NXP Semiconductors KITVR5510 A0EVM Series Instruction Manual

UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
Rev. 1 — 3 May 2021 User manual
Document information
Information Content
Keywords VR5510, KITVR5510xA0EVM, evaluation kit, automotive, multi-output power
management integrated circuit
Abstract This user manual describes how to use the KITVR5510xA0EVM evaluation
kit. The VR5510 is an automotive multi-output power management integrated
circuit which focuses on gateway, V2X, and infotainment applications.

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
Rev Date Description
v.1 20210503 Initial version
Modifications NA
Revision history
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
2 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
1 Introduction
This document is the user guide for the KITVR5510DA0EVM, KITVR5510BA0EVM,
and KITVR5510MA0EVM evaluation boards (referred to throughout this document as
KITVR5510xA0EVM). This document is intended for engineers involved in the evaluation,
design, implementation, and validation of VR5510 Power Management Integrated Circuit
(PMIC) for high performance applications.
The scope of this document is to provide the user with information that covers interfacing
with the hardware, installing the GUI software, using other tools, and configuring the
board for the application environment.
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
3 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
2 Finding Kit Resources and Information on the NXP Web Site
NXP Semiconductors provides online resources for this evaluation board and its
supported device(s) on http://www.nxp.com.
The information page for KITVR5510xA0EVM evaluation board is at http://www.nxp.com/
KITVR5510xA0EVM. The information page provides overview information,
documentation, software and tools, parametrics, ordering information and a Getting
Started tab. The Getting Started tab provides quick-reference information applicable
to using the KITVR5510xA0EVM evaluation board, including the downloadable assets
referenced in this document.
2.1 Collaborate in the NXP community
The NXP community is for sharing ideas and tips, ask and answer technical questions,
and receive input on just about any embedded design topic.
The NXP community is at http://community.nxp.com.
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
4 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
3 Getting Ready
Working with the KITVR5510xA0EVM requires the kit contents, additional hardware and
a Windows PC workstation with installed software.
3.1 Kit contents
•Assembled and tested KITVR5510xA0EVM connected to FRDM-K82F in an antistatic
bag
•2.6 ft USB-STD A to USB-B-micro cable
•Quick Start Guide
3.2 Additional hardware
In addition to the kit contents, the following hardware is necessary or beneficial when
working with this kit.
•Power supply with a range of 5.0 V to 24.0 V and current limit set initially to 100 mA
•Two power supply cables with banana connectors at one end
3.3 Windows PC workstation
This evaluation board requires a Windows PC workstation. Meeting these minimum
specifications should produce great results when working with this evaluation board.
•USB-enabled computer with Windows 7 or Windows 10
3.4 Software
Installing software is necessary to work with this evaluation board. All listed software is
available on the evaluation board's information page at .
•NXP_GUI_ PR_4.1.0: software interface GUI tool to generate debug scripts
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
5 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
4 Getting to Know the Hardware
This section describes the kit features and provides information on the board and its
components.
4.1 KITVR5510xAEVM overview
The KITVR5510xA0EVM is a development platform built around the VR5510 PMIC as
the Device Under Test (DUT). The board allows designers to evaluate various functions
of the DUT. Connectors on the board provide the capability of measuring power-related
functions such as power, efficiency, loop stability, load transients, etc. Jumpers on the
board enable the selection of various capabilities, such as I/O control and switching
regulator feedback. The EVM also allows the VR5510 to be set into Debug Mode to
facilitate the debugging of faults generated by the device.
The KITVR5510xA0EVM includes NXPs FRDM-K82F development platform board.
The FRDM-K82F attaches to the bottom of the board and serves as the communication
interface between the KITVR5510xA0EVM and GUI software on the PC.
4.2 KITVR5510xA0EVM features
The KITVR5510xA0EVM evaluation board offers the following features:
•VR5510 debug mode support
•Connectors for measuring:
–Loop stability
–Load transients (BUCK12 or VPRE)
–AMUX/JTAG
–Signal and power
–Efficiency
•Load terminals for VPRE, BUCKs, BOOST, LDOs, and HVLDO regulator output
•Jumper selection for:
–I/O control (RSTB, PGOOD, STANDBY, PWRON2, PSYNC, VDDIO)
–Debug mode entry/exit
–Switching regulators (BUCKx, VPRE) feedback
•Multiple test points
4.3 Board descriptions
The KITVR5510xA0EVM board provides connectors, jumpers, and test points for all of
the evaluation functions supported by the kit.
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
6 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
4.3.1 LEDs, switches, and the PMIC
Figure 1 shows the location of the LEDs, switches, and the PMIC on the
KITVR5510xA0EVM board. The meaning of each of the LEDs is shown in Table 1
Figure 1. LEDs, switches, and the PMIC
Label Color Name Indication
D4 Green PGOOD_G External PGOOD signal – PGOOD released
D6 Green RSTB_G External RSTB signal – RSTB released
D12 Red RSTB_R External RSTB signal – RSTB asserted low
D13 Red PGOOD_R External PGOOD signal – PGOOD asserted low
D14 Red INTB External INTB signal
D15 Red FSOB_R External FSOB signal – FSOB asserted low
D18 Green VPRE VPRE_OUT enabled
D20 Green VBST BOOST_OUT enabled
D21 Green VBAT VBAT on
D29 Green FSOB_G External FSOB signal – FSOB released
Table 1. LEDs
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
7 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
4.3.2 Connectors
Figure 2. Connectors
Figure 2 shows all of the connectors on the KITVR5510xA0EVM. Pinouts for individual
connectors are shown in the schematic.
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
8 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
4.3.3 Jumpers
Figure 3 shows the location of jumpers on the KITVR5510xA0EVM board. Table 2
describes the jumper functions and settings.
Figure 3. Jumpers
Jumper Function Position Description
1 – 2 shorted VPRE
3 – 4 shorted LDO1
5 – 6 shorted LDO2
7 – 8 shorted BUCK3
J8 VDDIO selection
9 – 10 shorted
(default)
VDDIO external LDO (supplied from FRDM- K82F board )
1 – 2 shorted 5 V to debug mode
J11 Debug mode selection 2 – 3 shorted
(default)
GND to normal mode
1 – 2 shorted 7P5V generated from VBAT/VIN directly
J12 Debug mode selection 2 – 3 shorted
(default)
7P5V generated from an onboard regulator
1 – 2 shorted PWRON2 pin controlled by FRDM-K82F board
2 – 3 shorted
(default)
PWRON2 pin to GND
J13 PWRON2 I/O control
open PWRON2 pin user controlled
1 – 2 shorted PSYNC pin pulled up to VBOS
2 – 3 shorted
(default)
PSYNC pin to GND
J14 PSYNC I/O control
open PSYNC controlled by FRDM-K82F board
Table 2. Jumpers
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
9 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
Jumper Function Position Description
1 – 2 shorted STANDBY pin pulled up to VPRE
2 – 3 shorted STANDBY pin to GNDJ15 STANDBY I/O control
open (default) STANDBY pin controlled by FRDM-K82F board
1 – 2 shorted BUCK1_OUT as VCOREMON input
J60 VCOREMON source
selection 2 – 3 shorted
(default)
BUCK1/BUCK2_DUAL_PHASE_OUT as VCOREMON input
1 – 2 shorted VSUP 2 as HV_HDLVO input
J70 HDLVO high-voltage
input source selection 2 – 3 shorted
(default)
VPRE_OUT as HV_HDLVO input
1 – 2 shorted
(default)
BUCK1_OUT as LV_LDLVO input
J71 HDLVO low-voltage
input source selection 2 – 3 shorted VPRE as LV_HDLVO input
1 – 2 shorted 1P8V
J72
Voltage setting for
VDDIO external
regulator (J8: 9–10)
selection
2 – 3 shorted
(default)
3P3V
1 – 2 shorted Pull up to VDDIO
J82 PGOOD pin and pull-
up source control 2 – 3 shorted
(default)
Pull up to VPRE
1 – 2 shorted Pull up to VDDIO
J83 RSTB pin and pull-up
source control 2 – 3 shorted
(default)
Pull up to VPRE
J95 Not used 1 – 2 (default open)
1 – 2 shorted
(default)
VMON1 = VPRE (3.3 V)
3 – 4 shorted
(default)
VMON2 = BUCK3 (1.1 V)
5 – 6 shorted
(default)
VMON3 = LDO2 (1.8 V)
7 – 8 shorted
(default)
VMON4 = LDO1 (1.8 V)
9 – 10 shorted VMON4 = BOOST (5 V)
J101
Regx outputs to
VMONx (divided down
to 0P8V) connection
11 – 12 shorted VMON4 = External (0.8 V)
1 – 2 shorted
(default)
Feedback from capacitor close to inductor
J102 VPRE feedback
selection 2 – 3 shorted Feedback from external source, if needed
1 – 2 shorted Feedback from the load
J103 BUCK2 feedback
selection 2 – 3 (default) Feedback from capacitor close to inductor
1 – 2 shorted Feedback from the load
J104 BUCK1 feedback
selection 2 – 3 shorted
(default)
Feedback from capacitor close to inductor
1 – 2 shorted Feedback from the load
J105 BUCK3 feedback
selection 2 – 3 shorted
(default)
Feedback from capacitor close to inductor
open (default) BUCK1/BUCK2 in Single Phase
SJ3
BUCK1/BUCK2
Multiphase
configuration shorted BUCK1/BUCK2 in Dual Phase
open
SJ4
BUCK1 Single/
Multiphase
configuration shorted (default) BUCK1 in both Single and Multiphase
Table 2. Jumpers...continued
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
10 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
Jumper Function Position Description
open
SJ5
BUCK2 Single/
Multiphase
configuration shorted (default) BUCK2 in both Single and Multiphase
Table 2. Jumpers...continued
4.3.4 Test points
Figure 4 shows the location and the function of the test points on the
KITVR5510xA0EVM board
Figure 4. Test points
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
11 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
5 Layout
Figure 5. KITVR5510xA0EVM layout – top
Figure 6. KITVR5510xA0EVM layout – layer 2
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
12 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
Figure 7. KITVR5510xA0EVM layout – layer 3
Figure 8. VR551-xA0EVM layout – layer 4
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
13 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
Figure 9. KITVR5510xA0EVM layout – layer 5
Figure 10. KITVR5510xA0EVM layout – layer 6
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
14 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
Figure 11. KITVR5510xA0EVM layout – layer 7
Figure 12. KITVR5510xA0EVM layout – bottom
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
15 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
6 Bill of Materials
NXP does not assume liability, endorse, or warrant components from external manufacturers that are referenced in circuit drawings or tables. While NXP offers component recommendations in this configuration, it is the
customer’s responsibility to validate their application.
DNP: do not populate
For critical components, it is vital to use the manufacturer listed.
Quantity Schematic label Value Description Part number Manufacturer name Assy
Opt
Active components
1 U15 IC PWR MANAGEMENT QM -0.3/5.5 V 60 V AEC-Q100 QFN56 MVR5510AMMA0ES NXP SEMICONDUCTORS
1 U16 250 mW, 7.5 V DIODE ZENER 7.5 V 250 mW AEC-Q101 SOT23 BZX84-A7V5 Nexperia
1 U17 1.5-15 V 150 mA 2.5-16
V
IC LIN VREG LDO 1.5-15 V 150 mA 2.5-16 V SOT23-5 MIC5205YM5 MICREL
1 U20 1.25 V-60 V 50 mA
4.5-60 V
IC LIN VREG ADJ 1.25 V-60 V 50 mA 4.5-60 V SOP-8 RT9068GSP RICHTEK
Capacitors
4 C11,C15,C24,C25 22 μF CAP CER 22 μF 10 V 10% X7R AEC-Q200 1206 GCM31CR71A226KE
02
MURATA
1 C115 47 μF CAP CER 47 μF 10 V 20% X5R AEC-Q200 1206 GRT31CR61A476ME
13L
MURATA
3 C121,C122,C123 1000 pF CAP CER 1000 pF 50 V 10% X7R AEC-Q200 0603 CGA3E2X7R1H102K
080AA
TDK DNP
8 C124,C125,C126,C127,C128,C129,C130,C131 22 μF CAP CER 22 μF 10 V 10% X7R AEC-Q200 1206 GCM31CR71A226KE
02
MURATA DNP
1 C13 2200 pF CAP CER 2200 pF 50 V 10% X7R 0603 C0603X7R500-222KNE VENKEL COMPANY DNP
1 C132 470 pF CAP CER 470 pF 50 V 5% C0G 0603 CC0603JRNPO9BN471 YAGEO AMERICA
4 C133,C134,C135,C136 22 pF CAP CER 22 pF 50 V 1% C0G 0402 04025A220FAT2A AVX DNP
1 C14 1000 pF CAP CER 1000 pF 50 V 10% X7R AEC-Q200 0402 GCM155R71H102KA
37D
MURATA DNP
1 C153 4.7 μF CAP CER 4.7 μF 10 V 10% X7S AEC-Q200 0805 GCM21BC71A475KA73 MURATA
2 C155,C174 1.0 μF CAP CER 1.0 μF 16 V 10% X6S 0402 GRM155C81C105KE
11D
MURATA
1 C156 2.2 μF CAP TANT ESR=1.800 ΩS 2.2 μF 10 V 10% 3216-18 TPSA225K010R1800 AVX
9 C16,C17,C26,C66,C67,C94,C102,C176,C177 0.1 μF CAP CER 0.1 μF 50 V 10% X7R AEC-Q200 0402 GCM155R71H104KE02 MURATA
1 C162 0.047 μF CAP CER 0.047 μF 50 V 10% X7R AEC-Q200 0603 CGA3E2X7R1H473K
080AA
TDK
1 C163 47 μF CAP ALEL 47 μF 50 V 20% AEC-Q200 SMD MAL214699101E3 VISHAY
INTERTECHNOLOGY
5 C164,C165,C166,C167,C168 10 μF CAP CER 10 μF 50 V 10% X7S AEC-Q200 1210 CGA6P3X7S1H106K2
50AB
TDK
1 C172 1 μF CAP CER 1 μF 25 V 10% X7R AEC-Q200 0603 CGA3E1X7R1E105K0
80AC
TDK
1 C173 0.22 μF CAP CER 0.22 μF 50 V 10% X7R 0805 C0805X7R500-224KNE VENKEL COMPANY
1 C178 330 pF CAP CER 330 pF 50 V 5% C0G AEC-Q200 0402 GCM1555C1H331JA
16D
MURATA DNP
2 C179,C180 0.022 μF CAP CER 0.022 μF 50 V 10% X7R AEC-Q200 0402
0.022 μF
GCM155R71H223KA
55D
MURATA
1 C181 18 pF CAP CER 18 pF 50 V 5% C0G AEC-Q200 0402 GCM1555C1H180JA16 MURATA
6 C19,C23,C104,C105,C108,C110 4.7 μF CAP CER 4.7 μF 16 V 10% X7R AEC-Q200 0805 GCM21BR71C475KA
73
MURATA
8 C20,C21,C106,C107,C148,C149,C150,C161 22 uF CAP CER 22 uF 16 V 20% X7R AEC-Q200 1210 GCM32ER71C226ME
19
MURATA
1 C61 10 μF CAP CER 10 μF 16 V 20% X7S AEC-Q200 0805 CGA4J1X7S1C106M1
25AC
TDK
3 C69,C113,C154 1000 pF CAP CER 1000 pF 50 V 10% X7R AEC-Q200 0402 GCM155R71H102KA
37D
MURATA
1 C71 0.01 μF CAP CER 0.01 μF 50 V 10% X7R AEC-Q200 0402 GCM155R71H103KA
55D
MURATA DNP
1 C72 0.01 μF CAP CER 0.01 μF 50 V 5% X7R 0603 C0603C103J5RACTU KEMET
1 C76 0.022 μF CAP CER 0.022 μF 25 V 10% X7R 0603 CC0603KRX7R8BB223 YAGEO AMERICA
17 C95,C96,C97,C98,C100,C112,C137,C138,C1
39,C140,C141,C142,C143,C144,C145,C146,
C147,C160
1 μF CAP CER 1 μF 10 V 10% X7S AEC-Q200 0402 GCM155C71A105KE
38D
MURATA
1 C99 1.0 μF CAP CER 1.0 μF 50 V 10% X7R FAIL SAFE AEC-Q200 1206 GCJ31CR71H105KA
12L
MURATA
Diodes
1 D10 2 A DIODE SCH PWR RECT 2 A 60V AEC-Q101 SOD-123 NRVTS260ESFT1G ON SEMICONDUCTOR
4 D12,D13,D14,D15 20 mA LED RED SGL 20 mA SMT LS M67K-H2L1-1-0-2-
R18-Z
OSRAM
1 D27 5 A DIODE SCH RECT 60 V 5 A AEC-Q101 SOT1289 PMEG060V050EPD Nexperia
Table 3. Bill of Materials (KITVR5510MA0EVM)
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
16 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
NXP does not assume liability, endorse, or warrant components from external manufacturers that are referenced in circuit drawings or tables. While NXP offers component recommendations in this configuration, it is the
customer’s responsibility to validate their application.
DNP: do not populate
For critical components, it is vital to use the manufacturer listed.
Quantity Schematic label Value Description Part number Manufacturer name Assy
Opt
1 D28 36 V DIODE TVS UNIDIR 36 V -- AEC-Q101 SOD882 AQHV36-01ETG LITTELFUSE
6 D4,D6,D18,D20,D21,D29 2 Ma LED GRN SGL 2 0mA SMT NRND LP M67K-E2G1-25 OSRAM
Resistors
1 R143 470 KΩ RES TF 470 KΩ 1/10 W 1% AEC-Q200 0402 ERJ-2RKF4703X PANASONIC
5 R149,R157,R158,R159,R160 0.01 Ω RES TF 0.01 Ω 1 W 1% AEC-Q200 1206 ERJ-8CWFR010V PANASONIC
9 R15,R20,R85,R86,R87,R219,R225,R228,R265 1.50 KΩ RES MF 1.50 KΩ 1/16 W 1% 0402 WR04X1501FTL WALSIN TECHNOLOGY
CORP.
1 R169 68.1 KΩ RES MF 68.1 KΩ 1/10 W 1% 0603 CRCW060368K1FKEA VISHAY
INTERTECHNOLOGY
3 R17,R21,R220 510 KΩ RES MF 510 KΩ 1/10 W 5% 0603 RC0603JR-07510KL YAGEO AMERICA
2 R170,R242 27.4 KΩ RES MF 27.4 KΩ 1/10 W 1% 0603 RC0603FR-0727K4L YAGEO AMERICA
1 R177 115.0 KΩ RES MF 115.0 KΩ 1/10 W 1% AEC-Q200 0603 RK73H1JTTD1153F KOA SPEER
1 R180 68.1 KΩ RES MF 68.1 KΩ 1/10 W 1% 0603 CRCW060368K1FKEA VISHAY
INTERTECHNOLOGY
DNP
1 R188 169 KΩ RES MF 169 KΩ 1/10 W 1% AEC-Q200 0402 RK73H1ETTP1693F KOA SPEER
1 R189 280 KΩ RES MF 280 KΩ 1/10 W 1% AEC-Q200 0402 RK73H1ETTP2803F KOA SPEER
3 R19,R248,R272 ZERO Ω RES MF ZERO Ω 1/10 W -- 0603 CR-03JL7----0R THYE MING TECH CO
LTD
1 R190 76.8 KΩ RES MF 76.8 KΩ 1/10 W 1% AEC-Q200 0402 RK73H1ETTP7682F KOA SPEER
22 R192,R193,R194,R195,R196,R197,R198,R199
,R200,R201,R202,R203,R204,R205,R206,R20
7,R208,R209,R210,R211,R212,R213
1 KΩ RES MF 1 KΩ 1/16 W 0.1% 0402 RN731ETTP1001B25 KOA SPEER
9 R2,R46,R47,R145,R217,R218,R229,R254,R
266
5.1 KΩ RES 5.1 KΩ 1/16 W 0.1% 0402 ERA2AEB512X PANASONIC
1 R237 0.01 Ω RES METAL STRIP 0.01 Ω 1 W 1% 2512 WSK2512R0100FEA VISHAY
INTERTECHNOLOGY
1 R25 2.2 Ω RES MF 2.2 Ω 1/10W 1% AEC-Q200 0603 CRCW06032R20FKEA VISHAY
INTERTECHNOLOGY
DNP
1 R251 620 KΩ RES MF 620 KΩ 1/10 W 1% AEC-Q200 0402 RK73H1ETTP6203F KOA SPEER
1 R252 115 KΩ RES MF 115 KΩ 1/10 W 1% AEC-Q200 0402 RK73H1ETTP1153F KOA SPEER
1 R258 1.00 KΩ RES MF 1.00 KΩ 1/10 W 0.1% AEC-Q200 0603 ERA3AEB102V PANASONIC
1 R259 10 KΩ RES MF 10 KΩ 1/10 W 0.1% AEC-Q200 0603 ERA-3AEB103V PANASONIC
2 R26,R27 1.0 MΩ RES MF 1.0 MΩ 1/16 W 1% AEC-Q200 0402 RK73H1ETTP1004F KOA SPEER
1 R260 100 KΩ RES MF 100 KΩ 1/10 W 5% AEC-Q200 0603 CRCW0603100KJNEA VISHAY
INTERTECHNOLOGY
2 R263,R264 1.8 KΩ RES MF 1.8 KΩ 1/10 W 1% AEC-Q200 0402 RK73H1ETTP1801F KOA SPEER
1 R271 1.5 KΩ RES MF 1.5 KΩ 1/16 W 0.1% AEC-Q200 0402 ERA-2AEB152X PANASONIC
1 R29 5.1 K Ω RES 5.1 K Ω 1/16 W 0.1% 0402 ERA2AEB512X PANASONIC DNP
1 R30 ZERO Ω RES MF ZERO Ω 1/16 W -- AEC-Q200 0402 CRCW04020000Z0ED VISHAY
INTERTECHNOLOGY
DNP
56 R31,R116,R117,R118,R119,R120,R121,R122
,R123,R124,R125,R126,R127,R128,R129,R1
30,R131,R132,R133,R134,R135,R136,R137,
R138,R139,R140,R141,R142,R150,R151,R15
2,R153,R154,R155,R156,R161,R167,R171,R
174,R178,R182,R183,R184,R185,R186,R187
,R191,R232,R233,R256,R261,R262,R267,R2
68,R269,R270
ZERO Ω RES MF ZERO Ω 1/16 W -- AEC-Q200 0402 CRCW04020000Z0ED VISHAY
INTERTECHNOLOGY
4 R36,R146,R147,R148 10 KΩ RES MF 10 KΩ 1/16 W 1% 0402 RC0402FR-0710KL Yageo
2 R38,R238 2.2 KΩ RES MF 2.2 KΩ 1/16 W 1% AEC-Q200 0402 CRCW04022K20FKED VISHAY
INTERTECHNOLOGY
1 R64 8.2 KΩ RES MF 8.2 KΩ 1/10 W 1% AEC-Q200 0402 RK73H1ETTP8201F KOA SPEER
1 R79 115.0 KΩ RES MF 115.0 KΩ 1/10 W 1% AEC-Q200 0603 RK73H1JTTD1153F KOA SPEER DNP
5 R88,R168,R172,R175,R179 22.1 KΩ RES MF 22.1 KΩ 1/10 W 1% 0603 CRCW060322K1FKEA VISHAY
INTERTECHNOLOGY
Switches, Connectors, Jumpers, and Test Points
1 J101 HDR 2X6 HDR 2X6 TH 100MIL CTR 338H AU 100L TSW-106-07-F-D SAMTEC
1 J106 CON 2X10 CON 2X10 POWER EDGE TH 2.5MM SP 600H AU 115L 45719-0007 MOLEX
1 J11,J12,J13,J14,J15,J60 HDR 1x3 HDR 1x3 TH 100MIL SP 343H SN 100L TSW-103-07-T-S SAMTEC
8 J31,J32,J33,J34,J97,J98,J99,J100 CON 1X2 CON 1X2 TB TH 5MM SP 398H SN 138L 691102710002 WURTH ELEKTRONIK
EISOS GMBH & CO.
KG (ELECTRONIC &
ELECTROMEHANICAL
COMP)
2 J6,J91 CON 2X8 CON 2X8 PLUG 2.54MM CTR 328H AU 120L 5-146257-8 TE Connectivity Ltd
9 J70,J71,J72,J82,J83,J102,J103,J104,J105 HDR 1X3 HDR 1X3 TH 100MIL SP 330H AU HTSW-103-07-S-S SAMTEC
Table 3. Bill of Materials (KITVR5510MA0EVM)...continued
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
17 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
NXP does not assume liability, endorse, or warrant components from external manufacturers that are referenced in circuit drawings or tables. While NXP offers component recommendations in this configuration, it is the
customer’s responsibility to validate their application.
DNP: do not populate
For critical components, it is vital to use the manufacturer listed.
Quantity Schematic label Value Description Part number Manufacturer name Assy
Opt
1 J73 CON 2X10 CON 2X10 PLUG 2.54MM CTR 328H AU 120L 6-146257-0 TE Connectivity Ltd
1 J75 CON 2X6 CON 2X6 PLUG 2.54MM CTR 328H AU 120L 5-146257-6 TE Connectivity Ltd
14 J76,J78,J84,J85 HDR 2X12 HDR 2X12 TH 100MIL CTR 338H AU 100L TSW-112-07-G-D SAMTEC
1 J8 HDR 2X5 HDR 2X5 TH 100MIL CTR 339H AU 95L 210-92-05GB01 Pinrex Enterprise Co., Ltd
2 J86,J87 HDR 2X5 HDR 2X5 TH 100mil CTR 330H Au TSW-105-08-G-D SAMTEC
1 J92 CON 1X2 CON 1X2 BANANA RED RA TH 15.3MM SP 488H AG 197L 571-0500 DELTRON EMCON LTD
1 J93 CON 1X2 CON 1X2 BANANA BLACK RA TH 15.3MM SP 488H AG 197L 571-0100 DELTRON EMCON LTD
1 J95 HDR 1X2 HDR 1X2 TH 100MIL SP 378H AU 130L 826629-2 TYCO ELECTRONICS
1 L11 4.7 μH IND PWR 4.7 μH@1 MHz 2.2A 20% AEC-Q200 SMD TFM252012ALMA4R7
MTAA
TDK
1 L2 1.0 μH IND PWR 1.0 μH@ 100KHz 17.9A 20% AEC-Q200 SMD SPM6545VT-1R0M-D TDK
3 L4,L5,L6 1.0 μH IND PWR 1.0 μH@1 MHZ 4.7A 20% AEC-Q200 SMD TFM252012ALMA1R0
MTAA
TDK
1 L7 4.7 μH IND PWR 4.7 μH@100 kHz 11A 20% AEC-Q200 SMT XAL6060-472ME COILCRAFT
3 Q4,Q5,Q10 30 V 400 mA TRAN NMOS PWR 30 V 400 mA AEC-Q101 SOT23 NX3008NBK,215 Nexperia
1 Q7 16.8 mΩ 49 A 60 V TRAN NMOS DUAL PWR 16.8 mΩ 49 A 60 V AEC-Q101
SO8FL
NVMFD5C672NL ON SEMICONDUCTOR
1 Q9 -20 VDS TRAN PMOS PWR -20VDS SOT-23 IRLML6302TRPBF INTERNATIONAL
RECTIFIER
22 SH1,SH2,SH5,SH6,SH7,SH8,SH9,SH10,SH11
,SH12,SH13,SH14,SH15,SH16,SH17,SH18,S
H19,SH20,SH21,SH22,SH23,SH24
0 Ω ZERO OHM CUT TRACE 0201 PADS; NO PART TO ORDER
3 SJ3,SJ4,SJ5 SOLDER BLOB JUMPER 0402 OPEN NO PART TO ORDER
4 SJ8,SJ9,SJ10,SJ11 SOLDER BLOB JUMPER 1206 OPEN NO PART TO ORDER
2 SW2,SW5 SW SPST DIP SLD 25 mA 24 V SMD A6S-1104-H OMRON
2 TP119,TP120 TEST POINT PAD 30 MIL DIA SMT, NO PART TO ORDER
25 TP51,TP96,TP97,TP98,TP99,TP100,TP101,TP
102,TP103,TP104,TP105,TP106,TP107,TP108
,TP109,TP130,TP132,TP133,TP134,TP141,TP
142,TP143,TP144,TP145,TP146
TEST POINT PAD SIZE 4.7 MM X 3.4 MM SMT 5016 KEYSTONE
ELECTRONICS
14 TP68,TP93,TP94,TP95,TP112,TP113,TP114,T
P115,TP116,TP117,TP118,TP131,TP147
TEST POINT PC MULTI PURPOSE RED TH 5010 KEYSTONE
ELECTRONICS
Table 3. Bill of Materials (KITVR5510MA0EVM)...continued
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
18 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
7 Installing and Configuring Software and Tools
Unzip the NXP_GUI_PR_4.1.0 into any desired location. Find the NXP_GUI-4.1.0-
Setup from the GUI folder inside the package and run it to install the GUI in any desired
location.
7.1 Freedom board BOOTLOADER refresh in a Windows 7 system
Note: This procedure does not apply if the board is already programmed.
1. Ensure that the boot loader in the GUI package is the latest specified in the link below.
If not, download the latest boot loader for the specific MCU(K82F) from the location
below:
https://os.mbed.com/blog/entry/DAPLink-bootloader-update/
2. Press the RST push button on the Freedom board and connect the USB cable to the
SDA port (J5) on the Freedom board. A new “BOOTLOADER” device appears on the
left pane of the File Explorer.
Figure 13. Freedom board
3. Drag and drop the downloaded file “0244_k20dx_bootloader_update_0x8000.bin” into
the BOOTLOADER drive.
Note: Ensure that enough time is allowed for the firmware to be saved in the boot
loader.
4. Disconnect and reconnect the USB cable into the SDA port (this time without pressing
the RST push button).
5. Drag and drop the file “k20dx_frdmk82f_if_crc_legacy_0x8000.bin” from the package
(MCU/K82F_FW folder) into the BOOTLOADER drive.
Note: Make sure to allow enough time for the firmware to be saved in the Bootloader.
The device should change to FRDM_K82FD.
6. Locate the file “nxp-gui-fw-frdmk82f-usb_hid-vr5510_b0_v0.7.3.bin” from the package
(MCU/K82F_FW folder) and drag and drop the file into the FRDM_K82FD device.
7. The Freedom board firmware is successfully loaded. Disconnect and reconnect the
USB cable to the USB port. Open the previously installed NXPGUI. The “Start” button
on the top left corner must be activated.
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
19 / 32

NXP Semiconductors UM11587
KITVR5510xA0EVM Evaluation Kit User Guideline
7.2 Freedom Board BOOTLOADER Refresh in a Windows 10 System
Note: This procedure does not apply if the board is already programmed.
1. If only the NXPGUI firmware has to be updated, start from Step 4 in Section 7.1
"Freedom board BOOTLOADER refresh in a Windows 7 system
". The PC detects FRDM_K82FD. Proceed to Step 6 to load the latest firmware file
received from NXP and follow up with Step 7.
2. If only the NXPGUI firmware has to be updated, start from Step 4 in Section 7.1
"Freedom board BOOTLOADER refresh in a Windows 7 system
". The PC detects FRDM_K82FD. Proceed to Step 6 to load the latest firmware file
received from NXP and follow up with step 7.
3. Download the latest bootloader from this location below for the specific MCU(K82F):
https://os.mbed.com/blog/entry/DAPLink-bootloader-update/
4. Disable the storage services: Run services.msc, then double click on the storage
service from the list and press the stop button.
5. Press the RST push button on the Freedom board and connect the USB cable to the
SDA port (J5) on the Freedom board. A new “BOOTLOADER” device appears on the
left pane of the File explorer .
6. Drag and drop the downloaded boot loader file into the BOOTLOADER drive.
Note: Ensure that enough time is allowed for the firmware to be saved in the boot
loader.
7. Disconnect and reconnect the USB cable to the SDA port (this time without pressing
the RST push button). The drive is changed to “MAINTENANCE”.
8. Follow Steps 5-7 from Section 7.1 "Freedom board BOOTLOADER refresh in a
Windows 7 system
".
9. If only firmware update is required, then repeat Step 1 above.
10.Reenable the services by following Step 2, but now pressing the start button.
UM11587 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2021. All rights reserved.
User manual Rev. 1 — 3 May 2021
20 / 32
