ObboMed MM-2700 User manual

1
Your healthy living center
www.obbomed.com
Compact Digital Body Fat Scale
Model No.: MM-2700
EXPLANATION SYMBOLS
Please carefully read through this manual before first use, and store it in safe place.
If you pass the product to another person, hand over this manual along with it!
INTENDED USE OF PRODUCT
SAFETY & INSTALLATION INSTRUCTION
- Please take off shoes before taking measurement to avoid scraping or scratching the glass plaorm.
- The glass plaorm may be prey slippery when wet, please make sure both the glass and your feet are dry
before use.
- The maximum capacity of the scale is 150 kg/330 lbs.
- Keep this product and its baery away from heat, moisture, and direct sunlight.
- Do not disassemble or aempt to repair. Any tampering voids warranty.
- Avoid dropping this product, as it is not shock resistant.
- Do not use this scale if you have a pacemaker or other internal medical device. When in doubt, contact your
doctor.
- Keep away from strong electro-magnec field when using the scale.
- Please keep this product out of reach of children or babies. Close supervision is necessary when this appliance
is used by, on or near children or those with limited dexterity or mobility.
PRODUCT FEATURES
- Tap on operaon
- Tempered-glass plaorm
- Three units Kg/lb/st
- Max capacity 150 kg
- Baery operated
- Auto off in 12 mins
- Low baery and overload indicator
- Store maximun 10 user datas.
SCOPE OF DELIVERY (ACCESSORIES)
- Electronic Personal Scale
- User’s manual
- Baery: 2 CR2032 lithium baeries
DANGER: Warning of risk of serious injury or health hazards
WARNING: Warning of risk of injury or health hazards
CAUTION: Safety informaon about possible damage to appliance/ accessories
NOTE: Important informaon
The product is not suitable for hospital or medical use.
The product is only usuable for indoor applicaon
Use device only for its intended use as described in the manual.
This product is designed for family use only, not recommended for commercial purpose.
All below informaon serves to protect health of user and the health of other person.
Also protects the product from any damage while using.

2
APPLIANCE DESCRIPTION & OPERATION
To ensure accuracy, we suggest you take measurement at the same me each day.
UNIT
Start Up:
1) Remove the insulang strip.
2) Place the scale steadily on a clean, firm, and flat surface.
Change Unit:
- Press the unit boom at the back of the scale to change unit.
Buon Operaon:
SET
Up
Power On, Menu Select, and Confirm
Down
Personal Data Seng:
1.Press “SET” key. Use “▲” or “▼” key to select your user data from P0 to P9. Once you reach the desired user data,
press “SET” again to confirm.
The user data P0-P9 represents 10 user data. Remember this number for future usage.
2. Press “▲”or “▼” to choose Male or Female when the gender symbol flashes on the screen and then press
“SET” to confirm.
3. Press “▲”or “▼” to choose age (10 - 80), press “SET” to confirm.
4. Press “▲”or “▼” to choose height (100 - 240), “press “SET” to confirm.
When all the data are set, the scale will display "0.0". You may measure body weight, body fat, hydraon,
muscle, bone, and calories. (Please refer to "Take a Measurment".)
TESTING GUIDELINES
• Put the scale on clear, firm, and flat surface. Make sure it is level.
• Feet must be bare and clean. Don't wear shoes or socks during measurement.
• Stand sll and straight and maintain contact with electrodes.
• You must wait several hours before taking a body fat reading aer: drinking coffee or alcohol, taking diurec
medicaons, or exercising.
• It is recommended to measure your body at the same me each day to ensure accuracy.
• Avoid strong electromagnec interference when measuring.
TAKE A MEASUREMENT
Weight Only:
1. Use one of the feet to tap on the scale to turn on. The screen will light up with blue backlight, and incate 0.0.
2. Step on the scale gently, posion your feet evenly near the center, stand sll and straight unl the LCD flashes
3 mes with your weight.
3. The scale will turn off automacally aer idling for 12 seconds.
Weight and Body Fat & Hydraon Percentage Readings:
1. Press “SET” to turn on and “▲”or “▼” to choose your personal data previously set. Confirm the user data by pressing
“SET”, and wait unl the screen shows 0.0.
2. Stand bare foot on scale, maintain contact with electrodes.
3. Your weight will be display first. Remain sll and straight while the LCD flashes “0000”.
4. Body Fat, Hydraon, Muscle, Bone, BMI and Basal Metabolic Rate informaon will appear on the display and cycle
3 mes and stored automacally.
kg
TBW
%
fat%
Health
Weight Body Fat Hydraon

3
kg
%
BMI
KCAL
5. The scale will turn off automacally aer idling for 12 seconds.
REFERENCE
Age Female Male
Fat% Hydrarion% Fat% Hydrarion%
4.0-20.5 66.0-54.7 4.0-15.5 66.0-58.1 Underfat
20.6-25.0 54.6-51.6 15.6-20.0 58.0-55.0 Healthy
25.1-30.5 51.5-47.8 20.1-24.5 54.9-51.9 Overfat
30.6-80.0 47.7-13.8 24.6-80.0 51.8-13.8 Obese
4.0-25.0 66.0-51.6 4.0-19.5 66.0-55.4 Underfat
25.1-30.0 581.5-48.1 19.6-24.0 55.3-52.3 Healthy
30.1-35.0 48.0-44.7 24.1-28.5 52.2-49.2 Overfat
35.1-80.0 44.6-13.8 28.6-80.0 49.1-13.8 Obese
<=30
>30
Display
Normal Ranges Of Body Fat Percentage and Hydraon Rate:
Muscle Percentage
Female Male
>34% >40%
Moderate
Female
Body Weight Below 45kg 45-60kg Over 60kg
Bone Weight >1.8kg >2.2Kg >2.5kg
Male
Body Weight Below 60kg 60-75kg Over75kg
Body Weight >2.5kg >2.9kg >3.2kg
Normal Parameter Of Body Muscle and Bone Rate:
Basal Metabolic Rate (Kcal):
Basal Metabolic Rate is the amount of calories needed to maintain breath, keep warm and some other basic living acvity.
Age Male Female
20-29 1540 1200
30-39 1515 1190
40-49 1465 1170
50-59 1390 1125
60-64 1320 1075
Different geographic areas and locaons may vary due to different culture and living style.
The above rates and data are for reference only.
CHANGE BATTERY
Baery type: CR2032 lithium baery
When the LCD shows LO, replace the baeries immediately.
1. Turn the main unit over and remove the baery cover.
2. Remove the drained baeries and insert two CR2032 lithium baeries.
3. Place the baery cover back.
Muscle Bone BMI
Basal Metabolic Rate

4
ERROR MESSAGES
TECHNICAL DATA
Product Name : Compact Digital Body Fat Scale
Item Number: MM-2700
Maximum Capacity: 330 lb / 150 kg
Working Power: 2 x CR2032 lithium baeries
Unit: Kg/ lb/ oz
Graduaon: 0.1kg/ 0.2 oz
Size: 30 x 30 x 2 cm/ 11.8 x 11.8 x 0.7 inches
Accuracy: ± 0.1 kg
DISPOSAL
Disposal of packing and product aer end of lifeme.
Deliver all packing materials at a collecon point or in the appropriate bins for recycling.
WARRANTY
The statutory warranty period applies. If the product is defecve, please contact the manufacturer's service centre
(see service e-mail at the end of this manual) or your retailer. For repair and warranty processing, please include the
following documents when you send in the product:
• A copy of the receipt with purchasing date.
• A reason for the claim or descripon of the fault.
No guarantee is provided when the product is not installed/ operated according to this manual, used for other purposes
or careless use of the product.
DISTRIBUTION & SERVICE
CARE AND STORAGE INSTRUCTION
- Use so ssue with alcohol or glass cleaner to clean the surface if it is dirty. No soap or other chemicals are needed.
- Keep it away from moisture, corrosive liquid, and extreme heat and coldness.
- Do not immerse the scale in water or rinse it under running water.
- The scale is high precision measuring device. Do not knock it heavily or disassemble.
- Handle with care to avoid dropping or breaking during moving.
- Remove the baeries from the scale if not used for long me.
- If the scale shows malfuncons, please check the baery, change a new one if necessary.
- Store the scale in cool and dry place.
Icon Display Cause Soluon
The baeries are exhausted. Replace baery at once.
The scale is overloaded.
The measuring makes an error.
Immediately step down from the
scale to prevent damage.
Do not wear shoes or socks during
measurement. Clean the boom
of bare feet with a damp cloth
may help to improve the contact
with the electrodes.
Repeat the measurement.
Body fat percentage is beyond the
range.
FATH
FATL Body fat percentage is less than 5%.
Body fat percentage is more than 50%.
Distribuon by ObboMed Group:
Webshop: www.obbomed.com
Europe:
Morseweg 11, 8503 Ah Joure
The Netherlands
Mail: [email protected]
Australia:
39/3 Kelso Crescent Moorebank,
NSW 2170, Australia
Mail: [email protected]
United States:
1210 E Lexington Ave,
Pomona, CA 91766, U.S.A.
Mail: [email protected]
ObboMed® is registered trade mark of ObboMed Group.
