nVent Hoffman JIC Swing-Out Panel Kit User manual

© 2018 Hoffman Enclosures Inc. PH 763 422 2211 • nVent.com/HOFFMAN 87558910
Rev. E P/N 99401468
JIC Swing-Out Panel Kit

© 2018 Hoffman Enclosures Inc. PH 763 422 2211 • nVent.com/HOFFMAN 87558910
- 2 -
WARNING
This accessory maintains UL/CSA Type 12, 4, 4X when installed per these
instructions.
This accessory is covered by UL le E61991 and CSA le LR42186.
To avoid electric shock and
equipmentdamage, disconnect any
power suppliesto the enclosure
before drilling mountingholes. Do not
energize any circuits beforeall internal
and external electrical andmechanical
clearances are checked toassure that
all assembled equipmentfunctions
safely and properly.

© 2018 Hoffman Enclosures Inc. PH 763 422 2211 • nVent.com/HOFFMAN87558910 - 3 -
Installation Steps:
1. Swing panel may be hinged on any side. Determine mounting position
desired and drill (8) Ø.172 (4mm) holes as shown.
2. Mount hinges (Item 7) and brackets (Item 8) using pan head screws
(Item 11) with nylon washers (Item 12) under the screw heads.
3. Mount swing panel to hinges (Item 7) with pan head screws (Item 3)
and lockwashers (Item 4). Adjust panel until it swings freely through
the door opening.
4. Captivate thumb screws (Item 5) to panel using retaining rings (Item 6)
provided.







© 2018 Hoffman Enclosures Inc. PH 763 422 2211 • nVent.com/HOFFMAN 87558910
- 4 -








 0,1%8//(7,1$&+$1)$6&$/3$'5
67</(&+4521/<
0,1%8//(7,1$/2$0$60
67</(+&/2*$21/<
0,1%8//(7,1$&+$1)$6&$/3$'5
$//27+(567</(6
;

%27+6,'(6


0,1%8//(7,1$&+$1)$6&$/3$'5
67</(&+4521/<
0,1%8//(7,1$/2$0$60
67</(+&/2*$21/<
0,1%8//(7,1$&+$1)$6&$/3$'5
$//27+(567</(6
<<
<
<
