NUTRICHEF PiCEM62 User manual



ICEMAKER
Instruction Manual
Model: PiCEM62

Thankyouforpurchasingourproduct.Makesureyouhavereadthismanualbeforeusing,properlyusethe
applianceinaccordancewiththeinstructions.

Pleasekeepthisinstructionmanualforfuturereference.

I.ProductFeatures
1.Adoptingcompressorrefrigeratingtechnology,theicemakerprocessicecubesveryefficiently.
2.ThisIcemakeriswidelyusedinvariousplaces,household,saloon,restaurant,etc.
3.Icemakingstatusiswatchedthroughthetransparentwindow.
4.Push‐buttonoperation.LCDindicatorlightindicatestheworkingstatusdynamically.
5.Automaticallyremindingforwatershortageandicecubesfullness,icemakingstatusisalwaysrepresentedon
thedisplaypanel

II.ComponentNames

①Transparentwindow
②Cover
③Operationpanel
④Airoutlet
⑤Airinlet
⑥Powercord
⑦Wateroutlet
⑧Icestoragebox
⑨Evaporator
⑩Icemakingbox







III.Safetyprecautions
1.PowersourcemustbesuitableforthestandardsoftheIcemaker.Ifthevoltagefluctuationrangeisbig(Outof
theratedvoltage±10%),theicemakermaynotworksmoothly.Insuchconditions,pleaseusetheicemakerwith
avoltageregulator.
2.Hazardousarticleswhichareexplosiveandflammableareprohibitedtoputinsidetheicemaker.Aswellas
highlycorrosiveacidandalkali.
3.Whilethepowercordisdamagedortheplugisinfault,stopusingiceMaker.Cableandplugshouldbe
replacedbyprofessionalservicepeople.
4.Firmlypulltheplugtounplugitfromanyconnectedsocket;donotpullonthecableforunplugging.
5.Donotusetheicemakerinaplacewithcoalgasorotherflammablegasleakage.
6.Beforecleaningormaintenancee,remembertounplugtheunit.
7.TheIcemakerismadespecificallyformakingicecubes;donotuseittorefrigeratefoodorbeverages,soasto
avoidmachinedamage.
8.DonotuseorstoregasolineorotherflammablematerialsbesidesIceinthemaker,soastoavoiddamageand
personalinjury.
9.UnplugthecablebeforemovingIcemaker,soastoavoidthedamagetotherefrigeratingsystem.
10.Withoutprofessionalservicepeopleortechnicians,donotbreakdownoropenpanelsontheIcemaker,soas
toavoiddamageandpersonalinjury.
11.Onlyusetheapplianceforitsintendedpurpose.Theapplianceisnotintendedforusebypersons(including
Children)whosephysicalandmentalabilityisflawed,orthosewholackofexperienceandelectricsknowledge,
includingchildren.Onlycertifiedservicetechniciansorrepairmenshouldaccessanyformofrepair
troubleshooting.
12.Neverletchildrenoperatetheappliancealone.

IV.Placement
1.PlacetheIceMakersecurelyontoasturdyandevensurface.
2.KeepAwayfromheatingsourcesandavoiddirectsunlight,soasnottoimpacttheice‐makingperformance.
3.TheIcemakershouldworkinaplacewithwell‐circulatedairventilation.Ensurethataminimumspaceof20cm
fromIcemaker’sairoutletandinletisnotobstructed.
4..AmbienttemperaturefortheIcemakershouldnotbelessthan5degreescelsius.
5.Theicemakershouldnotbeusedoutdoor.

V.PreparationbeforeUse
1.Openallthepackagecomponents.
2.Readtheinstructions.
3.Placetheicemakerinasuitableposition.
4.Itispreferabletocleanthemachinebeforeuse.

VI.BeginUse
1.SwitchONthepowersource.DonotturnontheIcemakerwithin30minutesaftermovingtheicemaker.
2.Pourwaterintothewatertank.Pleaseuseconsumable/drinkingwaterformakingice.
3.Presskeytostartmakingice.




VII.OperationPanel
















ButtonsandIconFunctions
Button
MakingIce,Standby,
Eliminatingfaults.
SELECTButtonSelectingIcecubesize：L,M,S‐‐threesizes.
▲keyPoweronorofftimesetting;poweronandofftimesetting;threestates
settingswitch
SETkeyClock‐timesetting,powerofftimesetting,poweronandofftimesetting
switch
IconIcedroppingfaultindication,trouble‐freeflashing
IconWaterabsencefaultindication,fault‐freeflashing
IconLarge,medium,smallsizeicesizeinstructions,thedefaultMedium.
IconIcefullinstruction.
IconReal‐timeindicatoricon
IconPowerontimesettingfunctionindicator
Icon
Clockiconindicatesrealtime(24hoursystem),setrealtime,regulartime,in
hoursandminutesrespectivelyblinking,notimesettingdisplayreal‐time,the
defaulttimedisplay12:00
IconIceworkingstatusindicator,flashingwhileicemakingtime,stillwhilestandby.


RealTimeSetting:PresstheSETbuttononetime,  hourblinking,pressthe▲buttontosethour,pressthe
SETbuttononetime,minutesflash,pressthe▲buttontosetminutes.
Thetimingforthemachinestartontimesetting:presstheSETbutton3times,hourblinking,pressthe▲
buttontosethour,presstheSETbuttononetime,minutesflash,pressthe▲buttontosetminutes;
Setthemachinepowerofftime:PresstheSETbutton5times,hourblinking,pressthe▲buttontosethour,
presstheSETbuttononetime,minutesflash,pressthe▲buttontosetminutes;Thetimerfunctionstake
onuse:Press▲tosettimer,setthecycletimerfunctionmode:timepoweron→mepoweroff→meoffpower
onandoff,powerondefaulttimeis8:00,poweroffdefaulttimeis12:00.

VIII.FaultsandTreatments
FaultsReason
T
reatment
WORKindicatorisnotlight. PowerSourceisnot
switchedon.
1.Checkthepowersupplymatches
2.Checkthepowercordisconnectedcorrectly
3.Internalcomponentsaredamaged.Maintenancein
professionaldepartment.
ICEFULLindicatorislight.
1.Icefullness.
2.low‐temperature
protection
1.RemovethefullIcecube.
2.MovetheIcemakertoawarmerplace,wherethe
ambienttemperatureishigherthan5degrees.
MalfunctionindicatorlightflashesIcemakingboxresetin
badcondition
1.Checkwhetheranyforeignbodystucktheicemaking
box.
2.Internalcomponentsaredamaged.Maintenancein
professionaldepartment.
WATERabsenceindicatorflashes Absenceofwater
1.Pourthestorageroomintocleanwater,pushthekey
t
oeliminatethefailure.
2.watersupplysystemorcomponentsdamaged,sendto
professionalservicedepartmenttomaintenance
Icemakingperformanceisnotgood.
1.Heateliminationisbad.
2.Watertemperatureis
toohigh.
3.Ambienttemperatureis
toohigh.
4.Refrigerantleaks.
1.Cleanthedustonthecoolingfanandairinlet/outlet
2.Fillnormaltemperaturewater.
3.Donotplacetheapplianceinhightemperature
conditions.
4
.Refrigeratingsystemisdamaged.Maintenancein
professionaldepartment.
A
bnormalnoiseFanorpumpisdamaged.1.Setuptheapplianceinrightlocation.
2.Maintenanceinprofessionaldepartment.

IX.Self‐CleanMode
Theself‐cleanmodeshouldbeputintooperationbeforeyouuseyouricemakerforthefirsttimeand/orifthere
hasbeenalongperiodwithoutuse.ThreeIconsasLarge,MediumandsmallIconswillbeonatthesametime
whentheicemakerisinself‐cleanmode.

Stage1
1. Addequalpartsofwaterandvinegar(1:1)totheicemaker’sreservoir.
2. Withthestand‐bymode,pressandholdON/OFFbuttonatleast5secondstoactivatetheself‐cleanmode.
Pleasenotethatself‐cleanmodewillstartautomaticallyafterthe“Beep”sound.
3. Duringtheselfcleanmode,theupperwaterbucketisfilledanddumped.Thepumpwillremainin
continuousoperationasitfeedswatertothebucketandevaporatorcoils.Thiscyclewillcontinuefivetimes.
4. Uponcompletion,theunitautomaticallychangestostand‐bymode.

Stage2
1. Drainthecleaningsolutionfromtheinternalreservoirbyremovingthereardraincapandplug.
2. AddfreshwatertotheMAX.permittedwatervolumeline.
3. Whileinstand‐bymode,pressandholdtheON/OFFbuttonatleast5secondstoactivatetheself‐clean
modeagainwhichwillnowactasarinse.
4. Uponcompletionofthisfinalstageoftheselfcleanprocess,theunitautomaticallychangestostand‐by
mode.Proceedtodrainthewaterfromtheinternalreservoirbyremovingthereardraincapandplug.Leave
thelidontheicemakeropentoallowittoairdry.

PleasenoteifthereisawatershortageduringSelf‐cleaningmode,theunitwillautomaticallygointostand‐by
mode;Ifwaterbucketisfailtoturnover,iconwillbeon,youneedtopressandholdtheON/OFFbutton
formorethan5secondstoreleasetheself‐cleaningmodetochangeforotheroperations.

X.CleaningandPostIceMakingUse
1.Makesuretounplugtheappliancebeforecleaningandlongtimeperiodsoftimeofnonuse.
2.Useadampclothtocleanboththeinteriorandexterioroftheappliance.
1).Unscrewthenutofthewateroutlet,todrainoffthewater.
2).Pourcleanwaterintothewatertank,useacleanclothtowipethewatertankaround.Pourcleanwateragain
untiltheflowingwaterisclean,andthendrainoffwatercompletely.
4.Donotuseorganicsolvents,boilingwater,cleaningagents,strongacids,and/orAlkalietcsubstancesfor
cleaning.
5.Ificemachinewillbeoffuseforalongtime,youshouldunplugtheappliance,drainoffthewateranddrythe
appliancewithacleancloth,storetheicemakerinacleananddryplace.



