NVT Phybridge FLEX-Link User manual

Activity
To FLEX
Activity
Link
To Endpoint
The FLEX-Link and FLEX-C adapters enable extended Ethernet and PoE reach
beyond traditional distances using 1, 2 or 4 pair UTP infrastructure. The
adapters, when used with the FLEX Switch or FLEX-Base, deliver 10/100 Mbps,
symmetrical full duplex. The FLEX offering is designed specifically to enable
easy deployment over UTP for reaches beyond that of standard Ethernet
eliminating the costs and disruption associated with IDF closet requirements.
FLEX-Link FLEX-C FLEX-Base
FLEX Adapter Applications
2 or 4 pair UTP
2 or 4 pair UTP
2 or 4 pair UTP
To Application
To Switch Local Power Option
Local Power Option
Local Power Option
Local Power Option
Local Power Option
10/100 Mbps (full duplex, symmetrical) & PoE++ over multi-pair UTP with 2,000ft (610M) reach.
NOTE: FLEX-Link max. power 50W over 4 pairs and FLEX-C maximum power 30W over 2 pairs
FLEX-C Installation Details
1. Remove the FLEX-C from its packaging.
2. Remove all legacy equipment from the UTP cable infrastructure.
NOTE: In order to avoid damage to endpoints, it is important that non-IP devices are
not connected when you connect the FLEX-C.
3. Connect the Network Infrastructure cable from the FLEX24 switch or
FLEX-Base to the FLEX-C (FLEX side).
4. Using CAT5 or higher category cable, connect the endpoint to FLEX-C
(Device side).
NOTE: FLEX-C can be used with FLEX24 switch or FLEX-Base
Product Details (NV-FLXLK-C)
• Paired with FLEX24, FLEX8 or FLEX-Base
• Up to 30W PoE
• PoE on spare pairs
• Supports IEEE compliant devices
FLEX-Link Installation Details
1. Remove the FLEX-Link from its packaging.
2. Remove all legacy equipment from the UTP cable infrastructure.
NOTE: In order to avoid damage to endpoints, it is important that non-IP devices are
not connected when you connect the FLEX-Link.
3. Connect the Network Infrastructure cable from the FLEX24 switch or
FLEX-Base to the FLEX-Link (FLEX side).
4. Using CAT5 or higher category cable, connect the endpoint to the FLEX-Link
(Endpoint side).
NOTE: FLEX-Link can be used with FLEX24 switch or FLEX-Base
Product Details (NV-FLXLK)
• Paired with FLEX24, FLEX8 or FLEX-Base
• Up to 50W PoE
• PoE on 4 pairs
• Local power option
• IEEE compliant
FLEX-Base
To Switch To Adapter
Installation Details
1. Remove the FLEX-Base from its packaging.
2. Remove all legacy equipment from the UTP cable infrastructure.
NOTE: In order to avoid damage to endpoints, it is important that non-IP devices are
not connected when you connect the FLEX-Base.
3. Connect FLEX-Base (Switch side) to downlink port on switch.
4. Connect the Network Infrastructure cable from the FLEX-Base (Adapter side) to
FLEX-Link or FLEX-C (FLEX side).
5. Using CAT5 or higher category cable, connect the endpoint to the FLEX-Link
or FLEX-C (Endpoint/Device side).
NOTE: FLEX-Base can be used with FLEX-Link or FLEX-C
Product Details (NV-FLXLK-Base)
• Paired with FLEX-Link or FLEX4
• Up to 50W PoE
NOTE: Please see page 2 for important safety instructions
QUICK INSTALL GUIDE
Copyright 2017 NVT Phybridge | 413-0003-1 | 2017/07 | Page 1888.901.3633 | [phone] | www.nvtphybridge.com
To FLEX To Endpoint
Activity
Link
Activity
• Local power option
• IEEE compliant
To FLEX To Device
Activity
Link/ Speed
Green:
100Mbps
Orange:
10Mbps Activity
Link
To FLEX To Device
To Switch To Adapter
Link/ Speed
Green:
100Mbps
Orange:
10Mbps
Link/ Speed
Green:
100Mbps
Orange:
10Mbps
37-55V DC In
37-55V DC In

QUICK INSTALL GUIDE
Copyright 2017 NVT Phybridge | 413-0003-1 | 2017/07 | Page 2888.901.3633 | [phone] | www.nvtphybridge.com
1 RJ45 port: UTP cable (2-pair or 4-pair)
4 pair CAT5e
Cable Type
1 pair CAT5e
2 pair CAT5e
2 pair CAT5e
100 Mbps
Data Rate
100 Mpbs
10 Mbps
100 Mbps
610m/ 2000ft
Reach
610m/2000ft
300m/1000ft
300m/1000ft
(adapter must be locally powered)
Important Safety Instructions
Product Description
These adapters are extremely simple to use, with
no IP or MAC address configuration required.
Status LEDs indicate power and link connectivi-
ty/activity for RJ45 ports.
The FLEX Adapters are backed by NVT
Phybridge's award winning customer support and
5 year warranty.
As an option, both the FLEX-Link and FLEX-Base
can be powered by an external Power adapter
with the following characteristics:
• Class 2,
• Efficiency VI
• Input voltage 100-240VAC, 50-60Hz
• Output voltage 55VDC / 1A or 2A
• Output connector: power barrel plug
(2.1mm ID and 5.5mm OD)
NVT Phybridge Part Numbers for the Power
Supplies are:
• NV-PS55-60W: 55VDC at up to 1000mA
(for FLEX-Link or FLEX-Base)
• NV-PS55-110W: 55VDC at up to 2000mA
(for FLEX-Base)
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with a dry cloth.
7) Install in accordance with the manufacturer’s
instructions.
8) Do not install near any heat sources such as
radiators, heat registers, stoves or other
apparatus (including DVRs) that produce heat.
9) Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
10) Only use attachments and accessories
specified by the manufacturer.
11) Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such as
a power supply cord or plug is damaged, liquid
has been spilled, or objects have fallen into the
apparatus, the apparatus has been exposed
!
TO REDUCE THE RISK OF ELECTRICAL
SHOCK, DO NOT REMOVE COVER OR
BACK. NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
WARNING: TO REDUCE THE RISK OF
ELECTRICAL SHOCK, DO NOT EXPOSE
THIS APPARATUS TO RAIN OR MOISTURE.
to rain or moisture, does not operate normally, or
has been dropped.
This installation should be made by a qualified
service person and should conform to all local
codes.
12) RJ45 PoE connection: to be connected only
to networks or circuits that are not routed to
outside plant or building.
Compliance and
Environmental Information
All the compliance and environmental
information is available on our website
www.nvtphybridge.com.
Refer to the FLEX24 or FLEX8 Quick Install
Guides under “Safety Warnings” for the FLEX
adapters
Reportez-vous aux Quick Install Guides FLEX24
ou FLEX8 sous "Safety Warnings" pour les
adaptateurs FLEX
Beachten Sie die FLEX24- oder FLEX8- Quick
Install Guides unter "Safety Warnings” für die
FLEX-Adapter
Consulte las Quick Install Guides FLEX24 o
FLEX8 bajo "Safety Warnings" para los
adaptadores FLEX
Katso FLEX24- tai FLEX8 Quick Install Guides
FLEX-sovittimien "Safety Warnings" alla
Raadpleeg de FLEX24 of FLEX8 Quick Install
Guides onder "Safety Warnings" voor de
FLEX-adapters
Se FLEX24 eller FLEX8 Quick Install Guides
under "Safety Warnings" för FLEX-adaptrarna.
Safety Warnings
Se FLEX24 eller FLEX8 Quick Install Guides
under "Safety Warnings" for FLEX-adaptere
Ανατρέξτε στους οδηγούς FLEX24 ήFLEX8
Quick Install Guides στην ενότητα "Safety
Warnings" για τους προσαρμογείς FLEX
Fare riferimento alla sezione FLEX24 o FLEX8
Quick Install Guides sotto "Safety Warnings"
per gli adattatori FLEX
Consulte o FLEX24 ou FLEX8 Quick Install
Guides em "Safety Warnings" para os
adaptadores FLEX
Irreferi għall-FLEX24 jew FLEX8 Quick Install
Guides taħt "Safety Warnings" għall-adapters
FLEX
Vaadake FLEX24 või FLEX8 Quick Install
Guides alusel "Safety Warnings" FLEX
adapterid
A FLEX adapterek "Safety Warnings" című
részében olvassa el a FLEX24 vagy a FLEX8
Quick Install Guides című részt
Nanašajo na FLEX24 ali FLEX8 Quick Install
Guides pod "Safety Warnings" za FLEX
adapterji
Další informace naleznete v příručkách FLEX24
nebo FLEX8 Quick Install Guides v části "Safety
Warnings" pro adaptéry FLEX
Kreiptis į FLEX24 ar FLEX8 Quick Install Guides
pagal "Safety Warnings" Už FLEX adapteriai
Skatiet FLEX24 vai FLEX8 Quick Install Guides
zem "Safety Warnings", lai FLEX adapteri
Pozrite si FLEX24 alebo FLEX8 Quick Install
Guides v časti "Safety Warnings" pre adaptéry
FLEX
Sjá FLEX24 eða FLEX8 Quick Install Guides
undir "Safety Warnings" fyrir FLEX-millistykki
Zobacz FLEX24 lub FLEX8 Quick Install Guides
w sekcji "Safety Warnings" w przypadku
adapterów FLEX
Se FLEX24 eller FLEX8 Quick Install Guides
under "Safety Warnings" for FLEX-adaptere
Consultați ghidurile FLEX24 sau FLEX8 Quick
Install Guides din secțiunea "Safety Warnings"
pentru adaptoarele FLEX
Обърнете се към FLEX24 или FLEX8 Quick
Install Guides в"Safety Warnings" за адаптери
FLEX.
