QUICK INSTALLATION GUIDE
NC-2M-MPOV12
Please read this guide thoroughly before use and keep it handy for future reference.
“Nuvico surveillance equipment is designed to be installed and served only by a
trained, state-licensed professional installer”
12x Full-HD Mini-PTZ
NETWORK CAMERA

2

3
1. Description
The network camera supports the network service for a sensor image with progressive scan, which
can be monitored on a real-time screen regardless of distances and locations. By using its
dedicated program, many users are able to have an access to the network camera at once or a
single user can monitor various network cameras at the same time. It also enables users to play,
store and retrieve a monitoring image by using a PC. All the settings and real-time monitoring
screens are also provided through an access to the web.
The network camera is fully featured for security surveillance and remote monitoring needs. It is
based on the DSP compression chip, and makes it available on the network as real-time, full frame
rate Motion JPEG and H.264 video streams.
1.1 Components
The camera is designed with compact, small size, hard dome camera housing. The housing is
constructed of aluminum, steel and plastic. The housing is designed to be mounted on a wall or a
ceiling. The housing meets the Protection Classification IP66 standards for dust and moisture
resistance.
* Dome Camera 1
* Installation Guide/CD 1
* Template Sheet 1
* Mounting Bracket 1
* Safety Lanyard 1
* Accessory Kit 1
1) Mounting screws (PH6 x 35.0) (4)
2) Plastic anchors (4)
3) O-Rings (4)
4) Torx wrench (1)
* Accessory Connector 1
1) 3-pin terminal block (1)
2) 6-pin terminal block (1)

4
1.2 Key Features
Brilliant video quality
The network camera offers the highly efficient H.264 video compression, which drastically
reduces bandwidth and storage requirements without compromising image quality. Motion
JPEG is also supported for increased flexibility.
Triple Streams
The network camera can deliver triple video streams simultaneously at full frame rate in all
resolutions up to 1920 x 1080 using Motion JPEG and H.264. This means that several video
streams can be configured with different compression formats, resolutions and frame rates for
different needs.
Image setting adjustment
The network camera also enables users to adjust image settings such as contrast, brightness
and saturation to improve images before encoding takes place.
Intelligent video capabilities
The network camera includes intelligent capabilities such as enhanced video motion detection.
The network camera’s external inputs and outputs can be connected to devices such as
sensors and relays, enabling the system to react to alarms and activate lights or open/close
doors.
Improved Security
The network camera logs all user access, and lists currently connected users. Also, its full
frame rate video can be provided over HTTPS.
PoE (Power over Ethernet)
This network camera can be powered through PoE, which simplifies installation since only one
cable is needed for carrying power, as well as video controls.
ONVIF Certificate
This is a global interface standard that makes it easier for end users, integrators, consultants,
and manufacturers to take advantage of the possibilities offered by network video technology.
ONVIF enables interoperability between different vendor products, increased flexibility,
reduced cost, and future-proof systems.

5
2. Installation
2.1 Installation
The dome camera is for use in surface or pendent mounting applications, and the mounting
member must be capable of supporting loads of up to 3.5 lb (1.6 kg). (Pendent mounting must use
pendent mount accessory.)
The dome camera’s mounting bracket should be attached to a structural object, such as hard wood,
wall stud or ceiling rafter that supports the weight of the dome camera.
CAUTION: A silicone rubber sealant must be applied to seal the housing to secure
waterproofing.
2.1.1 Locking Dome Camera
A. Make screw holes on the ceiling using the supplied mounting Template Sheet (Figure A).
B. Fix the Mounting Bracket to the ceiling using supplied Anchors (4x) and Mounting Screws (4x)
(Figure B).
C. Hook up the Safety Lanyard to the Safety Lanyard Hook of the Mounting Bracket (Figure C).
D. Align the locking tab on the bracket and the locking slot on the base of the dome (Figure D).
E. Turn the dome to the counterclockwise about 10 degree to the locked position (Figure E).

6
CAUTION: Before installing mounting bracket to surface pre-adjust the four mounting
screws "A" on the base of the dome camera to best match the mounting
bracket locked position. Unscrew the locking screw on the side of the dome's
base and fit the tab of the mounting bracket into the locking slot. Screws "A"
should not be too tight or too loose when the dome is in the locked position.
After setting the proper positions of screws "A" remove the mounting bracket
and install it to the proper surface. If it is too difficult to lock the dome in
position after the mounting bracket has been installed readjust the screws "A"
by unscrewing them a small amount and try to install dome camera again.

7
2.2 Basic Configuration of Camera System
No.
Connector
Wire Color
Description
1
3-pin terminal block
RED
24VAC or 12VDC+
WHITE
24VAC or 12VDC-
2
6-pin terminal block
PINK
GND
GRAY
ALARM INPUT
BROWN
GND
YELLOW
ALARM OUTPUT
GREEN
RS485+
BLUE
RS485-
3
RJ-45
BLACK
Ethernet, RJ-45 port compatible with
10/100Mbps having PoE functionality.
4
STEREO
GRAY
AUDIO OUTPUT
5
STEREO
BLACK
AUDIO INPUT
The camera must be installed by qualified service personnel in accordance with all local and
federal electrical and building codes.
AC+ AC- AC+ AC- FGND (Rx+) (Rx-) Rx(Tx)+ Rx(Tx)- GND

8
2.3 Connections
Connecting the Network
Connect a standard RJ-45 cable to the network port of the camera. Generally a cross-over
cable is used for directly connection to PC, while a direct cable is used for connection to a hub.
Connecting Alarms
- AI (Alarm Input)
You can use external devices to signal the camera to react on events. Mechanical or
electrical switches can be wired to the AI (Alarm Input) and G (Ground) connectors.
- G (Ground)
NOTE: All the connectors marked G or GND are common.
Connect the ground side of the alarm input and/or alarm output to the G (Ground) connector.
- AO (Alarm Output)
The camera can activate external devices such as buzzers or lights. Connect the device to
the AO (Alarm Output) and G (Ground) connectors.
Connecting to the RS485
The camera can be controlled remotely by an external device or control system, such as a
control keyboard, using RS485 half-duplex serial communications signals.
Connecting the Power
Connect power of 12VDC or 24VAC 1.5A for the camera.
When using a 12VDC adapter, connect the positive (+) pole to the ‘+’ position and
the negative (-) pole to the ‘-’ position.
Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed Class 2 power source only.
- Be careful not to reverse the polarity when you connect the power cable.
- You can also use a router featuring PoE (Power over Ethernet) to supply power to the
camera.
- If PoE and 12VDC are both applied, this camera will get supplied with power from PoE.
- 24VAC is recommended to use for the camera power for stable operation with heater kit.
If using PoE, the heater will not operate at all.

9
2.4 Network Connection & IP assignment
The camera supports the operation through the network. When a camera is first connected to the
network, it is necessary to allocate an IP address to the device with the “SmartManager” utility on
the CD. (Default IP 192.168.30.220)
1) Connect the network camera/device to the network and power up.
2) Start SmartManager utility (Start > All programs > SmartManager > SmartManager). The main
window will display, and after a short while any network devices connected to the network will
be displayed in the list.
3) Select the camera on the list and click right button of the mouse. You can see the pop-up
menu as below.
4) Select Assign IP Address. The Assign IP window will display. Enter the required IP address.
NOTE: For more information, refer to the SmartManager User’s Manual.

10
3. Operation
The network camera can be used with Windows® operating system and browsers. The
recommended browsers are Internet Explorer®, Safari®, Firefox®, Opera™ and Google®
Chrome® with Windows.
NOTE: To view streaming video in Microsoft Internet Explorer, set your browser to allow ActiveX
controls.
3.1 Access from a browser
1) Start a browser (Internet Explorer).
2) Enter the IP address or host name of the network camera in the Location/Address field of your
browser.
3) You can see a starting page. Click Live View or Setup to enter web page.
4) The network camera’s Live View page appears in your browser.

11
3.2 Access from the internet
Once connected, the network camera is accessible on your local network (LAN). To access the
network camera from the Internet you must configure your broadband router to allow incoming data
traffic to the network camera. To do this, enable the NAT traversal feature, which will attempt to
automatically configure the router to allow access to the network camera. This is enabled from
Setup > System > Network > NAT. For more information, please see “3.5.7 System > Network >
NAT” of User's Manual.
3.3 Setting the admin password over a secure connection
To gain access to the product, the password for the default administrator user must be set. This is
done in the “Admin Password” dialog, which is displayed when the network camera is accessed for
the setup at the first time. Enter your admin name and password, set by the administrator.
NOTE: The default administrator user name and password is “admin”. If the password is lost, the
network camera must be reset to the factory default settings. Please see “Resetting to the
factory default settings”.
To prevent network eavesdropping when setting the admin password, this can be done via an
encrypted HTTPS connection, which requires an HTTPS certificate (see NOTE below).
To set the password via a standard HTTP connection, enter it directly in the first dialog shown
below. To set the password via an encrypted HTTPS connection, please see “3.5.7 System >
Security > HTTPS” of User's Manual.
NOTE: HTTPS (Hypertext Transfer Protocol over SSL) is a protocol used to encrypt the traffic
between web browsers and servers. The HTTPS certificate controls the encrypted
exchange of information.
3.4 Live View Page
The Live View page comes in several screen modes: 1920x1080, 1280x1024, 1280x720, 704x576,
704x480, 640x480 and 320x240. Users are allowed to select the most suitable one out of those
modes. Adjust the mode in accordance with your PC specifications and monitoring purposes.

12
1) General controls
Live View Page Setup Page Help Page
The video drop-down list allows you to select a customized or pre-programmed
video stream on the Live View page. Stream profiles are configured under
Setup > Basic Configuration > Video & Image. For more information, please
see “3.5.1 Basic Configuration > Video & Image” of User’s Manual.
The resolution drop-down list allows you to select the most suitable one
out of video resolutions to be displayed on Live View page.
The protocol drop-down list allows you to select which combination of
protocols and methods to use depending on your viewing requirements, and
on the properties of your network.
The preset drop-down list allows you to select the preset number for the PTZ
camera being used. This icon is inactivated if the PTZ settings are not set.
2) Control toolbar
The live viewer toolbar is available in the web browser page only. It displays the following
buttons:
The Stop button stops the video stream being played. Pressing the key again toggles the
start and stop. The Start button connects to the network camera or starts playing a video
stream.
The Pause button pauses the video stream being played.
The Snapshot button takes a snapshot of the current image. The location where the
image is saved can be specified.
The Digital Zoom button activates a zoom-in or zoom-out function for video image on the
live screen.
The Full Screen button causes the video image to fill the entire screen area. No other
windows will be visible. Press the 'Esc' button on the computer keyboard to cancel full
screen view.
The Manual Trigger button activates a pop-up window to manually start or stop the
event.
The PTZ button activates a pop-up window for Pan, Tilt and Zoom control.
Use this scale to control the volume of the speakers.
Use this scale to control the volume of the microphone.
Use this scale to control the volume of the speakers and microphones.
3) Video Streams
The network camera provides several images and video stream formats. Your requirements
and the properties of your network will determine the type you use.
The Live View page in the network camera provides access to H.264 and Motion JPEG video
streams, and to the list of available video streams. Other applications and clients can also
access these video streams/images directly, without going via the Live View page.

13
3.5 Network Camera Setup
This section describes how to configure the network camera, and is intended for product.
Administrators, who have unrestricted access to all the Setup tools; and Operators, who have
access to the settings for Basic Configuration, Live View, Video & Image, Audio, Event, Dome
Configuration, System
You can configure the network camera by clicking Setup in the top right-hand corner of the Live
View page. Click on this page to access the online help that explains the setup tools.
When accessing the network camera for the first time, the “Admin Password” dialog appears. Enter
your admin name and password, set by the administrator.
NOTE: If the password is lost, the network camera must be reset to the factory default settings.
Please see “Resetting to the Factory Default Settings”.
Resetting to the factory default settings
To reset the network camera to the original factory settings, go to the Setup > System >
Maintenance web page (described in “3.5.7 System > Maintenance” of User’s Manual) or use the
Reset button on the network camera, as described below:
Using the Reset button:
Follow the instructions below to reset the network camera to the factory default settings using the
Reset button.
1. Switch off the network camera by disconnecting the power adapter.
2. Press and hold the Reset button (SW1) on the board with your finger while reconnecting the
power.
3. Keep the Reset button (SW1) pressed for about 2 seconds.
4. Release the Reset button (SW1).
5. The network camera resets to factory defaults and restarts after completing the factory reset.
CAUTION: When performing a Factory Reset, you will lose any settings that have been saved.
(Default IP 192.168.30.220)

14
System Requirement for Web Browser
Operating System: Microsoft Windows OS Series
CPU: Intel Core 2 Duo 2Ghz or higher, 1GB RAM or more, 10GB free disk or higher
VGA: AGP, Video RAM 32MB or higher (1024x768, 24bpp or higher)
General Performance Considerations
When setting up your system, it is important to consider how various settings and situations will
affect performance. Some factors affect the amount of bandwidth (the bit rate) required, others can
affect the frame rate, and some affect both. If the load on the CPU reaches its maximum, this will
also affect the frame rate.
The following factors are among the most important to consider:
- High image resolutions and/or lower compression levels (or high bitrates) result in larger
images. Frame rate and Bandwidth affected.
- Accessing both Motion JPEG and H.264 video streams simultaneously. Frame rate and
bandwidth affected.
- Heavy network utilization due to poor infrastructure. Frame rate and Bandwidth affected.
- Heavy network utilization via wireless router due to poor infrastructure. Frame rate and
bandwidth affected.
- Viewing on poorly performing client PCs lowers perceived performance. Frame rate affected.
More Information
For more information, please see the network camera User’s Manual, which is available on the CD
included in this package.

12xFull-HDMini-PTZNETWORKCAMERA
