1 GENERAL DESCRIPTION
The ISD3900 is a multi-message ChipCorder®featuring digital compression, comprehensive memory
management, and integrated analog/digital audio signal paths. The message management feature is
designed to make message recording simple and address-free as well as make code development
easier for playback-only applications. The ISD3900 utilizes winbond’s 25X and 25Q series flash
memory to provide non-volatile audio record/playback for a two-chip solution. Unlike other ChipCorder
series, the ISD3900 provides an I2S digital audio interface, faster digital recording, higher sampling
frequency, and a signal path with SNR equivalent to 12bit resolution.
The ISD3900 can take digital audio data via I2S or SPI interface. When I2S input is selected, it will
replace the analog audio inputs and will support sample rates of 32, 44.1 or 48 kHz depending upon
clock configuration. When SPI interface is chosen, the sample rate of the audio data sent must be one
of the ISD3900 supported sample rates.
The ISD3900 has built-in analog audio inputs, analog audio line driver, and speaker driver output. The
two analog audio inputs to the device are: (1) AUXIN has a fixed gain configured by SPI command,
and (2) ANAIN/ANAOUT has a fixed gain amplifier with the gain set by two external resistors.
ANAIN/ANAOUT can also be used as a microphone differential input (ANAIN/ANAOUT becomes
MIC+/MIC-) in conjunction with an automatic gain control (AGC) circuit configured by SPI command.
Analog outputs are available in three forms: (1) AUXOUT is a single-ended voltage output; (2)
AUDOUT can be configured as either a single-ended voltage output or a single-ended current output;
(3) BTL (bridge-tied-load) is a differential voltage output.
2 FEATURES
External Memory: support winbond’s 25X and 25Q SpiFlash.
oThe addressing ability of ISD3900 is up to 128Mbit
1
, which is 64-minute recording time based
on 8kHz/4bit ADPCM.
Fast Digital Programming
oProgramming rate can go up to 1Mbits/second mainly limited by the flash memory write rate.
Message Management
oPerform address-free recording: The ISD3900 allocates memory for new recording requests
and upon completion, returns a start address to the host via SPI interface
oStore pre-recorded audio (Voice Prompts) using high quality digital compression
oUse a simple index based command for playback
oExecute pre-programmed macro scripts (Voice Macros) designed to control the configuration
of the device and play back Voice Prompts sequences and message recordings.
Sample Rate
oSeven record and playback sampling frequencies are available for a given master sample
rate. For example, the record and playback sampling frequencies of 4, 5.3, 6.4, 8, 12.8, 16
and 32kHz are available when the device is clocked at a 32kHz master sample rate.
oFor I2S operation, 32, 44.1 and 48kHz master sample rates are available with record and
playback sampling frequencies scaling accordingly.
Compression Algorithms
oFor recording
ADPCM: 2, 3, 4 or 5 bits per sample
1
For details please refer to Section 8.

ISD3900
Publication Release Date: Dec 10, 2013
- 5 - Revision 1.5
µ-Law: 6, 7 or 8 bits per sample
Differential µ-Law: 6, 7 or 8 bits per sample
PCM: 8, 10 or 12 bits per sample. Each sampled value is stored as a code, offering no
compression but preserving maximum resolution
oFor Pre-Recorded Voice Prompts
µ-Law: 6, 7 or 8 bits per sample
Differential µ-Law: 6, 7 or 8 bits per sample
PCM: 8, 10 or 12 bits per sample
Enhanced ADPCM: 2, 3, 4 or 5 bits per sample
Variable-bit-rate optimized compression. This allows best possible compression given a
metric of SNR and background noise levels.
Oscillator
oInternal oscillator with internal reference: 2.048 MHz with ±10% deviation
oInternal oscillator with external resistor: 2.048 MHz with ±5% deviation when Rosc is
78.7Kohm
oExternal crystal or clock input
oI2S bit clock input
oCrystals and resonators support standard audio sampling rates of 2.048, 4.096, 8.192, 12.288
and11.2896MHz
Inputs
oAUXIN: Analog input with 2-bit gain control configured by SPI command
oANAIN/ANAOUT:
Analog input with the gain set by two external resistors from ANAOUT to ANAIN, or
Microphone differential input (ANAIN/ANAOUT becomes MIC+/MIC-)
oDigital AGC:
Automatic gain control of digitized data from the analog input
Outputs
oPWM: Class D speaker driver to direct drive an 8Ω speaker or buzzer
oAUDOUT: configurable as a current or voltage single-ended line driver
oAUXOUT: a single-ended voltage output
oBTL: a differential voltage output
I/Os
oSPI interface: MISO, MOSI, SCLK, SSB for commands and digital audio data
oI2S interface: I2S_CLK, I2S_WS, I2S_SDI, I2S_SDO for digital audio data
o8 GPIO pins (4 of the 8 GPIO pins share with I2S).
Three 8-bit Volume Control set by SPI command for flexible mixing
oVOLA: volume control for the digital audio data from I2S or analog inputs
oVOLB: volume control for the digital audio data from decompression block or SPI
oVOLC: master volume control for PWM, AUDOUT, AUXOUT and I2S outputs
Operating Voltage: 2.7-3.6V
Standby Current: 1uA typical
Package: Green 48L-LQFP
Temperature Options:
oIndustrial: -40C to 85C

ISD3900
Publication Release Date: Dec 10, 2013
- 6 - Revision 1.5
3 BLOCK DIAGRAM
AUDOUT
AUXIN
ANAIN
+Digital Signal Path:
Digital Filters
Resampling
Digital Mixing
Volume Control
DAC
ADC +
AUXOUT
PWM
Control
Compression
De-Compression
Flash Memory
Controller
I2S
Interface
SPI
Interface
Memory Management
and Command
Interpreter
SCK
SDI
WS
SCLK
SSB
MISO
MOSI
INTB
RDY/BSYB
AUDOUT
AUXOUT
SPK+
SPK-
SUM1 SUM2
ADC_MUX
SDO
SUM2_MUX
AUD_MUX AUX_MUX
GPIO
Controller
GPIO0
GPIO1
GPIO2
GPIO3
GPIO4/
GPIO5/
GPIO6/
GPIO7/
A
G
C
ANAIN
ANAOUT
Av = 0, 3, 6, 9dB
AUXIN
SPK+_MUX SPK-_MUX
CLK
CSB
DI
DO
Figure 3-1 ISD3900 Block Diagram, ANAIN Selected

ISD3900
Publication Release Date: Dec 10, 2013
- 7 - Revision 1.5
AUDOUT
AUXIN
MICIN
Digital Signal Path:
Digital Filters
Resampling
Digital Mixing
Volume Control
DAC
ADC +
AUXOUT
PWM
Control
Compression
De-Compression
Flash Memory
Controller
I2S
Interface
SPI
Interface
Memory Management
and Command
Interpreter
SCK
SDI
WS
SCLK
SSB
MISO
MOSI
INTB
RDY/BSYB
AUDOUT
AUXOUT
SPK+
SPK-
SUM2
SDO
SUM2_MUX
AUD_MUX AUX_MUX
GPIO
Controller
GPIO0
GPIO1
GPIO2
GPIO3
GPIO4/
GPIO5/
GPIO6/
GPIO7/
A
G
C
MIC+
MIC-
Av = 0, 3, 6, 9dB
AUXIN
SPK+_MUX SPK-_MUX
CLK
CSB
DI
DO
Figure 3-2 ISD3900 Block Diagram, MICIN Selected

ISD3900
Publication Release Date: Dec 10, 2013
- 8 - Revision 1.5
4 PINOUT CONFIGURATION
ISD3900
NC
2
3
4
5
6
7
8
9
10
1
2
11
12
13 14 15 16 17 18 19 20 21 22 23 24
25
26
27
28
33
32
31
30
29
44 43 42 41 40 39 38 3736
35
34
47 46 4548
VSSD
NC
VCCD
VREG
I2S_SDO/GPIO4
I2S_WS/GPIO5
I2S_SCK/GPIO6
I2S_SDI/GPIO7
DI
CSB
NC
VCCD_PWM
NC NC
SPK-
VSSD_PWM
SPK+
VCCD_PWM
MOSI
SSB
SCLK
MISO
NC
INTB
DO
CLK
RDY/BSYB
RESET
XTALOUT
XTALIN
GPIO3
NC
GPIO2
GPIO1
NC
NC NC NC AUDOUT AUXOUT VCCA VSSA ANAOUT/MIC- ANAIN/MIC+ AUXIN NC GPIO0
Figure 4-1 ISD3900 48-Lead LQFP Pin Configuration.

ISD3900
Publication Release Date: Dec 10, 2013
- 9 - Revision 1.5
5 PIN DESCRIPTION
Pin
Number
Pin Name
I/O
Function
1
NC
This pin should be left unconnected.
2
CSB
O
Chip Select Bar of the external serial flash interface.
3
DI
I
Serial data input to external serial flash interface. Connects to data
output (DO) of external flash memory.
4
I2S_SDI/
GPIO7
I
Serial Data Input of the I2S interface (If I2S is not used, this pin should
be grounded).
Or, can be configured as a GPIO pin.
5
I2S_SCK/
GPIO6
I/O
Clock input in slave mode or clock output in master mode. This pin can
be configured as an external clock buffer if I2S is not used (If I2S is not
used, this pin should be grounded).
Or, can be configured as a GPIO pin.
6
I2S_WS/
GPIO5
I/O
Word Select (WS) input in slave mode or WS output in master mode (If
I2S is not used, this pin should be grounded).
Or, can be configured as a GPIO pin.
7
I2S_SDO/
GPIO4
O
Serial Data Output of the I2S Interface (If I2S is not used, this pin
should be left unconnected).
Or, can be configured as a GPIO pin.
8
NC
This pin should be left unconnected.
9
NC
This pin should be left unconnected.
10
VSSD
I
Digital Ground.
11
VCCD
I
Digital power supply.
12
VREG
O
A 1.8V regulator to supply the internal logic. A 0.1uF capacitor should
be connected to this pin for supply decoupling and stability.
13
MISO
O
Master-In-Slave-Out. Serial output from the ISD3900 to the host. This
pin is in tri-state when SSB=1.
14
SCLK
I
Serial Clock input to the ISD3900 from the host.
15
SSB
I
Slave Select input to the ISD3900 from the host. When SSB is low
device is selected and responds to commands on the SPI interface.
16
MOSI
I
Master-Out-Slave-In. Serial input to the ISD3900 from the host.
17
VCCD_PWM
I
Digital Power for the PWM Driver.

ISD3900
Publication Release Date: Dec 10, 2013
- 10 - Revision 1.5
Pin
Number
Pin Name
I/O
Function
18
SPK+
O
PWM driver positive output. This SPK+ output, together with SPK- pin,
provide a differential output to drive 8Ωspeaker or buzzer. During
power down this pin is in tri-state.
Or, can be configured as BTL which, together with SPK- pin, provide a
differential voltage output.
Or, can independently switch to AUDOUT or AUXOUT.
19
VSSD_PWM
I
Digital Ground for the PWM Driver.
20
SPK-
O
PWM driver negative output. This SPK- output, together with SPK+
pin, provides a differential output to drive 8Ωspeaker or buzzer.
During power down this pin is tri-state.
Or, can be configured as BTL which, together with SPK+ pin, provide a
differential voltage output.
Or, can independently switch to AUDOUT or AUXOUT.
21
VCCD_PWM
I
Digital Power for the PWM Driver.
22
NC
This pin should be left unconnected.
23
NC
This pin should be left unconnected.
24
NC
This pin should be left unconnected.
25
INTB
O
Active low interrupt request pin. This pin is an open-drain output.
26
RDY/BSYB
O
An output pin to report the status of data transfer on the SPI interface.
“High” indicates that ISD3900 is ready to accept new SPI commands
or data.
27
RESET
I
Applying power to this pin will reset the chip. (A high pulse of 50ms or
more will reset the chip.)
28
DO
O
Serial data output of the external serial flash interface. Connects to
data input (DI) of external serial flash.
29
CLK
O
Serial data CLK of the external serial flash interface.
30
GPIO3
I/O
GPIO
31
GPIO2
I/O
GPIO
32
GPIO1
I/O
GPIO
33
NC
This pin should be left unconnected.
34
NC
This pin should be left unconnected.
35
XTALOUT
O
Crystal interface output pin.

ISD3900
Publication Release Date: Dec 10, 2013
- 11 - Revision 1.5
Pin
Number
Pin Name
I/O
Function
36
XTALIN
I
The CLK_CFG register determines one of the following three
configurations: (1) A crystal or resonator connected between the
XTALOUT and XTALIN pins. (2) A resistor connected to GND as a
reference current to the internal oscillator and left the XTALOUT
unconnected. (3) An external clock input to the device and left the
XTALOUT unconnected.
37
NC
This pin should be left unconnected.
38
GPIO0
I/O
GPIO
39
NC
This pin should be left unconnected.
40
NC
This pin should be left unconnected.
41
AUDOUT
O
Audio Out. This pin can be either a voltage output or a current output
configured by the internal registers via SPI command.
If AUDOUT is not used, this pin should be left unconnected.
42
AUXOUT
O
Aux Out. This pin is an analog voltage output.
If AUXOUT is not used, this pin should be left unconnected.
43
VCCA
I
Analog power supply pin.
44
VSSA
I
Analog ground pin.
45
ANAOUT/
MIC-
O
Variable gain analog output with the gain set by feedback resistance to
ANAIN.
Or, can be configured as MIC- which, together with MIC+, provides a
microphone differential input.
If ANAIN/ANAOUT is not used, this pin should be left unconnected.
46
ANAIN/
MIC+
I
Variable gain analog input.
Or, can be configured as MIC+ which, together with MIC-, provides a
microphone differential input.
If ANAIN/ANAOUT is not used, this pin should be left unconnected.
47
AUXIN
I
Auxiliary input with the gain set by SPI command
If AUXIN is not used, this pin should be left unconnected.
48
NC
This pin should be left unconnected.

ISD3900
Publication Release Date: Dec 10, 2013
- 12 - Revision 1.5
6 SPI INTERFACE
This is a standard four-wire interface used for communication between ISD3900 and the host. It
consists of an active low slave-select (SSB), a serial clock (SCLK), a data input (Master Out Slave In -
MOSI), and a data output (Master In Slave Out - MISO). In addition, for some transactions requiring
data flow control, a RDY/BSYB signal (pin) is available.
The ISD3900 supports SPI mode 3: (1) SCLK must be high when SPI bus is inactive, and (2) data is
sampled at SCLK rising edge. A SPI transaction begins on the falling edge of SSB and its waveform is
illustrated below:
0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7
SSB
SCLK
MISO
MOSI XC7 C6 C5XC4 C3 C2 C1 C0
S7 S6 S5 S4 S3 S2 S1 S0 D7 D6 D5 D4 D3 D2 D1 D0
D7 D6 D5 D4 D3 D2 D1 D0
Z X
Figure 6-1 SPI Data Transaction.
A transaction begins with sending a command byte (C7-C0) with the most significant bit (MSB –C7)
sent in first. During the byte transmission, the status (S7-S0) of the device is sent out via the MISO
pin. After the byte transmission, depending upon the command sent, one or more bytes of data will be
sent via the MISO pin.
RDY/BSYB pin is used to handshake data into or out of the device. Upon completion of a byte
transmission, RDY/BSYB pin could change its state after the rising edge of the SCLK if the built-in 32-
byte data buffer is either full or empty. At this point, SCLK must remain high until RDY/BSYB pin
returns to high, indicating that the ISD3900 is ready for the next data transmission. See below for
timing diagram.

ISD3900
Publication Release Date: Dec 10, 2013
- 13 - Revision 1.5
0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7
SSB
SCLK
MISO
MOSI XC7 C6 C5XC4 C3 C2 C1 C0
PD RDY INT FULL X VG
BSY BUF FUL CMD BSY PD RDY INT FULL X VG BSY BUF FUL CMD BSY
D7 D6 D5 D4 D3 D2 D1 D0
Z X
RDY/BSYB
BR
T/
=1 =1
Figure 6-2 R/B Timing for SPI Writing Transactions.
If the SCLK does not remain high, RDY bit of the status register will be set to zero and be reported via
the MISO pin so the host can take the necessary actions (i.e., terminate SPI transmission and re-
transmit the data when the RDY/BSYB pin returns to high).
For commands (i.e., DIG_READ, SPI_PCM_READ and SPI_RCV_ENC) that read data from ISD3900,
MISO is used to read the data; therefore, the host must monitor the status via the RDY/BSYB pin and
take the necessary actions.
The INT pin will go low to indicate (1) data overrun/overflow when sending data to the ISD3900; or (2)
invalid data from ISD3900. See Figure 6-3 for the timing diagram.

ISD3900
Publication Release Date: Dec 10, 2013
- 14 - Revision 1.5
0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7
SSB
SCLK
MISO
MOSI XC7 C6 C5XC4 C3 C2 C1 C0
PD RDY INT FULL X VG
BSY BUF FUL CMD BSY PD RDY INT FULL X VG BSY BUF FUL CMD BSY
D7 D6 D5 D4 D3 D2 D1 D0
Z X
RDY/BSYB
BR
T/
=1 =0
INT
Figure 6-3 SPI Transaction Ignoring RDY/BSYB

ISD3900
Publication Release Date: Dec 10, 2013
- 15 - Revision 1.5
7 ANALOG AND DIGITAL SIGNAL PATH
7.1 ANALOG SIGNAL PATH
Analog signal path provides a configurable set of two analog inputs and three analog outputs along
with multiplexing and summation blocks to route signals between analog blocks and the digital signal
path.
AUDOUT
AUXIN
ANAIN
+Digital Signal Path:
Digital Filters
Resampling
Digital Mixing
Volume Control
DAC
ADC +
AUXOUT
PWM
Control
AUDOUT
AUXOUT
SPK+
SPK-
SUM1 SUM2
ADC_MUX
SUM2_MUX
AUD_MUX AUX_MUX
A
G
C
ANAIN
ANAOUT
Av = 0, 3, 6, 9dB
AUXIN
SPK+_MUX SPK-_MUX
Figure 7-1 Analog Signal Path, ANAIN Selected
Analog inputs consist of variable gain input amplifiers:
AUXIN can be configured by SPI command
ANAIN is determined by a selection of external resistors. ANAIN can also be configured
as MICIN (ANAIN/ANAOUT becomes MIC+/MIC-), which provides a microphone
differential input.
AUDOUT
AUXIN
MICIN
Digital Signal Path:
Digital Filters
Resampling
Digital Mixing
Volume Control
DAC
ADC +
AUXOUT
PWM
Control
AUDOUT
AUXOUT
SPK+
SPK-
SUM2
SUM2_MUX
AUD_MUX AUX_MUX
A
G
C
MIC+
MIC-
Av = 0, 3, 6, 9dB
AUXIN
SPK+_MUX SPK-_MUX
Figure 7-2 Analog Signal Path, MICIN Selected

ISD3900
Publication Release Date: Dec 10, 2013
- 16 - Revision 1.5
Analog outputs consist of:
AUXOUT is a single-ended voltage output
AUDOUT can be configured as a single-ended voltage output or a single-ended current
output. When configured as a voltage output, AUDOUT is exactly the same as the
AUXOUT.
BTL (bridge-tied-load) is a differential voltage output, which shares the same two pins of
PWM (SPK+/SPK-). Signal source of BTL could be either from AUD_MUX or AUX_MUX.
oBesides BTL, SPK+ and/or SPK- can also be configured individually:
SPK+ can switch to AUDOUT or AUXOUT
SPK- can switch to AUDOUT or AUXOUT
The analog path consists of the following blocks: AUXIN, ANAIN (or MICIN), SUM1, ADC_MUX
(SUM1 and ADC_MUX are ineffective when MICIN is selected), SUM2, SUM2_MUX, AUD_MUX,
AUX_MUX, SPK+_MUX, and SPK-_MUX. The summation blocks, SUM1 and SUM2, are able to mix
two signals together. SUM1 mixes the two analog inputs (AUXIN and ANAIN) for input into the digital
signal path. SUM2 mixes the analog input (AUXIN, or ANAIN, or AUXIN plus ANAIN) with the digital
signal path output. ADC_MUX provides input selection into the ADC. AUD_MUX and AUX_MUX
provide input selection into the AUDOUT and AUXOUT blocks. SPK+_MUX and SPK-_MUX provide
input selection into the SPK+ and SPK- blocks. The configuration registers, CFG5-CFG9 & CFG18,
control the active path features, allow individual power control of each block and enable the muting of
certain path inputs. The details of the path configuration registers are described in Section 12.3.
7.1.1 ANAIN & MICIN Analog Input
Single-ended ANAIN Input
ANAIN
ANAOUT
ANAIN
1Vpp
Vin
coup
C
in
R
f
R
Figure 7-3 ANAIN Input Amplifier
The ANAIN input amplifier is designed to allow a variable gain set via two external resistors. The goal
of gain selection is to produce a
pp
V1
signal into the ISD3900 audio path. Voltage gain is:

ISD3900
Publication Release Date: Dec 10, 2013
- 17 - Revision 1.5
infv RRA 
.
ANAIN supports gain settings from 1 to 100 according to
infv RRA 
.
f
R
should satisfy
 kRfk10040
. To achieve a gain of 100,
f
R
can be set to 100
k
, and
in
R
set to 1
k
.
coup
C
AC couples signals into the ISD3900, forming a single pole high pass filter. The 3dB frequency
is given by:
coupin
pass CR
f
 21

For
FCcoup  1
,
 kRin 1
, signals above 160Hz will be fed into the audio path.
Differential MICIN Input
Figure 7-4 Differential MIC Input Amplifier
The ISD3900 allows the use of pins ANAIN and ANAOUT as differential MIC inputs. In this mode, the
ANAIN and ANAOUT pins become MIC+ and MIC- and allow a differential input to be applied to the
ADC. This configuration is designed to be used in conjunction with the AGC to amplify microphone
signals while achieving good common mode rejection of supply noise. No mixing with AUXIN is
possible in this mode.
7.1.2 AUX Analog Input
The AUX Analog Input amplifies input signals with a fixed gain of 0dB, 3dB, 6dB, or 9dB, selectable
via SPI command. Similar to ANAIN, the gain setting should be configured so that the output signal
has a 1Vpp swing.

ISD3900
Publication Release Date: Dec 10, 2013
- 18 - Revision 1.5
AUXIN
Av = 0, 3, 6, 9dB
AUXIN
Vin
1Vpp
coup
C
Figure 7-5 AUXIN Input Amplifier
The coupling capacitor,
coup
C
, like in the case of ANAIN, should be set according to the value of
in
R
to allow signals above a certain frequency to pass through. The relationship repeated here is:
coupin
pass CR
f
 21

in
R
is the input impedance of the AUXIN amplifier and is dependent upon the gain setting as shown in
Table 7-1 below.
Table 7-1 Gain Setting Vs. Rin
Setting Gain dB Gain Rin (kOhms)
00 0 1.00 40.0
01 3 1.41 33.2
10 6 2.00 26.7
11 9 2.82 21.0
The minimum value of
in
R
is approximately 20kOhms, so a
coup
C
of 1µF will allow audio signals to
pass through under all possible gain settings.

ISD3900
Publication Release Date: Dec 10, 2013
- 19 - Revision 1.5
7.1.3 AUX & AUD Analog Output
AUXOUT is a single-ended voltage output. It needs an external amplifier to drive the speaker.
AUXOUT together with the external amplifier is usually used when loud volume like 1 watt output is
needed.
AUDOUT can be configured as a single-ended voltage output or a single-ended current output. When
configured as a voltage output, AUDOUT is exactly the same as the AUXOUT. When configured as a
current output, it uses a transistor to drive the speaker. Please note that the signal coming out of
AUD_MUX is always voltage regardless configured as a voltage or current output; if configured as a
current output, the AUDOUT block that follows the AUD_MUX converts the voltage signal to current
signal.
AUDOUT
DAC
+
AUXOUT
PWM
Control
AUDOUT
AUXOUT
SPK+
SPK-
SUM2
SUM2_MUX
AUD_MUX AUX_MUX
SPK+_MUX SPK-_MUX
From Digital Path
From Digital Path
From SUM1
From AUXIN
From ANAIN
Figure 7-6 Analog Outputs

ISD3900
Publication Release Date: Dec 10, 2013
- 20 - Revision 1.5
7.1.4 BTL Analog Output
BTL (bridge-tied-load) is a differential voltage output, which shares the same two pins of PWM (SPK+
and SPK-). As a differential output, BTL is naturally better than AUXOUT, the single-ended output, in
terms of noise rejection.
BTL can directly drive a speaker or drive a speaker via an external amplifier. Since BTL direct-drive
cannot reach the volume level that most users require, a usage together with an external amplifier is
recommended. Below is a table comparing the BTL, AUXOUT, and PWM:
BTL
AUXOUT
PWM
Driving Method
Can direct drive, but an
external amplifier is
required to reach
adequate volume level.
Need an external
amplifier.
Direct drive.
Driving Ability
High: depends on the
external amplifier.
High: depends on the
external amplifier.
360 mW.
Quality
Typical 80dB with good
noise rejection.
Typical 80dB.
Typical 60dB
Cost
Extra cost of the external
amplifier.
Extra cost of the external
amplifier.
No extra cost.
Table 7-2 Comparison of BTL, AUXOUT, and PWM
Signal source of BTL could be either from AUD_MUX or AUX_MUX. Figure 7-6 (the red line) shows
an example of BTL setting from the AUX_MUX.
Besides BTL, SPK+ and/or SPK- can also be configured individually:
SPK+ can switch to AUDOUT or AUXOUT
SPK- can switch to AUDOUT or AUXOUT
For detailed settings, please refer to 12.3 Device Configuration Registers, CFG18.
