NVX NSW102V2 User manual

N-SERIES
SUBWOOFERS
USER MANUAL
NSW102V2 NSW104V2
NSW122V2 NSW124V2

THANK YOU FOR CHOOSING NVX
Congratulations on the purchase of your new NVX component subwoofer. The N-Series
subwoofer you hold in your hands is the culmination of an extensive research, development
and real world testing process. While this isn’t the easiest way to build a sub, the time and
personal attention we dedicate reects in the quality and performance of the nished product.
We are proud to build NVX subwoofers and are condent you will be proud to own one.
1
NVX N-SERIES SUBWOOFERS

SPECIFICATIONS
N-Series subwoofers incorporate
features designed to optimize
performance, durability and
usability in a real automotive
environment, including:
•Ultra-Light Non Pressed Paper Cone
Stiff and lightweight material allows
the subwoofer to remain accurate and
responsive even at high volume levels.
•
Custom Blended Foam Surround
High-roll design allows for extreme
excursion possible.
•
2” High Temperature Aluminum
Voice Coil
Provides robust power handling capabilities
and excellent heat dissipation.
•
High Strength Steel Basket
Retains exceptional rigidity to minimize distortion.
•Chrome-Plated, Spring-Loaded
Push Terminals
Simple and secure installation.
Visit: nvx.com | Call: 213.444.1689 |15303 Ventura Blvd. 9th Floor, Sherman Oaks, CA 91403 2
Varies based on enclosure type and volume. See pages 4 and 5.
A
B
D
C
N-SERIES NSW102V2 NSW104V2 NSW122V2 NSW124V2
Power Range (RMS) 200-350 W 200-350 W 200 - 350 W 200 - 350 W
Impedance per Voice Coil 2 Ohms 4 Ohms 2 Ohms 4 Ohms
Frequency Response 20-200 Hz 20-200 Hz 20 - 200 Hz 20 - 200 Hz
Xmax 10.78 mm 10.78 mm 12 mm 12 mm
Fs 36.40 35.40 28.50 28
Vas 17. 3 2 19.69 54.73 56.29
Sd 31.41 31.41 51.87 51.87
Qts 0.791 0.706 0.751 0.734
SPL (1W/M) 89 89 92 92
Net Weight 7.20 lbs (3.26 kg) 7.20 lbs (3.26 kg) 8.57 lbs (3.88 kg) 8.57 lbs (3.88 kg)
AOverall Diameter 10.28” (261 mm) 12.40” (315 mm)
BMounting Diameter 9.65” (245.11 mm) 11.69” (297 mm)
CCutout Diameter 9.06” (230.12 mm) 10.83” (275.08 mm)
DMounting Depth 4.20” (106.68 mm) 5.01” (127.25 mm)
NSW102V2 / 104V2 |NSW122V2 / 124V2

The enclosure designs listed
will give you the best possible
performance from your N-Series
subwoofer.
PORTED BOX
Ported boxes are the enclosure type we recommend for
optimum performance of your N-Series Subwoofer.
A ported box features a vent or port to couple the woofer’s
back-wave with the front-wave. This results in markedly
improved efciency and low frequency response. These
enclosures are somewhat larger than the sealed alternative.
SEALED BOXES
A sealed enclosure offers improved acoustic suspension and
cone control, which reduces distortion. They are smaller than
their ported counterparts, and offer atter bass response with
more consistency across the frequency range.
ENCLOSURES
3
N-SERIES NSW102V2 / 104V2 NSW122V2 / 124V2
Recommended
Enclosure Volume 0.75 ft.31.25 ft.3
Ideal Power RMS 350 W 350 W
F3 (Hz) 43 47
FC (Hz) 49 55
QTC 0.862 0.941
N-SERIES NSW102V2 / 104V2 NSW122V2 / 124V2
Recommended
Enclosure Volume 1.25 ft.31.75 ft.3
Tuning Frequency 34 Hz 36 Hz
Ideal Power RMS 300 W 350 W
F3 (Hz) 31 41
NVX N-SERIES SUBWOOFERS

•This limited warranty does not cover failure of the product resulting improper
installation, misuse, abuse, accident, neglect, mishandling, or wear from
ordinary use or environmental deterioration.
•This limited warranty does not cover cosmetic damage, including paint
damage, or consequential damage to ordinary use or environmental
deterioration.
•This limited warranty does not cover cosmetic damage, including paint
damage, or consequential damage to other components or premises which
may result for any reason from the failure of the product.
•This limited warranty is null and void for products not used in accordance
with NVX’s instructions.
•This limited warranty is null and void for products with altered or missing
serial numbers and for products not purchased from an authorized dealer.
•This limited warranty terminates if you sell or otherwise transfer this product
to another party.
•This limited warranty is null and void for any speaker or subwoofer that
has been damaged due to over-powering causing burnt voice coils and /or
mechanical failures such as ripped spiders or surrounds.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE, JURISDICTION TO JURISDICTION, OR
COUNTRY TO COUNTRY. NVX’S RESPONSIBILITY FOR MALFUNCTIONS AND DEFECTS IN HARDWARE IS LIMITED TO REPLACEMENT OR REPAIR AS SET FORTH IN THIS WAR-
RANTY STATEMENT. ALL EXPRESS AND IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, ARE LIMITED IN TIME TO THE TERM OF THIS WARRANTY. SOME STATES, JURISDICTIONS, OR COUNTRIES DO NOT ALLOW THE EXCLUSION OF
CERTAIN IMPLIED WARRANTIES OR CONDITIONS, OR LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY OR CONDITION LASTS, SO THIS LIMITATION MAY NOT APPLY TO
YOU. NVX DOES NOT ACCEPT LIABILITY FOR SPECIAL, INDIRECT, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING WITHOUT LIMITATION, ANY LIABILITY FOR THIRD
PARTY CLAIMS AGAINST YOU FOR DAMAGES OR FOR PRODUCTS NOT BEING AVAILABLE FOR USE. THE MAXIMUM LIABILITY FOR WHICH NVX MAY BE RESPONSIBLE WILL
BE NO MORE THAN THE AMOUNT YOU PAID FOR THE PRODUCT THAT IS THE SUBJECT OF THE CLAIM. SOME STATES, JURISDICTIONS, OR COUNTRIES DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
Warranty Outside the U.S.
The Warranty on this product shall comply with applicable law when sold to a consumer outside of the United States. To obtain any applicable warranty service, please contact the dealer from
which you purchased this product, or the distributor that supplied this product.
WARRANTY
Visit: nvx.com | Call: 213.444.1689 |15303 Ventura Blvd. 9th Floor, Sherman Oaks, CA 91403 4
NVX warrants to the original retail purchaser that this product is to be free from defective materials and workmanship for a period of one (1) year from the date of purchase, if it is properly used
and maintained. If this product proves defective in either material or workmanship, NVX, at it’s discretion, will (a) repair the product, or (b) replace the product, at no charge for parts or labor.
If the product model is no longer available and cannot be repaired effectively or replaced with an identical model, NVX at it’s sole option may replace the unit with a current model of equal or
greater value. To obtain a repair or replacement under the terms of this warranty, please return to dealer rst, if possible, and the dealer will direct you accordingly for repairs or replacement.
You will be required to submit a copy of the original receipt. Return shipping for exchanges/repairs is the sole responsibility of the original retail purchaser.
LIMITATIONS:
NSW102V2 / 104V2 |NSW122V2 / 124V2

•Receive your RA Number from NVX online at
nvx.com/support
•Package all defective components in the original packaging (if
available) or in a package that will prevent shipping damage.
•Package the original packaging in an additional shipping container to
avoid shipping damages and to comply with most shipping couriers
such as UPS and FedEx.
•Insure your return at the price paid as NVX is not responsible for
insurance losses or damages occurring in shipment to our facility.
•Clearly mark RA Number on the outside shipping container.
•Return only defective components as the return of functioning items
increases your return freight charges.
-Non-defective returns or products not eligible for warranty service will
be returned freight collect.
•Include a copy of the original receipt with the purchase date clearly
visible, and a “proof-of-purchase” statement listing the customer’s
name, dealer’s name and invoice number, and product purchased.
-Warranty expiration on items without proof-of-purchase will be
determined from type of sale and the manufacturing date code.
•Ship your package freight prepaid to the address below. Items sent
freight collect or COD will be refused.
NVX
Attn: Returns
10645 Freeport Dr.
Louisville, KY 40258-1873
Failure to follow the steps listed above may void your warranty. Any questions can be directed via email to [e-mail] or via mail at the
address listed above.
WHAT TO DO IF YOU NEED WARRANTY OR SERVICE
5
Defective products should be returned to the place of purchase. Your authorized NVX dealer is trained to handle
and expedite any warranty claim. Assistance in locating an authorized dealer can be found at nvx.com or by
contacting NVX directly.
Alternatively, if it becomes necessary for you to return defective product directly to NVX, please refer to
the following instructions for warranty service:
NVX N-SERIES SUBWOOFERS

Visit: nvx.com | Call: 213.444.1689 |15303 Ventura Blvd. 9th Floor, Sherman Oaks, CA 91403 6
NOTES
NSW102V2 / 104V2 |NSW122V2 / 124V2
Authorized Dealer’s Name:
Model Number:
Purchase Date:
Serial Number:

Visit: nvx.com | Call: 213.444.1689 | 15303 Ventura Blvd. 9th Floor, Sherman Oaks, CA 91403
