SD-Z18N-PHW Easy Track Mini PTZ Dome Camera
Nuvico - SD-Z18N-PHW Easy Track Mini PTZ Dome
Camera

Page 2 of 4
©2008, Surveillance-Video, Inc. This document is protected b International cop right laws. Coping and/or reproduction
is prohibited.
Product Code SD-Z18N-PHW
Description
The SD-Z18N-PHW from Nuvico is an easy trac mini PTZ dome
camera featuring Sony’s 1/4" Interline Transfer CCD Image
Sensor that offers high picture quality. The SD-Z18N-PHW from
Nuvico is a PTZ mini dome that delivers superb image quality
with a high horizontal resolution of 470 lines. It has a signal to
noise ratio of more than 50dB.
The SD-Z18N-PHW comes with day and night option ma ing it
perfect for round the cloc surveillance. It has a compact all
weather housing design that ma es it suitable for harsh outdoor
applications. The SD-Z18N-PHW offers an optical zoom of 18X
and digital zoom of 12X resulting in a combined zoom effect of
216X using a lens having a focal length ranging from 4.1mm to
73.8mm.
Specifications alues
Image Sensor 1/4" EX-view Color CCD (Sony)
Picture elements NTSC : 768x494 Approx. 380K pixels
PAL : 752x582 Approx. 440K pixels
Horizontal Resolution 470 / 460 lines(NTSC/PAL)
Lens f=4.1mm to 73.8mm
View angle Approx. 48°(WIDE end) to 2.8°(TELE end)
Minimum Illumination
0.7 lux(F1.4,normal shutter speed)
0.05 lux (F1.4,1/4S(NTSC) OR 1/3S(PAL)
0.01 lux (1/4s with IR Cut Filter Removed)
S/N ratio more than 50dB
Input Voltage 18 to 30 VAC; 24 VAC nominal
Control RS-485 baud rate:2400~38400bps (default:9600bps)
Access Time 0.75 second maximum preset recall time
Pan Angle 360° continuous rotation
Speed 0.4° to 90°/sec. (proportional to zoom)
360°/sec. maximum (with Turbo ey pressed)
Repeatability 0.2°
Flip Rotate 180° at bottom of tilt
Autoscan 4 auto scan include vector scan/1 Auto Pan
Preset Position 64 positions with camera status (16-character title)
Tour 4 tours
Pattern 1 patterns, 60 second

Page 3 of 4
©2008, Surveillance-Video, Inc. This document is protected b International cop right laws. Coping and/or reproduction
is prohibited.
On-Screen Display Displays camera ID and area name on screen
Power Requirement 24 VAC/VDC 850mA
Power Consumption Maximum 20W
Alarm Output 1 Normal relays 24 VDC/1A Max (selectable NC/NO)
Alarm Input 4 Normal dry contact (selectable NC/NO)
Weight Approx 3.8 g
Operating temperature 0°C to 50°C (32°F to 122°F)
Operating humidity 0 to 90%RH (non-condensing)
• Features
• Built-in 18X or 26X times Optical Power Zoom Camera.
• Sony’s 1/4" Interline Transfer CCD Image Sensor
• Comes with power-line surge protection and lightning protection.
• Offers a high horizontal resolution of 470 TV lines
• Built-in RS-485 receiver driver.
• True Night Shot function with ExView HAD ICR Day/Night function
