Ocean Insight OCEAN SR2 User manual

OCEAN SR2
Scientific-Grade Spectrometer
Installation and Operation Manual
For Product: Ocean SR2

MNL-1029 Rev A
i

MNL-1029 Rev A
ii

MNL-1029 Rev A
i
Table of Contents
Before You Get Started .................................... ii
Warnings & Cautions ....................................................................ii
Warranty .......................................................................................iv
Certifications and Compliance ...................................................iv
Introduction..................................................... 1
Product Description..................................................................... 1
Features........................................................................................ 1
Items Included with Shipment .................................................... 1
Installation and Setup ...................................... 2
Software Installation ................................................................... 2
Configuring the Ocean SR2......................................................... 3
Hardware Setup ........................................................................... 3
Hardware Features ...................................................................... 4
Troubleshooting .............................................. 7
Ocean SR2 Connected to Computer Prior to Application
Installation.................................................................................... 7
Frequently Asked Questions ....................................................... 8
Repairs........................................................................................ 10
Servicing ..................................................................................... 10
Technical Specifications ................................ 11
Timing Signals............................................................................ 13
External Triggering..................................................................... 14
Mechanical Dimensions ............................................................ 22
Calibration ..................................................... 23
Wavelength Calibration.............................................................. 23
Irradiance Calibrations .............................................................. 23
Copyright © 2022 Ocean Insight
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, by any means, electronic, mechanical, photocopying,
recording, or otherwise, without written permission from Ocean Insight.
This manual is sold as part of an order and subject to the condition that it shall not, by way of trade or otherwise, be lent, re-sold, hired out or otherwise circulated
without the prior consent of Ocean Insight, Inc. in any form of binding or cover other than that in which it is published.
Trademarks
All products and services herein are the trademarks, service marks, registered trademarks or registered service marks of their respective owners.
Limit of Liability
Every effort has been made to make this manual as complete and as accurate as possible, but no warranty or fitness is implied. The information provided is on an
“as is” basis. Ocean Insight shall have neither liability nor responsibility to any person or entity with respect to any loss or damages arising from the information
contained in this document.

MNL-1029 Rev A
ii
Before You Get Started
Warnings & Cautions
Caution: Do not let contaminants get into the bench. Keep the protective cap on the slit aperture when not connected to an
accessory, probe or fiber.
Caution: Only change the slit aperture in a clean environment where contaminants including dust cannot enter the bench during the
procedure.
Caution: Substitution of a component or accessory different from that supplied may result in measurement error, equipment
damage, increased radio-frequency emissions or decreased immunity from electrical disturbances.
Caution: Repairs should be undertaken only by personnel trained or authorized by Ocean Insight. The device does not contain any
user serviceable parts.
Caution: Do not immerse the device in any fluid, place fluids on top of or attempt to clean with liquid detergents or cleaning agents.
This may cause an electrical hazard. Do not use if accidental wetting occurs.
Caution: Do not remove any covers. Doing so may increase the risk of electrical shock or compromise the integrity of the optical
components.
Caution: Do not gas sterilize or autoclave this device.

MNL-1029 Rev A
iii
Caution: Consult local codes and ordinances for proper disposal of equipment and other consumable goods.
Caution: The device and/or accessories may not operate correctly if used or stored outside the relevant temperature and humidity
ranges described in the Technical Specifications.
Caution: Do not use if device is dropped and/or damaged. Have an authorized service representative check the device before using
again.
Caution: Be sure to install any software BEFORE connecting the spectrometer to your PC or host system. The software installs the
drivers required for spectrometer installation. If you do not install the software first, the system may not properly recognize
the spectrometer.
Caution: The user of this spectrometer shall have the sole responsibility for any malfunction that results from improper use, faulty
maintenance, improper repair, damage or alteration by anyone other than Ocean Insight or their authorized service
personnel.

MNL-1029 Rev A
iv
Warranty
For the most current warranty information, please visit OceanInsight.com.
Certifications and Compliance
This is an FCC Class A product. In a domestic environment, this product may cause radio interference in
which case the user may be required to take adequate measures.
Warning
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which the user will be required to
correct the interference at his own expense.
FCC Compliance
The authority to operate this equipment is conditioned by the requirement that no modifications will be
made to the equipment unless the changes or modifications are expressly approved by the manufacturer.
Warning

MNL-1029 Rev A
v
The WEEE symbol on the product indicates that the product must not be disposed of with normal
household waste. Instead, such marked waste equipment must be disposed of by arranging to return to a
designated collection point for the recycling of waste electrical and electronic equipment. Separating and
recycling this waste equipment at the time of disposal will help to conserve natural resources and ensure
that the equipment is recycled in a manner that protects human health and the environment.
WEEE Compliance
This device has been tested and complies with the following standards:
Electromagnetic Compatibility Directive –2004/30/EU
EN 61326-1:2013
EN 55011:2009 w/A1:2010
RoHS
Compliant
This device complies with RoHS materials standards.
ISO
Certification
Ocean Insight, the applied spectral knowledge company, has been certified for ISO 9001:2015
certification applicable to the design and manufacture of electro-optical equipment.

MNL-1029 Rev A
1
Introduction
Product Description
Ocean SR2 spectrometers are built using industry leading manufacturing techniques that help deliver high thermal stability and low
unit-to-unit variation without compromising the flexibility and configurability that are the hallmark of the design. Features such as
interchangeable slits, indicator LEDs and simple device connectors deliver more freedom and flexibility.
Features
•Plug-and-play capability via the USB-C connection.
•User-interchangeable slit.
•LEDs show data transfer status.
•Compact and lightweight.
•4 GPIO pins and the ability to provide power to external devices through the Ocean Insight standard 16 pin connector.
•OceanDirect Software Included
Items Included with Shipment
•Ocean SR2 Spectrometer
•USB-C Cable
•Wavelength Calibration Data Sheet
•Linearity Calibration Data Sheet (please save Calibration sheets for future reference)

MNL-1029 Rev A
2
Installation and Setup
Software Installation
Use OceanView version 2.0.10 and above for Ocean SR2. You can use OceanView on the following operating systems:
Windows
Mac
8
8.1
10
OS X Version 10.5 or later on
Intel processor
*Software may run with previous operating systems but Ocean Insight does not
actively support these installations.
Consult the OceanView manual for computer hardware requirements.
NOTE
Be sure to install the spectroscopy application BEFORE connecting the spectrometer to your PC. The software installs the drivers
required for spectrometer installation. If you do not install the software first, the system will not properly recognize the
spectrometer. If you have already installed the OCEAN SR2 to a computer running on a Windows platform prior to installing the
operating software, consult the Troubleshooting section for information on correcting a corrupt OCEAN SR2 installation.
NOTE
Be sure that you download the correct software package for your computer version (32 or 64-bit). See the Frequently Asked
Questions in Troubleshooting for more information on determining your computer version.

MNL-1029 Rev A
3
Configuring the Ocean SR2
The Ocean SR2 can be used with OceanView software when connected to the USB port. If you have followed the previous steps and
started your spectroscopy application, the spectrometer is already acquiring data. Even with no light in the spectrometer, there
should be a dynamic trace displayed in the bottom of the graph. If you allow light into the spectrometer, the graph trace should rise
with increasing light intensity. This means the software and hardware are correctly installed.
Hardware Setup
The Ocean SR2 Spectrometer connects to a computer via the USB port. When connected through a USB 2.0 or 1.1 port, the
spectrometer draws power from the host computer, eliminating the need for an external power supply
Follow the steps below to connect the OCEAN SR2 to a computer via the USB port:
1. Install the spectrometer operating software on the
destination computer.
2. Locate the USB cable (USB-Cable) provided with
the Ocean SR2.
3. Insert the micro connector end of the cable into
the side of the Ocean SR2 and the larger end of
the cable into the USB port of the computer.
4. Connect any spectroscopy accessories. To find
operating instructions for Ocean SR2-compatible
products (such as light sources, sampling
chambers, and probes), consult the Ocean Insight
website at OceanInsight.com.
5. Attach the fiber to the fiber optic connector on the
spectrometer.
If you installed the spectrometer operating software prior to connecting the Ocean SR2, the software automatically installs the
correct drivers. If the drivers do not successfully install (or if you connected the Ocean SR2 to the computer before installing the
software), consult Troubleshooting.

MNL-1029 Rev A
4
Hardware Features
Status Indicator LEDs
The Ocean SR2 features two indicator lights that operate as shown:
LED
Steady
Flashing
Red
Unit is on
N/A
Green
N/A
Unit is transmitting
data
NOTE
LEDs can be turned off in OceanView or by using a software API command in OmniDriver or OceanDirect.

MNL-1029 Rev A
5
16 Pin IO Connector
This port allows the Ocean SR2 to be connected to Ocean Insight light sources
and other external equipment.
PIN
Function
Description
PIN
Function
Description
1
Reserved
9
GPIO.0
General purpose I/O
2
Reserved
10
GPIO.1
General purpose I/O
3
GND
Ground
11
GPIO.2
General purpose I/O
4
RSTn
External reset input
12
GPIO.3
General purpose I/O
5
LampEnable
Output
13
Reserved
6
ExtTrigIn
External trigger input
14
Reserved
7
SingleStrobe
Single strobe output
15
+5VDC
External power supply input
8
ContStrobe
Continuous strobe output
16
GND
Ground
Pins 4 –12, on the auxiliary connector are 3.3V CMOS compatible inputs and outputs, with +/- 1mA drive capability
15 13 11 9 7 5 31
16 14 12 10 8 6 42
Pin 1

MNL-1029 Rev A
6
External Reset Input Pin
The Ocean SR2 can reset itself via an external reset pin. Applying a logic low input to the RSTn pin places the SR2 into a hardware
reset condition and will remain in reset until the input is brought high again. Note that this is a full hardware reset, all operating
parameters are also reset to defaults that can be restored by re-initializing via software commands.
16 Pin Connector Cable (CBL-ISDF-DB15)
This cable connects to the following external light sources:
DH-3P
DH–2000 (US)
HPX–(US)
HL–2000–FSHA
HL–3P
16 Pin Connector Cable (CBL-ISDF-PX-DB15)
PX-2

MNL-1029 Rev A
7
Troubleshooting
Sometimes things do not go according to plan. When issues arise, do not hesitate to contact us and our Tech Support team will leap
into action. Some typical questions are answered here. For more information, consult the FAQs on the Ocean Insight website.
Ocean SR2 Connected to Computer Prior to Application Installation
Windows Operating Systems
If you connected your Ocean SR2 device to the computer prior to installing your spectroscopy application (OceanView) on a Windows
platform, you may encounter installation issues that you must correct before your Ocean Insight device will operate properly.
Follow the applicable steps below to remove the incorrectly installed device, device driver, and installation files.
Remove the Unknown Device from Windows Device Manager
1. Open Windows Device Manager. Consult the Windows operating instructions for your computer for directions, if needed.
2. Locate the Other Devices option and expand the Other Devices selection by clicking on the "+" sign to the immediate left.
NOTE
If these procedures do not correct your device driver problem, you must obtain the Correcting Device Driver Issues document
from the Ocean Insight website: OceanInsight.com
NOTE
Improperly installed USB devices can also appear under the Universal Serial Bus Controller option. Be sure to check this
location if you cannot locate the unknown device.

MNL-1029 Rev A
8
3. Locate the unknown device (marked with a large question mark). Right-click on the Unknown Device listing and select the
Uninstall or Remove option.
4. Click the OK button to continue. A warning box appears confirming the removal of the Unknown Device. Click the OK
button to confirm the device removal.
5. Disconnect the Ocean SR2 from your computer.
6. Replug the spectrometer into your computer.
The system should now be able to locate and install the correct drivers for the USB device.
Apple Mac OSX Operating Systems
Since there are no device files for the Ocean SR2 Spectrometer in a Mac operating system, you should not encounter any problems if
you installed the spectrometer before the operating software.
Frequently Asked Questions
I connected the USB cable and started OceanView but I
don’t see my spectrometer attached.
Use the “Action -> Scan for hardware changes” selection in the Device Manager to
rescan for attached devices.
I am having trouble installing the drivers, what should I do?
Hardware device driver installation is usually seamless on Microsoft Windows operating systems and should happen in the
background when you connect your spectrometer to a computer with the software installed. However, some Windows systems
require a bit more care when connecting your spectrometer for the first time.

MNL-1029 Rev A
9
If your spectrometer is not recognized by OceanView on your computer, you need to manually install the spectrometer drivers. See
your OceanView manual for this procedure. Also consult the Correcting Device Driver Issues document on www.OceanInsight.com
How do I know my spectrometer has power?
The red LED on the spectrometer should be constantly on if the unit is receiving power.
How do I know my spectrometer is transmitting data?
The green LED on the spectrometer flashes when transmitting data.
I’m installing OceanView but I need a product key; where can I find this?
The product key was sent to the contact e-mail on the sales order when you purchased your OceanView license. Contact
[email protected]om for more information. You’ll need your sales order number, quotation number, the serial number of the
spectrometer that was purchased with the software, and, if known, the e-mail address under which your product key was created to
recover your key.
I connected the Ocean SR2 to the computer before installing my spectroscopy operating
software to install the drivers. What do I do now?
As detailed below, the steps to take to resolve this issue differ, depending on your computer’s operating system.
How do I check the configuration of my spectrometer?
Check the label on the bottom of your spectrometer. You can also check your configuration using OceanView by opening the
Schematic window and double-clicking the spectrometer icon.

MNL-1029 Rev A
10
Repairs
Sometimes accidents happen! If you need to return your Ocean Insight Product for repair, here is what to do:
1. Contact us to evaluate and diagnose the problem. If it is determined that the product must be returned, the representative will
issue an RMA number.
2. Package your product, ideally in the original packaging, and return it to Ocean Insight, along with the RMA number that you
received.
Upon careful examination, we’ll advise you with an estimate. When your product is ready, it will be returned to you.
Servicing
To keep your instrument in tip-top shape we recommend yearly wavelength recalibration. You can do this yourself if you have
appropriate tools or we can do this for you. Contact your local representative to find out more about service availability and cost. We
offer the following services:
•Wavelength Calibration
•Absolute Irradiance Calibrations
NOTE
For RMA returns under warranty we will organize and pay for shipping both ways. For accidental damage, you pay only to have the
product shipped to your closest Ocean Insight or Distributor Office.

MNL-1029 Rev A
11
Technical Specifications
Test conditions for the following data: 25o C
Specification
OCEAN SR2
Optical and Spectroscopic
Integration Time
1 µs –1.5 s
Dynamic Range for single acquisition1
3400:1
Dynamic Range of system2
1.1 x 108
Signal-to-Noise (single acquisition)
380:1
Resolution (FWHM)
1.3 nm (25 µm slit UV-VIS)
Scan rate (typ) 3
480 Hz
Thermal Stability
0.06 nm/°C
Triggering
Software, External rising edge, External level
Wavelength Range
190 - 920 nm (UV-VIS)
Grating
Configurable
Entrance Slit
5, 10, 25, 50, 100, 200 µm
Detector
Active Pixels
2098
Corrected Linearity
>99.8%(10-90% saturation)
(1 µs - 1.5 s)
Electrical

MNL-1029 Rev A
12
Specification
OCEAN SR2
Power-up Time
3s
Connectors
USB Type-C, SMA, 16 pin Samtec TFM
USB Type-C Ratings: VCC
Minimum 4.40V, Nominal 5V, Maximum 5.25V
IO Standard
3.3V CMOS
Absolute Maximum Ratings:
Voltage on any pin (other than input
power)
5V
Interface
USB 2.0 High Speed
External Triggering Jitter
10 ns
Mechanical
Input Fiber Connector
SMA 905
Physical Dimensions
88.9 mm x 63.5 mm x 31.9 mm
Weight
275g
Environmental
Temperature:
Storage
Operation
-30 to 70°C
0 to 55°C
Humidity
0-85% non-condensing
1 Dynamic range for a single acquisition is a measure of the ratio of full signal to noise.
2 Dynamic range of the system is the range of the detectable light level and can be thought of as the maximum detectable light level at
the minimum integration time divided by the minimum detectable light level at the maximum integration time.
3 Scan rate is dependent on factors external to the spectrometer. This figure was obtained using OmniDriver and OceanDirect APIs.
