Nuvico CV-H2N User manual

NTSC
Customer Service | [email protected]
Technical Support | [email protected]
Corporate Headquarters | [email protected] • T 866.523.1700 • 201.541.1605
International Operations | [email protected]
Customer Service | [email protected]
Technical Support | [email protected]
Corporate Headquarters | [email protected] • T 866.523.1700 • 201.541.1605
International Operations | [email protected]
Customer Service | [email protected]
Technical Support | [email protected]
Corporate Headquarters | [email protected] • T 866.523.1700 • 201.541.1605
International Operations | [email protected]
Customer Service | [email protected]
Technical Support | [email protected]
Corporate Headquarters | [email protected] • T 866.523.1700 • 201.541.1605
International Operations | [email protected]
TECHNICAL SPECIFICATIONS
*specications are subject to change without any prior notice.
CV-H2N
NTSC/PAL
1/3” CCD
550 TV Lines
No
Fixed 2.9mm
120°
Internal
768(H) x 494(V)
525 Lines. 2:1 Interlaced
1/60 ~ 1/100,000 sec.
1.0 Vp-p Composite, 75 ohm
1.0 Vp-p Composite, 75 ohm
0.1 Lux
More than 48dB (AGC Off)
CV-H2N
23ºF ~ 113ºF
Within 90% RH
500 mA
12VDC
Technical Specications
Video Format
Image Sensor
Horizontal Resolution
Day/Night Functionality
Lens Type
Angle of View
Sync System
Effective Pixels
Scanning System
Electronic Shutter
Main Video Output
Service Monitor Output
Minimum Illumination
S/N Ratio
General Information
Operating Temperature
Operating Humidity
Power Consumption
Input Voltage
CV-H39N
Vari-focal 3.8mm-9.5mm
95.5°(W) ~ 37.3°(T)
1/60 sec.
CV-H39N
12VDC/24VAC Dual Voltage
CV-H2N • CV-H39N
KEY FEATURES
• 1/3” CCD Sensor
• 550 TV Lines
• 2.9mm Fixed Lens, or 3.8mm~9.5mm, DC Auto Iris Lens
• 0.1 Lux
• 12VDC or 12VDC/24VAC Dual Voltage
CONSTRUCTION
• 3” Polycarbonate Bubble
• 3-Axis Gimbal
• Impact Resistant Dome w/ Aluminum Housing
• Compact Size
AVAILABLE MODELS
• CV-H2N (Ivory Housing Only) - 2.9mm Fixed Lens
• CV-H39N (Ivory Housing Only) - 3.8mm~9.5mm, DC Auto Iris Lens
EasyView™Lite Series
High Resolution, 550 TV Lines, Vandalproof Dome Camera
5.16” (131)
R25,0
R44,0
3.54” (90)
2.09” (53)
12°
5.16” (131)
DIMENSIONS Unit: Inches (mm)
Rotation 355°
Tilting 90°
Panning 355°
1
2
3
3-AXIS GIMBAL, SIMPLY MOUNT AND POINT
All EasyView™ Lite dome camera gimbal has the ability to rotate, tilt, and pan for easy camera placement. Simply
mount the camera to the ceiling, wall, or under the eaves on the exterior of building or a house and point the
camera to the area you want to surveillance.
1Rotation 355°
LENS OPTION
• 2.9mm Fixed Lens - CV-H2N (12VDC)
• 3.8~9.5mm, DC Auto Iris Lens - CV-H39N (12VDC/24VAC Dual Voltage)
CV-H2N
CV-H39N
3Panning 355°
2Tilting 90°
