MIMXRT1050 EVKB Board Hardware User’s
Guide
NXP Semiconductors Document identifier: MIXRT1050EVKBHUG
User's Guide Rev. 1, 11/2020

Contents
Chapter 1 Introduction........................................................................................... 3
1.1 Board overview..........................................................................................................................3
1.2 IMXRT1050 EVKB contents...................................................................................................... 4
1.3 IMXRT1050 EVKB board revision history..................................................................................4
Chapter 2 Specifications........................................................................................ 5
2.1 i.MX RT1050 processor.............................................................................................................6
2.2 Boot mode configurations..........................................................................................................7
2.3 Power tree................................................................................................................................. 7
2.4 SDRAM memory......................................................................................................................10
2.5 SD card slot.............................................................................................................................10
2.6 Hyper Flash............................................................................................................................. 10
2.7 QSPI Flash.............................................................................................................................. 10
2.8 Ethernet connector.................................................................................................................. 10
2.9 USB PHY connector................................................................................................................10
2.10 Audio input/output connector.................................................................................................10
2.11 OpenSDA circuit (DAP-Link)................................................................................................. 10
2.12 JTAG connector.....................................................................................................................11
2.13 Arduino expansion port..........................................................................................................11
2.14 Camera module connector.................................................................................................... 12
2.15 User interface switch............................................................................................................. 12
2.16 Sensor................................................................................................................................... 13
2.17 User interface LED indicator..................................................................................................13
2.18 LCD interface.........................................................................................................................13
Chapter 3 PCB information.................................................................................. 14
Chapter 4 EVKB design files................................................................................15
Chapter 5 Contents of the Evaluation kit............................................................. 16
Chapter 6 Revision history...................................................................................17
NXP Semiconductors
MIMXRT1050 EVKB Board Hardware User’s Guide, Rev. 1, 11/2020
User's Guide 2 / 18

Chapter 1
Introduction
This document is a Hardware User’s Guide for the IMXRT1050 Evaluation Kit (EVKB) based on the NXP Semiconductor i.MX
RT1050 Processor. This board is fully supported by NXP Semiconductor. The manual includes system setup and debugging, and
provides detailed information on the overall design and usage of the EVKB board from a hardware systems perspective.
1.1 Board overview
This EVK board is a platform designed to showcase the most commonly used features of the i.MX RT1050 Processor in a small,
low cost package. The IMXRT1050 EVKB board is an entry level development board, which gives the developer the option of
becoming familiar with the processor before investing a large amount or resources in more specific designs.
Table 1 describes features of the IMXRT1050 EVKB board.
Table 1. Board features
Processor NXP Processor MIMXRT1052DVL6B (A1 silicon)
DRAM Memory SDRAM 256 Mb, 166 MHz MT48LC16M16A2B4-6AIT: G
DCDC MPS MP2144GJ
LDO UNION UM1550S-18 UM1750S-00
Mass Storage
TF Card Slot
64 Mbit Quad SPI Flash
512 Mbit Hyper Flash
Display Interface LCD Connector
Ethernet 10/100 Mbit/s Ethernet Connector. PHY Chip: KSZ8081RNB
USB
USB 2.0 OTG Connector
USB 2.0 Host Connector
Audio Connector
3.5 mm Audio Stereo Headphone Jack
Board-Mounted Microphone
Left & Right Speaker Out Connectors
SPDIF Interface (unpopulated)
Power Connector 5V DC-Jack
Debug Connector
JTAG 20-pin Connector (SWD by default)
OpenSDA with DAP-Link
Sensor FXOS8700CQ: 6-Axis Ecompass (3-Axis Mag, 3-Axis Accel)
Camera CMOS Sensor Interface
CAN CAN Bus Connector
User Interface Button ON/OFF, POR Reset, Reset, USER Button
Led Indicator Power Status, Reset, OpenSDA, USER LED
Table continues on the next page...
NXP Semiconductors
MIMXRT1050 EVKB Board Hardware User’s Guide, Rev. 1, 11/2020
User's Guide 3 / 18

Table 1. Board features (continued)
Expansion Port Arduino Interface
PCB 3.937-inch × 5.9055-inch (10 cm × 15 cm), 4-layer board
1.2 IMXRT1050 EVKB contents
The IMXRT1050 EVKB contains the following items:
• IMXRT1050 EVKB board
• USB cable (Micro B)
1.3 IMXRT1050 EVKB board revision history
• EVKB: Mass product
1. EVKB boards are based on A1 silicon.
2. Change C88 to 2.2 uf/35 V or 1.0 uf/35 V to ensure the back light control circuits working normally. This
change is only for Rev A, A1 and B, but not for Rev B1. For details, see Figure 1.
Figure 1. EVKB board revision history
NOTE
NXP Semiconductors
Introduction
MIMXRT1050 EVKB Board Hardware User’s Guide, Rev. 1, 11/2020
User's Guide 4 / 18

Chapter 2
Specifications
This chapter provides detailed information about the electrical design and practical considerations of the EVKB Board. Each block
of the EVKB board, as shown in Figure 2, will be discussed.
Figure 2. Block diagram
The overview of the IMXRT1050 EVKB board is as shown in Figure 3 and Figure 4.
NXP Semiconductors
MIMXRT1050 EVKB Board Hardware User’s Guide, Rev. 1, 11/2020
User's Guide 5 / 18

Figure 3. Overview of the IMXRT1050 EVKB board (Front side)
Figure 4. Overview of the IMXRT1050 EVKB board (Back side)
2.1 i.MX RT1050 processor
The i.MX RT1050 is a new processor family featuring NXP's advanced implementation of the Arm® Cortex®-M7 core. It provides
high CPU performance and best real-time response. The i.MX RT1050 provides various memory interfaces, including SDRAM,
Raw NAND FLASH, NOR FLASH, SD/eMMC, Quad SPI, HyperBus and a wide range of other interfaces for connecting
NXP Semiconductors
Specifications
MIMXRT1050 EVKB Board Hardware User’s Guide, Rev. 1, 11/2020
User's Guide 6 / 18

peripherals, such as WLAN, Bluetooth™, GPS, displays, and camera sensors. Same as other i.MX processors, i.MX RT1050 also
has rich audio and video features, including LCD display, basic 2D graphics, camera interface, SPDIF and I2S audio interface.
The i.MX RT1050 applications processor can be used in areas such as industrial HMI, IoT, motor control and home appliances.
The architecture's flexibility enables it to be used in a wide variety of other general embedded applications too. The i.MX processor
provides all interfaces necessary to connect peripherals such as WLAN, Bluetooth™, GPS, camera sensors, and multiple displays.
For more detailed information about i.MX RT1050, see i.MX RT1050 Datasheet and Reference manual.
2.2 Boot mode configurations
The device has four boot modes (one is reserved for NXP use). The boot mode is selected based on the binary value stored in
the internal BOOT_MODE register. Switch (SW7-3 & SW7-4) is used to select the boot mode on the IMXRT1050 EVKB board.
Table 2. Boot mode pin settings
BOOT_MODE[1:0] (SW7-3 SW7-4) BOOT type
00 Boot From Fuses
01 Serial Downloader
10 Internal Boot
11 Reserved
Typically, the internal boot is selected for normal boot, which is configured by external BOOT_CFG GPIOs. Table 3 describes the
typical Boot mode and Boot device settings.
Table 3. Typical boot mode and boot device settings
SW7-1 SW7-2 SW7-3 SW7-4 Boot device
OFF ON ON OFF Hyper Flash
OFF OFF ON OFF QSPI Flash
ON OFF ON OFF SD card
For more information about boot mode configuration, see the System Boot chapter in i.MX RT1050 Processor
Reference Manual (document IMXRT1050RM).
For more information about IMXRT1050 EVKB boot device selection and configuration, see Main board schematic.
NOTE
2.3 Power tree
A DC 5 V external power supply is used to supply the IMXRT1050 EVKB Board at J2, and a slide switch SW1 is used to turn the
Power ON/OFF. J28 and J9 can also be used to supply the EVKB Board. Different power supply need to configure different Jumper
setting of J1. Table 4 describes the details.
Table 4. Jumper settings of power supply
Power supply J1 settings
J2 1-2
Table continues on the next page...
NXP Semiconductors
Specifications
MIMXRT1050 EVKB Board Hardware User’s Guide, Rev. 1, 11/2020
User's Guide 7 / 18

Table 4. Jumper settings of power supply (continued)
Power supply J1 settings
J9 3-4
J28 5-6
Some computers’ USB cannot support 500 ma before establishing communication. In this case, it is recommended
to replace the computer or use the power adapter (J2) to power the EVKB board.
NOTE
Figure 5 shows the power tree.
Figure 5. Power tree
Figure 6 shows the power control logic of the IMXRT1050 EVKB board.
• It will power up SNVS firstly, then PMIC_REQ_ON will be switched on to enable external DC/DC to power up other power
domains.
• ON/OFF button is used to switch ON/OFF PMIC_REQ_ON to control power modes.
• The RESET button and WDOG output are used to reset the system power.
NXP Semiconductors
Specifications
MIMXRT1050 EVKB Board Hardware User’s Guide, Rev. 1, 11/2020
User's Guide 8 / 18

Figure 6. Power control diagram
Table 5 describes the power rails on the board.
Table 5. Power rails
Power rail MIN (V) TYP (V) MAX (V) Description
VDD_SOC_IN 0.925 —1.26 Core supplies input voltage
VDD_HIGH_IN 3 3.3 3.6 VDD_HIGH_IN supply voltage
DCDC_IN 33.313.61Power for DCDC
VDD_SNVS_IN 2.4 3 3.6 Power for SNVS and RTC
USB_OTG1_VBUS
USB_OTG2_VBUS
4.4 5 5.5 Power for USB VBUS
VDDA_ADC 33.3 3.6 Power for 12-bit ADC
NVCC_SD0
3 3.3 3.6 Power for GPIO in SDIO1 bank (3.3 V mode)
1.65 1.8 1.95 Power for GPIO in SDIO1 bank (1.8 V mode)
NVCC_SD1
3 3.3 3.6 Power for GPIO in SDIO2 bank (3.3 V mode)
1.65 1.8 1.95 Power for GPIO in SDIO2 bank (1.8 V mode)
NVCC_EMC
3 3.3 3.6 IO supply for GPIO in EMC bank (3.3 V mode)
1.65 1.8 1.95 IO supply for GPIO in EMC bank (1.8 V mode)
NVCC_GPIO 3 3.3 3.6 IO power for GPIO
NXP Semiconductors
Specifications
MIMXRT1050 EVKB Board Hardware User’s Guide, Rev. 1, 11/2020
User's Guide 9 / 18

1. For silicon A0, DCDC_IN voltage domain is 2.9 - 3.1 V.
2.4 SDRAM memory
One 256 Mb, 166 MHz SDRAM (MT48LC16M16A2B4-6AIT: G) is used on the EVK board.
2.5 SD card slot
There is a SD card slot (J20) on the IMXRT1050 EVKB Board. J20 is the Micro SD slot for USDHC1 interface. If the developer
wants to boot from the SD card, the boot device switch (SW7) settings should be: ON, OFF, ON, OFF, as shown in Table 3.
2.6 Hyper Flash
On the IMXRT1050 EVKB Board, there is one 512 Mbit Hyper Flash device. If the developer wants to boot from the Hyper Flash,
the boot device switch (SW7) settings should be: OFF. ON, ON, OFF, as shown in Table 3.
2.7 QSPI Flash
A 64Mbit QSPI Flash is used on the IMXRT1050 EVKB Board. If the developer wants to boot from the QSPI Flash, the boot device
switch(SW7) settings should be: OFF, OFF, ON, OFF, as shown in Table 3.
By default, this QSPI Flash is disabled on the EVKB. To enable the onboard QSPI Flash, the settings need to be changed.
1. Remove resistors R356 and R361 to R366.
2. Weld 0 Ω resistors: R153 to R158.
2.8 Ethernet connector
There is one Ethernet Mac controller in the MIMXRT1050 processor. The Ethernet subsystem of the IMXRT1050 EVKB board is
provided by the KSZ8081RNB 10/100M Ethernet Transceiver (U16) and a RJ45 (J19) with integrated Magnetic.
2.9 USB PHY connector
The MIMXRT1050 contains two integrated USB 2.0 PHYs capable of connecting to USB host/device systems at the USB
Low-Speed (LS) rate of 1.5 Mbits/s, Full-Speed (FS) rate of 12 Mbits/s or at the USB 2.0 High-Speed (HS) rate of 480 Mbits/s.
2.10 Audio input/output connector
The Audio CODEC used on the IMXRT1050 EVKB Board is Wolfson’s Low Power, high quality Stereo Codec, WM8960.The
IMXRT1050 EVKB board includes:
• One headphone interface (J12)
• One onboard MIC (P1)
• Two speaker interfaces (J16, J17)
• The SPDIF interface (J14 & J18, DNP)
J12 is a 3.5 mm audio stereo headphone jack, which supports jack detect.
2.11 OpenSDA circuit (DAP-Link)
The OpenSDA circuit (CMSIS–DAP) is an open-standard serial and debug adapter. It bridges serial and debug communications
between a USB host and an embedded target processor.
CMSIS-DAP features a Mass Storage Device (MSD) bootloader, which provides a quick and easy mechanism for loading different
CMSIS-DAP Applications such as flash programmers, run-control debug interfaces, serial-to-USB converters, and more. Two or
more CMSIS-DAP applications can run simultaneously. For example, run-control debug application and serial-to-USB converter
NXP Semiconductors
Specifications
MIMXRT1050 EVKB Board Hardware User’s Guide, Rev. 1, 11/2020
User's Guide 10 / 18
