribed by the Home Ventilating Institute, for off-the-shelf
products, as they are available to consumers. Product performance is rated
at 0.1 in. static pressure, based on tests conducted inAMCA’s state-of-the-art
test laboratory. Sones are a measure of humanly-perceived loudness, based
on laboratory measurements.
LISTED
TYPICAL SPECIFICATION
RangehoodshallbeNuToneNS1Series.
Unitwillhaveclean,contouredappearancewithnosharp
edges.Finishtobebaked-onpolyesterpaint(mattenish
stainlesssteel).Itmust have a fully-enclosed bottom and
dishwasher-safe,fulllters.
Hoodto be convertiblebetween3¼" x 10"and7" round
ducted (using two washable aluminum lters) as well as
non-ducted(usingtwocharcoallters-mustbepurchased
separately).Ductconnectorsmustbeadjustabletoaccom-
modateoff-centerductwork.
Rangehoodtohaveacentrifugalblowerand50-watt(max.)
halogen ood lights. Blower and lights shall be operated
usingaspecially-designed,adjustablecontrolwith2-speed
rocker.
Airdeliveryshallbenolessthan100cfmandsoundlevel
nogreaterthan0.9Sones(350cfmand8.0SonesonHigh
Speed).AirandsoundratingstobecertiedbyHVI.Unit
shallbeU.L.andCU.L.listed.
