nutritower Vertical Hydroponic Indoor Garden Quick guide

Assembly and Maintenance Guide
Indoor Garden
© Nutritower Inc - 2022

Maintanance Guide
Contents
02
Assembly
Guide
01
2Assembly and Maintenance Guide
Welcome!
Congratulations on purchasing a Nutritower indoor
hydroponic garden! This guide is here to help you
every step along the way as you start to explore the
joys of indoor gardening.

Welcome to the Nutritower family and the exciting new world of indoor hydroponic
gardening!
Contrary to popular belief, you don’t need a green thumb to be a good gardener. This
guide will help you get the most out of your plants. Once you get your seeds started
and transplanted into the Nutritower, you’ll find it’s easy to maintain, and it won’t be
long until you are regularly enjoying the nutritious and delicious food you have grown.
Our YouTube channel offers a fully guided set of instructions. They also offer a wealth
of additional videos to help you grow your own food in your tower.
We are all here to help you and we can be reached Monday - Friday, 8am to 5pm EST
800-721-8419 or i[email protected]
You can also ask questions online on our support page and directly from our website
www.nutritower.com
Nutritower Assembly 01
3Assembly and Maintenance Guide

THESE WARNINGS SHOULD BE STUDIED BEFORE ANY ELECTRICAL
CONNECTIONS ARE MADE.
Indoor use only, this product is not designed for outdoor use.
Installation of the Nutritower ideally requires the collaboration of 2 people.
Do not touch any wire or electrical components with wet hands.
DO NOT PLUG The tower into a GFCI OUTLET (three-prong outlet with a reset button) - It can cause permanent damage to the lighting
system.
Children should not use the Nutritower without adult supervision.
If any smell, noise, or smoke is emitted from the system at any time, immediately unplug and contact customer service at 1-800-721-8419
or email us at: [email protected]
To reduce the risk of water damage, we recommend that the Nutritower be placed on a floor mat.
ALWAYS UNPLUG the Nutritower before performing any maintenance to avoid the risk of a shock or potential injury.
Misuse of the Nutritower can result in serious injury.
DO NOT PULL ON or HANG FROM any part of this product.
WARNING – RISK OF INJURY – it is recommended to wear gloves and safety glasses at all times when removing the product from its
carton, installing, servicing, or performing maintenance.
WARNING – RISK OF ELECTRICAL SHOCK
Disconnect or turn off the power before assembly and servicing.
Make all electrical and grounded connections in accordance with the National Electrical Code (NEC) and any applicable local code
requirements.
WARNING-RISK OF BURN
Allow lamp/fixture to cool before handling. Do not touch the enclosure or light source.
4Assembly and Maintenance Guide

Base Structure
Top Assembly
Reservoir
Pump
Seedling Starter Kit
Clay Pellets
Timers (2)
Dolly (if ordered)
• Central Column
• 32 x White Feeder Pots
• 32 x Netting pot
• Nutrient A + B
• 4 x T5HO Bulbs
• 32 x Retainer Clips
• Roll of Feeder Tube
• 16 x Suspension Cable
• Hardware Kit (8 screws + 2 Allen Keys
+ Washers)
List of contents box A List of contents box B
Box Contents
5Assembly and Maintenance Guide
*All replacement parts are available at nutritower.com

*Make sure that all the connectors are hand-tightened as much as possible.
Part 1: The Top
1.1 - Lay the top upside-down on the floor.
1.2 - Rest the column top on the edge of the top. (Figure 1)
1.3 - Attach all the power connectors by colour (blue, yellow, and green) for the lighting system (male pins into female
receptor and twist to tighten). (Figure 2)
1.4 - Squeeze the watering tube onto the manifold fitting in the center of the top. The tube must be fully inserted to
ensure a tight seal. (Figure 3)
Figure 1: Figure 2:
Assembling Your Nutritower
6Assembly and Maintenance Guide
*Before you begin your assembly, lay out all of the parts included in the packaging

1.5 - Insert all wiring and tubing into the column. (Figure 3)
1.6 - Raise the column vertically and insert the metal guides
on the top into the column.
*Be careful not to pinch any of the wires from the top
assembly between the top and the column’s edge.
1.7 - Fasten 4 of the included screws to secure the top to
the column. (Figure 4)
*Hand-tighten the 4 top screws with the Allen key a 1/4
turn. Align the column and tighten all screws.
Figure 3: Figure 4:
7Assembly and Maintenance Guide

*When attaching the power cord to the lighting power cable inside the base, make sure to check that
the connector is tightly fastened - it may have loosened during transport.
Open the removable door on the base and remove all the contents.
Rest the bottom of the column on the top of the base.
Attach the power cord connector from the column to the connector at the top of the base. Insert the watering tube in
the opening at the top of the base. (Figure 5)
With a partner, lift the top and column into position with the bottom above the guides on the base.
Guide the column onto the support guides on the base.
Tighten the 4 support screws to attach the column to the base. (Figure 6)
1.
2.
3.
4.
5.
6.
Part 2: Column Assembly
Leveling the Column
Loosen all four screws that hold the column to the base by a half-turn, or enough that the column can move with a slight
resistance against the screws.
Level the column. This is made easier with a second person to hold the column straight while you evaluate that it is level
from a few feet away.
Start by tightening the screws opposite to the direction of the lean until tight.
Follow with the opposite side screw and continue until all screws are secured.
As part of the assembly of your Nutritower, you may need to level the column portion of the tower. Here are the steps to
follow if you have a leaning tower:
1.
2.
3.
4.
8Assembly and Maintenance Guide

Figure 5:
Figure 6:
9Assembly and Maintenance Guide

3.3 - Fasten the waterproof end caps back onto the sockets. (Figure 10)
3.4 - Once all 4 lamps are properly installed, plug in the lead cord for the lights to test that all the lamps turn on.
3.1 - Insert the waterproof end caps on each extremity off the lamp with one facing up and the other facing down. (Figure 8)
3.2 - Insert the lamp pins into the sockets on the tower at both extremities (top and bottom). The bulb will click into
position. (Figure 9)
*Be careful to keep the bulb pins in the right position in the tube holders as you tighten the waterproof end caps.
*It is important to make sure the caps are screwed tightly on to prevent water from penetrating into the lighting fixtures.
*If any of the lamps don’t light up, start by verifying all of the connection points - The most common culprit is that the lamp
isn’t inserted far enough into the socket! Please contact customer support if the problem persists.
*You should hear the bulbs click into place when properly inserted. Please refer to our youtube video for more information.
Part 3: Light Bulb Installation
10 Assembly and Maintenance Guide

Figure 9:
Figure 7: Figure 8:
Figure 10:
11 Assembly and Maintenance Guide

4.3 - Suspend each pot by inserting the cables into
the cable guides and seating them onto the cable
clamps. (Figure 12)
4.5- Place the retention clip on either side of the pot to
secure it in place.
4.1 - Lay out the 16 suspension cables.
4.2 - Insert the top clinch nut of each cable into the
keyholes on the underside of the top housing. (Figure 11)
*Make sure that the end with the short span between
clinch nuts is at the top! This is the end identified as
'top'
Figure 11:
Figure 12:
Part 4: Hanging the Pots
12 Assembly and Maintenance Guide
4.4- Make sure the top Feeder tubes line up with the
pots (Figure 13)
Figure 13:

4.5 - Attach the feeder tubes to the bottom of each
pot and cut the length of the tube even with the top
of the pot beneath it (a half-inch below the retention
clip). (Figure 14, 15)
Figure 16:
Figure 14, 15:
13 Assembly and Maintenance Guide
4.6 - Attach the feeder tubes to the retention
clips on each pot. (Figure 16)
* Do not pre-cut all the tubes as the length may
vary from pot to pot and the bottom row
requires a longer length of tubing.

4.6 - Cut the bottom feeder tubes to approximately
35cm (14 inches) in length and attach the bottom pots.
4.7 - Insert the tubes in the openings on the top of the
base. (Figure 17, 18)
Figure 17:
Figure 18:
*If these tubes are cut too long they can
cause an airlock and subsequent overflow
of the bottom pot.
14 Assembly and Maintenance Guide

Figure 19:
Figure 20:
5.1 - Connect the main watering tube inside the base
to the pump. (Figure 19)
5.2 - Fill the reservoir with water and place it inside
the base. Submerge the pump in the water and
position it in the center of the reservoir.
***Make sure the flow valve is fully opened by setting
the dial all the way to the left towards the + sign.
5.3 - Place all 8 Feeder tubes into the reservoir. (Figure
20)
*Always check that all 8 of the feeder tubes are
reinserted into the reservoir to avoid water overflows.
Part 5 - Connecting the Pump
15 Assembly and Maintenance Guide
*If the tube is difficult to insert, you can place it in a
cup of hot water for a few seconds.
***

5.6 - Plug in the lights and let them run for a few
minutes.
5.4 - Double check that all the feeder tubes between the
pots are properly inserted.
5.5 - Plug in the pump and let run for a few minutes keeping
an eye on the tower checking for any overflows. (Figure 21)
Congratulations! You’ve completed
your Nutritower set up! You are now
ready to start transferring seedlings to
the pots!
Happy Growing :-)
Figure 21:
16 Assembly and Maintenance Guide

02 Maintenance
Guide
A well maintained Nutritower will provide a
bounty of produce for you and your family.
Check your Nutritower on a daily basis so
you will always know what is ready to be
harvested.
This section will explain the basic tasks of
growing and maintaining a healthy and
vibrant hydroponic indoor garden.
17 Assembly and Maintenance Guide

Check the water level in your reservoir. As plants mature water will need to be topped up on a more regular basis.
Check the water flow. If water flow isn’t consistent there may be a blockage.
Check timer to ensure that everything is running smoothly.
Trim any dead or wilted foliage.
Change the water. Clean all residue from the reservoir using mild soap and water. Rinse thoroughly. Fill the reservoir
7cm (3 inches) from the top. Add the nutrients to the water.
Rotate the plants. If the foliage is approaching the lights, rotate the plants 180 degrees.
Harvest as needed or trim foliage.
Remove the netting pots to check the roots. This is a common cause of leakage.
Rinse all sediment that has been collected on the screen.
Trim back the roots by up to 1/3 of the current length to prevent clogging and stimulate continued growth.
Quickly rinse the foliage under light water flow.
Daily
Weekly
Monthly
Quick Maintenance Guide
18 Assembly and Maintenance Guide

If you are going away, it is safe to leave your tower by modifying your watering cycle. If plants are getting fed less often, they will simply
grow a little less quickly. You can comfortably reduce your watering time to 15 minutes every 8 hours to simply maintain your garden. This
will allow your reservoir to last up to 10 days!
The Nutritower is unique because it allows you to grow various plants at various stages. Many different methods work but
here are that a few simple guidelines can be followed to guarantee success.
Recommended settings are 15 minutes every 2 hours while the lights are on.
Plants feed throughout the day at unpredictable times. The more often the system is watering, the more likely the plants
will have readily available nutrients when they need them. Plant roots need oxygen to survive as well. This is why it is
possible to drown plants by overwatering. Giving them time to oxygenate between waterings helps them metabolize
nutrients and is vital to good root health.
Plants generally don’t feed at night. Yes, plants sleep too! It’s crucial to the flowering process to have at least a part of
the day spent in darkness. While the lights are off, you can also turn off your watering cycle without causing any stress to
the plants. Taking all this into consideration, we’ve found that optimal growth is achieved when the watering cycles (on
time) are between 15 and 30 minutes. This should be repeated every 2 hours (off time) throughout the day to ensure that
there are sufficient nutrients available at all times.
Watering Schedule
Vacation watering cycle
Watering your plants does not need to be complicated!
19 Assembly and Maintenance Guide

Determine where the drip is coming from and check if the feeder tube has an obstruction.
If the feeder tube is clear, unclip the pot and lift the plant out by the black mesh pot. Check for potential water build-up in the bottom.
Clear out or trim any excess roots or small rocks that might be causing a blockage.
MAKE SURE THAT ALL 8 FEEDER TUBES ARE POSITIONED IN THE BUCKET.
If the water is dripping from the center column, please reach out to us for immediate assistance at 800-721-8419.
What to do if my tower is dripping from a pot?
What to do if there is water accumulating in the base of my tower?
Leak Troubleshooting
Water management is a very important part of the health and functionality of any hydroponic
garden - It will have a direct impact on the growth rate and health of your plants.
The Nutritower was designed to make water management easy by integrating a removable
reservoir. This allows the user to quickly refresh or replace the nutrient solution which helps
maximize plant health and reduce the risk of water-born illnesses and pests.
Complete a reservoir change once a month as nutrients will deplete as your plants grow.
Refer to this article for instructions on changing the water and nutrients here.
Monitor your water level periodically and top up the reservoir by pouring from a pitcher
directly into one of the pots. Make sure to keep an eye on the water level to not overfill. This
way you do not need to remove the reservoir other than during a complete nutrient
replacement.
How often do I need to change the water?
20 Assembly and Maintenance Guide
Table of contents
