NYMAS G1235C User manual

Installation and Operating Instructions
PI_GXX35C_00
Round flange steel grab rail - 35mm diameter
Round ange steel grab rail - 305mm G1235C
Available colours:
WHITE (WH). DARK BLUE (DB). GREY (GY). DARK GREY (DG).
Congratulations on the purchase of your rail. This rail has been designed to provide users with
extra support while moving from one position to another and assists with the independent
standing/sitting of persons.
Warnings:
• Always read the installation, operating and maintenance
instructions.
• Due to manufacturing tolerances we do not recommend
pre-drilling fixing holes before physically receiving this
product.
• A thorough check must be carried out on receiving
delivery of this product and report any defects
immediately.
• Opening the packaging without due care and attention
could result in damage to the product or injury to
yourself or others.
• This product must be stored in a dry place, the right way
up and not stacked under other equipment on site.
• The wall on which the rail is installed must be flat and
capable of taking the load.
• Installation must be carried out by a qualified tradesman
using suitable fixings for the wall substrate.
• Never alter the fixing holes as this could affect the
strength and integrity of the rail.
• Improper installation / use can cause accidents and
injuries.
• Beware after installation a functional test must be carried
out prior to use
• These instructions should be retained by the user of the
product for its whole life time.
• Do not use the rail for any purpose other than that for
which it was designed.
• Do not use the rail if damaged / not securely fixed as this
may cause injury.
• Keep plastic bag packaging away from children.
• The rail should not be subjected to impact or downward
force.
• To maintain the integrity and functionality of this product,
regular cleaning and inspection is necessary.
• If in doubt, carry out your own risk assessment for each
installation.
• Max rated load - 100kg.
Round ange steel grab rail - 455mm G1835C
Round ange steel grab rail - 610mm G2435C
Round ange steel grab rail - 915mm G3635C

Installation and Operating Instructions
PI_GXX35C_00
Installation:
Installation should be carried out by a suitably qualified
tradesman using correct fixings for the wall substrate.
Fixings are not supplied with this product to allow the
correct fixing method to be selected per installation.
Consult a fixing manufacturer if unsure of which type of
fixings to use.
1. Once the correct wall fixings have been selected, at
least 3x 6mm fixings should be employed per flange
2. Offer the rail up to the wall at the position required
3. Mark the fixing hole locations.
4. Drill the holes in the wall of a diameter and depth
recommended by supplier of wall fixings.
5. Once each flange is fixed, clip the flange covers
back onto the flanges.
6. Always carry out a functional test after installation
and report any issues immediately.
7. Please leave these instructions with the user.
Using this product:
Always check this rail is fitted securely to the wall and shows no signs of wear or damage prior to use. Please keep these in-
structions in a safe place for future use. These instructions are available in braille if required.
Cleaning and maintenance:
This rail must be checked regularly by a qualified personnel to ensure that it is in perfect working order. This rail can be cleaned
using only a very mild detergent. Do not use acidic, alkaline, chlorine based or abrasive cleaning materials.
Disclaimer:
Nymas pursues a policy of continuing improvement in design and performance of its products and so reserves the right to
change specifications without prior notice. The information contained on this document was correct at date of issue and
dimensions are provided as a guide only. Some variation may occur due to manufacturing tolerances.
We accept no liability whatsoever for personal injury or damage to property that is or has been caused due to incorrect
assembly, installation, or use of this product. Failure to install / use this product in line with these instructions will invalidate any
warranty and may affect product safety.
Packaging:
This product is supplied in plastic wrapping and cardboard carton to keep the product unsoiled until installation. Both are
suitable for recycling operations and should be disposed of in accordance with local recycling regulations.
Warranty:
The standard of manufacture and quality control allows Nymas to offer warranties on all products. The W symbol denotes the
number of years covered if different to the standard 1 year warranty. Where L appears this means the product is guaranteed for
life (terms and conditions apply).
