1. Introduction
The MPT612 is the first dedicated IC performing Maximum Power Point Tracking (MPPT)
designed for applications using solar photovoltaic (PV) cells, or fuel cells. To simplify
development and maximize system efficiency, the MPT612 is supported by:
•a patent-pending MPPT algorithm
•an application-specific software library
•easy-to-use application programming interfaces (APIs)
Dedicated hardware functions for PV panels, including voltage and current measurement
and panel parameter configuration, simplify design and speed development.
MPT612 is based on a low-power ARM7TDMI-S RISC core operating up to 70 MHz
achieving overall system efficiency ratings up to 98 %. It controls the external switching
device through a signal derived from a patent-pending MPPT algorithm which delivers up
to 99.5% Maximum Power Point Tracking (MPPT) efficiency. The solar PV DC source can
be connected to the IC through appropriate voltage and current sensors. The IC
dynamically extracts the maximum power from the PV panel without user intervention
when enabled. The IC can be configured for boundary conditions set in software. There is
up to 15 kB of flash memory available for application software.
In this user manual, solar PV terminology is primarily used as an example. However, the
MPT612 is equally useful for fuel cells or any other DC source which has MPP
characteristics.
2. Features
•ARM7TDMI-S 32-bit RISC core operating at up to 70 MHz
•128-bit wide interface and accelerator enabling 70 MHz operation
•10-bit ADC providing:
–Conversion times as low as 2.44 s per channel and dedicated result registers
minimize interrupt overhead
–Five analog inputs available for user-specific applications
•One 32-bit timer and external event counter with four capture and four compare
channels
•One 16-bit timer and external event counter with four compare channels
•Low-power Real-Time Clock (RTC) with independent power supply and dedicated
32 kHz clock input
•Serial interfaces including:
–Two UARTs (16C550)
–Two Fast I2C-buses (400 kbit/s)
–SPI and SSP with buffering and variable data length capabilities
•Vectored interrupt controller with configurable priorities and vector addresses
•Up to 28, 5 V-tolerant fast general-purpose I/O pins
•Up to 13 edge- or level-sensitive external interrupt pins available

UM10413 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 1 — 16 December 2011 4 of 268
NXP Semiconductors UM10413
MPT612 User manual
•Three levels of flash Code Read Protection (CRP)
•70 MHz maximum clock available from programmable on-chip PLL with input
frequencies between 10 MHz and 25 MHz and a settling time of 100 ms
•Integrated oscillator operates with an external crystal at between 1 MHz and 25 MHz
•Power-saving modes include:
–Idle mode
–Two Power-down modes; one with the RTC active and with the RTC deactivated
•Individual enabling/disabling of peripheral functions and peripheral clock scaling for
additional power optimization
•Processor wake-up from Power-down and Deep power-down mode using an external
interrupt or the RTC
•In-System/In-Application Programming (ISP/IAP) via on-chip bootloader software.
Single flash sector or full chip erase in 100 ms and programming of 256 bytes in 1 ms
3. Applications
•Battery charge controller for solar PV power and fuel-cells. The use cases are
–Battery charging for home appliances such as lighting, DC fans, DC TV, DC motors
or any other DC appliance
–Battery charging for public lighting and signaling, such as: LED street lighting,
garden/driveway lighting, dusk-to-dawn lighting, railway signaling, traffic signaling,
remote telecom terminals/towers
–Battery charging for portable devices
•DC-to-DC converter per panel to provide improved efficiency
•Micro inverter per panel removes the need for one large system inverter
4. Device information
5. Architectural overview
The MPT612 comprises:
•ARM7TDMI-S CPU with emulation support
•ARM7 Local Bus for interface to on-chip memory controllers
•AMBA Advanced High-performance Bus (AHB) to interface the interrupt controller
•ARM Peripheral Bus (APB, a compatible superset of ARM AMBA Advanced
Peripheral Bus) for connecting on-chip peripheral functions
The MPT612 configures the ARM7TDMI-S processor core in little endian byte order.
Table 1. MPT612 device information
Type number Flash memory RAM ADC Temperature
range (C)
MPT612FBD48 32 kB 8 kB 8 inputs 40 to +85

UM10413 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 1 — 16 December 2011 5 of 268
NXP Semiconductors UM10413
MPT612 User manual
AHB peripherals are allocated a 2 MB range of addresses at the top of the 4 GB ARM
memory space. Each AHB peripheral is allocated a 16 kB address space within the AHB
address space. Apin connect block controls on-chip peripheral connections to device pins
(see Section 12.4 “Register description” on page 62) configured by software to specific
application requirements for the use of peripheral functions and pins.
5.1 ARM7TDMI-S processor
The ARM7TDMI-S is a general purpose 32-bit processor core offering high performance
and very low-power consumption. The ARM architecture is based on Reduced Instruction
Set Computer (RISC) principles making the instruction set and decode mechanisms much
simpler than micro programmed Complex Instruction Set Computers (CISC). This
simplicity results in a high instruction throughput and impressive real-time interrupt
response from a small, cost-effective processor core.
Pipeline techniques are employed ensuring all parts of the processing and memory
systems can operate continuously. Typically, while one instruction is being executed, its
successor is being decoded and a third instruction is being read from memory.
The ARM7TDMI-S processor also employs a unique architectural strategy known as
Thumb making it suitable for high-volume applications with memory restrictions, or
applications where code density is an issue.
The key idea behind Thumb is a super-reduced instruction set. Essentially, the
ARM7TDMI-S processor has two instruction sets:
•the standard 32-bit ARM set
•the 16-bit Thumb set
The Thumb 16-bit instruction sets allow up to twice the density of standard ARM code
while retaining most of the performance advantage of ARM over a traditional 16-bit
processor using 16-bit registers, made possible using the ARM code 32-bit register set.
Thumb code provides up to 65 % of standard ARM code and 160 % of the performance of
an equivalent ARM processor connected to a 16-bit memory system.
The particular flash implementation in the MPT612 also allows full speed execution in
ARM mode. Programming performance-critical and short code sections in ARM mode is
recommended. The impact on the overall code size is minimal but the speed can increase
by 30 % over Thumb mode.
5.2 On-chip flash memory system
The MPT612 incorporates a 32 kB flash memory system. This memory can be used for
both code and data storage. Various methods can be used to program flash memory, such
as using:
•the built-in JTAG interface
•In Systems Programming (ISP)
•UART
•In Application Programming (IAP)

UM10413 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 1 — 16 December 2011 6 of 268
NXP Semiconductors UM10413
MPT612 User manual
The application program can erase and/or program flash memory while the application is
running using IAP, allowing greater flexibility, for example, data storage field firmware
upgrades. The entire flash memory is available for user code as the bootloader resides in
a separate memory.
The MPT612 flash memory provides a minimum of 100 000 erase/write cycles and 20
years of data-retention memory.
5.3 On-chip Static RAM (SRAM)
On-chip static RAM can be used for code and/or data storage. The SRAM can be
accessed as 8-bit, 16-bit and 32-bit. The MPT612 provides 8 kB of static RAM.
6. Block diagram
Fig 1. MPT612 block diagram
001aam089
PV VOLTAGE
MEASUREMENT
PV voltage sense
PV CURRENT
MEASUREMENT
PV current sense
BATTERY VOLTAGE
MEASUREMENT
battery voltage sense
BATTERY CURRENT
MEASUREMENT
battery current sense
TEMPERATURE
MEASUREMENT
temperature sense
LOAD CURRENT
MEASUREMENT
these blocks are needed for MPPT functionality
these blocks can be used for customer specific applications
PV CONFIGURATION
BLOCK
MPT612
MPPT ALGORITHM
BATTERY CHARGE
CYCLE ALGORITHM
BATTERY
CONFIGURATION BLOCK
LOAD MANAGEMENT
LOAD CONFIGURATION
BLOCK
load configuration
parameters
battery configuration
parameters
STATUS INDICATION
PV configuration parameters
SWITCH CIRCUIT
CONTROL
BATTERY
PROTECTION BLOCK
LOAD PROTECTION
LEDs
PWM
battery
load
load current sense

UM10413 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 1 — 16 December 2011 7 of 268
NXP Semiconductors UM10413
MPT612 User manual
7. Memory addressing
7.1 Memory maps
The MPT612 incorporates several distinct memory regions, shown in Figure 2 to Figure 4.
Figure 2 shows the overall map of the entire address space from the user program
viewpoint following reset. The interrupt vector area supports address remapping, which is
described later in this section.
Fig 2. System memory map
aaa-000568
0.0 GB
1.0 GB
0x0000 0000
RESERVED ADDRESS SPACE
8 kB ON-CHIP STATIC RAM
RESERVED ADDRESS SPACE
0x4000 2000
0x4000 1FFF
0x4000 0000
2.0 GB 0x8000 0000
BOOT BLOCK
0x7FFF E000
0x7FFF DFFF
3.0 GB 0xC000 0000
RESERVED ADDRESS SPACE
3.75 GB
4.0 GB
3.5 GB
AHB PERIPHERALS
APB PERIPHERALS
0xE000 0000
0xF000 0000
0xFFFF FFFF
32 kB ON-CHIP NON-VOLATILE MEMORY
0x0000 8000
0x0000 7FFF

UM10413 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 1 — 16 December 2011 8 of 268
NXP Semiconductors UM10413
MPT612 User manual
Figure 3, Figure 4, and Table 2 show different views of the peripheral address space. Both
the AHB and APB peripheral areas are 2 MB spaces which are divided up into 128
peripherals. Each peripheral space is 16 kB in size, simplifying address decoding for each
peripheral. All peripheral register addresses are word aligned (to 32-bit boundaries)
regardless of their size, eliminating the need for byte lane mapping hardware to allow byte
AHB section is 128 16 kB blocks (totaling 2 MB).
APB section is 128 16 kB blocks (totaling 2 MB).
Fig 3. Peripheral memory map
aaa-000569
RESERVED
RESERVED
0xF000 0000
0xEFFF FFFF
APB PERIPHERALS
0xE020 0000
0xE01F FFFF
0xE000 0000
AHB PERIPHERALS
0xFFFF FFFF
0xFFE0 0000
0xFFDF FFFF
3.75 GB
3.5 GB
3.5 GB + 2 MB
4.0 GB - 2 MB
4.0 GB

UM10413 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 1 — 16 December 2011 9 of 268
NXP Semiconductors UM10413
MPT612 User manual
(8-bit) or half-word (16-bit) accesses at smaller boundaries. This method requires all word
and half-word registers to be accessed at once. For example, it is not possible to read or
write the upper byte of a word register separately.
Fig 4. AHB peripheral map
aaa-000570
VECTORED INTERRUPT CONTROLLER
(AHB PERIPHERAL #0)
0xFFFF F000 (4G - 4K)
0xFFFF C000
0xFFFF 8000
(AHB PERIPHERAL #125)
(AHB PERIPHERAL #124)
(AHB PERIPHERAL #3)
(AHB PERIPHERAL #2)
(AHB PERIPHERAL #1)
(AHB PERIPHERAL #126)
0xFFFF 4000
0xFFFF 0000
0xFFE1 0000
0xFFE0 C000
0xFFE0 8000
0xFFE0 4000
0xFFE0 0000

UM10413 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 1 — 16 December 2011 10 of 268
NXP Semiconductors UM10413
MPT612 User manual
7.2 MPT612 memory remapping and boot block
7.2.1 Memory map concepts and operating modes
Basically, each memory area in the MPT612 has a "natural" location in the memory map,
and is the address range for which code residing in that area is written. Most memory
spaces remain permanently fixed in the same location, eliminating the need to design
parts of the code to run in different address ranges.
Because of the ARM7 processor interrupt vector locations (at addresses 0x0000 0000
through 0x0000 001C, as shown in Table 3), a small portion of the boot block and SRAM
spaces need remapping to allow alternative uses of interrupts in the different operating
modes described in Table 4. Remapping of the interrupts is accomplished via the memory
mapping control feature (Section 10.7 “Memory mapping control” on page 42).
Table 2. APB peripheries and base addresses
APB peripheral Base address Peripheral name
0 0xE000 0000 Watchdog timer
1 0xE000 4000 reserved
2 0xE000 8000 Timer 1
3 0xE000 C000 UART0
4 0xE001 0000 UART1
5 0xE001 4000 not used
6 0xE001 8000 not used
7 0xE001 C000 I2C0
8 0xE002 0000 SPI0
9 0xE002 4000 RTC
10 0xE002 8000 GPIO
11 0xE002 C000 pin connect block
12 0xE003 0000 not used
13 0xE003 4000 ADC
14 to 22 0xE003 8000
0xE005 8000 not used
23 0xE005 C000 I2C1
24 0xE006 0000 not used
25 0xE006 4000 not used
26 0xE006 8000 SSP
27 0xE006 C000 not used
28 0xE007 0000 reserved
29 0xE007 4000 Timer 3
30 to 126 0xE007 8000
0xE01F 8000 not used
127 0xE01F C000 system control block

UM10413 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 1 — 16 December 2011 11 of 268
NXP Semiconductors UM10413
MPT612 User manual
7.2.2 Memory remapping
In order to allow for compatibility with future derivatives, the entire boot block is mapped to
the top of the on-chip memory space. This arrangement avoids larger or smaller flash
modules having to change the location of the boot block (which requires changing the
bootloader code) or changing the boot block interrupt vector mapping. Memory spaces
other than the interrupt vectors remain in fixed locations. Figure 5 shows the on-chip
memory mapping in the modes defined in Table 4.
The portion of memory remapped to allow interrupt processing in different modes includes
the interrupt vector area (32 bytes) and an additional 32 bytes for a total of 64 bytes. The
remapped code locations overlay addresses 0x0000 0000 through 0x0000 003F. A typical
user program in the flash memory can place the entire FIQ handler at address
0x0000 001C without any need to consider memory boundaries. The vector in the SRAM,
external memory, and boot block, must contain branches to the interrupt handlers, or to
other instructions that establish the branch to the interrupt handlers.
There are three reasons this configuration was chosen:
•To give the FIQ handler in the flash memory the advantage of not having to take a
memory boundary, caused by the remapping, into account.
•Minimize the need for the SRAM and boot block vectors to deal with arbitrary
boundaries in the middle of code space.
Table 3. ARM exception vector locations
Address Exception
0x0000 0000 reset
0x0000 0004 undefined instruction
0x0000 0008 software interrupt
0x0000 000C prefetch abort (instruction fetch memory fault)
0x0000 0010 data abort (data access memory fault)
0x0000 0014 reserved
Remark: Identified as reserved in ARM documentation, used by the
bootloader as the valid user program key. Details described in
Section 25.5.2 on page 218.
0x0000 0018 IRQ
0x0000 001C FIQ
Table 4. MPT612 memory mapping modes
Mode Activation Usage
Boot
loader
mode
hardware
activation by
any reset
bootloader always executes after any reset. Boot block interrupt
vectors are mapped to the bottom of memory to allow handling
exceptions and using interrupts during the boot loading process.
User flash
mode software activation by
boot code
activated by bootloader when a valid user program signature is
recognized in memory and bootloader operation is not forced. Interrupt
vectors are not remapped and are found at the bottom of the flash
memory.
UserRAM
mode software activation by
user program
activated by a user program as desired. Interrupt vectors are
remapped to the bottom of the static RAM.

UM10413 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 1 — 16 December 2011 12 of 268
NXP Semiconductors UM10413
MPT612 User manual
•To provide space to store constants, for jumping beyond the range of single word
branch instructions.
Remapped memory areas, including the interrupt vectors, continue to appear in their
original location in addition to the remapped address.
Details of remapping and examples can be found in Section 10.7 “Memory mapping
control” on page 42.
7.3 Prefetch abort and data abort exceptions
If an access is attempted for an address that is in a reserved or unassigned address
region, the MPT612 generates the appropriate bus cycle abort exception. The regions
are:
•Areas of the memory map that are not implemented for a specific ARM derivative. For
the MPT612:
–Address space between on-chip Non-Volatile Memory and on-chip SRAM, labeled
"Reserved Address Space" in Figure 2. For this device, memory address range is
from 0x0000 8000 to 0x3FFF FFFF.
–Address space between on-chip static RAM and the boot block. Labeled
"Reserved Address Space" in Figure 2. For this device, memory address range is
from 0x4000 2000 to 0x7FFF DFFF.
–Address space between 0x8000 0000 and 0xDFFF FFFF, labeled "Reserved
Address Space".
–Reserved regions of the AHB and APB spaces; see Figure 3.
•Unassigned AHB peripheral spaces; see Figure 4.
•Unassigned APB peripheral spaces; see Table 2.
Fig 5. Map of lower memory showing remapped and remappable areas (MPT612 with
32 kB flash)
aaa-000571
8 kB BOOT BLOCK
32 kB ON-CHIP FLASH MEMORY
0.0 GB
ACTIVE INTERRUPT VECTORS
FROM BOOT BLOCK
0x7FFF FFFF
2.0 GB - 8 kB
2.0 GB
(BOOT BLOCK INTERRUPT VECTORS)
0x0000 0000
0x0000 7FFF
0x7FFF E000
(SRAM INTERRUPT VECTORS)
ON-CHIP SRAM
8 kB ( 0x4000 2000)
RESERVED ADDRESS SPACE
1.0 GB 0x4000 0000
RESERVED ADDRESS SPACE

UM10413 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 1 — 16 December 2011 13 of 268
NXP Semiconductors UM10413
MPT612 User manual
For these areas, both attempted data access and instruction fetch generate an exception.
In addition, a prefetch abort exception is generated for any instruction fetch that maps to
an AHB or APB peripheral address.
Within the address space of an existing APB peripheral, a data abort exception is not
generated in response to an access to an undefined address. Address decoding within
each peripheral is limited to distinguish only defined registers within the peripheral itself.
For example, an access to address 0xE000 D000 (an undefined address within the
UART0 space) can result in a register access defined at address 0xE000 C000. Details of
such address aliasing within a peripheral space are not defined in the MPT612
documentation and are not a supported feature.
Remark: the ARM core stores the prefetch abort flag and the (meaningless) associated
instruction in the pipeline, and processes the abort only if an attempt is made to execute
the instruction fetched from the illegal address. This method prevents accidental aborts
caused by prefetches occurring when code is executed very close to a memory boundary.
8. Memory Acceleration Module (MAM)
The MAM block in the MPT612 maximizes the performance of the ARM processor when it
is running code in flash memory using a single flash bank.
8.1 Operation
Essentially, the Memory Accelerator Module (MAM) attempts to have the next ARM
instruction that is needed in its latches in time to prevent CPU fetch stalls. The MPT612
uses one bank of flash memory, compared to the two banks used on predecessor
devices. It includes three 128-bit buffers called the prefetch buffer, the branch trail buffer
and the data buffer. The ARM is stalled while a fetch is initiated for the 128-bit line for an
Instruction Fetch not satisfied by either the prefetch or branch trail buffer, or a prefetch not
initiated for that line. If a prefetch is initiated but not yet completed, the ARM is stalled for
a shorter time. Unless aborted by a data access, a prefetch is initiated when the flash has
completed the previous access. The flash module latches the prefetched line, but the
MAM does not capture the line in its prefetch buffer until the ARM core presents the
address from which the prefetch is made. If the core presents a different address from the
one from which the prefetch is made, the prefetched line is discarded.
The prefetch and branch trail buffers each include four 32-bit ARM instructions or eight
16-bit Thumb instructions. During sequential code execution, typically the prefetch buffer
contains the current instruction and the entire flash line that contains it.
The MAM uses the LPROT[0] line to differentiate between instruction and data accesses.
Code and data accesses use separate 128-bit buffers. Three of every four sequential
32-bit code or data accesses "hit" in the buffer without requiring a flash access (7 of 8
sequential 16-bit accesses, 15 of every 16 sequential byte accesses). The fourth (eighth,
16th) sequential data access must access flash, aborting any prefetch in progress. When
a flash data access is concluded, any prefetch in progress is re-initiated.
Timing of flash read operations is programmable and is described later in this section.
There is no code fetch penalty for sequential instruction execution when the CPU clock
period is greater than or equal to one fourth of the flash access time. The average amount
of time spent processing program branches is relatively small (less than 25 %) and can be

UM10413 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 1 — 16 December 2011 14 of 268
NXP Semiconductors UM10413
MPT612 User manual
minimized in ARM (rather than Thumb) code by using the conditional execution feature
present in all ARM instructions. This conditional execution can often be used to avoid
small forward branches that would otherwise be necessary.
Branches and other program flow changes cause a break in the sequential flow of
instruction fetches previously described. The branch trail buffer captures the line to which
such a non-sequential break occurs. If the same branch is taken again, the next
instruction is taken from the branch trail buffer. When a branch outside the contents of the
prefetch and branch trail buffer is taken, the branch trail buffer is loaded after several clock
periods. Typically, there are no further instruction fetch delays until a new and different
branch occurs.
8.2 MAM blocks
The MAM is divided into several functional blocks:
•A flash address latch and an incrementing function to form prefetch addresses
•A 128-bit prefetch buffer and an associated address latch and comparator
•A 128-bit branch trail buffer and an associated address latch and comparator
•A 128-bit data buffer and an associated address latch and comparator
•Control logic
•Wait logic
Figure 6 shows a simplified block diagram of the MAM data paths.
In the following descriptions, the term “fetch” applies to an explicit flash read request from
the ARM. “Pre-fetch” is used to denote a flash read of instructions beyond the current
processor fetch address.
8.2.1 Flash memory bank
There is one bank of flash memory on the MPT612 MAM.
Flash programming operations are handled as a separate function and not controlled by
the MAM. A separate boot block in ROM contains flash programming algorithms that can
be called by the application program, and a loader that can be run to allow serial
programming of flash memory.

UM10413 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 1 — 16 December 2011 15 of 268
NXP Semiconductors UM10413
MPT612 User manual
8.2.2 Instruction latches and data latches
The MAM treats code and data accesses separately. There is a 128-bit latch, a 15-bit
address latch, and a 15-bit comparator associated with each buffer (prefetch, branch trail,
and data). Each 128-bit latch holds 4 words (4 ARM instructions, or 8 Thumb instructions).
Also associated with each buffer are 32 4:1 multiplexers that select the requested word
from the 128-bit line.
Each data access that is not in the data latch causes a flash fetch of 4 words of data,
which are captured in the data latch. This speeds up sequential data operations, but has
little or no effect on random accesses.
8.2.3 Flash programming issues
Since the flash memory does not allow access during programming and erase operations,
the MAM must force the CPU to wait if a memory access to a flash address is requested
while the flash module is busy. Under some conditions, this delay can result in a watchdog
time-out. You must ensure that an unwanted watchdog reset does not cause a system
failure while programming or erasing the flash memory.
To preclude the possibility of stale data being read from the flash memory, the MPT612
MAM holding latches are automatically invalidated at the beginning of any flash
programming or erase operation. Any subsequent read from a flash address initiates a
new fetch after the flash operation has completed.
8.3 MAM operating modes
There are three MAM modes of operation defined, trading off performance for ease of
predictability:
Mode 0: MAM off. All memory requests result in a flash read operation (see Table 5,
note 2). No instruction prefetches are performed.
Fig 6. Simplified block diagram of the Memory Accelerator Module (MAM)
aaa-000572
BUS
INTERFACE
BUFFERS
MEMORY ADDRESS
ARM LOCAL BUS
FLASH MEMORY
BANK

UM10413 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 1 — 16 December 2011 16 of 268
NXP Semiconductors UM10413
MPT612 User manual
Mode 1: MAM partially enabled. If the data is present, sequential instruction accesses
are fulfilled by the holding latches. Instruction prefetch is enabled. Non-sequential
instruction accesses initiate flash read operations (see Table 5, note 2). This means that
all branches cause memory fetches. All data operations cause a flash read because
buffered data access timing is hard to predict and is very situation-dependent.
Mode 2: MAM fully enabled. Any memory request (code or data) for a value that is
contained in one of the corresponding holding latches is fulfilled from the latch.
Instruction prefetch is enabled. Flash read operations are initiated for instruction
prefetch and code or data values not available in the corresponding holding latches.
[1] Instruction prefetch is enabled in modes 1 and 2.
[2] If available, the MAM actually uses latched data, but mimics the timing of a flash read operation. This
method saves power while resulting in the same execution timing. The MAM can truly be turned off by
setting the fetch timing value in MAMTIM to one clock.
[1] If available, the MAM actually uses latched data, but it mimics the timing of a flash read operation. This
method saves power while resulting in the same execution timing. The MAM can truly be turned off by
setting the fetch timing value in MAMTIM to one clock.
8.4 MAM configuration
After reset the MAM defaults to the disabled state. Software can turn memory access
acceleration on or off at any time. This method allows most of an application to be run at
the highest possible performance, while certain functions can be run at a slower but more
predictable rate if more precise timing is required.
8.5 Register description
All registers, regardless of size, are on word address boundaries. Details of the registers
appear in the description of each function.
Table 5. MAM Responses to program accesses of various types
Program memory request type MAM mode
012
Sequential access, data in latches initiate fetch[2] use latched
data[1] use latched data[1]
Sequential access, data not in latches initiate fetch initiate fetch[1] initiate fetch[1]
Non-sequential access, data in latches initiate fetch[2] initiate fetch[1][2] use latched
data[1]
Non-sequential access, data not in latches initiate fetch initiate fetch[1] initiate fetch[1]
Table 6. MAM responses to data accesses of various types
Data memory request type MAM mode
012
Sequential access, data in latches initiate fetch[1] initiate fetch[1] use latched data
Sequential access, data not in latches initiate fetch initiate fetch initiate fetch
Non-sequential access, data in latches initiate fetch[1] initiate fetch[1] use latched data
Non-sequential access, data not in latches initiate fetch initiate fetch initiate fetch

UM10413 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 1 — 16 December 2011 17 of 268
NXP Semiconductors UM10413
MPT612 User manual
[1] Reset value reflects the data stored in used bits only. It does not include reserved bits content.
8.6 MAM Control register (MAMCR - 0xE01F C000)
Two configuration bits select the three MAM operating modes, as shown in Table 8.
Following reset, MAM functions are disabled. Changing the MAM operating mode causes
the MAM to invalidate all of the holding latches, resulting in new reads of flash information
as required.
8.7 MAM Timing register (MAMTIM - 0xE01F C004)
The MAM Timing register determines how many CCLK cycles are used to access the
flash memory. This method allows tuning MAM timing to match the processor operating
frequency. Flash access times from 1 clock to 7 clocks are possible. Single clock flash
accesses removes the MAM from timing calculations. In this case, the MAM mode can be
selected to optimize power usage.
Table 7. Summary of MAM registers
Name Description Access Reset
value[1] Address
MAMCR MAM control register. Determines MAM functional
mode: to what extent the MAM performance
enhancements are enabled; see Table 8.
R/W 0x0 0xE01F C000
MAMTIM MAM timing control. Determines number of clocks
used for flash memory fetches (1 to 7 processor
clocks).
R/W 0x07 0xE01F C004
Table 8. MAMCR - address 0xE01F C000 bit description
Bit Symbol Value Description Reset
value
1:0 MAM_mode
_control 00 MAM functions disabled 0
01 MAM functions partially enabled
10 MAM functions fully enabled
11 reserved; not to be used in application
7:2 - - reserved; user software must not write logic 1s to reserved
bits; value read from a reserved bit is not defined n/a

UM10413 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 1 — 16 December 2011 18 of 268
NXP Semiconductors UM10413
MPT612 User manual
8.8 MAM usage notes
When changing MAM timing, the MAM is turned off by writing a zero to MAMCR. A new
value can then be written to MAMTIM. Finally, the MAM can be turned on again by writing
a value (1 or 2) corresponding to the desired operating mode to MAMCR.
For a system clock slower than 20 MHz, MAMTIM can be 001. A suggested flash access
time for a system clock between 20 MHz and 40 MHz is 2 CCLKs, while systems with a
system clock faster than 40 MHz, 3 CCLKs are proposed. System clocks of 60 MHz and
above require 4CCLKs.
9. Vectored Interrupt Controller (VIC)
9.1 Features
•ARM PrimeCell Vectored Interrupt Controller
•32 interrupt request inputs
•16 vectored IRQ interrupts
•16 priority levels dynamically assigned to interrupt requests
•Software interrupt generation
Table 9. MAM Timing register (MAMTIM - address 0xE01F C004) bit description
Bit Symbol Value Description Reset
value
2:0 MAM_fetch_
cycle_timing 000 0 - reserved 07
001 1 - MAM fetch cycles are 1 processor clock (CCLK) in
duration
010 2 - MAM fetch cycles are 2 CCLKs in duration
011 3 - MAM fetch cycles are 3 CCLKs in duration
100 4 - MAM fetch cycles are 4 CCLKs in duration
101 5 - MAM fetch cycles are 5 CCLKs in duration
110 6 - MAM fetch cycles are 6 CCLKs in duration
111 7 - MAM fetch cycles are 7 CCLKs in duration
Remark: these bits set duration of MAM flash fetch operations as
listed. Improper setting of values can result in incorrect operation of
the device.
7:3 - - reserved; user software must not write logic 1s to reserved
bits; value read from a reserved bit is not defined n/a
Table 10. Suggestions for MAM timing selection
System clock Number of MAM fetch cycles in MAMTIM
< 20 MHz 1 CCLK
20 MHz to 40 MHz 2 CCLK
40 MHz to 60 MHz 3 CCLK
> 60 MHz 4 CCLK

UM10413 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 1 — 16 December 2011 19 of 268
NXP Semiconductors UM10413
MPT612 User manual
9.2 Description
The Vectored Interrupt Controller (VIC) takes 32 interrupt request inputs and assigns them
to 3 categories, FIQ, vectored IRQ, and non-vectored IRQ. The programmable
assignment scheme means that priorities of interrupts from the various peripherals can be
dynamically assigned and adjusted.
Fast Interrupt reQuest (FIQ) requests have the highest priority. If more than one request is
assigned to FIQ, the VIC ORs the requests to produce the FIQ signal to the ARM
processor. The fastest possible FIQ latency is achieved when only one request is
classified as FIQ because the FIQ service routine then deals with that device. If the FIQ
class is assigned several requests, the FIQ service routine can read a word from the VIC
that identifies which FIQ source(s) is (are) requesting an interrupt.
Vectored IRQs have the middle priority, but only 16 of the 32 requests can be assigned to
this category. Any of the 32 requests can be assigned to any of the 16 vectored IRQ slots
where slot 0 has the highest priority and slot 15 the lowest.
Non-vectored IRQs have the lowest priority.
The VIC ORs the requests from all the vectored and non-vectored IRQs to produce the
IRQ signal to the ARM processor. The IRQ service routine can start by reading a register
from the VIC and jumping there. If a vectored IRQ is requesting, the VIC provides the
address of the highest-priority requesting IRQ service routine, otherwise it provides the
address of a default routine shared by all the non-vectored IRQs. The default routine can
read another VIC register to see what IRQs are active.
All registers in the VIC are word registers. Byte and halfword read/write are not supported.
Additional information on the Vectored Interrupt Controller is available in the ARM
PrimeCell Vectored Interrupt Controller (PL190) documentation.
9.3 Register description
The VIC implements the registers shown in Table 11. More detailed descriptions follow.
Table 11. VIC register map
Name Description Access Reset
value[1] Address
VICIRQStatus IRQ status register. Reads out status of interrupt requests that are
enabled and classified as IRQ. RO 0 0xFFFF F000
VICFIQStatus FIQ status requests. Reads out status of interrupt requests that are
enabled and classified as FIQ. RO 0 0xFFFF F004
VICRawIntr raw interrupt status register. Reads out status of the 32 interrupt
requests/software interrupts, regardless of enabling or classification. RO 0 0xFFFF F008
VICIntSelect interrupt select register. Classifies each of the 32 interrupt requests
contributing to FIQ or IRQ. R/W 0 0xFFFF F00C
VICIntEnable interrupt enable register. Controls which of the 32 interrupt requests
and software interrupts are enabled to contribute to FIQ or IRQ. R/W 0 0xFFFF F010
VICIntEnClr interrupt enable clear register. Allows software to clear one or more
bits in the interrupt enable register. WO 0 0xFFFF F014
VICSoftInt software interrupt register. Contents of this register are ORed with
the 32 interrupt requests from various peripheral functions. R/W 0 0xFFFF F018

UM10413 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2011. All rights reserved.
User manual Rev. 1 — 16 December 2011 20 of 268
NXP Semiconductors UM10413
MPT612 User manual
VICSoftIntClear software interrupt clear register. Allows software to clear one or more
bits in the software interrupt register. WO 0 0xFFFF F01C
VICProtection protection enable register. Allows limiting access to the VIC registers
by software running in privileged mode. R/W 0 0xFFFF F020
VICVectAddr vector address register. When an IRQ interrupt occurs, the IRQ
service routine can read this register and jump to the value read. R/W 0 0xFFFF F030
VICDefVectAddr default vector address register. Holds address of Interrupt Service
Routine (ISR) for non-vectored IRQs. R/W 0 0xFFFF F034
VICVectAddr0 vector address 0 register. Vector address registers 0 to 15 hold
addresses of ISRs for the 16 vectored IRQ slots. R/W 0 0xFFFF F100
VICVectAddr1 vector address 1 register R/W 0 0xFFFF F104
VICVectAddr2 vector address 2 register R/W 0 0xFFFF F108
VICVectAddr3 vector address 3 register R/W 0 0xFFFF F10C
VICVectAddr4 vector address 4 register R/W 0 0xFFFF F110
VICVectAddr5 vector address 5 register R/W 0 0xFFFF F114
VICVectAddr6 vector address 6 register R/W 0 0xFFFF F118
VICVectAddr7 vector address 7 register R/W 0 0xFFFF F11C
VICVectAddr8 vector address 8 register R/W 0 0xFFFF F120
VICVectAddr9 vector address 9 register R/W 0 0xFFFF F124
VICVectAddr10 vector address 10 register R/W 0 0xFFFF F128
VICVectAddr11 vector address 11 register R/W 0 0xFFFF F12C
VICVectAddr12 vector address 12 register R/W 0 0xFFFF F130
VICVectAddr13 vector address 13 register R/W 0 0xFFFF F134
VICVectAddr14 vector address 14 register R/W 0 0xFFFF F138
VICVectAddr15 vector address 15 register R/W 0 0xFFFF F13C
VICVectCntl0 vector control 0 register. Vector control registers 0 to 15 each control
one of the 16 vectored IRQ slots. Slot 0 has highest priority and slot
15 the lowest.
R/W 0 0xFFFF F200
VICVectCntl1 vector control 1 register R/W 0 0xFFFF F204
VICVectCntl2 vector control 2 register R/W 0 0xFFFF F208
VICVectCntl3 vector control 3 register R/W 0 0xFFFF F20C
VICVectCntl4 vector control 4 register R/W 0 0xFFFF F210
VICVectCntl5 vector control 5 register R/W 0 0xFFFF F214
VICVectCntl6 vector control 6 register R/W 0 0xFFFF F218
VICVectCntl7 vector control 7 register R/W 0 0xFFFF F21C
VICVectCntl8 vector control 8 register R/W 0 0xFFFF F220
VICVectCntl9 vector control 9 register R/W 0 0xFFFF F224
VICVectCntl10 vector control 10 register R/W 0 0xFFFF F228
VICVectCntl11 vector control 11 register R/W 0 0xFFFF F22C
VICVectCntl12 vector control 12 register R/W 0 0xFFFF F230
Table 11. VIC register map …continued
Name Description Access Reset
value[1] Address
