Nuvico NVJV-4000 User manual

JV SERIES DVR
0

JV SERIES DVR
1
CONTENT VERIFICATION
Before installing the DVR, please make sure that the following items are included in the
box:
1. Digital Video Recorder
2. NVAC-RC110 Remote Controller
3. DVR Client Software CD
4. Power Cable
5. Two AAA Batteries
6. 8-ch Loop Out Cable (Only applicable to 8-ch unit)
7. This Instruction Manual
If any of these materials are missing, please contact the vendor or NUVICO customer
help desk immediately.

JV SERIES DVR
2
DISCLAIMER
•While every effort has been made to ensure that the information contained in this
guide is accurate and complete, no liability can be accepted for any errors or
omissions.
•NUVICO reserves the right to change the specifications of the hardware and
software described herein at any time without prior notice.
•No part of this guide may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language in any form, by any means,
without prior written permission of NUVICO.
•NUVICO makes no warranties for damages resulting from corrupted or lost data
due to a mistaken operation or malfunction of the Digital Video Recorder, the
software, the hard drives, personal computers, peripheral devices, or
unapproved/unsupported devices.
Trademark Acknowledgements
•NUVICO, DVRPlayer and DVR Mini Player are trademarks of NUVICO, Inc.
•DiamondMax Plus 9, DiamondMax 16, MaxLine II and MaxLine Plus II are a
trademark of Maxtor Corporation.
•Microsoft, Windows98, Windows ME, Windows NT, Windows XP, Internet
Explorer are either registered trademarks or trademarks of Microsoft Corporation
in the United States and/or other countries.
•Other names and products not mentioned above may be registered trademarks
or trademarks of their respective companies.
Copyright ©2005 NUVICO, Inc. All rights reserved.

JV SERIES DVR
3
FCC NOTICE
Digital Video Recorder: Model NVJV-4000N, NVJV-8000N
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions;
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for Class B
digital devices, pursuant to Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by on or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experience radio/TV technician for help.
The hard disk provided with the digital video recorder must be used with this equipment
in order to comply with Class B limits in subpart B of Part 15 on FCC rules.
Do not make any changes or modifications to the equipment unless otherwise specified
in the manual. If such changes or modifications should be made, you could be required
to stop operation of the equipment.
NUVICO, Inc.
53 Smith Street
Englewood, NJ 07631
Tel: [phone]
Canadian Radio Interference Regulations
THIS CLASS B DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF THE
CANADIAN INTERFERENCE CAUSING EQUIPMENT REGULATIONS.

JV SERIES DVR
4
Read this First
Test Sessions
Before you try to record important subjects, we highly recommend that you make
several test recording and playback sessions to ensure that the Digital Video Recorder
is operating and being operated correctly. Please note that NUVICO, its subsidiaries
and affiliates, and its distributors are not liable for any consequential damages arising
from any malfunction of a Digital Video Recorder or its accessory, including the hard
disk drive, which results in the failure of an image to be recorded or to be recorded in a
format that is machine sensible.
The Privacy act of 1974 (5 U.S.C. § 552a)
Please note that NUVICO Digital Video Recorders are intended for recording of
surveillance use and should never be used in a manner that invades other people’s
privacy or contravenes international or domestic privacy act and its regulations. Please
be advised that in certain cases the recording of individuals, private properties, or
commercial properties by means of camera or other devices may contravene legal
rights of such individuals even if the images were recorded for personal use.
Warranty Limitations
This Digital Video Recorder’s warranty is only effective in the country of sale. If a
problem arises while the DVR is in use abroad, please convey it back to the country of
sale before proceeding with a warranty claim to NUVICO customer help desk.

JV SERIES DVR
5
SAFETY PRECAUTIONS
•Before using the Digital Video Recorder, please ensure that you read and
understand the safety precautions described below. Always ensure that the
Digital Video Recorder is operated correctly.
•The safety precautions noted on the following pages are intended to instruct you
in the safe and correct operation of the DVR and its accessories to prevent
injuries or damage to the self, other persons and equipment.
•In this Instruction Manual, the term “DVR”, “equipment” and “device” refers
primarily to the Digital Video Recorder and its accessories such as power supply
and its remote controller.
WARNING
•Do not cover the ventilation opening or slots on the outer casing. To prevent the
DVR from overheating, provide at least two inches of air space around the vent
and the slots.
•Do not drop metallic parts through slots. This could permanently damage the
Digital Video Recorder. Immediately turn the DVR’s power off or unplug the
power cord from the power outlet. Contact a qualified service personnel
authorized by the equipment distributor or a NUVICO customer help desk.
•Do not attempt to disassemble or alter any part of the equipment that is not
expressly described in this guide. Disassembly or alteration may result in high
voltage electrical shock. Internal inspections, alterations and repairs should be
conducted by qualified service personnel authorized by the equipment distributor
or NUVICO customer help desk.
•Stop operating the equipment immediately if it emits smoke or noxious fumes.
Failure to do so may result in fire or electrical shock. Immediately turn the DVR’s
power off, remove the power cable from the power outlet. Confirm that smoke
and fume emissions have ceased. Please consult the DVR distributor or the
closest NUVICO customer help desk.
•Stop operating the equipment if a heavy object is dropped or the casing is
damaged. Do not strike or shake. Failure to do so may result in fire or electrical
shock. Immediately turn the DVR’s power off or unplug the power cord from the
power outlet. Please consult the DVR distributor or the closest NUVICO
customer help desk.
•Do not allow the equipment come into contact with, or become immersed in,
water or other liquids. Do not allow liquids to enter the interior. The DVR has not
been waterproofed. If the exterior comes into contact with liquids or salt air, wipe
it dry with a soft, absorbent cloth. In the event that the water or other foreign
substances enter the interior, immediately turn the DVR’s Power off or unplug the
power cord from the power outlet. Continued use of the equipment may result in
fire or electrical shock. Please consult the DVR distributor or the closest NUVICO
customer help desk.

JV SERIES DVR
6
•Do not use substances containing alcohol, benzene, thinners or other flammable
substances to clean or maintain the equipment. The use of these substances
may lead to fire. Use a dry cloth on a regular periodic basis and wipe away the
dust and dirt that collects on the device. In dusty, humid or greasy environments,
the dust that collects around the ventilation or the slots on the outer casing over
long periods of time may become saturated with humidity and short-circuit,
leading to fire.
•Do not cut, damage, alter or place heavy items on the power cord. Any of these
actions may cause an electrical short circuit, which may lead to fire or electrical
shock.
•Do not handle the device or power cord if the hands are wet. Handling it with wet
hands may lead to electrical shock. When unplugging the cord, ensure that you
hold the solid portion of the plug. Pulling on the flexible portion of the cord may
damage or expose the wire and insulation, creating the potential for fires or
electrical shocks.
•Use only the recommended power accessories. Use of power sources not
expressly recommended for this equipment may lead to overheating, distortion of
the equipment, fire, electrical shock or other hazards.
•Do not place the battery near a heat source or expose it to direct flame or heat.
Neither should you immerse them in water. Such exposure may damage the
battery and lead to the leakage of corrosive liquids, fire, electrical shock,
explosion or serious injury.
•Do not attempt to disassemble, alter or apply heat to the battery. There is
serious risk of injury due to an explosion. Immediately flush with water any area
of the body, or clothing that comes into contact with the inner contents of the
battery. If the eyes or mouth contact these substances, immediately flush with
water and seek medical assistance from a medical professional.
•Avoid dropping or subjecting the battery to severe impacts that could damage the
casings. It could lead to leakage and injury.
•Do not short-circuit the battery terminals with metallic objects, such as key
holders. It could lead to overheating, burns and other injuries.
•The supplied power supply and power cord are designed for exclusive use with
the Digital Video Recorder. Do not use it with other products or battery. There is
a risk of fire and other hazards.

JV SERIES DVR
7
CAUTION
•Avoid using, placing or storing the equipment in places subject to strong sunlight
or high temperatures, such as the greenhouse or trunk of a car. Exposure to
intense sunlight and heat may cause the battery to leak, overheat or explode,
resulting in fire, burns or other injuries. High temperatures may also cause
deformation of the casing. Ensure that there is good ventilation when using the
equipment.
•Do not store the equipment in humid or dusty areas. Storage in such areas could
lead to fire, electrical shock or other damage.
•Do not operate the DVR beyond its specified temperature, humidity or power
source ratings. Do not use the DVR in an extreme environment such as in high
temperature or high humidity. Use the device at temperatures within 41°F -
104°F and humidity below 90 %. The normal operating power source for this
device is 110V-220V AC 50/60Hz.
•Fully charge up the backup battery prior to operation. Keep the Digital Video
Recorder turned on or connected to a power outlet for at least 24 hours to
recharge the backup battery. This procedure is necessary when using the DVR
for the first time or after it has been unplugged for a long time from the power
outlet. Insufficient charging of the battery may cause loss of the time and date
settings if the power supply should fail. The battery, when fully charged, will
store the saved settings for approximately 170 hours.
PREVENTING MALFUNCTION
•Avoid Strong Magnetic Fields. Never place the DVR in close proximity to electric
motors or other equipment generating strong electromagnetic fields. Exposures
to strong magnetic fields may cause malfunctions or corrupt image data.
•Avoid Condensation Related Problems. Moving the equipment rapidly between
hot and cold temperatures may cause condensation (water droplets) to form on
its external and internal surfaces. You can avoid this by placing the equipment in
an airtight, resalable plastic bag and letting it adjust to temperature changes
slowly before removing it from the bag.
•If Condensation forms inside the Digital Video Recorder. Stop using the
equipment immediately if you detect condensation. Continued use may damage
the equipment. Remove the power cord from the power outlet and wait until the
moisture evaporates completely before resuming use.

JV SERIES DVR
8
TABLE OF CONTENTS
C
CO ON NT TE EN NT T V VE ER RI IF FI IC CA AT TI IO ON N. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .1 1
D
DI IS SC CL LA AI IM ME ER R. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .2 2
F
FC CC C N NO OT TI IC CE E. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .3 3
R
RE EA AD D T TH HI IS S F FI IR RS ST T. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .4
4
S
SA AF FE ET TY Y P PR RE EC CA AU UT TI IO ON NS S. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .5 5
W
WA AR RN NI IN NG G. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .5 5
C
CA AU UT TI IO ON N. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .7 7
P
PR RE EV VE EN NT TI IN NG G M MA AL LF FU UN NC CT TI IO ON N. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .7 7
D
DI IG GI IT TA AL L V VI ID DE EO O R RE EC CO OR RD DE ER R L LA AY YO OU UT T. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .1 12 2
1. FRONT PANEL LAYOUT ..................................................................................... 12
2. REAR PANEL LAYOUT ....................................................................................... 15
3. IR REMOTE CONTROLLER................................................................................. 17
U
US SI IN NG G T TH HI IS S M MA AN NU UA AL L. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .1 18 8
I
I. . B BA AS SI IC C S SE ET TT TI IN NG GS S. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .1 19 9
TIME &DATE SETUP .................................................................................................... 19
SCREEN POSITION ADJUSTMENT................................................................................... 19
I
II I. . B BA AS SI IC C O OP PE ER RA AT TI IO ON N. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .2 20 0
1. MAIN SCREEN..................................................................................................... 20
2. INFORMATION &LOG LIST ................................................................................ 23
3. LIVE VIEW............................................................................................................ 25
1. LIVE VIEW SWITCH SEQUENCE.................................................................................. 25
4. BASIC RECORDING............................................................................................ 28
5. BASIC PLAYBACK .............................................................................................. 29
1. PLAY / STILL / STOP ..................................................................................................... 29
2. FIELD BY FIELD / FAST FORWARD / FAST REVERSE............................................. 30
3. AUDIO PLAYBACK........................................................................................................ 31
I
II II I. . A AD DV VA AN NC CE ED D O OP PE ER RA AT TI IO ON N. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .3 32 2
1. LOCK.................................................................................................................... 32
2. BACKUP............................................................................................................... 32
3. PAN /TILT /ZOOM CONTROL............................................................................. 34
1. PAN AND TILT CONTROL............................................................................................. 34
2. FOCUS CONTROL ......................................................................................................... 34
3. ZOOM CONTROL ........................................................................................................... 35
4. IRIS COTROL.................................................................................................................. 35
5. AUTOMATIC PAN / TILT / ZOOM CONTROL............................................................... 35

JV SERIES DVR
9
6. LIMITING THE CAMERA POSITION ............................................................................. 36
4. ADVANCED RECORDING................................................................................... 37
1. ALARM RECORDING..................................................................................................... 37
2. MOTION RECORDING ................................................................................................... 38
5. ADVANCED PLAYBACK..................................................................................... 39
1. TIME SEARCH................................................................................................................ 39
2. EVENT SEARCH............................................................................................................. 39
I
IV V. . A AD DV VA AN NC CE ED D S SE ET TT TI IN NG GS S. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .4 40 0
1. DISPLAY SETUP.................................................................................................. 41
1. PIP / SPOT SETUP ......................................................................................................... 41
2. AUTO SEQUENCE MODE ............................................................................................. 43
3. SEQUENCE INTERVAL ................................................................................................. 43
4. CAMERA SELECT.......................................................................................................... 43
2. RECORD SETUP.................................................................................................. 48
1. RECORD MODE.............................................................................................................. 48
2. HDD OVERWRITE.......................................................................................................... 48
3. DEFINE GROUP.............................................................................................................. 49
4. PICTURE QUALITY........................................................................................................ 49
5. AUDIO RECORD............................................................................................................. 49
6. RECORD TYPE............................................................................................................... 50
7. RECORD SPEED............................................................................................................ 50
8. RECORD CAMERA ........................................................................................................ 51
4. EVENT SETUP ..................................................................................................... 53
1. EVENT RECORD ............................................................................................................ 53
2. RECORD DURATION..................................................................................................... 53
3. ALARM BUZZER ............................................................................................................ 54
4. RELAY OUT .................................................................................................................... 54
5. RELAY TYPE .................................................................................................................. 54
6. CAMERA SELECT.......................................................................................................... 54
5. SCHEDULE SETUP.............................................................................................. 56
6. TIME AND DATE SETUP...................................................................................... 59
7. SYSTEM SETUP................................................................................................... 60
1. USER AND THE ADMINISTRATOR PASSWORD........................................................ 60
2. FORMAT HDD.................................................................................................................. 61
3. AUTO KEY LOCK........................................................................................................... 62
4. KEY TONE....................................................................................................................... 62
5. SELECT DVR ID.............................................................................................................. 63
8. NETWORK SETUP............................................................................................... 64
1. CONFIGURING THE DVR WITH A STATIC IP ADDRESS........................................... 64
2. CONFIGURING THE DVR WITH A ROUTER INTO A LAN.......................................... 66
3. CONFIGURING THE DVR WITH A CABLE MODEM ................................................... 71
4. CONFIGURING THE DVR WITH A CROSSOVER CABLE.......................................... 73
5. SERVICE PORT.............................................................................................................. 76
6. E-MAIL............................................................................................................................. 76
V
V. . C CE EN NT TR RA AL L M MA AN NA AG GE EM ME EN NT T S SO OF FT TW WA AR RE E. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .7 77 7
1. SYSTEM REQUIREMENT.................................................................................... 77
2. INSTALLING DVRPLAYER.................................................................................. 77

JV SERIES DVR
10
3. EXECUTING DVRPLAYER................................................................................... 79
4. DVRPLAYER........................................................................................................ 80
5. DVRPLAYER –LIVE MODE................................................................................. 94
1. INDIVIDUAL DVR MONITORING................................................................................ 94
2. VIRTUAL DVR MONITORING..................................................................................... 95
6. DVRPLAYER –PLAYBACK MODE..................................................................... 97
7.CONTEXT MENU................................................................................................ 101
A. Channel Context Menu............................................................................................. 101
B. DVR Context Menu.................................................................................................... 101
C. Virtual DVR Context Menu....................................................................................... 102
8. DVR SETUP........................................................................................................ 103
1) Display Setup ............................................................................................................ 103
2) Camera Setup............................................................................................................ 103
3) Record Setup – General........................................................................................... 104
4) Record Setup – Group.............................................................................................. 104
5) Event Setup ............................................................................................................... 104
6) Motion ........................................................................................................................ 105
7) Schedule Setup......................................................................................................... 105
8) System Setup ............................................................................................................ 106
9) Network Setup........................................................................................................... 107
V
VI I. . W WE EB B C CM MS S. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .1
10 08 8
1. CONNECT TO THE UNIT VIA INTERNET EXPLORER ...................................... 108
1.1 Users with the Windows XP Service Pack 2............................................................ 108
1.2 Log-in Procedure........................................................................................................ 109
V
VI II I. . T TE EC CH HN NI IC CA AL L S SU UP PP PO OR RT T. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .1 11 11 1

JV SERIES DVR
11
QUICK START PAGE
The Factory Default password for the unit is “000000”
The Default password to run the CMS software is “0”

JV SERIES DVR
12
DIGITAL VIDEO RECORDER LAYOUT
1. FRONT PANEL LAYOUT
1. REMOVABLE HARD DISK DRIVE BAY
2. STATUS INDICATOR
Five LEDs display the status of the Digital Video Recorder. From the left, Power (red),
Recording (red), Scheduled Recording (green), Button Lock (green) and Network.
3. IR RECEIVER
Do not block the receiver as the remote controller needs the line of sight to the receiver.
4. ENTER / +10
This button selects and enables the configuration changes made on the menu and sub-
menu screens. It is also used to enter numbers greater than 10 when entering numeric
entries or motion grid selection.
5. DISPLAY / UP
This button is used to switch between quad view mode and picture-in-picture display
mode. It is also used to navigate up in some menus.
6. CANCEL/OSD OFF
This button cancels any selection changes in submenus. In Zoom mode, pressing this
button will exit to the original display screen. In the regular display screen, this button is
used to hide the On-Screen-Display information such as time, date and channel icons.
This button also removes any of the alert icons on the upper right corner of the screen
(AL, VL and PL). This button is also used to turn off the alarm buzzer.
7. PLAY / STOP / FAST REWIND / FAST FORWARD / RECORD / POWER
From left to right:
1 2 4 53 6
10 13798
11
12
14
15

JV SERIES DVR
13
PLAY/REVERSE playback button
This button is used to start the playback of recorded data. By default, the playback
starts from the earliest recording in the storage device.
STOP
This button stops recording or playback.
FAST REWIND / LOCK
This button is used to fast rewind during playback. It also locks all buttons on the Digital
Video Recorder along with the remote controller. The LOCK LED light is turned on
when this feature is activated. To unlock, press the lock button again and enter the
password when prompted. The DVR cannot be locked in playback mode.
FAST FORWARD / SWAP / PTZ
This button is used to fast forward during playback. It is also used as the Pan, Tilt and
Zoom submenu in live mode. Press and hold the button to activate the hard drive hot
swappable mode button.
RECORD
This button starts recording.
POWER
This button turns the Digital Video Recorder on or off.
8. NUMERIC BUTTONS (1~9, 10/0)
These buttons have a number of functions to enter data and to make selections. They
are used to enter numerical data when prompted for the password, to make
channel/camera selection, to choose the day in schedule option, and to enter alphabets
to label each channel.
9. USB 1.1 PORT
USB 1.1 compliant port allows use of memory sticks to backup video files.
10. TIME SEARCH
This button accesses the time search menu. Use the directional buttons to select the
date and the time. Press this button again to start the playback of the selection.
11. ZOOM / LEFT
This button allows to digitally zoom into a specific area in both live and playback screen.
Press the button to display the zoom area box, use the arrow keys to move the box, and
then press the Enter button again to enlarge the selected area. It is also used to
navigate left in some menus.
12. BACKUP / DOWN
This button allows back up of video clips onto USB 1.1 compliant memory sticks. If there
are no backup devices present, this button is disabled automatically.

JV SERIES DVR
14
13. MENU
This button accesses the main menu. It is also used to save and for any menu screens.
14. INFO / RIGHT
This button displays system information screen: USB device, internal HDD size, Boot-
Rom version, Application version, host name and IP address. Press this button once
more to access the system log.
15. ALARM SEARCH
This button accesses the alarm search menu. Use the directional buttons to select the
date and the time. Press this button again to start the playback of the selection.

JV SERIES DVR
15
2. REAR PANEL LAYOUT
NVJV-4000N
NVJV-8000N
1. CAMERA INPUTS
BNC connectors for composite video inputs
2. LOOP OUTPUTS
BNC connectors for composite video outputs
3. VIDEO OUT / SPOT OUT
Composite main and spot monitor outputs
4. 75 OHM TERMINATION SWITCH
Video signal termination for loop-outs
5. S-VIDEO OUTPUT
6. AUDIO INPUT / OUTPUT
RCA jack connector
7. ALARM SIGNAL INPUTS / OUTPUT / RS-422 / RS-485
8. VGA OUTPUT
1 2 3 6 9710
4 5 8 11

JV SERIES DVR
16
9. RS-232C
Factory use only
10. RJ45 ETHERNET PORT
10/100Base-T RJ45 ethernet port for network connection
11. AC POWER SOCKET

JV SERIES DVR
17
3. IR REMOTE CONTROLLER
FAST REWIND
PLAY
POWER
PAN/TILT/ZOOM
BACK UP
DVR ID
MENU
RESTORE
RECORDING
STOP
FAST FORWARD
DISPLAY MODE
LOG
INFORMATION AUDIO-PB
SCHEDULE REC ON/OFF
TIME SEARCH
ENTER / CH SELECT
ZOOM
FIELD BY FIELD
CANCEL / OSD OFF
ALARM SEARCH
NUMBERS & ALPHABET

JV SERIES DVR
18
USING THIS MANUAL
Throughout this manual, the following icons will be displayed at the bottom of the menu
screens in menus to guide you through navigating and configuring the Digital Video
Recorder.
Use the directional buttons to navigate through the menu (Up,
Down, Left, Right).
Use the directional buttons to navigate up or down between
item selection.
Use the directional buttons to navigate left or right between
item selection.
Use the directional buttons to modify the values of submenus.
Use the numeric buttons to enter the values or to switch
between channels. Use 10+ button in combination with single
digit buttons to enter or channels higher than 10.
Use the menu or enter key to confirm the settings.
Use the OSD/CANCEL button to revert back to previous
settings.

JV SERIES DVR
19
I. BASIC SETTINGS
Time & Date Setup
When the DVR is powered on for the very first time, the time and date configuration
screen will appear after initialization. Enter the appropriate time in 24 hour format and
date using the numeric buttons. Press the Menu Button to save and exit.
The password prompt will appear as soon as the time and date has been entered.
Enter “000000” as the default password.
Screen Position Adjustment
The screen position is adjustable during live view or playback. Use the directional
buttons on the remote controller to adjust the screen position to best fit the monitor.
Default Position Up position Bottom right corner position
