NVT Phybridge FLEX-Base User manual

Local Power
Up to 110W, 55V
(Optional)
Local Power
Up to 60W, 55V
(Optional)
Local Power
Up to 60W, 55V
(Optional)
The FLEX Extender Kits are robust, long reach single port UTP solutions. The kit
includes a FLEX-Base, a FLEX-Link or FLEX4 adapter and a 60 Watt or 110 Watt 55V
power supply. The FLEX-Link and FLEX4, when connected to the FLEX-Base unit via
2 or 4 pair UTP can deliver 100Mbps (symmetrical full duplex) with up to 50 watts of
power with 2,000ft (610m) reach. The FLEX offering is designed specifically to
enable easy deployment over UTP for reaches beyond that of standard Ethernet
eliminating the costs and disruption associated with IDF closet requirements.
NOTE: Please see page 2 for important safety instructions
Copyright 2018 NVT Phybridge | 413-0004-B | Page 1888.901.3633 | [phone] | www.nvtphybridge.com
Product Details (NV-FLXLK-Base)
• Paired with FLEX-Link or FLEX4
• Up to 50W PoE
• Local power option
• IEEE compliant
PRODUCT OVERVIEW
IP
Endpoint
To Switch
PoE over 2 or 4 Pair
UTP to 2,000ft (610m)
FLEX-Base FLEX-Link
Product Details (NV-FLXLK)
• Paired with FLEX24, FLEX8 or FLEX-Base
• Up to 50W PoE
• PoE on 4 pairs
• Local power option
• IEEE compliant
NOTE: FLEX-Link can be used with FLEX24 switch or FLEX-Base
1. Remove the FLEX-Base and FLEX-Link/FLEX4 from packaging.
2. Must ensure cable is properly terminated before connecting any FLEX product.
3. Remove all legacy equipment from the UTP cable infrastructure.
NOTE: In order to avoid damage to endpoints, it is important that non-IP devices are not connected when you connect the FLEX-Base.
4. Connect FLEX-Base (Switch side) to downlink port on switch.
5. Connect the Network Infrastructure cable from the FLEX-Base (LRE side) to FLEX-Link/FLEX4 (LRE side).
6. Using CAT5 or higher category cable, connect the endpoint to the FLEX-Link/FLEX4 (Endpoint side).
INSTALLATION STEPS (FOR NV-FLXLK-XKIT OR NV-FLX-04-XKIT EXTENDER KITS)
4 IP
Endpoints
FLEX4
FLEX4
Long Reach PoE over UTP
Product Details (NV-FLX-04)
• Paired with FLEX-Base, FLEX8, FLEX24
• 1 uplink port and 4 downlink ports
• Max 30W per downlink port
• Supports IEEE compliant devices
• Can be locally powered for additional PoE delivery
Speed
Green:
100Mbps
Orange:
10Mbps 100/ACT10/ACT
To LRE To Endpoint
FLEX Extender Kit (FLEX-Link+ FLEX-Base + 60W, 55V Power Supply)
P/N: NV-FLXLK-XKIT
FLEX Extender Kit (FLEX4 + FLEX-Base + 110W, 55V Power Supply)
P/N: NV-FLX-04-XKIT
FLEX-Base FLEX4
To Switch
PoE over 2 or 4 Pair
UTP to 2,000ft (610m)
FLEX-Base
Product Details (NV-FLXLK-Base)
• Paired with FLEX-Link or FLEX4
• Up to 50W PoE
• Local power option
• IEEE compliant
FLEX-Link
Note: The bandwidth speed shared by the four ports (“To Endpoint”) can be determined by looking at the
LED indicators on the RJ45 connector (“To LRE”). If the left side green LED activates, the bandwidth available
is 100Mbps. If the right side orange LED activates, the bandwidth speed available is 10Mbps.
FLEX-Link
Long Reach PoE over UTP
Local Power
Up to 60W, 55V
(Optional)
FLEX-Base
Long Reach PoE over UTP
Activity
Link
To Switch
Activity
To LRE
Toggle switch allows
option between
100Mbps (Green) or
10Mbps (Orange)
37-55V DC In
Link
Activity
To LRE
Link/ Speed
Green:
100Mbps
Orange:
10Mbps 37-55V DC In Activity
Link
To Endpoint
FLEX-Base
Long Reach PoE over UTP
Activity
Link
To Switch
Activity
To LRE
Toggle switch allows
option between
100Mbps (Green) or
10Mbps (Orange)
37-55V DC In
Link
QUICK INSTALL GUIDE - FLEX EXTENDER KIT

Copyright 2018 NVT Phybridge | 413-0004-B | Page 2
1 RJ45 port: UTP cable (2-pair or 4-pair)
4 pair CAT5e
Cable Type
1 pair CAT5e
2 pair CAT5e
2 pair CAT5e
100 Mbps
Data Rate
100 Mpbs
10 Mbps
100 Mbps
610m/ 2000ft
Reach
610m/2000ft
300m/1000ft
300m/1000ft
(adapter must be locally powered)
QUICK INSTALL GUIDE - FLEX EXTENDER KIT
888.901.3633 | [phone] | www.nvtphybridge.com
Compliance and Environmental Information
All the compliance and environmental information is available on our website www.nvtphybridge.com
Refer to the FLEX24 or FLEX8 Quick Install Guides under “Safety Warnings” for the FLEX adapters
Reportez-vous aux Quick Install Guides FLEX24 ou FLEX8 sous "Safety Warnings" pour les adaptateurs FLEX
Beachten Sie die FLEX24- oder FLEX8- Quick Install Guides unter "Safety Warnings” für die FLEX-Adapter
Consulte las Quick Install Guides FLEX24 o FLEX8 bajo "Safety Warnings" para los adaptadores FLEX
Katso FLEX24- tai FLEX8 Quick Install Guides FLEX-sovittimien "Safety Warnings" alla
Raadpleeg de FLEX24 of FLEX8 Quick Install Guides onder "Safety Warnings" voor de FLEX-adapters
Se FLEX24 eller FLEX8 Quick Install Guides under "Safety Warnings" för FLEX-adaptrarna
Se FLEX24 eller FLEX8 Quick Install Guides under "Safety Warnings" for FLEX-adaptere
Ανατρέξτε στους οδηγούς FLEX24 ήFLEX8 Quick Install Guides στην ενότητα "Safety Warnings" για τους προσαρμογείς FLEX
Fare riferimento alla sezione FLEX24 o FLEX8 Quick Install Guides sotto "Safety Warnings" per gli adattatori FLEX
Consulte o FLEX24 ou FLEX8 Quick Install Guides em "Safety Warnings" para os adaptadores FLEX
Irreferi għall-FLEX24 jew FLEX8 Quick Install Guides taħt "Safety Warnings" għall-adapters FLEX
Vaadake FLEX24 või FLEX8 Quick Install Guides alusel "Safety Warnings" FLEX adapterid
A FLEX adapterek "Safety Warnings" című részében olvassa el a FLEX24 vagy a FLEX8 Quick Install Guides című részt
Nanašajo na FLEX24 ali FLEX8 Quick Install Guides pod "Safety Warnings" za FLEX adapterji
Další informace naleznete v příručkách FLEX24 nebo FLEX8 Quick Install Guides v části "Safety Warnings" pro adaptéry FLEX
Kreiptis į FLEX24 ar FLEX8 Quick Install Guides pagal "Safety Warnings" Už FLEX adapteriai
Skatiet FLEX24 vai FLEX8 Quick Install Guides zem "Safety Warnings", lai FLEX adapteri
Pozrite si FLEX24 alebo FLEX8 Quick Install Guides v časti "Safety Warnings" pre adaptéry FLEX
Sjá FLEX24 eða FLEX8 Quick Install Guides undir "Safety Warnings" fyrir FLEX-millistykki
Zobacz FLEX24 lub FLEX8 Quick Install Guides w sekcji "Safety Warnings" w przypadku adapterów FLEX
Se FLEX24 eller FLEX8 Quick Install Guides under "Safety Warnings" for FLEX-adaptere
Consultați ghidurile FLEX24 sau FLEX8 Quick Install Guides din secțiunea "Safety Warnings" pentru adaptoarele FLEX
Обърнете се към FLEX24 или FLEX8 Quick Install Guides в"Safety Warnings" за адаптери FLEX
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Safety Warnings and Precautions
All of the above instructions provide basic installation information necessary for the proper and safe functioning of this equipment. Persons installing or
maintaining this product must read all of the safety instructions and the parts of system grounding, which are applicable to the system being maintained.
Only trained, qualified service personnel shall install or maintain this product.
Note the following:
• Keep these instructions with the equipment.
• Do not attempt to install or service this equipment unless you are skilled in the installation and maintenance of electronic telecommunications equipment and have
successfully completed specific training for this equipment.
WARNING: FAILURE TO FOLLOW ALL INSTRUCTIONS MAY RESULT IN IMPROPER EQUIPMENT OPERATION AND/OR RISK OF ELECTRICAL SHOCK.
WARNING: ANY CONNECTION TO AN OUTSIDE PLANT LEAD, AN OFF-PREMISE APPLICATION, OR ANY OTHER EXPOSED PLANT APPLICATION MAY
RESULT IN A FIRE OR SHOCK HAZARD, AND/OR DEFECTIVE OPERATION, AND/OR EQUIPMENT DAMAGE.
The NVT Phybridge Technical Support Group is available to assist you with product installation, configuration, monitoring and troubleshooting procedures. Should you
experience trouble with this equipment or for repair or warranty information, please contact NVT Phybridge at +1 905.901.3633 or [email protected].
Technical Support
Warranty: The FLEX adapters are backed by NVT Phybridge’s award-winning customer support and 5-year warranty.
