Nuvap ProSystem N1 User manual

Nuvap N1 is an innovative device for monitoring the air
quality in the environments where we live.
USER MANUAL

Caution: carefully read and keep this manual.
This guide can be viewed online and downloaded from our website
www.nuvap.com
Nuvap N1 User Manual
Rev 1.1 Februay 15th, 2016

3
TABLE OF CONTENTS
GETTING TO KNOW N1
What you need
Where positioning N1
p.4
p.8
p.31
p.32
p.33
1
2
4
6
7
8
INFORMATION ON PRODUCT COMPLIANCE
COPYRIGHT AND TRADEMARKS
TERMS AND CONDITIONS OF WARRANTY
5SAFETY
Safety precautions
Opeating imits
GENERAL MAINTENANCE
Cleaning
Backup battey
Life of N1
Assistance
3INSTRUCTIONS FOR USE
Types of voice alet: WARNING and DANGER
Types of ight signal
Opeating modes
Auto-test
Manual opeating testing
Reset
SETUP - Getting stated
p.10
p.22
p.25

4
1
GETTING TO KNOW N1
The contents of the box that you have just opened are the following:
N1
Kit for water analysis
Power adapter 5V
User manual
N1 is the first device specifically designed for monitoring the main
sources of indoor pollution that over time can harm the health of your
family.
Thanks to its sensors, Nuvap N1 is able to detect up to 24 different
paameters:
• High and low frequency electromagnetic fields
• Radon gas
• Ionizing adiation
• Wi-Fi
• Methane (CH4)
• Smoke/fire
• Air quaity (H2, LPG, Alcohol, NH3, Ethanol, Toluene, CO)
• Paticulate Matter
• Water quaity (Chlorine, Hardness, Akainity, Ph, Nitrite and Nitate)
• Noise pollution
• Tempeature
• Humidity

5
1
All data recorded by N1 can be viewed, at any time and wherever you
are, through Nuvap App and Nuvap Web platform.
This manual provides instructions for N1 setup and proper use.

6
In order to use N1 you need the following:
a Wi-Fi connection,
a smatphone or Android or iOS tablet,
a Nuvap account to view the measurements of your N1.
NOTE: In the absence of a Wi-Fi connection only N1 local alarm
functions can be available.
What you need
1
Warning: This device is designed for indoor use, like single residential
units / offices. It is not a measuring instrument and therefore cannot
be used to establish compliance according to the paameters set by
law with respect to the presence of environmental pollutants.
It does not replace professional measuring and technical suveys.
Touch key
Power button
5V DC Connector Test tubes with
water quaity kit
Status LED

7
1
N1 must be placed in rooms where you spend most of your time (living
room, kitchen, bedroom, office), away from electromagnetic sources
such as smat phones and cordless phones, TV, appliances and away from
sources of pollution produced locally, not to impair proper opeation.
It is also not recommended the positioning of N1 in environments with a
moisture content above 80% or in the presence of a lot of dust.
N1 does not need installation or hardware. It is designed to be easily
moved around, allowing you to monitor the levels of pollutants in your
home or working environment.
N1 is equipped with a battey that allows up to 3 hours of use, so as to
be placed tempoarily for specific measures in remote areas without
power supply or in areas other than your house.
Depending on the chaacteristics of the environment that you would
like to monitor (such as, for example, ceiling height, dwelling on seveal
loors, wall thickness, etc.). N1 may not detect a significant presence of
some paameters.
For more information about the optimal placement of N1 please visit
www.nuvap.com.
Where positioning N1

8
1. Remove N1 and the power adapter from the package.
2. Place N1 in the environment that you want to monitor.
(see Ch. 1, § WHERE POSITIONING N1).
3. Connect N1 to the power supply
Connect the adapter to N1 and inset the
plug into the electrical socket.
4. Push the power button
Switch on N1 by pressing the power button
located on the side of the device.
5. Download the APP and create
your NUVAP account
Before use, you need to download the App
from Apple StoreSM or Google PlayTM
and create your Nuvap Account.
6. Login from the APP
Enter the credentials of your Nuvap account.
7. Scan the QR CODE
located under your device.
8. Follow the easy steps guided by the App
to complete the setup.
2
SETUP - Getting stated
Code Serial MAC
Code Serial MAC

9
2
9. Now wait for the message: “Continuous measurement has stated”.
N1 has been properly setup and has just stated monitoring the
pollutants in your home or office.
10.Press the touch key to peform the
manual opeational test.
Press the touch key located on the top of
N1 and listen to the message:
“No pollutants were detected in the
monitored area”.
11.View all data monitored by your N1,
through Nuvap App, anytime
and anywhere you are.
Environmental conditions may change over time. A reliable
assessment of the quality of monitored environment requires the
use of N1 in continuous mode for a period of at least 30 consecutive
days. You will know about NUVAP QUALITY INDEX of the environment
where you live at any time through the App and Nuvap Platform
http://my.nuvap.com
For futher information or clarification, please visit our website
www.nuvap.com

10
3
INSTRUCTIONS FOR USE
N1 is a smat device, able to communicate with you with voice
messages, light signals and NUVAP App.
N1 is progammed to give two types of voice alarm, CAUTION and
DANGER, and five types of light signals through its LEDs: green, yellow,
red, blue and violet.
In the event that N1 detects the presence of pollutants at WARNING
or DANGER levels, in addition to sound an alarm locally, the device will
send you a notification through NUVAP App and Platform at the address
http://my.nuvap.com.
Wherever you are you will be so informed in real time about the quality
of the environment that you have chosen to monitor with N1.
Types of Voice Alarm: CAUTION and DANGER
N1 emits two types of voice alarm to repot increased levels of
pollutants monitored (see § GETTING TO KNOW N1): “WARNING” alarm
and “DANGER” alarm.
The “CAUTION” alarm is intended to warn about the aising of the
levels of one or more of the pollutants monitored before they reach the
danger threshold.
In this case, N1 emits the voice message: “Presence of (name of
pollutant)”.
N1 simultaneously emits a lashing yellow light
(see § below TYPES OF LIGHT SIGNALS).

11
3
The “DANGER” alarm occurs when the level of one or more pollutants
reaches the threshold of danger. N1 will sound an alarm and the voice
message: “Danger, high level of (name of pollutant)”
N1 will simultaneously emit a lashing red light
(see § below TYPES OF LIGHT SIGNALS).
In both cases, N1 will keep repeating the voice signal alarm and the light
signal until it is deactivated by pressing the touch key on top of the
device.
You can always access NUVAP App to see all details of the
measurements made.
We suggest that you check the enty regarding the pollutant on
www.nuvap.com/en/solutions

12
3
Types of Light Signal
N1 can send out four types of light signal:
• Green signal: occurs periodically, it means that the device is
functioning properly and there are no anomalies or pollutants
detected (see Ch. 3, § AUTO-TEST).
• Yellow signal: occurs in case of detection of higher levels of one
or more of the pollutants monitored before they reach the danger
threshold (“CAUTION”) Simultaneously N1 emits the voice message:
“Presence of (name of pollutant)” (see § above TYPES OF VOICE ALARM:
CAUTION AND DANGER).
• Red signal: occurs when the level of one or more pollutants reaches
the threshold of danger, in case of “DANGER”. N1 simultaneously
sounds the alarm and the voice message: “Danger, high presence of
(name of pollutant)” (see § above TYPES OF VOICE ALARM: CAUTION
AND DANGER).
• Blue signal: warns about malfunctions, for example, problems with
Wi-Fi connection, battey, sensors.
• Violet signal: indicates that punctual measurement has stated (see
ch.3 § Opeating Modes).

13
Voice Message LED
Color What It Means What To Do
(rising note) Blue N1 is booting Wait until N1stats
Ready awaiting
configuation Blue N1 is awaiting configuation
Set up N1
(see § Ch. 2 SETUP - Getting
Stated)
Continuous
measurement
initiated
Green
N1 stated
monitoring the
environment in
continuous mode
Wait for status repots of the
monitored environment
Punctual
measurement
initiated
Green
N1 stated
monitoring the
environment in
punctual mode
Wait for message repoting the
end of punctual measurement
of the monitored environment
No pollutants
detected in the
monitored area
Green
N1 did not
detect any
pollutants in
the monitored
area after the
measurement in
Punctual mode
/
Presence of
Electromagnetic
Fields
Yellow
N1 has detected
the presence of
high-frequency
EMF at levels of
“WARNING”
See the enty for the pollutant
on
www.nuvap.com/en/solutions
3

14
Voice Message LED
Color What It Means What To Do
Presence of
Magnetic Fields Yellow
N1 has detected
the presence of
low-frequency
EMF at levels of
“WARNING”
See the enty for the pollutant
on
www.nuvap.com/en/solutions
Presence of Noise Yellow
N1 has detected
the presence of
Noise at levels of
“WARNING”
See the enty for the pollutant
on
www.nuvap.com/en/solutions
Presence of air
pollutants Yellow
N1 has detected
the presence of
air pollutants
at levels of
“WARNING”
See the enty for the pollutant
on
www.nuvap.com/en/solutions
Presence of
Paticulates or
smoke
Yellow
N1 has detected
the presence
of Smoke or
paticulate
matter at levels
of “WARNING”
See the enty for the pollutant
on
www.nuvap.com/en/solutions
Presence of
Ionizing nuclear
adiation
Yellow
N1 has detected
the presence of
Ionizing nuclear
adiation at levls
of “WARNING”
See the enty for the pollutant
on
www.nuvap.com/en/solutions
3

15
Voice Message LED
Color What It Means What To Do
Presence of Wi-Fi
networks Yellow
N1 has detected
the presence of
Wi-Fi networks
at levels of
“WARNING”
See the enty for the pollutant
on
www.nuvap.com/en/solutions
Presence of
Radon Gas Yellow
N1 has detected
the presence
of Radon Gas
at levels of
“WARNING”
See the enty for the pollutant
on
www.nuvap.com/en/solutions
For details access
data on Nuvap
application
/
N1 recommends
viewing the data
recorded on
NUVAP App
See complete measurements
made by N1 through NUVAP
App or Platform.
Danger, high
presence of
Electromagnetic
Fields
Red
N1 detected a
high presence of
Electromagnetic
Fields
See the enty for the pollutant
on
www.nuvap.com/en/solutions
Danger, high
presence of
Magnetic Fields
Red
N1 detected a
high presence of
Magnetic Fields
See the enty for the pollutant
on
www.nuvap.com/en/solutions
Danger, high
presence of Noise Red
N1 detected a
high presence of
Noise
See the enty for the pollutant
on
www.nuvap.com/en/solutions
3

16
Voice Message LED
Color What It Means What To Do
Danger, high
presence of air
pollutants
Red
N1 detected a
high presence of
air pollutants
See the enty for the pollutant
on
www.nuvap.com/en/solutions
Danger, high
presence of
Paticulates or
Smoke
Red
N1 detected a
high presence
of Paticulate
Matter or Smoke
See the enty for the pollutant
on
www.nuvap.com/en/solutions
Danger, high
presence of
Ionizing Nuclear
Radiation
Red
N1 detected a
high presence of
Ionizing Nuclear
Radiation
See the enty for the pollutant
on
www.nuvap.com/en/solutions
Danger, high
presence of Wi-Fi
networks
Red
N1 detected a
high presence of
Wi-Fi networks
See the enty for the pollutant
on
www.nuvap.com/en/solutions
Quality of the
monitored
environment
Excellent / Good
/ Poor
Green
Yellow
Red
N1 indicates that
the quality of
the environment
monitored is
Excellent / Good
/ Poor
See complete measurements
made by N1 via NUVAP App or
platform (http://my-nuvap.com).
If it detected Inadequate
quality, check the pollutant
that caused the alarm and see
the enty on
www.nuvap.com/en/solutions
3

17
Voice Message LED
Color What It Means What To Do
Fatal Error Blue Geneal error
Turn off N1 then turn it back
on.
In the event that the message
is repeated, reset N1 (see Ch. 3
§ RESET).
Visit
www.nuvap.com/en/suppot for
information
Please wait Blue
N1 cannot
peform the
action requested
manually
Wait. N1 will peform the
requested action when ready.
Low battey Blue
N1 indicates
that the battey
level is below
minimum
Connect N1 to your power
supply. Visit
www.nuvap.com/en/suppot for
information.
Wi-Fi password
error Blue
A wrong Wi-Fi
password has been
set up
Reset N1 (see Ch.3 § RESET)
and repeat Setup (see Ch.2 §
SETUP - Getting Stated).
3

18
3
Environmental conditions may change over time. A reliable quality
assessment of the monitored environment requires the use of N1 in
continuous mode for a period of at least 30 consecutive days. You
will know about NUVAP QUALITY INDEX of the environment where
you live at any time through NUVAP App and Platform at
http://my.nuvap.com.
Opeating modes
N1 has three modes of opeation: continuous mode,punctual mode 1
and punctual mode 2.
After the initial Setup N1 is on continuous mode of opeation: the
device constantly analyzes the paameters and daily provides an oveall
assessment of the quality of the environment monitored, based on an
algorithm (“NUVAP QUALITY INDEX“), available through NUVAP App and
Platform at http://my.nuvap.com.
Locally, anytime, pressing N1 touch key, you will know the oveall quality
of the monitored area in the last 24 hours.

19
To switch to punctual mode of opeation, just hold down the touch
button for a few seconds until the violet led light.
On punctual modes N1 provides real-time results regarding the analysis
of the environmental quality paameters of the monitored area.
While opeating on punctual mode 1, N1 will provide you with the
current result of the analysis of the environmental quality paameters
of the monitored area: through the App, you will know the levels of all
monitored paameters «here and now», anytime and anywhere you
feel like. This mode is recommended whenever you want to monitor a
specific environment. If, for example, you placed N1 in your living room,
you can check the environmental quality of your bedroom by simply
placing the device there.
When opeating on punctual mode 2, N1 provides you, with the reading
of one sensor at a time on «live» mode, updating the data evey two
seconds and dawing a real-time gaph.
3

20
Auto-test
N1 peforms an automatic test of correct opeation at predetermined
time intevals, emitting a green light signal if there are no opeating
anomalies or presence of pollutants.
If desired, you can turn off the green light signaling through the App. In
case of detection of pollutants in the monitored area, N1 will however
emit the WARNING or DANGER alarm signal, depending on the level
found. For your safety, it is not possible to disable them via the App.
Moreover, if the test results indicate opeating anomalies such as, for
example, problems with Wi-Fi connection, battey, sensors, etc., N1 will
emit a light blue lashing signal.
3
