Oakley RADARPACE User manual

USER GUIDE

2 |OAKLEY RADAR PACE USER GUIDE
TABLE OF CONTENTS
WELCOME...........................................................3
In The Box ..........................................................4
Overview............................................................5
System Requirements........................................5
Charging The Internal Battery ...........................5
Status Indicator .................................................5
Radar Pace App .................................................5
Pairing With Phone And External Sensors ........5
Power Button .....................................................6
Touch Pad...........................................................7
Changing The Lens ............................................7
Attaching The Aero Clip ....................................7
INTERACT WITH RADAR PACE .......................8
COACHING PHILOSOPHY................................. 9
TRAINING PROGRAMS...................................12
TROUBLESHOOTING .......................................12
Sensor Pairing..................................................12
Resetting Radar Pace ......................................13
MAINTENANCE................................................13
Storing Radar Pace ..........................................13
Charging...........................................................14
Cleaning And Maintenance.............................14
TECHNICAL SPECIFICATIONS .......................15
SUPPORT...........................................................15
Oakley Limited Warranty.................................16

3 |OAKLEY RADAR PACE USER GUIDE
Say hello to your new personal coach.
RADAR PACE is a real-time voice activated coaching
system. It’s like having a trainer with you whenever
you’re running or cycling, a mentor that gives you the
help and motivation you need to take performance to a
whole new level.
There isn’t much motivation in raw numbers, so instead
of dumping data for a coach to analyze after your
session, RADAR PACE becomes your personal coach
in the here and now. It interprets your information and
communicates with you during your running or cycling
session, providing feedback in real time. All the vital
information is stored for later, but you don’t have to wait
to take advantage of it.
There’s a lot of technology packed into RADAR PACE.
An integrated gyroscope, accelerometer and proximity
sensor combined with a mobile phone app, monitor
what you’re doing and how you move. A pressure sensor
gauges the environment and adjusts your workout plan
as things change. And RADAR PACE lets you interface
with all that technology in the best possible way — by
eliminating the interface. You simply talk to it.
Speak freely. With RADAR PACE, communication is
intuitive and natural. Ask it workout-related questions
in different ways, as though you’re speaking to an
actual coach who’s right there with you and knows how
hard you’re pushing yourself on rides and runs. It even
understands the context of your questions, so go ahead
and ask follow-up questions.
Whether you’re taking on a hill or stopping to rest,
RADAR PACE will know where you are and what you’re
doing, and it gives you relevant information in the right
moment. And just like a real coach, it learns about you
and uses that knowledge to provide dynamic, custom
training that continually adapts to help you improve.
With ANT+™and Bluetooth®connectivity, RADAR PACE
can link wirelessly to most added external sensors to
enhance the experience. Forget about slowing down and
reaching for something to see a readout. Simply say,
“Okay Radar...” to get its attention, then the information
you need can be accessed with a simple question. When
your heart rate sensor is wirelessly linked, all you have
to do is ask, “What’s my heart rate?” or just say, “heart
rate.”
To use this smart eyewear, connect it wirelessly to your
smartphone. A handy app makes setup easy and lets
you tell RADAR PACE your training goals and access
performance metrics. Let it know about an upcoming
event and it will develop a training plan that assesses
your level of preparation and dynamically adapts your
ongoing training.
An indicator light tells you the status of remaining
battery power and helps you with wireless pairing, and
a touch pad on the frame lets you control even more
functions with simple taps and swipes. You can adjust
volume, control music, answer calls, and more from your
paired phone.
The water-resistant design is a showcase of Oakley’s
best performance eyewear technologies including
comfortably lightweight O Matter™frame material,
and pure Plutonite®for the lens. RADAR PACE uses an
interchangeable lens design so you can adapt quickly
and easily to the environment. Oakley’s Prizm™Road lens
helps endurance athletes spot subtle changes in the
texture of road surfaces, and see hazards more easily
so they can react faster and perform at their best. The
unrivaled optics maintain razor-sharp clarity at all angles
of view — even at the sides of sweeping contours
that extend peripheral vision while maximizing side
protection against sun, wind and impact.
The power of technology meets the power of possibility.
We put the best of everything into the world’s first real-
time voice activated coaching system. With your new
personal trainer for running and cycling, it’s time to reach
for the next level and beyond. Possibility is waiting.
WELCOME

4 |OAKLEY RADAR PACE USER GUIDE
The following items are included in the box:
1. Eyewear Case
2. RADAR PACE with PRIZM™ Road Lens with Small Nose Pad
3. 2 Ear Booms
4. Clear Lens for Low Light Conditions
5. RADAR PACE Large Nose Pad
6. Aero Clip
7. RADAR PACE Micro USB Cable
8. Micro Bag
9. Quick Start Guide*
10. Warranty Card*
*Not pictured above
IN THE BOX
1
8
2
4
6
57
3

5 |OAKLEY RADAR PACE USER GUIDE
OVERVIEW
SYSTEM REQUIREMENTS
To use RADAR PACE, you need an Android™smartphone (version 4.4 or later) or an Apple®iPhone®5S or later
(iOS 9 or later).
CHARGING THE BATTERY
Remove either earpiece by pulling it straight down. Plug the RADAR PACE Micro USB cable into the exposed port.
Plug the other end of the cable into any available adapter rated for 5V output. The indicator light on RADAR PACE
will glow green when charging is complete. A full charge requires approximately three hours.
IMPORTANT: Oakley RADAR PACE comes with a specially designed Micro USB cable. Before charging RADAR PACE,
always make sure the USB ports are clean and sweat-free.
STATUS INDICATOR
RADAR PACE has an indicator light that lets you check the status of remaining battery power, and tells you when it is
pairing with a Bluetooth®-enabled device.
WHILE CHARGING:
GREEN: Remaining power is greater than 99%
YELLOW: Remaining power is between 50% and 99%
RED: Remaining power is less than 50%
WHILE POWERED ON:
LIGHT BLUE FLASHING: Booting up or shutting down
LIGHT BLUE SOLID: Device is ready
DARK BLUE FLASHING: Bluetooth®pairing mode
RED FLASHING: Factory reset mode
RADAR PACE APP
Download the RADAR PACE app on your smartphone from the Apple® App Store®or on Google Play™. Launch the app
and follow the onscreen instructions. Let the app help you pair RADAR PACE with your phone and external sensors.
Use the app to give RADAR PACE the information it needs to build your personal training program.
PAIRING WITH PHONE AND EXTERNAL SENSORS
Pair RADAR PACE with your smartphone by pressing the power button twice quickly. The indicator light will flash dark
blue. If pairing is successful, it will turn solid light blue.
A solid dark blue light indicates pairing was not successful. Ensure RADAR PACE is in pairing mode by pressing the
power button twice quickly. Also note that pairing should be done only via the RADAR PACE app; do not pair via any
other application on your phone.
After pairing with your smartphone is complete, the app will assist you with pairing external sensors such as your
heart rate monitor and speed sensor. Be sure the devices are powered on and ready for pairing. If you are unable to
pair RADAR PACE with a sensor, have your phone “forget” all sensor pairing (go into Bluetooth®settings on
your phone and unpair all sensors). Note the additional information below, and see the Troubleshooting section
for added help.

6 |OAKLEY RADAR PACE USER GUIDE
IF YOU HAVE ANY ISSUES WHEN ATTEMPTING TO PAIR RADAR PACE WITH EXTERNAL BLUETOOTH SENSORS,
PLEASE NOTE THE FOLLOWING:
•Pair only via the RADAR PACE app.
•Ensure the battery of the sensor device has enough charge to broadcast its signal to RADAR PACE.
•Some sensors require movement to begin broadcasting to the RADAR PACE app.
•Ensure the sensor device is not paired with another device; if it is currently paired with your phone, go to phone system
settings and unpair to ensure the device is discoverable.
•Refer to the owners manual that came with your external sensor for more troubleshooting information.
FOR ISSUES RELATED TO PAIRING WITH EXTERNAL ANT+ SENSORS, PLEASE NOTE THE FOLLOWING:
•Ensure the battery of the sensor device has enough charge to broadcast its signal to RADAR PACE.
•Some sensors require movement to begin broadcasting to the RADAR PACE app.
•Refer to the owners manual that came with your external sensor for more troubleshooting information.
FOR ISSUES RELATED TO CONNECTED SENSORS, PLEASE NOTE THE FOLLOWING:
•Ensure the sensor device is not currently paired with another device.
•Most connected sensors require movement to begin broadcasting to the RADAR PACE app.
POWER BUTTON
Located on the inner facing of the temple, the power button has multiple functions:
FOR YOUR SESSION
Power on: HOLD FOR MORE THAN 2 SECONDS. (The indicator light on the outer facing of the temple will show the remaining battery power
by glowing red, yellow or green, then will blink light blue.)
Pair with phone: PRESS TWICE QUICKLY. (The indicator light will flash
dark blue. If pairing is successful, it will turn solid light blue. If unsuccessful,
it will turn solid dark blue; see the Troubleshooting section.)
Power off: HOLD FOR MORE THAN 3 SECONDS. (The indicator light will
blink light blue.)
FOR RESETTING RADAR PACE
Factory reset and reboot: HOLD FOR MORE THAN 12 SECONDS.
(The indicator light will blink red.)
Factory reset and power off: HOLD FOR MORE THAN 18 SECONDS. (The
indicator light will blink red.)

7 |OAKLEY RADAR PACE USER GUIDE
TOUCH PAD
The touch pad on the temple lets you control functions with simple taps and swipes. You can adjust the volume,
control music and calls, and more from your paired phone.
CONTROL VOLUME
Increase volume: SWIPE FORWARD
Decrease volume: SWIPE BACKWARD
CONTROL MUSIC
Pause or play song: SINGLE TAP
Jump to next song: DOUBLE TAP
Return to previous song: TRIPLE TAP
Fast forward: DOUBLE TAP and HOLD
Rewind: TRIPLE TAP and HOLD
CONTROL CALLS
Answer call: SINGLE TAP
End call: SINGLE TAP
Decline call: HOLD then RELEASE (Use this function when you are not on a current call, and the phone is ringing.)
End current call and switch to incoming or on-hold call: HOLD then RELEASE
Switch back and forth between incoming call and current call: SINGLE TAP (A single tap puts the current call on hold and answers the
incoming call. Each single tap after that switches between the two calls, placing one on hold.)
CONTROL SIRI®/ GOOGLE NOW™
Activate Siri®or Google Now™:HOLD then RELEASE
CHANGING THE LENS
To remove a lens from RADAR PACE, follow the instructions below. (To install a lens, simply reverse the procedure.)
1. With two fingers, carefully pinch the two nose bridge tabs inward.
2. Push the nose bridge toward the top of the frame until the lens releases from the top.
3. Pull the lens down and out.

8 |OAKLEY RADAR PACE USER GUIDE
ATTACHING THE AERO CLIP
By reducing wind noise, the Aero Clip allows RADAR PACE to hear you more easily when you are cycling at high speeds.
It is recommended for cycling speeds faster than 20 mph (32 kph). The clip attaches to the left stem of the frame.
To attach the Aero Clip:
1. Hold the clip so the thinner/longer section is orientated with the top of the frame.
2. At the front of the left temple, slide the clip into position.
3. Push the clip firmly until it locks into place.
1 2 3
INTERACT WITH RADAR PACE
RADAR PACE is your personal, real-time coach. Just say, “Okay Radar...” to get its attention. After you hear the tone,
ask your question. Try it out by saying, “Okay Radar. What can I ask you?”
CURRENT METRICS*
Ask RADAR PACE about current metrics during your workout after you’ve paired it with your smartphone and external
sensors. Ask, “What’s my pace?” or just say, “pace.” Connect it wirelessly to your external heart rate monitor, then
ask, “What’s my heart rate?” or just say, “heart rate.” Ask about your speed, power or calories burned.
Ask about today’s plan. During your workout, ask about your progress. Find out how many hills are left to conquer or
how high you have climbed. Ask about the time elapsed, the workout remaining or the training you have done so far.
At the end of the session, ask for a workout summary.
You can even ask about the battery level of RADAR PACE, or the battery level of your phone.
If you want RADAR PACE to stop responding to you during your workout, say, “Stop listening. ”To get RADAR PACE’s
attention again, Say, “Okay Radar...”
TRAINING INFORMATION
You can ask RADAR PACE questions about training. For example, “What’s a marathon program?”, “How do I improve
my endurance?” and “How do I change my stride rate?”
COMMON PHRASES
GETTING GOING
•“Start workout” to get going once you have selected a workout in the app
•“Let’s do a freeform run/ride” if you want to go for a run/ride of your choice
•“What’s today’s workout?” after you have set up your training plan
•“Are my sensors connected?” to check sensor status

9 |OAKLEY RADAR PACE USER GUIDE
METRICS*
•“What’s my heart rate?” or just say “Heart rate”
•Follow up with “How’s my pace?” to check whether your heart rate is on target
•“What’s my pace?” or just say “Pace”
•Follow up with “How’s my pace?” to check whether your pace is on target
•“What’s my power?” or just say “Power”
•“Average metrics” to get your average metrics so far
•“Distance” to get distance traveled and remaining
•“Time” to get workout time
•“What’s left?” to get reps, vertical distance and distance left for a workout
•“Current metrics” to get your pace, heart rate, power, cadence, etc.
WRAPPING UP
•“Stop listening” if you want the coach to stop responding (in social situations)
•“Cancel workout” if you would like to end but not save your workout
•“Finish workout” if you would like to nish and save your workout
*Heart rate, cycling power and cycling cadence metrics require pairing RADAR RACE to external sensors. (sold
separately).
COACHING PHILOSOPHY
TRAINING PROGRAM CUSTOMIZATION
To create a program for you, RADAR PACE will begin by asking a few initial questions such as basic biometric
information, self-assessment of your levels of fitness and expertise, workout objectives, and your desired training
schedule. The training volume will be based on this initial assessment. As the coaching engine of RADAR PACE gets
to know you, the program will gradually become more customized to help you reach your goals.
•The RADAR PACE digital coach will monitor your running/riding for about 120 minutes before customizing the training zones of
your effort level. This customization will guide you during subsequent sessions.
•The customization never ends. To get you in the best form for race day, RADAR PACE will continually monitor your performance
and make adjustments to your training zones.
PROPER TECHNIQUE
By giving you reminders from time to time, RADAR PACE will help you achieve the most efficient technique. Here are
some of the tips that will guide you:
When running...
•Stand upright with your shoulders above your hips.
•Keep your head upright with your eyes on the horizon.
•Ensure your foot contact is directly under the body, mid-foot, with toes pointed forward. This is especially important on hills.
•Move your arms fore and aft in the direction of travel.
•Relax your hands, jaw and shoulders.
•Keep your stride rate at optimum high cadence by shortening your stride length.

10 |OAKLEY RADAR PACE USER GUIDE
When riding...
•Set an appropriate gear on your bike to keep your pedaling rate at optimum high cadence.
•Bring your knees in and stabilize your hips to avoid rocking your pelvis from side to side.
Note that in training, the underlying philosophies for running and cycling are similar. Long training and speed training
in running and cycling are grouped together, as are “Hills” running and “Big Gear” cycling.
EASY WORKOUTS
Easy workouts are designed to build your aerobic system. They are also scheduled as recovery sessions, and their
pace allows you to focus on technique. Easy runs and rides provide the following benefits:
•Improved muscle memory in fatigued conditions, such as after endurance runs.
•Improved circulation in fatigued muscles to “flush out the bad and replenish the good.”
•Improved economy and efficiency. (Running or riding just a bit too fast can condition your body for short bursts of speed instead
of controlled long-distance pacing.)
Recovery activities are just as important as long workout activities, and the benefits come when you work your
muscles under fatigued conditions. With a recovery session scheduled after a long workout, you can begin the easy
segment without having to put your body through the stress of achieving fatigue.
Whether you plan on doing a 5K, a marathon, a time trial or a century ride, the most important predictor of
performance is the strength of your aerobic cardiovascular system. The program is designed to help your technique,
perfect your cadence, build your endurance, increase your aerobic base, improve your muscle strength and help you
control your speed. Most of the workouts will be executed at an easy aerobic pace.
Even though you are probably still fatigued from the last workout, follow it with a scheduled easy workout to take
advantage of the benefits. Treat the entire easy workout as though it were a low pace warm-up, and finish at a
relaxed pace. An easy effort should feel like a 6 or 7 out of 10. A good way to assess this is the “easy conversation
test.” If you’re cycling and you can talk comfortably without having to pause your conversation to catch a breath,
you’re riding at an easy effort level. Don’t worry; RADAR PACE will be monitoring to make sure you don’t push
yourself too hard.
HILL WORKOUTS
Here are some important things to keep in mind for hill workouts:
•Gentle slopes can dramatically improve performance in the flats.
•The ideal gentle slope has a gradient between 3% and 7%.
•Maintain a cadence of 88-92 in hilly areas by adjusting your stride length or gear.
•Running or riding up gentle slopes can help reduce impact stress and adds resistance without altering mechanics.
•Running down gentle slopes allows your cardio system to recover while gravity assists you, and it helps improve fast-
twitch muscle response.
•Running up steep hills alters the mechanics of your stride and is not good preparation for running in the flats.
•Running down steep hills can lead to sore knees and injury.
This isn’t mountain climbing. Gentle slopes are best because they trick the body in a way that dramatically improves
performance in the flats. When you begin a hill effort, RADAR PACE will measure the gradient and notify you if the
hill is too steep.

11 |OAKLEY RADAR PACE USER GUIDE
Maintain a consistent energy burn throughout the workout. While going up a slope, maintain your cadence so the
effort feels consistent.
LONG WORKOUTS
These are the most important workouts for distance training. When performed at an aerobic pace, they offer multiple
benefits, and are designed for the following:
•Increasing your aerobic capacity.
•Improving capillary flow, strengthening heart muscles and improving heart stroke volume.
•Burning body fat as fuel. (Running too fast will train your body to burn carbohydrates and the limited amount of glycogen
stored in your legs, making it harder to go the distance.)
•Improving your leg strength and endurance.
•Breaking through the mental and physical thresholds of fatigue.
While challenging at first, long workouts will feel easier as these changes occur. The key to achieving them is
maintaining an easy pace — one at which you would still be able to carry on a conversation with a fellow runner.
Control your pace throughout the workout. The pace should feel overly easy at the beginning, just right in the middle
and moderately challenging at the end.
To help maintain performance and speed recovery, be sure to take in fluids with electrolytes during long workouts.
SPEED WORKOUTS
A well-balanced training program includes a small number of speed workouts. These shorter segments are designed
for the following:
•Enhancing fast-twitch muscle response.
•Improving how your brain and muscles work together for better running efficiency.
•Improving your strength.
•Improving your oxygen uptake for greater endurance.
Speed workouts are mostly gentle, but you should approach them with a fair amount of mental intensity. Find a flat
area and gradually, over a period of 10-15 seconds, accelerate toward your target pace. Once you hit your target
pace, use your mental intuition to lock it in for the duration of the rep.
RADAR PACE will gradually increase your speed training intensity during the program.
This isn’t a sprint. On a scale of effort, the targeted tempo of speed training is about 8 out of 10 — the same effort
as running a 5K or 10K race, or riding a 25-minute time trial. The key is controlling your pace.
When performing speed workouts in cycling, speed is affected by wind and drag. RADAR PACE will coach you in
higher effort zones by assessing your power rather than your actual speed. You’ll need to find reasonably flat terrain
for a speed session.
CYCLING “FLAT BIG GEAR” (FBG)
In big gear training, you need to increase your effort gently while gradually changing to the next bigger gear. This
training is done for the same reason as training on hills: to make your legs stronger. Both types of training are
necessary because your posture is different on hills, so you’re training slightly different muscles. Hill training makes
you faster on hills. Big gear training makes you faster on the flat.

12 |OAKLEY RADAR PACE USER GUIDE
BUNCH RIDING
Riding in a group can be scary, but if you plan to cycle in an event, you need to learn some techniques to help you do
it safely, politely and successfully. The most obvious tips are to brake gently if riders are behind you, and to steer very
gradually so other riders can react to your movements. Another good tip is to make sure you look with your eyes, not
your head, as turning your head can easily cause you to turn the bike along with it.
The speed of the group will change due to differences in abilities and tactics utilized, as well as from the ripple
effects of decisions such as avoiding a pothole. You need to practice catching up to a group, taking your turn in the
lead and pulling away from the pack. A group workout is the only time RADAR PACE will let your effort fluctuate, as
you might need to freewheel to stay in the bunch, or pedal hard to surge to the front. You can practice these things
even when you’re on your own. Doing so is important because without practice, your legs could cramp up on race day
when you’re forced to perform these actions.
If you’re new to group riding, stay at the back (or close to the back) until you get used to it. If you need to use the
brakes, do so very gently. Sitting up straighter will increase drag, which can be a good way to slow down gradually.
Never overlap wheels, as a small gust of wind or the need to avoid a hazard could cause the wheels to touch. Never
use your aero bars in a bunch; you need your hands on the brakes!
TRAINING PROGRAMS
Use the RADAR PACE app to create personalized training plans to help improve your general fitness or prepare for
events and competitions. Choose Running or Cycling on the app, then answer the onscreen questions to tell RADAR
PACE about your current training regimen, and how you want to focus and schedule your training. If you’re training for
an upcoming event, use the app to tell RADAR PACE, and it will create a custom-tailored plan for you.
The training programs of RADAR PACE represent decades of development in sport science. For the best results,
consistently execute the scheduled daily plan during the week (on running days and rest days), and throughout the
“build and recover” weeks of the entire plan. This means running as much as the plan calls for, but not more.
Each plan week will focus on developing a portion of your overall fitness and muscle memory. These gains will be
realized during the final two weeks, and specifically during the final days of the plan as you prepare mentally and
physically for the event day.
TRUST THE PROGRAM
•Athletes don’t get stronger during their run; they get stronger in recovery. Take scheduled rest days and go easy on easy days.
Instead of bringing the challenge to long days, let the length and duration of each run bring the challenge to you. Start a long
run at a pace you can maintain throughout the run, especially at the end.
•Try not to miss your long workouts. They are the most important sessions.
•Keep in mind that running on gentle slopes will help dramatically increase your efficiency on flats.
•Most workouts are easy. Consistently training hard will train your body to burn carbohydrates instead of fats, leaving you
fatigued and unprepared to go the distance. There is a time and a place for focused hard workouts. Trust the coach and save
yourself for the event day.

13 |OAKLEY RADAR PACE USER GUIDE
TROUBLESHOOTING
SENSOR PAIRING
Sensors that can be paired with RADAR PACE include a heart rate monitor, foot pod, power meter, cadence sensor
and speed sensor. These sensors are sold separately. RADAR PACE and your sensor must both be powered on for
pairing. Many sensors require motion to “wake up” and make the connection. Also note that sensors should be
paired using the RADAR PACE app, not with your phone settings.
Here are some tips on pairing external sensors:
•Have your phone “forget” all sensor pairing. (Go into Bluetooth®settings on your phone and unpair all sensors.)
•If a sensor is unable to pair with RADAR PACE, make sure the sensor is functional by temporarily pairing it with another
device.
•If you have a Bluetooth®sensor, make sure it is pairing only with RADAR PACE and not other peripheral devices.
•For a heart rate monitor, start by checking the battery. Next, try moistening the strap. (Make sure the strap is not too worn, as
this may prevent it from working properly.)
•For a foot pod, check the battery. Then try waking up the sensor by shaking it, stomping your feet and taking a few steps.
•For a power meter, check the battery. Then spin the crank to wake up the sensor.
•For a cadence sensor, check the battery. Then spin the crank to wake up the sensor. Also read the instructions that came with
the sensor to see if the issue is being caused by improper alignment of the crank and sensor, or by their proximity.
•For a speed sensor, check the battery. Then spin the crank to wake up the sensor. For spoke-mounted sensors, read the
instructions that came with the sensor to see if the issue is being caused by improper alignment of the crank and sensor, or by
their proximity.
For additional information, see below.
PAIRING RADAR PACE WITH PHONE
•Ensure RADAR PACE is in pairing mode by pressing the power button twice quickly.
•Pair only via the RADAR PACE app; do NOT pair via any other application on your phone.
PAIRING WITH EXTERNAL BLUETOOTH SENSORS
•Make sure both the sensor and RADAR PACE are powered on and within range.
•Make sure the sensor is pairing only with RADAR PACE and not another device.
•Pair only via the RADAR PACE app.
•Ensure the battery of the sensor device has enough charge to broadcast its signal to RADAR PACE.
•Some sensors require movement to begin broadcasting.
•Ensure the sensor device is not paired with another device; if it is currently paired with your phone, go to phone system
settings and unpair to ensure the device is discoverable.
•Refer to the user guide that came with your external sensor for more troubleshooting information.
PAIRING WITH EXTERNAL ANT+ SENSORS
•Ensure the battery of the sensor device has enough charge to broadcast its signal to RADAR PACE.
•Some sensors require movement to begin broadcasting.
•Refer to the user guide that came with your external sensor for more troubleshooting information.

14 |OAKLEY RADAR PACE USER GUIDE
CONNECTED SENSORS
•Ensure the sensor device is not currently paired with another device.
•Most connected sensors require movement to begin broadcasting.
RESETTING RADAR PACE
•To perform a factory reset and reboot RADAR PACE, hold the power button for more than 12 seconds. The indicator light will
blink red.
•To perform a factory reset and power off RADAR PACE, hold the power button for more than 18 seconds. The indicator light
will blink red.
MAINTENANCE
STORING RADAR PACE
For optional performance, fully charge RADAR PACE before storing for an extended period of time. Charging once
every two to three months during extended storage is recommended.
CHARGING
Oakley RADAR PACE comes with a specially designed Micro USB cable. Before charging RADAR PACE, always make
sure the USB ports are clean and sweat-free.
CLEANING AND MAINTENANCE
To help preserve the superior optical quality of Plutonite®lenses, your new Oakley eyewear comes with a woven,
microber cloth bag specially designed for cleaning and storage. Hand wash and air-dry the microber bag regularly.
Keep in the cloth or hard case in a dry place at a temperature between 14 °F (–10 °C) and 95 °F (+35 °C).
To clean your lenses and frames, use water and soap, avoiding all types of solvents or alcohol. Do not use dirty
or abrasive cloths, which could alter the features of their filters. Use care when washing and do not expose the
electronic device to water or soap. This product conforms to a water rating of IPX5, which ensures the product will
show no adverse damage even if exposed to water splashing from any direction. However, the electronic device is
not waterproof, so it should never be washed with water or immersed in water.
Use only original accessories and spare parts.
Iridium®Lenses: Oakley’s Iridium®is a thin-film reflective coating engineered to help reduce glare and improve
contrast. This coating should be treated with special care to avoid scratching. Only use Oakley’s cleaning kits/
solutions with Iridium®lenses.
Do not wear or clean the product while you are charging it. Always unplug the charger first before cleaning the product.
Do not use abrasive cleaners to clean your product.
Do not expose the electronic device to detergent, soap, soapy water, acidic foods, pool water, sunscreen, lotion, oil,
adhesive remover, hair dye or solvents.
Do not place the product in a dishwasher, washing machine, microwave oven, oven or dryer.
Do not expose the product to extremely high or low temperatures.
Do not go swimming with or shower with the product.
Do not expose the product to saunas, steam rooms or water at high pressure.
Do not leave the product in direct sunlight for an extended period of time.

15 |OAKLEY RADAR PACE USER GUIDE
TECHNICAL SPECIFICATIONS
Mechanical Specifications
Weight: Approx. 56 grams (2 oz.)
Storage Temperature Range: -20 °C to 60 °C (-4 °F to 140 °F)
Operating Temperature Range: -10 °C to 30 °C (-4 °F to 86 °F)
Vibration Resistance: 4.4g rms 5 Hz to 2000 Hz
Shock / Drop Resistance: 40g, 15-23 ms, ½ Sine (1m vertical drop)
Enclosure: Water-resistant enclosure, IPx5
Sensor Technology
9-Axis Sensors: 3D Accelerometer | 3D Gyroscope | 3D Magnetometer
Pressure Sensor: Altimeter
Proximity Sensor: Senses when device is worn on head
Networking Subsystem
Bluetooth®4.0 (Bluetooth®Smart)
ANT+
Apple MFi Bluetooth®support
USB / Micro-USB 2.0 (5-pin) - Device charging
Power requirements
Primary Supply Voltage: 3.7 lithium polymer rechargeable battery
Charge Time: Approx. 3 hours for full charge
Battery Size & Life: 1200 mAh; 3.5 hours or more per charge
Environmental Considerations
RoHS compliant
Brominated flame-retardant-free
Mercury-free
SUPPORT
For additional service, support, tutorials and FAQs, please visit:
www.oakley.com/Radar-Pace
E-mail: [e-mail]
Call Oakley Customer Care: 1-800-403-7449
EUROPE
Call: 00800 6255 3985
E-mail: [e-mail]
AUSTRALIA
Contact Oakley Customer Care
E-mail: [e-mail]
Phone: [phone]

16 |OAKLEY RADAR PACE USER GUIDE
SAFETY INFORMATION
NOTICES
Apple®, App Store®, Siri®and iPhone®are trademarks of Apple Inc.
Google Now™and Google Play™are trademarks of Google Inc.
The Bluetooth®word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of
such marks by Oakley, Inc. is under license.
Other trademarks and trade names are those of their respective owners.
©2016 Oakley, Inc. All rights reserved.
OAKLEY LIMITED WARRANTY
The Oakley eyewear product accompanying this warranty (Product) is warranted for one year (two years in
the European Union) from the date of purchase against manufacturer’s defects (Limited Warranty Period). This
warranty is valid only to the end consumer with a proof of purchase from an Authorized Oakley Dealer that
clearly shows the purchase date. Oakley does not warrant any lens scratches. Alteration, misuse, abuse or
installation of non-Oakley lenses will void this warranty. The customer’s exclusive remedy under this warranty
will be the repair or replacement of the item as determined by Oakley. This warranty does not affect the legal
rights of customers under applicable state and national law governing the sale of consumer goods.
HARDWARE, FIRMWARE AND SOFTWARE TECHNICAL SUPPORT
During the Limited Warranty Period, Oakley will provide Product technical support. Please note that when contacting
Oakley via telephone, long distance and other charges may apply, depending upon your calling area. The scope of
technical support consists of helping to diagnose and resolve problems with defects in the Product.
LIMITATIONS AND EXCLUSIONS
THIS LIMITED WARRANTY DOES NOT COVER AND OAKLEY IS NOT RESPONSIBLE FOR:
•Delivery or installation, or labor charges for setup of the product and/or adjustment of customer controls on the product.
•Damages caused by misuse, abuse, accidents, re, theft, disappearance, misplacement, uctuations and power surges,
connections to improper voltage or incorrect electrical line voltage, viruses, malware, reckless, willful or intentional conduct.
•Damages caused by servicing not authorized by Oakley.
•Damages caused by usage that is not in accordance with product instructions.
•Damages caused by failure to follow the product instructions or failure to perform cleaning or preventive maintenance.
•Damages caused by the combination of the product with other non-Oakley branded products, accessories, parts or components
or use of products, equipment, systems, utilities, services, parts supplies, accessories, applications, installations, repairs,
external wiring or connectors not supplied or authorized by Oakley that damage the product.

17 |OAKLEY RADAR PACE USER GUIDE
•Signal issues, reception problems and distortion related to noise, echo, interference or other signal transmission and delivery
problems.
•Results of normal usage, such as gradual image degradation, uneven screen aging, burned-in images and pixel failure within
designed specications or that do not materially alter the product’s functionality.
•Uninterrupted or error-free operation of the product.
•Any equipment or components that were not included in your product as originally sold.
•Normal wear and tear, including lens scratches.
•Damage caused as a result of improper transportation or packing/packaging when returning the product to Oakley or an Oakley
authorized dealer.
•A product that requires modication or adaptation to enable it to operate in any country other than the country for which it was
designed, manufactured, approved and/or authorized, or repair of products damaged by these modications.
•Damage to products where the anti-counterfeiting code (or equivalent) has been removed, erased, defaced, altered or made
illegible.
IMPLIED WARRANTIES
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE AND NON-INFRINGEMENT ARE DISCLAIMED.
LIMITATION OF LIABILITY
EXCEPT TO THE EXTENT PROHIBITED BY LAW, OAKLEY SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY.
OAKLEY’S MAXIMUM LIABILITY IS LIMITED TO THE PURCHASE PRICE PAID FOR THE PRODUCT PLUS ANY
INTEREST ALLOWED BY LAW. OAKLEY IS NOT LIABLE FOR EVENTS BEYOND ITS CONTROL, SUCH AS ACTS OF
GOD, VIRUSES, PROPERTY DAMAGE, LOSS OF USE, INTERRUPTION OF BUSINESS, LOST PROFITS, LOST DATA OR
OTHER CONSEQUENTIAL, PUNITIVE OR SPECIAL DAMAGES, HOWSOEVER CAUSED, WHETHER FOR BREACH OF
WARRANTY, CONTRACT, TORT (INCLUDING NEGLIGENCE), STRICT LIABILITY OR OTHERWISE.
For end consumers who are covered by consumer protection laws or regulations in the jurisdiction of purchase or, if
different, their country of residence, the benefits conferred by this warranty are in addition to all rights and remedies
conveyed by such consumer protection laws and regulations.
This warranty does not exclude, limit or suspend any rights of end consumers arising out of non-conformity with
a sales contract. Some countries, states and provinces do not allow the exclusion or limitation of incidental or
consequential damages or allow limitations on how long an implied warranty or condition may last, so the limitations
or exclusions described herein may not apply. This warranty provides specific legal rights, and the end consumer may
also have other rights that vary by country, state or province.
HOW TO MAKE A WARRANTY CLAIM
Within the United States, the customer should telephone our Global Headquarters at 1 [phone] with their
purchase information. Australian customers, please see below. Customers outside the United States and Australia
should contact their local Authorized Oakley Dealer or visit our website at www.oakley.com for the phone number of
the nearest Oakley Distributor.
Unless specifically stated elsewhere in this warranty policy, to make a warranty claim, return your product to
the Authorized Oakley Dealer from which the product was purchased together with proof of purchase. If your

18 |OAKLEY RADAR PACE USER GUIDE
warranty claim is deemed to be valid, we will replace or repair the product. IT IS THE RESPONSIBILITY OF THE END
CONSUMER TO REMOVE ANY DATA FROM THE PRODUCT RETURNED TO OAKLEY OR AN OAKLEY AUTHORIZED
DEALER. OAKLEY IS NOT RESPONSIBLE FOR ANY LOSS OF DATA WHATSOEVER.
Any expenses incurred in returning product for warranty assessment will be done so at the expense of the end
consumer. If the returned product is deemed to be a valid warranty claim then Oakley will incur the cost of any further
freight charges. If the warranty claim is deemed to be invalid, we will contact you to see if you want us to conduct
repairs at your cost and, in any event, you will be charged for outbound freight based on Oakley’s standard shipping
rates.
FOR END CONSUMERS IN AUSTRALIA:
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure. The benefits given to you under our express warranty are in addition to other
rights and remedies you have under the Australian Consumer Law and other laws.
OUR EXPRESS WARRANTY IN AUSTRALIA IS PROVIDED BY:
Oakley South Pacific Pty Ltd
(ABN 47 090 585 149)
24 The Esplanade
St Kilda, VIC, 3182
Australia
1-800-637-001
[e-mail]
REGULATORY STATEMENTS :
MODEL: RADAR PACE
MANUFACTURER:
Oakley, Inc.
One Icon
Foothill Ranch, CA 92610 USA
AUTHORIZED REPRESENTATIVE FOR EUROPEAN UNION:
Luxottica Group S.p.A., Piazzale Luigi Cadorna 3, 20123 Milano.
DEFINITION OF MARKINGS:
: manufacturer’s mark
: mark indicates European Conformity
Filter Category (Protection Index) and Filter Type are identified by a number and a letter found on the packaging or
on the bar code sticker. The number indicates the category of the filter (see Table 1) and the letter indicates the filter
type (N=normal/plano, P=polarized, F=photochromic). In the case of photochromic lenses (F), the filter category of
both the faded and darkened states are indicated.
MANUFACTURER’S CONFORMANCE NOTE:
The Product exceeds the US FDA Reg. 21 CFR 801.410 requirement for impact resistance and the requirements for
sunglasses identified in ANSI Z80.3:2010. The Product is in conformance with the provisions of Council Directive
89/686/EEC and as such is conforming to the harmonized standard ISO 12312-1:2013.

19 |OAKLEY RADAR PACE USER GUIDE
SUNGLASS FILTER CATEGORIES TABLE
0 1 2 3 4
tV> 80% 43% < tV≤ 80% 18% < tV≤ 43% 8% < tV≤ 18% 3% < tV≤ 8%
FCC STATEMENT (USA)
The Product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. The Product generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation.
If the Product does cause harmful interference to radio or television reception, which can be determined by turning
the Product off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the Product and receiver.
•Connect the Product to an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio or television technician for help.
The Product complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) the
Product may not cause harmful interference, and (2) the Product must accept any interference received, including
interference that may cause undesired operation.
WARNING! Exposure to Radio Frequency Radiation. The radiated output power of the Product is below the FCC and
Industry Canada radio frequency exposure limits.
The Product must not be co-located or operating in conjunction with any other antenna or transmitter.
FCC requires a user be notified that any changes or modifications made to the Product that are not expressly approved
by the manufacturer, may void the user’s authority to use the Product.
ICES-003 (CANADA)
The Product does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the
interference-causing equipment standard entitled: “Digital Apparatus,” ICES-003 of the Canadian Department of
Communications.
Cet appareil numérique respecte les limites bruits radioélectriques applicables aux appareils numériques de Classe
Bprescrites dans la norme sur le matériel brouilleur: “Appareils Numériques,” NMB-003 édictee par le Ministre
Canadian des Communications.
The Product complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two
conditions: (1) the Product may not cause interference, and (2) the Product must accept any interference, including
interference that may cause undesired operation of the Product.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2)
l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
Industry Canada ICES-003 Compliance Label: CAN ICES-3 (*)/NMB-3(*)

20 |OAKLEY RADAR PACE USER GUIDE
EUROPE (CE DECLARATION OF CONFORMITY)
This product complies with the Low Voltage Directive 2006/95/EC; EMC Directive 2004/108/EC, EU
Directive R&TTE Directive 1999/5/EC, and RoHS Directive 2011/65/EU.
Point of contact: Luxottica Group S.p.A., Piazzale Cadorna 3, 20123 Milano (Italy).
“In the EU, this symbol means that this product must not be disposed of with household waste. It is your
responsibility to bring it to a designated collection point for the recycling of waste electrical and electronic
equipment. For more information, please contact your local waste collection center or your point of purchase of this
product.”
BATTERY DISPOSAL AND WEEE INFORMATION
Oakley is committed to the proper disposal, reuse, recycling and recovery of batteries and Waste Electrical and
Electronic Equipment (WEEE). Batteries and WEEE should not be disposed of in normal domestic waste bins. For
more information on proper disposal please contact your local Oakley Support Specialists based on the information
provided at http://www.oakley.com/en/support/product-care.
WARNINGS AND IMPORTANT SAFETY INSTRUCTIONS
The Product is not designed to protect the wearer from all injury in the event of impact with hard objects. To perform
properly, the lens must be fitted securely in the frame. Oakley eyewear should not be used for direct viewing of the
sun or strong artificial light sources, nor should tinted lenses be used for driving at night or with poor visibility. If the
eyewear impairs your peripheral vision, do not wear while driving. Certain lens tints are specifically designed for
performance applications and may be unsuitable for traffic signal recognition. TR22 and TR45 (with or without Iridium
Coating) are not suitable for driving and road use and must not be used for driving.
Symbol: Not suitable for driving and road use
Not suitable for direct viewing of the sun or for viewing of solar eclipses; not suitable for use as protection against
UV rays from artificial light sources (e.g. tanning beds); not suitable for use as eye protection against blows or impact;
not suitable for driving at night or in poor visibility conditions.
To prevent possible hearing damage, do not listen at high volume levels for long periods. Adjust volume before
inserting the headphones into your ears to protect against sudden bursts of sound. Use caution when inserting
headphones into your ears.
Do not attempt to open, disassemble or tamper with the Product. Substances contained in the Product and/or its
battery may damage the environment and/or human health if handled and disposed of improperly.
Do not use the Product in circumstances that could cause a dangerous situation, such as using the device while
operating heavy machinery or driving a moving vehicle in a manner that might cause you to take your eyes off the
road or become so absorbed in the activity that your ability to concentrate on the act of driving becomes impaired.
Use caution and stay alert if using the Product while running or biking.
As with any product, RADAR PACE should only be used in compliance with local laws, rules and regulations, including
highway and traffic laws. Please be mindful of safety concerns and consult all applicable rules, regulations and laws
before using on roadways.
