NUTRICHEF PICEM70 User manual

■Thanks for purchasing our product.
■Read the manual carefully before use, and use it properly according to the instruction manual.
■Keep the manual for future reference.
Parts Name
1. Transparent window
2. Upper cover
3. Evaporator
4. Float ball switch
5. Drop ice testing panel
6. Storage for ice cubes/Water box
7. Operation Panel
8. Air outlet
9. Water outlet
10. Air inlet
11. Power cord
12. Water outlet
①
②
③
④
⑤
⑥
⑦
⑦
⑧
⑩
⑾
⑨
⑿

● Safety precautions
1. Power source must be suitable for the standards of the Ice maker. If the voltage
fluctuation range is big (Out of the rated voltage ± 10%), the ice maker may not
work smoothly. In such conditions, please use the ice maker with a voltage
regulator.
2. Hazardous articles which are explosive and flammable are prohibited to put
inside the ice maker. As well as highly corrosive acid and alkali.
3. While the power cord is damaged or the plug is in fault, stop using ice Maker.
Cable and plug should be replaced by professional service people.
4. Firmly pull the plug to unplug it from any connected socket; do not pull on the
cable for unplugging.
5. Do not use the ice maker in a place with coal gas or other flammable gas leakage.
6. Before cleaning or maintenance e, remember to unplug the unit.
7. The Ice maker is made specifically for making ice cubes; do not use it to
refrigerate food or beverages, so as to avoid machine damage.
8. Do not use or store gasoline or other flammable materials besides Ice in the
maker, so as to avoid damage and personal injury.
9. Unplug the cable before moving Ice maker, so as to avoid the damage to the
refrigerating system.
10. Without professional service people or technicians, do not break down or open
panels on the Ice maker, so as to avoid damage and personal injury.
11. Only use the appliance for its intended purpose. The appliance is not intended
for use by persons (including Children) whose physical and mental ability is flawed,
or those who lack of experience and electrics knowledge, including children. Only
certified service technicians or repairmen should access any form of repair
troubleshooting.
12. Never let children operate the appliance alone.

Placement
1. Place the Ice Maker securely onto a sturdy and even surface.
2. Keep Away from heating sources and avoid direct sunlight, so as not to impact
the ice-making performance.
3. The Ice maker should work in a place with well-circulated air ventilation.
Ensure that a minimum space of 20cm from Ice maker’s air outlet and inlet is not
obstructed.
4. Ambient temperature should not be less than 5 degrees celsius.
5. The ice maker should not be used outdoor.
Preparation before Use
1. Open all the package components.
2. Read the instructions.
3. Place the ice maker in a suitable position.
4. It is preferable to clean the machine before use.
Beginning of use
1. Switch on the power. The appliance needs to sit, and should not be moved for 30
minutes after moved, and then switch the power on.
2. Only use consumable / drinkable water when using the ice maker.
C. Push ice-making key, start making ice cubes.
● Panel and Functions - LCD Display
A
B
A: Tear down the stopper of inlet water
valve.
B: Insert one end of the water connection
pipe into the device's inlet water valve,
connect other end with water tapping.
Fault Icon
Large ice icon small ice icon
Ice full icon

Function Description:
1. Stand-by mode
When the appliance is power on, LCD display are shown as right picture, the
machine is in stand-by mode.
2. Ice-making mode
With the stand-by, ice-full, water leakage and malfunction reminder mode, put
the ice-making key and the ice-making indicator keeps blinking, the machine
enter into ice-making mode, will make ice per prescribed procedure.
3. Ice shape selection
With the stand-by working or ice-full, water leakage and malfunction reminder
mode, push SELECT button to set the ice cube shape, choose the accordingly icon
of each ice size.
4. Ice-Full reminder
When the drop ice testing panel is pressed down by ice cubes, ICE-FULL indicator
will light up and the machine enters into ice-full reminder condition; if removed
the ice cubes and let the drop ice testing panel upwards, the machine will be in
ice-making mode automatically.
5. Water leakage reminder
When the float switch is in low level, ”ADD WATER” indicator will blinking; when
the pump is drawing water and the float switch is still in low level, “ADD WATER”
indicator will keep bright, the hummer ringing presents water leakage.
The machine with automatically feed water function, will open inlet valve to add
water when “ADD WATER” indicator blinking.
When water leakage reminder appears, please add appropriate volume of water.
Once the float switch leave the low level, the machine will enter into ice-making
mode automatically.
Ice sizes
select icon
Timing setting icon
Clock setting
icon
Real time
clock icon
Clock
Add water icon
Ice making icon
Timing off icon
Timing on icon
Ice making

6. Malfunction reminder
If the ice maker machine can’t detect ice drop signal for three times during ice
making process, it will show fault icon and a buzzer sound will be on at the same
time. Machine goes into fault alert status; At this point, you need to check
whether there is ice or foreign bodiesblock the ice detection plate’s turning off.
7. Self-clean mode
With the stand-by mode, keep pressing ON/OFF switch for 5 seconds, the
indicator of WORK, ICE-FULL, and ADD WATER blinking simultaneously, the
machine enters into self-clean mode; press the ON/OFF switch for 5 seconds to
exit self-clean mode.
8. Force to take off the ice pattern
In the standby mode, press the clock setting and ice type selection iconsat the
same time for 5 seconds, fault icon flashes, and go into the force to take off the
ice pattern; Again, press the ice making and ice select icons for 5 seconds at the
same time can be forced to exit to take off the ice pattern.
9. Clock and time setting function
1）Real Time Setting: Press the SET button one time, 88 hour blinking, press the
▲button to set hour, press the SET button once again, 88 minutes flash, press
the ▲button to set the minutes.
2）
The timing for machine start on time setting: press the SET button 3 times, 88
hour blinking, press the ▲button
88 minutes flash, press the ▲button to set minutes.
3）Set the machine power off time: Press the SET button 5 times, 88 hour
blinking, press the ▲button to set hour, press the SET button once again, 88
minutes flash, press the ▲button to set minutes.
4）The timer functions take on use: Press ▲to set
function mode: time power on→time power off →time off power on and off,
power on default time is 8:00, power off default time is 12:00.
5
5

● Troubleshooting
Failures Reasons Treatments
Power indicator is not
bright
Power source is not
switched on.
1. Check the power supply matches.
2. Check the power cord is connected correctly.
3. Internal components are damaged.
Maintenance required-seek professional help.
Ice making
performance is not
good
1. Ambient
temperature is too
high or poor
ventilation
2. Water temperature
is too high
3. Refrigerant leak
1. Clean the dust on the cooling fan and air
inlet/outlet.
2. Fill room temperature water.
3. Refrigerating system is damaged.
Maintenance required-seek professional help.
ADD WATER and ICE
FULL indicator flash
simultaneously( LED
display)
The ice maker
machine can’t
detected ice
drop signal for
three times
during ice
making process
1. Check whether any foreign matters
obstructing the ice making box.
2. Internal components are damaged.
Maintenance required-seek professional help.
Malfunction indicator
flashes(LCD display)
In ice-making mode,
WORKING indicator
flashes(LED display)
Temperature sensor
in bad condition.
1. Maintenance required- replace the
temperature sensor.
ICE FULL indicator
flashes(LCD display)
Abnormal noise Fan or pump is
damaged
1. Make sure put the appliance on a suitable
position.
2. Maintenance required-seek professional help.

● Cleaning
1. Make sure to unplug the appliance before cleaning and long time of non-use.
2. Use a damp cloth to clean both the interior and exterior of the appliance.
3. Water tank cleaning:
First Phase:
1) Add equal parts of water and vinegar (1:1) into water storage box.
2) With the stand-by mode, keep pressing ON/OFF switch at least 5 seconds
to activate self-cleaning mode. Please note self-cleaning mode will
automatically start after the “Beep” sound.
3) During the self-cleaning mode, pump will remain in continuous operation
as it feeds water to the bucket and evaporator coils. This cycle will continue
for 5 times.
4) Upon completion, the unit automatically changes to stand-by mode.
Second Phase:
1) Remove the rear drain cap and plug, and then drain off the water and grip
the nut.
2) Add fresh water to the maximum permit water volume line.
3) With the stand-by mode, keep pressing ON/OFF switch at least 5 seconds
to activate self-cleaning mode again which will now act as a rinse.
4) Upon completion of this final stage of the self-clean process, the unit
automatically changes to stand-by mode. Proceed to drain the water from
the internal reservoir by removing the rear drain cap and plug. Leave the
upper lid open to allow it to air dry.
4. Do not use organic solvents, boiling water, cleaning agents, strong acid ans alkali
etc. substances for cleaning.
5. If the ice machine will be off use for a long time, you should unplug the appliance,
drain off the water and dry the appliance with a clean cloth, store the ice maker in a
clean place.
6
