Nuvico Xcel TE-100-4M User manual

•Front Panel
•Rear Panel
1
1
1
1
2
2
2
2
3
3
3
3
4
4
4
4
5
5
5
5
6
6
6
6
7
7
8
8
Micro SD card slot
Reset
PoE network interface
HD-TVI/AHD video input
Analog video output
Grounding
Audio input
Alarm output
Audio output
Alarm input
Power indicator
RS 485 interface
HD-TVI / AHD
Security Camera
Sound pickup
DC12V
Loudspeaker
PTZ
Monitor
Sensor Alarm out
DC12V power output
DC12V power input
LAN/
WAN
Thank you for purchasing our product. Please read these instructions
carefully for correct use of the product and keep it for further reference. All
examples and pictures used here are for reference only. There may be several
technically incorrect places or printing errors in this manual. The updated
information will be added into the new version of this manual. The content is
subject to change without notice.
■If the product does not work properly, please contact your dealer or
the nearest service center. Never attempt to disassemble the device
yourself. (We shall not be responsible for any problems caused by
unauthorized repair or maintenance.)
■Keep away from liquid while in use.
■In the use of the product, you must be in strict compliance with the
electrical safety regulations of the nation and region. When the product is
mounted on wall or ceiling, the device shall be firmly fixed.
■Do not use the device beyond specified voltage range.
■Do not drop it or subject it to physical shock.
■If cleaning is necessary, please use clean cloth to wipe it gently.
■Do not place it in extremely hot, cold (the operating temperature shall
be -4˚F~131˚F), dusty or damp locations, and do not expose it to high
electromagnetism radiation.
■To avoid heat accumulation, good ventilation is required for operating
environment.
■A few parts of the device shall be replaced regularly according to their
average enduring time. Regular checking is recommended for all users.
TE-100-4M Encoder
Quick Start Guide
1Warning and Caution
Package
Overview
2
3
TF
RESET
VIDEO I N
Audio
PWR
+ -
IN
OUT
DC12V OUT
Device Quick Start Guide CD
Plastic plug ×4
4 tapping screws PA 4×25

TE-100-4M450043000742 A0
MENU
Device
Network Cable Network Cable
Switch
Router Computer
TF
RESET
VIDEO I N
Audio
PWR
+ -
IN
OUT
DC12V OUT
•Access through Xcel IP Utility
①Make sure that the device and the PC are well connected via LAN.
②Find the Xcel IP Utility on the CD and then install it in the
computer. After that, run the Xcel IP Utility as shown below.
①Make sure that the device and the PC are well connected via LAN.
②Find Xcel IP Utility on the CD and then install it in the computer.
After that, run Xcel IP Utility.
③Modify the IP address and make sure its network address is in the same
local network segment as that of the computer.
④Open the web browser and input the modified IP address in the address
bar to log in the web browser client. If it is the first time for you to log in,
you should download the Active X control and run it in the computer.
After that, input the default user name and password to login.
Device Network Search
Immediate Refresh
name
name
name
IPC
IPC
IPC
unknown
unknown
unknown
192.168.226.201
192.168.1.2
192.168.1.3
80
80
80
9008
9008
9008
255.255.
255.255.
255.255.
Modify Network Parameter
Mac Address
IP Address
Modify
CE :98 :23 :75 :35 :22
192 .168 . 226 . 201
255 . 255 . 255 . 0
192 .168 . 226 . 1
i
Tip: Enter the administrator password, and
then modify the network parameters.
Total Device: 3 Local IP Address:192.168.1.4Subnet Mask:255.255.255.0 Gateway: 192.168.1.1 DNS：210.21.196.6
Device Name Device Type IP Address Http Port Data Port Subnet
Product Model
About
Subnet Mask
Gateway
Restore IPC Default Configuration
Modify the IP address and gateway of the device and make sure the
network address is in the same local network segment as the computer.
Please modify the IP address of your device according to the practical
situation.
Mac Address
IP Address
Modify Network Parameter
Modify
CE :98 :23 :75 :35 :22
192 .168 . 1 . 201
255 . 255 . 255 . 0
192 .168 . 1 . 1
Subnet Mask
Gateway
Here we take accessing the device via LAN for example. In LAN,
there are two ways to access. 1. Access through Xcel IP Utility;
2. Directly Access through the web browser
The default network settings are as shown below:
IP address: 192.168.226.201 HTTP:80
Subnet Mask: 255.255.255.0 Data Port:9008
Gateway: 192.168.226.1
You may use the above default settings when you log in the device
for the first time.
Network Connection
4
For example, the IP address of your computer is 192.168.1.4. So the IP address
of the device shall be changed to 192.168.1.X. After modification, please input
the password of the administrator and click “Modify” button to modify the
setting.
The default password of the administrator is “123456”.
④Double-click the IP address and then the system will pop up the
browser to connect the IP Camera. Download the Active X control and run it
in the computer. Then input the user name and password in the login
interface.
The default username is admin; the default password is 123456.
•Directly Access Through Web Browse
Login
Name：
Password：
Stream Type：
Language：
Remember me
admin
1920x1080 25fps
English
③Modify the IP address. The default IP address of this device is
192.168.226.201. Click the information of the device listed in the
above table to show the network information on the right hand.
