nVent CADDY Speed Link SLS Locking Device–SLS3C50
• Single barrel locking device allows for quick prefabrication of strut or brackets
• Push-on nut quickly and securely installs to strut or bracket to keep the locking device in position and eases installation
• Finger tightening of nut secures the locking device into position without tools
• Installs in strut profiles without the need to insert fingers or tools into the strut
• Push-on nut guides the cable into the locking device and brings stability to the support
• Installs with open side of the strut channel facing up or down for more flexibility
W
TS
H1
H2
HS
SS
T
Part Number SLS3C50
Material Steel
Polypropylene
Zinc Alloy
Wire Rope Diameter 3 mm
Thread Size (TS) M12
Height 1 (H1) 2.1"
Height 2 (H2) 1.8"
Width (W) 0.8"
Thickness (T) 1/4" Max
Hole Size (HS) 0.50" – 0.56"
Slot Size (SS) 0.47" x 0.39" - 0.47" x 0.56"
Certifications cULus
Standard Packaging Quantity 50 pc
UPC 78285691386
EAN-13 0782856913863
The 2 mm locking device is compatible with C-Channel Types E0 and E0L.
The 3 mm locking device is compatible with C-Channel Types E1, E2, E2L, E3, E4, E5, Strut Channel Type C, Slotted, Strut Channel Type A, Slotted, Strut Channel Type AS, Perforated,
Strut Channel Type CC, Slotted, Strut Channel Type AA, Slotted.
Locking devices are only to be used with nVent CADDY Speed Link wire spools and accessories with the same specified Wire Rope Diameter as the locking device. Do not use with any
other wires.

UL, UR, cUL, cUR, cULus and cURus are registered certification marks of UL LLC.

WARNING
nVent products shall be installed and used only as indicated in nVent's product instruction sheets and training materials. Instruction sheets are available at www.erico.com and from
your nVent customer service representative. Improper installation, misuse, misapplication or other failure to completely follow nVent 's instructions and warnings may cause product
malfunction, property damage, serious bodily injury and death and/or void your warranty.

