NXP Semiconductors Freescale 56F800 User manual

56F800
16-bit Digital Signal Controllers
freescale.com
56F800 Demonstration Board
User Manual
DSP56F800DBUM
Rev. 0
09/2005

TABLE OF CONTENTS
Freescale Semiconductor i
Preliminary
Preface
Chapter 1
Introduction
1.1 56F800 Demonstration Board Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.2 SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Chapter 2
Technical Summary
2.1 OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.1.1 HOST_ENABLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.1.2 CUT_AWAY Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.2 PORTS AND CONNECTORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2.1 PWR Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2.2 POWER PORT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2.3 GPIO / SERIAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2.4 TIMER / PWM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.2.5 ADC Port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.2.6 COM1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.2.7 JTAG / OnCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.2.8 P1 - HOST JTAG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.3 USER FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.3.1 MICROPHONE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.3.2 POTENTIOMETER (POT) - R12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2.4 Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Appendix A
56F800 Demonstration Board Schematics

56F800 Demonstration Board User’s Manual, Rev. 0
ii Freescale Semiconductor

LIST OF FIGURES
Freescale Semiconductor iii
1-1 56F800 Demonstration Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
2-1 Power Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
A-1 56F800 Demonstration Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

56F800 Demonstration Board User’s Manual, Rev. 0
iv Freescale Semiconductor

TABLE OF CONTENTS
Freescale Semiconductor i
Preliminary
2-1 CUT_AWAY Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2-2 Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

56F800 Demonstration Board User’s Manual, Rev. 0
ii Freescale Semiconductor

Preface, Rev. 0
Freescale Semiconductor 3
Preface
This reference manual describes in detail the hardware on the 56F800 Demonstration
Board.
Audience
This document is intended for application developers who are creating software for
devices using the Freescale 56F800 Demonstration Board.
Organization
This manual is organized into two chapters and one appendix.
•Chapter 1, Introduction - provides an overview of the Demonstration Board and its
features.
•Chapter 2, Technical Summary - describes the 56F800 Demonstration Board in
detail.
•Appendix A, 56F800 Demonstration Board Schematics - contains the schematics of
the 56F800 Demonstration Board.
Suggested Reading
Related documentation for the 56F800 family of digital signal controllers may be found at:
http://www.freescale.com/dsc

56F800 Demonstration Board User’s Manual, Rev. 0
4Freescale Semiconductor
Notation Conventions
This manual uses the following notational conventions:
Typeface, Symbol or
Term Meaning Examples Typeface, Symbol or Term
Courier
Monospaced Type
Code examples //Process command
for line flash
Courier
Monospaced Type
Italic Directory names,
project names,
calls,
functions,
statements,
procedures,
routines,
arguments,
file names,
applications,
variables,
directives,
code snippets
APIs
in text
...and contains these core
directories:
applications contains
applications software...
...CodeWarrior project,
3des.mcp is...
...the pConfig argument....
...defined in the C header
file, aec.h....
Italic
Bold Reference sources,
paths,
emphasis
...refer to the Target-
ing DSP56F80x Plat-
form
manual....
...see: C:\Program
Files\Embedded
SDK\help\tutorials
Bold
Blue Text Linkable ...refer to Chapter 7,
License....
Blue Text
Number Any number is consid-
ered a positive value,
unless preceded by a
minus symbol to sig-
nify a negative value
3V
-10
DES-1
Number
ALL CAPITAL LET-
TERS
# defines/
defined constants
# define
INCLUDE_STACK_CH
ECK
ALL CAPITAL LETTERS
Brackets [...] Function keys ...by pressing function
key [F7]
Brackets [...]

Preface, Rev. 0
Freescale Semiconductor 5
Cautionary Notes
1. Electrostatic Discharge (ESD) prevention measures should be applied whenever
handling this product. ESD damage is not a warranty repair item.
2. EMC Information on the 56F800 Demonstration Board:
a. This product as shipped from the factory with associated power supplies and
cables, has been tested and meets with requirements of CE and the FCC as a
CLASS A product.
b. This product is designed and intended for use as a development platform for
hardware or software in an educational or professional laboratory.
c. In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate prevention measures.
d. Attaching additional wiring to this product or modifying the products operation
from the factory default as shipped may effect its performance and also cause
interference with other apparatus in the immediate vicinity. If such interference
is detected, suitable mitigating measures should be taken.
Terminology
This development board applies option selection jumpers. Terminology for application of
the option jumpers is as follows:
Jumper on, in, or installed = jumper is a plastic shunt that fits across 2 pins and the shunt is
installed so that the 2 pins are connected with the shunt.
Jumper off, out, or idle = jumper or shunt is installed so that only 1 pin holds the shunt, no
2 pins are connected, or jumper is removed. It is recommended that the jumpers be idled
by installing on 1 pin so they will not be lost.
This development board applies CUT_AWAY option selections. These option selections
apply surface mount resistor locations with a printed circuit board trace connecting both
component pads. This type connection places an equivalent 0-ohm type resistor in series
with the I/O signal and the user component or I/O connector on the board. These
connections maybe cut with a razor blade or similar type knife between the component
pads to isolate the default connection provided. Reconnection of the cut-away type pads
can be made by either installing a 0 ohm 0805 size surface mount resistor or a small wire
jumper on the component pads.

56F800 Demonstration Board User’s Manual, Rev. 0
6Freescale Semiconductor
Definitions, Acronyms, and Abbreviations
Definitions, acronyms and abbreviations for terms used in this document are defined below for
reference.
References
The following sources were referenced to produce this manual:
DSP56800 Family Manual
DSP56F80x User’s Manual
Technical Data, 56F801 16-Bit Digital Signal Controller
ADC Analog-to-Digital Converter
CTS Clear To Send
ESD Electrostatic Discharge
GPIO General Purpose Input and Output Port
JTAG Joint Test Action Group. A bus protocol/interface used for test and
debug.
OnCETM On-Chip Emulation, a debug bus and port created by Freescale to enable
designers to create a low-cost hardware interface for a professional
quality debug environment.
PC Personal Computer
POT Potentiometer
PWM Pulse Width Modulation
RTS Request To Send

Introduction, Rev. 0
Freescale Semiconductor 1
Chapter 1
Introduction
The 56F800 Demonstration Board is used to demonstrate the abilities of the 56F800
family and to provide a hardware tool allowing the development of applications that use
the 56F800 devices.
1.1 56F800 Demonstration Board Features
• 56F801FA60 (60 MHz version)
• RESET Switch
• IRQ Switch
• GPIO / SERIAL Port (10 pin) *
• TIMER / PWM Port (10 Pin) *
• ADC Port (10 Pin) *
• JTAG / OnCE Port (14 pin) *
• Host JTAG Port (P1- DB25P)
• COM1 Port - SCI to RS232 (DB9S) *
• PWR Jack supply connector
• Power Port *
• Power Indicator
• 10 User Indicators
• User Potentiometer (R12)
• Microphone with amplifier
• Crystal Reference (Y1) *
* All components may not be installed at the factory. The user may install the components
to apply associated feature.
The 56F800 Demonstration Board is detailed in Figure 1-1.

56F800 Demonstration Board User’s Manual, Rev. 0
2Freescale Semiconductor
Figure 1-1. 56F800 Demonstration Board
2
R2
L1
C3
+
C8
1
D3
U3
74ACT05
1
R12
JTAG
1
Y1
C5
U5
74LCX125
U4
74ACT125
JP1
U2
74ACT05
IRQ
1
D11
PWR
TIMER -PORT
1
U6
74ACT00
15
96
COM1
GND
VDDA+3.3V
+VIN
MICRO
PHONE
U7
ON_OFF
VR1
U1
DSP56F801
3
4
56
7
GND
C1
C2
R3 R5
R4 R6
R7
R8
R9
R10
R11
R13
R14
C6
R1
R16
R17
R23
R24
R25
R27
R26
R28
R22
R21
R15
R19
R20
C9 C11
C15C14
C16
C17
C18
R34
C12R30
R29
R31
R32
C13
R33
C10C7
4
6
9
RTSCTS
GND
P1
13
25
1
14
D5
D6
D7
D8
D9
D10
D1
RESET
D2
POWER
D4
C4
U8 SP3232
RESET
ANALOG -PORT
1
GPIO -PORT
1
VR2
SILKSREEN LAYER
REV.A
AXM-0311
DEMO
DSP56F801
DSP56F801DEMO AXM-0311 REV.A
AXIOM MANUFACTURING
4.200
"
3.000
"
0.000
"
0.000
"

SPECIFICATIONS
Introduction, Rev. 0
Freescale Semiconductor 3
1.2 SPECIFICATIONS
• +9V DC input voltage typical, 200ma
• Input voltage range: +7 to +15V DC
• On board regulated +5V DC and +3.3V DC supplies
• Board size: 3 x 4.2 inches

56F800 Demonstration Board User’s Manual, Rev. 0
4Freescale Semiconductor

Technical Summary, Rev. 0
Freescale Semiconductor 1
Chapter 2
Technical Summary
This chapter describes the 56F800 Demonstration Board’s available options.
2.1 OPTIONS
2.1.1 HOST_ENABLE
The HOST_ENABLE option jumper is installed by default and enables the Host JTAG
interface on the board. With the option jumper installed, the 56F801 device will reset into
Debug mode and await Host commands on the Host JTAG port (P1). Removing the
HOST_ENABLE option jumper will allow the 56F801 device to reset normally and
execute program code contained in the device’s Flash memory.
•HOST_ENABLE = INSTALLED: Debug Mode; host JTAG port is active
•HOST_ENABLE = OPEN or IDLE: Normal Mode; executes user code in Flash
2.1.2 CUT_AWAY Options
CUT_AWAY options allow the user to disconnect dedicated 56F801 I/O port resources
from development board connectors or peripherals. The CUT_AWAY options also allow
for re-establishing the connection by installing surface-mount 0805-size 0 ohm resistors or
mod wire with the use of a soldering iron. Normal operation of the 56F800 Demonstration
Board generally does not require any manipulation of the CUT_AWAY options.
Table 2-1. CUT_AWAY Options
CUT_AWAY # Description 56F801 Signal Connection Signal
1 ADC reference supply VREF VDDA
2 User POT (R12) to ADC ANA6 R12 wiper
3 Crystal oscillator isolation XTAL / GPIOB3 GPIO / SERIAL pin 4

56F800 Demonstration Board User’s Manual, Rev. 0
2Freescale Semiconductor
2.2 PORTS AND CONNECTORS
2.2.1 PWR Jack
This connector provides power input to the board by default. The PWR jack accepts a
standard 2.0 ~ 2.1mm center-barrel plug connector (positive voltage center) to provide the
+VIN supply of +9V DC at 200ma.
2.2.2 POWER PORT
Provides access to the +9V DC input, GND (power ground), +5V DC and +3.3V DC
power supplies. The +9V DC input should only be applied by PWR jack or Power Port,
but not both, or a supply conflict may occur and the 56F800 Demonstration Board could
be damaged. Power Port accepts a 3.5mm pin space terminal block.
Figure 2-1. Power Port
4 Crystal oscillator isolation EXTAL / GPIOB2 GPIO / SERIAL pin 3
5 COM1 serial port TXD0 / GPIO0 U8 pin 11 (COM1 TXD)
6 COM1 serial port RXDO / GPIOB1 U8 pin 12 (COM1 RXD)
7 Microphone to ADC ANA2 U7 pin 4 (Microphone output)
Table 2-1. CUT_AWAY Options (Continued)
CUT_AWAY # Description 56F801 Signal Connection Signal
+3.3V DC
GND
+5V DC
+9V DC

PORTS AND CONNECTORS
Technical Summary, Rev. 0
Freescale Semiconductor 3
2.2.3 GPIO / SERIAL
2.2.4 TIMER / PWM
2.2.5 ADC Port
2.2.6 COM1
RTS and CTS flow control connection pads are provided on the 56F800 Demonstration Board to
apply unassigned 56F801 I/O to support flow control on COM1. The RTS pad provides RS-232
level output conversion to COM1 port pin 8. The CTS pad provides RS-232-converted input
from COM1 pin 7.
The 1, 4, 6, and 9 pins provide RS-232 status. The 1, 4, and 6 pins are connected on the bottom
of the development board to provide NULL status to the host. The user may isolate pins and
provide the status connections to the host by applying I/O signals and RS-232 level conversion.
TXD0 / GPIOB0
GPIOB2
MISO / GPIOB6
IREQA*
SCLK / GPIOB4
GPIOB1 / RXD0
GPIOB3
GPIOB7 / SS*
RESET*
GPIOB5 / MOSI
1
3
7
9
5
2
4
7
10
6
GPIO B port provides alternate functions
as SCI (COM1 and indications) and SPI
ports. IREQ and RESET signals are also
provided on this connector.
TD0 / GPIOA0
TD2 / GPIOA2
PWMA2
PWMA0
PWMA4
GPIOA1 / TD1
FAULTA0
PWMA3
PWMA1
PWMA5
1
3
7
9
5
2
4
7
10
6
GPIOA0 - 2 port provides alternate
functions of Timer TD0 - 2 I/O.
Note that most of these ports provide a
user indication.
ANA6
ANA4
ANA0
VREF
ANA2
ANA7
ANA5
ANA1
GND
ANA3
1
3
7
9
5
2
4
7
10
6
Analog inputs. Note that ANA2 and
ANA6 provide Microphone and User
POT R12 input, respectively.
1
TXD0
4
GND
RXD0
6
RTS
9
CTS
1
2
4
5
3
6
8
9
7
The COM1 port has a female DB9 connector that
interfaces to the 56F801 internal SCI0 serial port via
the U8 RS-232 transceiver. It uses a simple 2-wire
asynchronous serial interface and is translated to
RS-232 signaling levels.
1,4,6 connected (host null)

56F800 Demonstration Board User’s Manual, Rev. 0
4Freescale Semiconductor
2.2.7 JTAG / OnCE
The JTAG 14-pin connector is compatible with the Freescale OnCE development port. This
connector allows the connection of a OnCE-style background debug cable for software
development, programming and debugging in real time.
Note: HOST_ENABLE option must be open or idle to apply this connector.
2.2.8 P1 - HOST JTAG
The P1 - Host JTAG connector provides development port interface to a hosting Personal
Computer’s LPT or Printer port. The HOST_ENABLE option jumper must be installed for this
port to operate.
Note: HOST_ENABLE option must be installed to apply this connector.
2.3 USER FEATURES
Several circuits are provided for demonstration of 56F800 applications.
TDI
TDO
RESET in
TCK
GND
GND
(key)
TMS
GND
1
3
7
9
5
2
4
7
10
6
JTAG / OnCE BDM connection.
11
13
12
14
+3.3V DC
DE* TRST* in
Reset in
TCK
TDI
TMS
Pin 8 tie
GND
GND
1
2
4
5
3
14
15
17
18
16
P1 - HOST JTAG connector is a DB25
pin connector. Signals are organized for
direct connection to an IBM-compatible
PC with a straight-through DB25 cable.
Pin 7 / DE* signal, if supported, can be
enabled by installing R23 (51 ohms)
6
7
19
20
TRST*
DE* (Note R23)
GND
GND
21
22
24
25
23
13
Pin 15 tie
TDO
P-CON
GND
GND
GND
GND
GND
8
9
11
12
10
